EoC Receiver – 16 BNC and 3 RJ45 with POC management
Introduction
The EECF16-GN3-R is an Ethernet over Coax (EoC) switch with 16 coax ports
with Power Over Coax (PoC) and 3*10/100/1000M Ethernet ports. This switch
provides connectivity up to 16 units PoC/PoE version EECF1-LS1-T-IN-B or
EECF1-LS1-T-MN-B transmitter. Power is supplied to the transmitter through
the coaxial cable. Varying data rates are supported depending on cable
distance and quality. This product also provides PoC management which
allows the operator to remotely switch power on or off to any of the coax
channels. Plug-and-play design ensures ease of installation with no electrical
adjustment needed. LED indicators are provided to show the operational
status of the unit clearly.
This switch is available in 1U rack configuration.
Features
•
16 coax ports with PoC
•
3 *10/100/1000M Ethernet ports (1 at the front and 2 at the back)
•
PoC management
•
Full switching capability
•
Connect up to 16 units EECF1-LS1-T-IN-B , EECF1-LS1-T-MN-B or any
combination
•
Coax data rate >50Mbps (300m)
•
PoE+ is supported up to 300m based on coax quality and applied voltage
to coax (48~57VDC)
•
Over current and short circuit protection
•
Unique PoC transmission protection design so that no power is output
when transmitter end is not connected.
Downloads
Full specifications, features and additional information can be found on the
relevant product page on the KBC website as well as in the downloads section:
http://www.kbcnetworks.com/downloads
QSG-EECF16-GN3-R-RX-B_Series-Rev1808
Copyright © KBC Networks 2018
Quick Start Guide
EECF16-GN3-R-RX-B
eCopper™
www.kbcnetworks.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KBC eCopper EECF16-GN3-R
Summary of Contents for KBC eCopper EECF16-GN3-R
- Page 1 Unique PoC transmission protection design so that no power is output when transmitter end is not connected. Downloads Full specifications, features and additional information can be found on the relevant product page on the KBC website as well as in the downloads section: http://www.kbcnetworks.com/downloads QSG-EECF16-GN3-R-RX-B_Series-Rev1808 www.kbcnetworks.com...
- Page 2 General Check the product upon receipt for any visible damage which may have been caused during shipping. Physical Deployment This equipment must be installed and operated in accordance with instructions found in this document. Failure to comply with these instructions will invalidate warranty.
-
Page 3: Panel Views
Panel views Front Panel NOTICE: DISCONNECT THE AC POWER CABLE BEFORE SERVICING Reset 10/100/1000Base-T Rear Panel Page 3 of 8... -
Page 4: Dimensions (Unit = Mm)
Color Status Description Green Power supply is normal. 3*10/100/1000M Network link is IP-LINK Green normal. C-LINK Green EoC connection is normal. When the total power of 4 channels I-MAX Green more than 175W. PoC1~16 Green PoC power on. Dimensions (Unit = mm) 9~12 9~12 13~16... -
Page 5: Specifications
Specifications Items Description Power supply 110~240VAC/5A Power Consumption 500W (with PoC) 75-5 or above coaxial cable Transmission Medium and Cat5e/6 cable Operating frequency 2M~28M Modulation Wavelet-OFDM Transmission rate 210Mbps (Max.) Cable Power negotiation cycle Overcurrent 720mA Overcurrent protection <2mS time Transmission distance 500m RJ45... -
Page 6: Installation Instructions
If the problem still exists, please contact the dealer. Warranty Information KBC Networks extends the Limited Warranty to the original owner/purchaser of this product in according to the Warranty Policy posted in KBC Networks’ website at www.kbcnetworks.com. KBC Networks extends the following Limited Warranty to the original... - Page 7 The cost of the repaired or replaced parts or portions of this product; d) No other expressed or implied warranties have been made or will be made on behalf of KBC Networks with respect to the sale, repair, installation, operation, or replacement of this product. KBC Networks disclaims any implied warranty of merchantability of this product or its fitness for any purpose, and the buyer agrees that this product is sold “as is”...
