Introduction
The KBC EECF4-DN1-R is an Ethernet over Coax (EoC) receiver with 4 coax
ports with Power over Coax (PoC) and 1*10/100/1000M Ethernet port,
1*1000Base-FX SFP port. This switch provides connectivity for up to 4 units
PoC/PoE version EECF1-LS1-T-IN-B or EECF1-LS1-T-MN-B transmitter. Power is
supplied to the transmitters through the coaxial cable. Varying data rates are
supported depending on cable distance and quality. This product also provides
PoC management which allows the operator to remotely switch power on or
off to any of the coax channels. Plug-and-play design ensures ease of
installation with no electrical adjustment needed. LED indicators are provided
to show the operational status of the unit clearly.
This switch is available in wall mount.
Features
•
4 coax ports with PoC
•
1*10/100/1000M Ethernet port, 1*1000Base-FX SFP port
•
PoC management
•
Connect up to 4 units EECF1-LS1-T-IN-B, EECF1-LS1-T-MN-B or any
combination
•
Coax data rate >50Mbps (300m)
•
PoE+ is supported on transmitters up to 300m based on coax quality and
applied voltage to coax (48~57VDC)
•
Over current and short circuit protection
•
Unique PoC transmission protection design so that no power is output
when transmitter end is not connected
Downloads
Full specifications, features and additional information can be found on the
KBC website: www.kbcnetworks.com
QSG-EECF4-DN1-R-XN-B_Series-Rev2403
Copyright © KBC Networks Ltd. 2024
EECF4-DN1-R-XN-B
eCopper
Quick Start Guide
EoC Receiver – 4 BNC, 1 RJ45
and 1 SFP with PoC Management
www.kbcnetworks.com
TM
