Table Of Contents - Pioneer AVIC-Z2 - Navigation System With DVD player Installation Manual

Contents
Important Safety Information.................... 1
ABOUT THIS MANUAL.................................. 1
PLEASE READ ALL OF THESE
INSTRUCTIONS REGARDING
YOUR NAVIGATION
SYSTEM AND RETAIN THEM
FOR FUTURE REFERENCE .................... 1
Connecting the System ............................ 3
Before installing this navigation system ............ 4
To prevent damage ............................................ 5
Parts supplied .................................................... 6
Connecting the system ...................................... 7
Connecting the multi-channel processor ............9
Connecting the power cord (1) ........................ 11
Connecting the power cord (2) ........................ 13
When connecting to separately sold power
amp .......................................................... 15
When connecting a rear view camera ............ 17
When connecting the external video component
.................................................................. 18
When connecting the external unit featuring video
source ........................................................18
When connecting the rear display ....................19
When using a rear display connected to rear
-
video output
Installation ................................................ 20
To guard against electromagnetic
interference .............................................. 21
Before installing .............................................. 21
Installing this navigation system ...................... 22
Installation notes
-
Parts supplied
-
Installation using the screw holes on the side
-
of the navigation unit
Installing the GPS antenna .............................. 25
Installation notes
-
Parts supplied
-
- When installing the antenna inside the vehi-
cle (on the rear shelf)
When installing the antenna outside the vehi-
-
cle (on the body)
Installing the microphone..................................28
Parts supplied
-
Mounting on the sun visor
-
Installation on the steering column
-
Adjusting the microphone angle ......................29
After Installing this Navigation System
.............................................................. 30
2
