VC
EoU Transmitter & Receiver - 1 UTP Connecter and 1 RJ45
Introduction
The KBC EERN1-LN1-T-MX-B is a fully ruggedized Ethernet over UTP
transmitter and the EERN1-LN1-R-MX-B is a fully ruggedized Ethernet over UTP
receiver. This product provides connectivity for one 10/100Mbps IEEE
standard electrical copper port over UTP cable. Varying data rates are
supported depending on cable distance and quality. The plug-and-play design
ensures ease of installation with no electrical adjustment needed. LED
indicators are provided to clearly show the operational status of the unit.
The size of the product is suited for fitting inside camera housings and where
space is minimal.
Features
•
1 UTP port and 1*10/100M Ethernet port
•
UTP data rate >30Mbps (600m)
•
12~24VDC power input
•
Complete protection design including surge protection and lightning
protection
Downloads
Full specifications, features and additional information can be found on the
relevant product page on the KBC website as well as in the downloads section:
www.kbcnetworks.com
QSG-EERN1-LN1-X-MX-B_Series-Rev1904
Copyright © KBC Networks 2019
Quick Start Guide
EERN1-LN1-X-MX-B
eCopper™
www.kbcnetworks.com
Advertisement
Table of Contents
Related Manuals for KBC eCopper EERN1-LN1-X-MX-B
Summary of Contents for KBC eCopper EERN1-LN1-X-MX-B
-
Page 1: Quick Start Guide
Complete protection design including surge protection and lightning protection Downloads Full specifications, features and additional information can be found on the relevant product page on the KBC website as well as in the downloads section: www.kbcnetworks.com QSG-EERN1-LN1-X-MX-B_Series-Rev1904 www.kbcnetworks.com Copyright © KBC Networks 2019... - Page 2 General Check the product upon receipt for any visible damage which may have been caused during shipping. Physical Deployment This equipment must be installed and operated in accordance with instructions found in this document. Failure to comply with these instructions will invalidate warranty.
- Page 3 Top View (Receiver) Panel View Network cable panel Ethernet panel 1 - Power input; 2 - LED indicators; 3 - Network cable connecter; 4 - Ethernet RJ45 port; 5 – Grounding Color Status Description Green Power supply is normal. T-LINK Green EoU connection is normal.
- Page 4 RJ45 Definition Signal Dimensions (Unit = mm) Equipment: Installation Accessories: Page 4 of 8...
-
Page 5: Specifications
Specifications Item Description Power Input 12/24VDC Power Consumption <2W Transmission Medium Cat5e/6 cable Operating Frequency 2M~28M Modulation Wavelet-OFDM Transmission Rate 210Mbps (Max.) Cable Power Negotiation Cycle Overcurrent 720mA Overcurrent Protection <2mS Time Transmission Distance 600m Transmission Medium Cat5e/6 Ethernet Port Standard IEEE802.3, IEEE802.3U Ethernet Delay... -
Page 6: Installation Instructions
Installation Instructions Please check the following items before installation. If any missing, please contact the dealer. ⚫ EoU transmitter/receiver----------- x1 Wall mounting clamp---------------- x1 ⚫ QSG/User manual-------------------- x1 ⚫ Screw---------------------------------- x2 ⚫ Please follow the installation steps below: Attach the clamp to the wall using the 3X10mm screws; Press the transmitter/receiver into the clamp;... -
Page 7: Troubleshooting
If the problem still exists, please contact the dealer. Warranty Information KBC Networks extends the Limited Warranty to the original owner/purchaser of this product in according to the Warranty Policy posted in KBC Networks’ website at www.kbcnetworks.com. KBC Networks extends the following Limited Warranty to the original... - Page 8 The cost of the repaired or replaced parts or portions of this product; d) No other expressed or implied warranties have been made or will be made on behalf of KBC Networks with respect to the sale, repair, installation, operation, or replacement of this product. KBC Networks disclaims any implied warranty of merchantability of this product or its fitness for any purpose, and the buyer agrees that this product is sold “as is”...
