Aplex ARCHMI-8 A Series User Manual

7”, 8”, 10.1”, 12.1”, 12.1w”, 15”, 15.6”, 17”, 18.5”, 19” and 21.5” intel apollo lake n4200/n3350 fanless industrial compact size panel pc
Hide thumbs Also See for ARCHMI-8 A Series:

Advertisement

Quick Links

Download this manual
Intel Apollo Lake N4200/N3350 Fanless Industrial Compact Size Panel PC
Release Date
Sep.2024
®2024 Aplex Technology, Inc.
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883
ARCHMI-8XXA Series
7", 8", 10.1", 12.1", 12.1W", 15", 15.6", 17", 18.5", 19" and 21.5"
User Manual
https://www.aplex.com/
URL:
All Rights Reserved.
Revision
V2.2
Published in Taiwan
