- Page 1 VT-TABLET-5081S User Manual Product Version: 1.0 Date: 2021/11/22 For any question, please contact Chengdu Vantron Technology, Ltd. Copyright © Vantron Technology, Ltd. All rights reserved.
- Page 2 Change History This document describes VT-TABLET-5081S briefly and is intended for all readers. This table describes the version and release date. Version Date Description Author First release. Kang 2021/11/22...
- Page 3 Vantron reserves all rights of this manual, including the right to change the content, form, product features, and specifications contained herein at any time without prior written notice.
- Page 4 Limitation of Liability/Non-warranty For direct or indirect damage to this device or other devices of Vantron caused by failure of conforming to this manual or the safety instructions on device label, Vantron assumes neither warranty nor legal liability even if the device is still under warranty.
- Page 5 Clean with a damp cloth. Do not try cleaning exposed electronic components unless with a dust collector. Support for special fault: Power off and contact technical support personnel of Vantron in case of the following faults: The device is damaged.
-
Page 6: Table Of Contents
Contents 1. OVERVIEW ................................... 1 Introduction ........................1 Order Information ......................2 VT-TABLET-5081S HARDWARE INSTRUCTIONS ........................ 3 Product Appearance ......................3 Specifications ........................5 Buttons ..........................6 Interface Description ......................6 2.4.1 USB OTG (Type C) ..............................6 2.4.2 Audio Jack ................................. 6 2.4.3... -
Page 7: Overview
VT-TABLET-5081S 1. Overview 1.1 Introduction Thank you for choosing Vantron. It is our commitment to provide our valued customers with the embedded devices equipped with the state-of-the-art technology and product services. Tablet enables interaction between operators/users and applications, connects industrial control products such as wireless, transducer, built-in battery, storage, etc. -
Page 8: Order Information
User Manual VT-TABLET-5081S 1.2 Order Information Table 1-1 is an example of order information. Table 1-1 Order information 5VDC Input ,8 '' IPS TFT LCD, RK3368, Quad-core 1.4 GHz, OTG VT-TABLET-5081S TYPEC USB, Two SPEAKERS, WIFI a/b/g/n/ac BT5.0,LTE B48,Wireless Charge etc. -
Page 9: Vt-Tablet-5081S Hardware Instructions
User Manual VT-TABLET-5081S 2. VT-TABLET-5081S Hardware Instructions 2.1 Product Appearance Figure 2-1 Figure 2-2 show the views of our product. Figure 2-1 Top view... - Page 10 User Manual VT-TABLET-5081S Figure 2-2 Back view...
-
Page 11: Specifications
User Manual VT-TABLET-5081S 2.2 Specifications Table 2-1 shows the specifications. Table 2-1 Specifications RK3368+RK808-B, Quad-core ARM Cortex-A55 (up to 1.4GHz) Processor LPDDR3-1333 512M*32b Flash eMMC 32GB 8” LCD, Resolution1280x800. Color depth: 16.7M. Display brightness : Typical 250 cd/m2 Capacity Touch screen, support 5 point and double tap to wake... -
Page 12: Buttons
User Manual VT-TABLET-5081S Operation -0C ~ +40℃ Temp. Storage -20C ~ +60℃ Temp. 2.3 Buttons Power Button Power off the device and on/off the screen. Volume buttons You can use volume up and down buttons to adjust the volume and use the down button to download the software. -
Page 13: Speakers
User Manual VT-TABLET-5081S Speakers 2.4.3 2x1w speakers is in the tablet。It can supply comfortable audio for the user. 2.4.4 Support FM function, Frequency 87~108MHz. Wi-Fi and Bluetooth 2.4.5 The tablet supports 802.11 a/b/g/n/ac Wi-Fi and BLE 5.0 With 2 internal antennas, both Wi-Fi and BLE can achieve better performance. -
Page 14: Software Instruction
User Manual VT-TABLET-5081S 3. Software Instruction VT-TABLET-5081S has been pre-loaded with Android image, so the system can run Android tool to update the system image. -
Page 15: Device Instructions
User Manual VT-TABLET-5081S 4. Device instructions 1), Power supply: This device only supports 5V DC input. Please use the adapter provided with the DC- Jack. 2), Typec usb supports both host and client modes. 3), Enter the download mode method: 1) Hold down the download key (the middle of the three keys) on the board. -
Page 16: Tips
Unauthorized changes to this product or its components are prohibited. In the aim of avoiding accidents as far as possible, it is not allowed to replace the system or change components unless with permission and certification. Please contact the technical department of Vantron or local branches for help. - Page 17 Vantron reserves the right to make necessary changes to this manual without prior notice. No part of this manual may be reprinted or publicly released in forms of photocopy, tape, broadcast, e-...
-
Page 18: Fcc Warning Statements
User Manual VT-TABLET-5081S 6. FCC Warning statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 19: Rf Exposure Information(Sar)
User Manual VT-TABLET-5081S 7. RF Exposure Information(SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. -
Page 20: Appendix A: How To Contact Us
Address: 440 Boulder Court, Suite 300, Pleasanton, CA 94566, USA Tel: 925-621-8758 Email: sales@vantrontech.com China Office: Chengdu Vantron Technology, Ltd Address: 6th Floor, 1st Building, No.9, 3rd Wu Ke East Street, Wu Hou District, Chengdu 610045, China Tel: 86-28-8512-3930/3931, 8515-7572/6320 Email:...
