Page 1 MNKOMNS kÉï=~ë=çÑW= pfkfrp=L=pfkfrp=`p=L=pfkfrp=qp léÉê~íáåÖ=fåëíêìÅíáçåë båÖäáëÜ båÖäáëÜ Operating Instructions SINIUS sliding track device, SINIUS CS and SINIUS TS...
Page 3 Sirona Dental Systems GmbH Table of contents Operating Instructions SINIUS / SINIUS CS / SINIUS TS Table of contents General information ....................Dear Customer, .................... Contact information ..................Notes on these Operating Instructions ............1.3.1 General information on the operating Instructions ......
Page 4 Table of contents Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS System overview ................... Patient chair ....................Headrest......................3.5.1 Motor-driven headrest ..............3.5.2 Double-jointed head support ............Foot control ....................Dentist element ..................... 3.7.1 Instrument positions .................
Page 5 Sirona Dental Systems GmbH Table of contents Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4.3 Triggering an immediate movement stop ........4.4.4 Armrests ..................4.4.5 VARIO footrest ................4.4.6 Adjusting the motor-driven headrest ..........4.4.6.1 Moving the headrest in/out ..........
Page 6 Table of contents Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5.8.6 Setting the foot control as a direct starter or speed foot control 4.5.8.7 Setting the spray amount ..........4.5.8.8 Preparing for use of NaCl saline solution ......
Page 7 Sirona Dental Systems GmbH Table of contents Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.6.6.3 Connecting the Mini L.E.D..........4.6.6.4 Functional description............4.6.6.5 Operating the Mini LED ............ 4.6.6.6 Technical data ..............Water unit ..................... 4.7.1 Swiveling the cuspidor bowl ............
Page 8 Table of contents Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14.2.2 Calibrating the touchscreen..........189 4.14.2.3 Adjusting the touchscreen brightness ....... 189 4.14.3 Setting the date and time ..............190 4.14.4 Configuring control options .............. 191 4.14.4.1 Preselecting the number of user profiles......
Page 9 Sirona Dental Systems GmbH Table of contents Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.2.7 Thermally disinfecting the instrument holder of the dentist element and sterilizing the silicone mat 5.2.8 Thermally disinfecting the instrument holder of the assistant element and sterilizing the silicone mat 5.2.9...
Page 10 Table of contents Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS Sanitation ...................... 251 5.7.1 Interactively guided sanitation of the treatment center..... 251 5.7.2 Display sanitation report..............258 5.7.3 Sanitizing the treatment center manually ......... 259 5.7.4...
Page 11 Operating Instructions SINIUS / SINIUS CS / SINIUS TS 1.1 Dear Customer, General information Dear Customer, We are pleased that you have equipped your practice with the Sirona ® SINIUS treatment center. Our aim is to recognize our customers' demands in good time and to create innovative solutions.
Page 12 Online portal for technical documents We have set up an online portal for the Technical Documents at http:// www.sirona.com/manuals. From here, you can download these Operating Instructions along with other documents. Please complete the online form if you would like a hard copy of a particular document. We will then be happy to send you a printed copy free of charge.
Page 13 The instructions as well as any warning and safety information contained therein also must be observed. There are separate operating instructions for each of the following Sirona products: ● Treatment instruments and accessories HUGO, CARL and PAUL ●...
Page 14 1 General information Sirona Dental Systems GmbH 1.7 Formats and symbols used Operating Instructions SINIUS / SINIUS CS / SINIUS TS Formats and symbols used The formats and symbols used in this document have the following meaning: Prerequisite Requests you to do something.
Page 15 Sirona Dental Systems GmbH 2 Safety instructions Operating Instructions SINIUS / SINIUS CS / SINIUS TS 2.1 Identification of the danger levels Safety instructions Identification of the danger levels To prevent personal injury and material damage, please observe the warning and safety information provided in the present operating instructions.
Page 16 To ensure compliance with the medical and national legal requirements Disinfection system, optional for water from treatment centers, Sirona recommends equipping the treatment center with a disinfection system. If you decide to operate the treatment center without a disinfection system, you must make alternative arrangements to ensure good water quality.
Page 17 Sirona Dental Systems GmbH 2 Safety instructions Operating Instructions SINIUS / SINIUS CS / SINIUS TS 2.6 Connection to the public drinking water system Connection to the public drinking water system Treatment center isolated from the public drinking water supply Disinfection system, optional...
Page 18 No restrictions apply when using salt blasting devices in connection with Suction of steel abrasives permissible Sirona treatment centers. However, in such cases, make sure that the system is subsequently flushed with an adequate amount of water. 2.10 Patient chair Please observe the maximum load capacity of 165 kg (363.8 lbs) for the...
Page 19 Sirona accessories or third-party accessories expressly approved by Sirona. The user assumes the risk of using non-approved accessories. If any devices not approved by Sirona are connected, they must comply with the applicable standards, e.g.: ● IEC 60950-1 for data devices (e.g. PC, Ethernet Switch, Ethernet...
Page 20 2 Safety instructions Sirona Dental Systems GmbH 2.17 Electromagnetic compatibility Operating Instructions SINIUS / SINIUS CS / SINIUS TS The treatment center monitor must fulfill the requirements of the IEC 60950-1 standard. The loudspeaker port of the monitor may be connected only to a device that complies with IEC 60950-1 (e.g.
Page 21 Sirona Dental Systems GmbH 2 Safety instructions Operating Instructions SINIUS / SINIUS CS / SINIUS TS 2.18 Electrostatic discharge 2.18 Electrostatic discharge Protective measures Electrostatic discharge (abbreviated: ESD – ElectroStatic Discharge) Electrostatic discharge from people can damage electronic components when the components are touched. Damaged components usually have to be replaced.
Page 22 2 Safety instructions Sirona Dental Systems GmbH 2.19 Dismantling/Installation Operating Instructions SINIUS / SINIUS CS / SINIUS TS Tip: 1 nanosecond = 1/1,000,000,000 second = 1 billionth of a second Voltage differentials exceeding 30,000 volts per centimeter may lead to a charge transfer (electrostatic discharge, lightning, arc-over).
Page 23 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.1 Standards/Approvals Unit description Standards/Approvals ® The treatment center SINIUS complies with the following standards, Compliance with standards, without HF surgery among others: ● IEC 60601-1 (electrical and mechanical safety plus software reliability) ●...
Page 24 The current approvals of the wireless foot control are listed on the rating label on the underside of the wireless foot control. ® SINIUS is a registered trademark of Sirona Dental Systems GmbH. Product name is a registered trademark 63 22 726 D3561 D3561.201.01.10.02 01.2016...
Page 25 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.2 Technical data Technical data Model designation: SINIUS / SINIUS CS / TS SINIUS Model designation, power ratings Power connection: 100 – 230 V AC ± 10%...
Page 26 3 Unit description Sirona Dental Systems GmbH 3.2 Technical data Operating Instructions SINIUS / SINIUS CS / SINIUS TS Transport and storage Temperature: -40 °C – +70 °C Operating and transport conditions 1060 conditions: (-40 °F – 158 °F) Relative humidity: 10% – 95% Air pressure: 500 hPa –...
Page 27 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.3 System overview System overview The SINIUS, SINIUS CS and SINIUS TS treatment centers comprise the SINIUS, SINIUS CS, SINIUS TS following main components: SINIUS treatment center (sliding track device) Patient chair [ →...
Page 28 3 Unit description Sirona Dental Systems GmbH 3.3 System overview Operating Instructions SINIUS / SINIUS CS / SINIUS TS SINIUS CS treatment center (swivel arm unit) System overview SINIUS CS Patient chair [ → 30] Motor-driven headrest [ → 31] (shown here) or Double articulating headrest [ →...
Page 29 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.3 System overview SINIUS TS treatment center (OTP unit) Patient chair [ → 30] Motor-driven headrest [ → 31] (shown here) or Double articulating headrest [ → 32] Foot control [ →...
Page 30 3 Unit description Sirona Dental Systems GmbH 3.4 Patient chair Operating Instructions SINIUS / SINIUS CS / SINIUS TS Patient chair The patient chair features a variety of adjustment options to optimally adapt the patient's position for the given treatment. Motor-driven headrest (shown here) or articulating headrest...
Page 31 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.5 Headrest Headrest 3.5.1 Motor-driven headrest The headrest allows for the following adjustment options: ● Motor-driven extension/retraction to adapt to the patient's stature ● Motor-driven tilting for maxillary/mandibular treatment ●...
Page 32 3 Unit description Sirona Dental Systems GmbH 3.5 Headrest Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.5.2 Double-jointed head support The double articulating headrest is equipped with two rotary joints. They allow the head inclination to be manually adjusted over a wide range for maxillary/mandibular treatment.
Page 33 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.6 Foot control Foot control The foot control enables hand-free control of the treatment instruments. Via the integrated cursor control, virtually all functions of the treatment center can be controlled via the foot control as an alternative to hand control.
Page 34 3 Unit description Sirona Dental Systems GmbH 3.7 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Dentist element All functions of the treatment center can be controlled via the EasyTouch control panel on the dentist element. The treatment center can be fitted with following dentist elements: ●...
Page 35 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.7 Dentist element Support arm, height adjustable by service engineer Slide of sliding track SINIUS CS dentist element SINIUS CS dentist element The SINIUS CS dentist element is attached to the water unit with a flexible support arm.
Page 36 3 Unit description Sirona Dental Systems GmbH 3.7 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Swivel arms Support arm SINIUS TS dentist element The SINIUS TS dentist element is attached to the water unit with a flexible support arm. The dentist element is held in place at the adjusted height with a pneumatic locking brake in the support arm.
Page 37 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.7 Dentist element Touchscreen for display and operation Fixed keys Main switch Skid-proof silicone mat Removable NaCI bottle holder Additional holder for intraoral camera Support arm 3.7.1...
Page 38 3 Unit description Sirona Dental Systems GmbH 3.7 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.7.2 EasyTouch user interface User interface of the SINIUS TS and SINIUS dentist elements SINIUS CS user interface User interface of the SINIUS CS dentist element...
Page 39 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.7 Dentist element 3.7.3 Touchscreen The touchscreen displays virtual function keys according to the program selected. A list of all function keys is provided in the Appendix of this document, see "Overview of all function keys"...
Page 40 3 Unit description Sirona Dental Systems GmbH 3.7 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.7.4 Fixed keys on the dentist element For a more detailed description of the fixed key functions, see "Fixed keys on the dentist element" [ → 83].
Page 41 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.7 Dentist element Flushing Starts or stops cuspidor flushing. When the Flushing key is pressed (> 2 s), the Flushing Time settings screen appears. Freely selectable function e.g., call key...
Page 42 3 Unit description Sirona Dental Systems GmbH 3.8 Assistant element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Assistant element The functional scope of the assistant element is adapted to the dental assistant's field of activity. It can, however, also be positioned so as to enable unassisted treatment by the dentist.
Page 43 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.8 Assistant element 3.8.1 Instrument positions The following instrument positions are available: Holder 1 Holder 2 Holder 3 Holder 4 Mini LED curing light SPRAYVIT M...
Page 44 3 Unit description Sirona Dental Systems GmbH 3.8 Assistant element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.8.2 User interface There are three fixed keys located on each side, to the left and right of the assistant element. 3.8.3 Fixed keys on the assistant element For a more detailed description of the fixed key functions, see "Fixed keys...
Page 45 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.9 Water unit Water unit The water unit can be optionally equipped with a disinfection system. It adds a disinfectant to the water that the patient comes in contact with.
Page 46 3 Unit description Sirona Dental Systems GmbH 3.9 Water unit Operating Instructions SINIUS / SINIUS CS / SINIUS TS Suction hose connection for assistant element Legend for SINIUS, SINIUS CS, SINIUS TS Manually swiveling cuspidor Tumbler filler (depicted) or tumbler filler with automatic sensor...
Page 47 Sirona Dental Systems GmbH 3 Unit description Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3.10 External device connection 3.10 External device connection External medical accessories can be connected to the external device connector. They must comply with the requirements of the Medical Device Directive 93/42/EEC.
Page 48 3 Unit description Sirona Dental Systems GmbH 3.10 External device connection Operating Instructions SINIUS / SINIUS CS / SINIUS TS IEC socket with power supply (max. 6 A) Fuse for IEC socket (6.3 A slow-blow) Quick coupling for air Quick coupling for water...
Page 49 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.1 Starting up the treatment center Operation Starting up the treatment center 4.1.1 Initial startup Sanitation must be performed prior to initial startup of your treatment center.
Page 50 4 Operation Sirona Dental Systems GmbH 4.1 Starting up the treatment center Operating Instructions SINIUS / SINIUS CS / SINIUS TS Main switch 4.1.2.2 Switching the treatment center on The main switch switches the treatment center from Standby mode to operational readiness.
Page 51 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.1 Starting up the treatment center 4.1.3 Selecting a user profile The treatment center allows for the management of up to six user profiles. This way, multiple users can operate the treatment center without having to forego their own individual treatment and operation related settings.
Page 52 4 Operation Sirona Dental Systems GmbH 4.2 Control concept of touchscreen Operating Instructions SINIUS / SINIUS CS / SINIUS TS Control concept of touchscreen 4.2.1 Virtual function keys The touchscreen displays virtual function keys according to the program selected. Required functions can be activated either by touching the function keys with your finger or via cursor with the foot control.
Page 53 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.2 Control concept of touchscreen 4.2.2 Start program operating modes Start program After the treatment center is switched on, the automatically appears. The start program can run in two operating modes. In the...
Page 54 4 Operation Sirona Dental Systems GmbH 4.2 Control concept of touchscreen Operating Instructions SINIUS / SINIUS CS / SINIUS TS Start Other general functions of the treatment center are listed in the sub- Sub-screen screen. This can be accessed via the key.
Page 55 Switching between the Start and Instrument programs does not apply. This makes operation of the SINIUS dental treatment center similar to other Sirona dental treatment centers that are operated without a touchscreen. EasyMode Start program...
Page 56 ● The treatment functions for implantology and endodontic treatments are not available. EasyMode Start program operating mode is intended for users who would like to retain the familiar operating concept of other Sirona treatment centers and who can do without the functions listed above. Program change keys Standard...
Page 57 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.2 Control concept of touchscreen Settings screens In many cases, functions not only can be switched on or off, but also can be set. If a function key is pressed and held (> 2 s), the corresponding settings screen appears.
Page 58 4 Operation Sirona Dental Systems GmbH 4.3 Foot control Operating Instructions SINIUS / SINIUS CS / SINIUS TS Foot control The treatment center can be operated using a wireless foot control or a foot control with a cable connection. 4.3.1 Wireless foot control Technical data of the wireless module, see Foot control radio interface"...
Page 59 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.3 Foot control 4.3.2 Operating the foot control The foot control operating elements are assigned different functions, depending on whether the instruments are all in place or an instrument is removed from its holder.
Page 60 4 Operation Sirona Dental Systems GmbH 4.3 Foot control Operating Instructions SINIUS / SINIUS CS / SINIUS TS Right button ✔ All instruments are in place. ➢ Press the right button.  The chair moves to entry/exit position 0. ✔ An instrument (motor, turbine) is removed.
Page 61 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.3 Foot control 4.3.3 Using the cursor control EasyMode Start program The cursor control cannot be used in the operating mode. 4.3.3.1 Functionality Cursor control as an alternative mode of operation The touchscreen and the fixed keys of the dentist element can also be operated hand-free via the foot control.
Page 62 4 Operation Sirona Dental Systems GmbH 4.3 Foot control Operating Instructions SINIUS / SINIUS CS / SINIUS TS Cursor path The cursor path runs between the pairs of keys, moving from top to bottom and from left to right, usually in multiple loops. The cursor path can be traversed between the starting and end points either in a forward or a reverse direction.
Page 63 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.3 Foot control Operating the cursor control 4.3.3.2 Moving the cursor ➢ Briefly slide the 4-way foot control plate upward or downward.  The orange cursor moves forward or back one cursor position.
Page 64 4 Operation Sirona Dental Systems GmbH 4.3 Foot control Operating Instructions SINIUS / SINIUS CS / SINIUS TS Changing programs ✔ Cursor control with program change is switched on. 1. Position the cursor at the starting point of the cursor path. 2. Move the cursor past the start position. Hold the 4-way foot control plate in the upward position.
Page 65 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4 Patient chair Patient chair 4.4.1 Safety instructions ü û Patient chair, chair movements CAUTION The free space under the patient couch and up to the water unit can be decreased due to chair movements.
Page 66 4 Operation Sirona Dental Systems GmbH 4.4 Patient chair Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4.2 Safety stop The treatment center is equipped with various safety stops to prevent crushing and damages. The cutoff trigger points are shown in the...
Page 67 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4 Patient chair 4.4.3 Triggering an immediate movement stop You can stop the movement of the chair to a programmed position as follows: Shock positioning ➢ Press the main switch or the fixed key on the dentist element.
Page 68 4 Operation Sirona Dental Systems GmbH 4.4 Patient chair Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4.4 Armrests Armrests are available for the patient chair. The right armrest can be swiveled forward to facilitate getting in and out of the chair.
Page 69 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4 Patient chair 4.4.6 Adjusting the motor-driven headrest The motor-driven headrest can be adjusted via the touchscreen or directly on the headrest. Headrest, motor-driven, catching of hair...
Page 70 4 Operation Sirona Dental Systems GmbH 4.4 Patient chair Operating Instructions SINIUS / SINIUS CS / SINIUS TS Inclining the headrest 4.4.6.2 The headrest can be tilted either via motor drive or manually (quick mechanical adjustment). Via touchscreen Tilting headrest via touchscreen, Standard Start program ✔...
Page 71 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4 Patient chair 4.4.7 Adjusting the double articulating headrest The double articulating headrest is equipped with two rotary joints. They facilitate manual adjustment of head inclination for maxillary/mandibular treatments.
Page 72 4 Operation Sirona Dental Systems GmbH 4.4 Patient chair Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4.8 Moving the patient chair via chair programs The chair programs can be selected via the touchscreen. The entry/exit Chair programs 0 and S on the assistant element, references to “Creating chair programs”...
Page 73 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4 Patient chair Via foot control ✔ All instruments are in place. ➢ Press the right button of the foot control. Via the assistant element ➢ Press the key on the assistant element briefly (<...
Page 74 4 Operation Sirona Dental Systems GmbH 4.4 Patient chair Operating Instructions SINIUS / SINIUS CS / SINIUS TS Activating other chair programs 4.4.8.4 ✔ Start program is displayed on the touchscreen. ➢ Touch the key or the key briefly (< 2 s).
Page 75 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4 Patient chair Manual Chair Adjustment  The screen is displayed. 2. Perform the settings described in the following sections. Tilting the patient couch 4.4.9.2 Movement of the seat and backrest without any compression or...
Page 76 4 Operation Sirona Dental Systems GmbH 4.4 Patient chair Operating Instructions SINIUS / SINIUS CS / SINIUS TS Adjusting the chair height 4.4.9.3 Chair height via touchscreen, EasyMode Start program, manual chair adjustment Via touchscreen ✔ Manual Chair Adjustment EasyMode Start program or the program is displayed on the touchscreen.
Page 77 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4 Patient chair 4.4.10 Creating chair and shock positioning programs Chair programs The four chair programs preset in the factory: ● Mouth rinsing position S ● Entry/exit position 0 ●...
Page 78 4 Operation Sirona Dental Systems GmbH 4.4 Patient chair Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.4.11 Setting the active lumbar support The patient chair has the option of lumbar support. Opening Start sub-screen Standard or EasyMode Start program ✔...
Page 79 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Dentist element 4.5.1 Maximum load capacity The maximum load of the SINIUS (sliding track unit) dentist element is 2 kg (4.4 lb). A sterilizable silicone mat can be placed over the dentist element.
Page 80 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5.2 Height adjustment The height of the SINIUS (sliding track unit) dentist element can be adjusted to achieve an ergonomic instrument height. Please contact your service engineer.
Page 81 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Dentist element on support arm, collision, manual movement WARNING The SINIUS CS dentist element could be positioned within the movement range of the patient chair.
Page 82 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS SINIUS TS dentist element In the OTP version, the dentist element is attached to the water unit with a flexible support arm. The dentist element is held in place at the adjusted height with a pneumatic locking brake in the support arm.
Page 83 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.4 Fixed keys on the dentist element Arrangement of fixed keys on the SINIUS and SINIUS TS dentist elements Fixed keys SINIUS CS Arrangement of fixed keys on the SINIUS CS dentist element 4.5.4.1...
Page 84 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS It is not possible: ● to switch to the Instrument program or the sub-screen of an instrument when no instrument has been removed ● to switch to the SIVISION program when the PC connection is turned...
Page 85 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Starting the timer Timer 1. Press the fixed key briefly.  The most recently set timer is started immediately. The set and Timer function elapsed time are displayed in the status bar.
Page 86 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Operating Light 1. Press and hold the fixed key on the dentist element (> 2 s).  The settings screen of the operating light is displayed on the touchscreen.
Page 87 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Tumbler Filling 2. Press the fixed key.  The tumbler is filled with water for the preset time. Tumbler Filling Pressing the fixed key again stops the filling function immediately.
Page 88 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Setting the flushing time Flushing 1. Press and hold the key on the dentist element (> 2 s). Flushing  The settings screen appears on the touchscreen.
Page 89 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.5 Quick setting keys and function levels Depending on which instrument is taken from the holder, the corresponding instrument program or respective functions appear in the EasyMode Start program.
Page 90 The operating concept corresponds with other Sirona treatment centers that have membrane keys. Start program in EasyMode with instrument functions for motor and ultrasonic...
Page 91 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.6 Saving instrument settings With static quick setting keys Memory You can determine whether the key should be displayed in the instrument programs with the quick setting keys, see "Preselecting the quick setting key or function level types".
Page 92 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS  An acoustic signal sounds. The set speed and preselection and activation of the coolant are saved on the quick setting key. 3. Repeat this process for other quick setting keys if necessary.
Page 93 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.7 Placing the instruments in their holders Automatic opening of instrument dialogs Standard Start program In the operating mode, the touchscreen will automatically display the Instrument program of the removed instrument.
Page 94 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Instrument hoses NOTICE Instrument hoses The instrument hoses contain electrical cables and media pipes. Over-tensioning or pinching the hoses may cause the electrical cables to break and the media pipes to leak.
Page 95 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.8 General instrument functions Settings for the coolant, instrument light, and foot switch can be made in the sub-screen of the instrument removed from the holder.
Page 96 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Via touchscreen EasyMode Start program The preselected coolant in the operating mode can only be turned on/off with the foot control buttons, see below.
Page 97 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element ✔ Sub-screen of the removed instrument is displayed on the touchscreen. Direct Starter/speed foot control ➢ Touch the key.  If the key is highlighted gray, the direct starter function is switched on.
Page 98 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3. Set the spray amount by turning the screw. 4. Check the set spray amount with a burr drive. Correct the setting if necessary.
Page 99 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Preparing for use of NaCl saline solution 4.5.8.8 The peristaltic pump prepares a sterile saline solution instead of spray water for cooling. The peristaltic pump hose is a disposable item. To reorder it, see "Spare parts and consumables"...
Page 100 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 6. Push the short end of the hose with the cannula through the stopper and into the NaCl bottle. The regulator in the hose clip E must be completely open (regulating wheel in top position).
Page 101 NOTICE Flow rate of the ultrasonic tip Ultrasonic tips of third-party manufacturers in some cases don't offer a sufficient flow rate in conjunction with the NaCl function. ➢ Use only ultrasonic tips from Sirona. 63 22 726 D3561 D3561.201.01.10.02 01.2016...
Page 102 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5.9 ApexLocator The ApexLocator can be used to measure the working length of the root canal file in endodontic treatments using electrical impedance. The ApexLocator can be used as follows: ●...
Page 103 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Preparing to use the ApexLocator 4.5.9.1 Apex adapter, mucosal electrode, and file clamp The mucosal electrode and the file clamp are connected to the socket of Sliding track, swivel arm and OTP dentist element the dentist element using the apex adapter.
Page 104 For endodontic treatments with the ApexLocator, the Sirona ENDO handpiece 6:1 (starting from SN 6407 / July 2010), ENDO 6L, or ENDO L is required when using the treatment function; the Sirona handpiece SIRONiTi Apex is required when the motor program (without electronic torque limitation) is used.
Page 105 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Distance display 4.5.9.2 The measured root canal depth is shown in the distance display on the touchscreen. A bar with 11 display levels shows the distance from the root canal file to the physiological apex (apical constriction).
Page 106 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Green region The tip of the root canal file has reached the physiological apex. Red region The tip of the root canal file has pierced the physiological apex. The instrument overshoot is displayed.
Page 107 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Dental unit plugin "ApexLocator distance display" The distance display on the touchscreen can be additionally shown on the SIVISION monitor. For this, SIDEXIS 4 and the dental unit plugins must be installed on the PC .
Page 108 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Beeps 4.5.9.3 In addition to the graphical distance display on the touchscreen, the position of the file in the root canal can also be indicated as an acoustic signal.
Page 109 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Performing manual measurements with the file clamp 4.5.9.4 For endodontic examination, a manual measurement can be performed using the file clamp and a root canal file.
Page 110 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5.10 Electric motor IMPORTANT Electric motor, observe the Operating Instructions Also observe the operating instructions for the different motors. 4.5.10.1 Motor and coupling versions Different brushless motors are available depending on the type of use and the coupling of the handpiece.
Page 111 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element BL ISO E/C motors The green coded instrument hose (GN) must be used for the BL ISO E/C motors. BL ISO E BL ISO C The BL ISO E/C motors are directly equipped with an ISO coupling.
Page 112 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Setting the speed 4.5.10.2 Standard Start program In the operating mode, settings can be made using the static quick setting keys (with the key values 0.09 or 0.2, 20, 40), with programmable quick setting keys (with changeable key values), or via function levels (E1, E2).
Page 113 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Setting intermediate speed values with static quick setting keys ✔ The electric motor is removed from the holder. ✔ Motor program EasyMode with static quick setting keys or the Start program is displayed on the touchscreen.
Page 114 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Setting the speed with function levels ✔ The electric motor is removed from the holder. ✔ Motor program with function levels is displayed on the touchscreen.
Page 115 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element EasyMode Start program operating mode, the direction of rotation must be set via the foot switch. ✔ An electric motor is removed. ✔ Motor program...
Page 116 IMPORTANT ApexLocator, SIRONiTi APEX SIRONiTi APEX Only Sirona SIRONiTi APEX must be used to perform apex measurement using a torque-limiting handpiece! The electrical conductivity can only be ensured using this handpiece. The SIRONiTi handpiece can also be used to perform endodontic treatments without the ApexLocator.
Page 117 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Apex stop 3. Touch the key.  If the key is highlighted orange, the motor stops automatically when the physiological apex is reached. The – and + keys and AutoReverse key are displayed.
Page 118 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS acoustic signals vary according to the measured distance from the physiological apex. If this function is switched on, the acoustic signals vary depending on the measured distance to the preset motor stop position.
Page 119 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.11 Highspeed handpiece Using the highspeed handpiece 4.5.11.1 IMPORTANT High-speed handpiece, observe the Operating Instructions Also observe the operating instructions for the different high-speed handpieces.
Page 120 Operating Instructions SINIUS / SINIUS CS / SINIUS TS Preselecting the instrument light operating voltage The original Sirona halogen and LED lamps are usually operated at 3.6 V. Voltages over 3.8 V destroy the lamp. The operating voltage can be adjusted for lamps made by other manufacturers.
Page 121 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.12 SPRAYVIT M multifunctional syringe The multifunctional syringe is used to clean the treatment areas and blow them dry. It supplies air and preheated water media. The heating cartridge for the water is located in the handpiece.
Page 122 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS IMPORTANT Multifunctional syringe, electronic flow monitoring Electronic flow monitoring If the electronic flow monitoring system detects low flow, the water heater will be deactivated and the system displays the corresponding error message, see also "Error messages"...
Page 123 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Instrument light SPRAYVIT 2. Touch the key.  If the key is highlighted orange, the instrument light is turned on at the multifunctional syringe SPRAYVIT M if this is the only instrument to have been removed.
Page 124 ➢ Always attach the torque wrench to the scaler for protection as soon as you deposit the handpiece. Ultrasonic handpiece, only Sirona tips CAUTION In some cases, ultrasonic tips from other manufacturers do not guarantee safe operation. ➢ Use only ultrasonic tips from Sirona. 63 22 726 D3561 D3561.201.01.10.02 01.2016...
Page 125 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Setting the intensity 4.5.13.2 Standard Start program In the mode, settings can be made using the static quick setting keys (with the key values 1, 25, 50, 75, 100), with programmable quick setting keys (with changeable key values), or via function levels (E1, E2).
Page 126 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Setting intermediate intensity values with static quick setting keys ✔ The SIROSONIC TL scaler is removed from the holder. ✔ Ultrasonic program with static quick setting keys or the EasyMode Start program is displayed on the touchscreen.
Page 127 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element function is only seen on the user interface if the intensity is increased on the display. The key is not available. ✔ The SIROSONIC TL scaler is removed from the holder.
Page 128 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Ultrasonic  The sub-screen is displayed. Endo 2. Touch the key.  The key is highlighted orange. In the first row of the ultrasonic program, the endodontics intensity is displayed instead of the ultrasonic intensity.
Page 129 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.14 Implantology and endodontic treatment The treatment functions support implantology and endodontic treatments. The speed and torque of the rotating instrument can be precisely adjusted and saved for later reference, if desired.
Page 130 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 3. Remove the burr drive that is marked with an orange dot in the status bar from the instrument holder. Endodontics  Depending on the type of treatment selected, the...
Page 131 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Motor screen removed from its holder. In order for the to be displayed again the next time the burr drive is removed, the Treatment function must be switched off beforehand.
Page 132 Implantology 4.5.14.2 Contra-angle handpiece, implantology CAUTION Only the Sirona contra-angle handpiece IMPLANT 20:1 may be used for the Implantology function. Instruments from other manufacturers can lead to malfunctions. Outside instruments may be improperly calibrated for implantology. ➢ Use only the IMPLANT 20:1 contra-angle handpiece from Sirona for implantology.
Page 133 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element IMPORTANT Treatment, torque adjustment Torque adjustment The maximum adjustable torque depends on the system motor and the speed settings. Endodontics, speed and torque settings CAUTION Improperly selected speeds and torque values endanger the patient.
Page 134 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS ✔ Implantology program is displayed on the touchscreen. previous step ➢ Select the required implantology work step. Touch the next step key.  The selected work step is displayed on the touchscreen. The settings saved in the work step are preset.
Page 135 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.14.2.6 Functions in the sub-screen Opening the implantology sub-screen ✔ Implantology program is displayed on the touchscreen. Sub-screen ➢ Touch the key. Implantology  The sub-screen is displayed.
Page 136 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Activating NaCl rinsing via button on foot control ✔ NaCl rinsing Implantology program key is displayed in the ➢ Press the right button of the foot control.
Page 137 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.14.2.7 Preparing the treatment center for sterile operation The requirements for sterile operation must be fulfilled for surgical procedures. Work only with the cursor control to avoid touching the user interface.
Page 138 4.5.14.3 Contra-angle handpiece, endodontics CAUTION Only the Sirona ENDO 6:1 (after SN 6407 / July 2010) and ENDO 6 L contra-angle handpieces can be used for the endodontics function. Instruments from other manufacturers can lead to malfunctions. Third- party instruments may be improperly calibrated for endodontics.
Page 139 This includes a measurement of motor current at different speeds to assess the properties of the system. Calibration only with Sirona instruments CAUTION Use only Sirona instruments to guarantee correct calibration. ✔ Endodontics program is displayed on the touchscreen. 1. Attach the contra-angle handpiece that you would like to use for the treatment to the electric motor.
Page 140 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5.14.3.4 Using reciprocal rotating files For endodontic treatment with reciprocal rotating files, the sequence of the files and the preset values recommended by the manufacturer cannot be changed.
Page 141 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.14.3.6 Functions in the sub-screens Opening the endodontics sub-screen Settings, such as changing the preselected speed and torque values [ → 141], or removing a file from the sequence [ → 144], are file- specific.
Page 142 ➢ Observe the manufacturer's instructions regarding file systems. Contra-angle handpiece, endodontics CAUTION Only the Sirona ENDO 6:1 (after SN 6407 / July 2010) and ENDO 6 L contra-angle handpieces can be used for the endodontics function. Instruments from other manufacturers can lead to malfunctions. Third- party instruments may be improperly calibrated for endodontics.
Page 143 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element Turning on/off the automatic motor stop of the ApexLocator If your treatment center is equipped with the ApexLocator option, you can set the motor to stop at the physiological apex. The motor stop can be...
Page 144 > 2 s.  The selected file is removed from the sequence. Switch instrument light on/off The Sirona ENDO 6L handpiece is equipped with an optical fiber. Instrument light ➢ Switch the instrument light on or off with the key.
Page 145 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 4.5.14.3.7 Endodontic treatment administration Up to three endodontic treatments can be added to the treatment list of Treatment selection screen. The following functions are for managing the endodontic treatment list: ●...
Page 146 4 Operation Sirona Dental Systems GmbH 4.5 Dentist element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Copy endodontic treatment 2. Touch the key.  A keyboard is displayed. The name of the endodontic treatment to be copied is displayed in the text box.
Page 147 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.5 Dentist element 1. Touch the button of an endodontic treatment that you would like to delete.  The selected button is highlighted orange. Delete endodontic treatment 2.
Page 148 4 Operation Sirona Dental Systems GmbH 4.6 Assistant element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Assistant element 4.6.1 Maximum load capacity The maximum load of the assistant element is 1.5 kg (3.3 lbs). A skid- proof silicone mat can also be used.
Page 149 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.6 Assistant element Tumbler filling 4.6.3.1 If the your treatment center is equipped with the Tumbler filling option with automatic sensor control, see “Tumbler filling with automatic sensor control”...
Page 150 4 Operation Sirona Dental Systems GmbH 4.6 Assistant element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Hash key 4.6.3.5 Hash key on the assistant element can be configured in the Setup program. The key allows the user to switch the X-ray viewer or the white screen function on the SIVISION monitor on or off or alternatively to activate the bell or hash relay, see “Setting function of the Hash key on...
Page 151 ➢ Make sure that you hold the suction tip in such a way that the opening cannot accidentally attach to the oral mucous membranes. Sirona recommends using spray aspirator cannulas with additional air intake, see "Spare parts, Consumables" [ → 269].
Page 152 4 Operation Sirona Dental Systems GmbH 4.6 Assistant element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Saliva ejector A curved tip that can be placed in the corner of the mouth is provided for saliva ejection. Surgical suction device The surgical cannula can be inserted directly into the saliva ejector handpiece.
Page 153 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.6 Assistant element 4.6.5 SPRAYVIT M multifunctional syringe The functionality is described in the chapter on the dentist element, see "SPRAYVIT L multifunctional syringe" [ → 121].
Page 154 4 Operation Sirona Dental Systems GmbH 4.6 Assistant element Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.6.6 Mini LED curing light The curing light is used to cure composite material with short-wave light. 4.6.6.1 Safety instructions Curing light, laser radiation CAUTION The curing light contains powerful LEDs.
Page 155 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.6 Assistant element Connecting the Mini L.E.D. 4.6.6.3 The Mini L.E.D. is connected to the assistant element in holder 1. Mini LED in holder 1 1. Connect the supply cable A to the treatment center.
Page 156 4 Operation Sirona Dental Systems GmbH 4.6 Assistant element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Quick curing mode In the quick curing mode, the Mini LED operates at full power for 10 seconds. In this mode, the light intensity output is as follows: Sec.
Page 157 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.6 Assistant element Operating the Mini LED 4.6.6.5 IMPORTANT Curing light, contact with the material to be cured Contact with the material to be cured Make sure that the light guide never touches the material to be cured, as this may cause damage to the light guide and reduce its effectiveness.
Page 158 4 Operation Sirona Dental Systems GmbH 4.6 Assistant element Operating Instructions SINIUS / SINIUS CS / SINIUS TS Technical data 4.6.6.6 General Technical Data on Mini L.E.D. Model: Mini L.E.D. Weight of handpiece without hose: 105 g Dimensions: Dia. 23mm x 240mm Current consumption of handpiece: 5 V DC / 0.65 A...
Page 159 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.7 Water unit Water unit 4.7.1 Swiveling the cuspidor bowl The cuspidor on the water unit can be manually swiveled approx. 110 mm toward the patient chair.
Page 160 4 Operation Sirona Dental Systems GmbH 4.7 Water unit Operating Instructions SINIUS / SINIUS CS / SINIUS TS Setting the filling level The tumbler filling level can be preset. 1. Open the maintenance flap A on the base of the water unit.
Page 161 Microorganisms can multiply in the water. These microorganisms could increase the risk of damage to one's health. ➢ Sirona recommends never operating the treatment center without disinfectants. ➢ Mix fresh water for the stand-alone water supply every day. At the end of the work day, the remaining water must be flushed out of the disinfectant tank using the tumbler filling function.
Page 162 4 Operation Sirona Dental Systems GmbH 4.7 Water unit Operating Instructions SINIUS / SINIUS CS / SINIUS TS Opening Start sub-screen ✔ Start program is displayed on the touchscreen. Standard Start program Sub-screen ➢ In the : Touch the key. EasyMode Start program...
Page 163 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.7 Water unit Start Aqua  In the sub-screen, the key is highlighted in orange. The disinfection system is now changed to stand-alone water supply. If the treatment center is changed to self-sufficient water supply, the...
Page 164 4 Operation Sirona Dental Systems GmbH 4.8 Tray Operating Instructions SINIUS / SINIUS CS / SINIUS TS Tray 4.8.1 Tray on the support arm (for SINIUS) Maximum load capacity SINIUS treatment centers as a sliding track device can be equipped with a tray on a support arm.
Page 165 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.8 Tray Removing the brake knob The brake knob of the support arm can be removed if it is found to be disturbing. 1. Loosen the brake knob at the safety screw A.
Page 166 4 Operation Sirona Dental Systems GmbH 4.8 Tray Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.8.3 Tray on the SINIUS TS dentist element Maximum load capacity SINIUS TS treatment centers can be equipped with a tray mounted to the left of the dentist element.
Page 167 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.8 Tray Adjusting the stiffness of the rotary joint In the head of the tray holder there is a regulating screw for setting the necessary exertion for turning the tray.
Page 168 4 Operation Sirona Dental Systems GmbH 4.9 Panoramic X-ray image viewer Operating Instructions SINIUS / SINIUS CS / SINIUS TS Panoramic X-ray image viewer The SINIUS TS treatment center can be equipped with an X-ray viewer on the support arm of the dentist element arm.
Page 169 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.9 Panoramic X-ray image viewer 4.9.2 Attaching the anti-glare film An anti-glare film is supplied with the X-ray viewer for viewing intraoral dental images. 1. Remove the three retaining clips A.
Page 170 4 Operation Sirona Dental Systems GmbH 4.10 Operating light Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.10 Operating light The operating light is attached to a multi-jointed support arm. It can be easily adjusted to illuminate the treatment area using the handles. Brakes in the support arm hold the operating light in the position to which it has been adjusted.Surgical light...
Page 171 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.10 Operating light Sensor control 3. Touch the key.  If the key is highlighted in orange, the operating light can be controlled with the contactless sensor. The keys for adjusting the operating distance are displayed.
Page 172 4 Operation Sirona Dental Systems GmbH 4.11 X-ray tube unit Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.11 X-ray tube unit The SINIUS, SINIUS CS, and SINIUS TS treatment centers can be PLUS equipped with the HELIODENT X-ray tube unit. However, for the SINIUS CS, this is possible only if the dentist element is mounted in the standard position on the water unit, see section "Positioning the dentist...
Page 173 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.12 SIVISION digital video system 4.12 SIVISION digital video system The SIVISION digital video system enables intraoral and extraoral images to be made. The SiroCam AF / AF+ intraoral camera generates digital image data which can be transmitted via a USB 2.0 port (high-...
Page 174 4 Operation Sirona Dental Systems GmbH 4.12 SIVISION digital video system Operating Instructions SINIUS / SINIUS CS / SINIUS TS Attachment versions Monitor on lamp support tube The monitor can be rotated and swiveled. Monitor on tray arm The monitor can be rotated and swiveled.
Page 175 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.12 SIVISION digital video system 4.12.2 SiroCam AF / AF+ intraoral camera Safety instructions 4.12.2.1 The SiroCam AF / AF+ intraoral camera is a sensitive optical instrument and must therefore always be handled with care.
Page 176 4 Operation Sirona Dental Systems GmbH 4.12 SIVISION digital video system Operating Instructions SINIUS / SINIUS CS / SINIUS TS Connecting the SiroCam AF / AF+ intraoral camera 4.12.2.3 Connecting the intraoral camera to the SINIUS and SINIUS TS dentist elements Depending on the equipment version, the intraoral camera can be placed at instrument position five or in the additional holder.
Page 177 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.12 SIVISION digital video system Removing the intraoral camera The plug of the intraoral camera is secured against unintentional removal. ➢ Grasp the plug by its locking device A and pull this out without tilting, if possible.
Page 178 4 Operation Sirona Dental Systems GmbH 4.12 SIVISION digital video system Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.12.2.4.2 Using the camera with SI Video Using SI Video, up to four still images can be generated with the SiroCam AF / AF+ intraoral camera. These can be displayed on the SIVISION monitor either as a sequence of single images or simultaneously as a quad image.
Page 179 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.12 SIVISION digital video system Switching between quad image and single image When you change from quad to single image, the previously marked quad image is displayed as a single image. Conversely, the displayed single image is marked in the quad image.
Page 180 4 Operation Sirona Dental Systems GmbH 4.12 SIVISION digital video system Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.12.2.4.3 Using the camera with SIDEXIS Besides the display and processing of X-ray images, SIDEXIS XG or SIDEXIS 4 can be used additionally as a video application for the SiroCam AF / AF+ intraoral camera.
Page 181 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.12 SIVISION digital video system Saving an image ✔ The patient must be registered in SIDEXIS. ✔ The still image to be saved is displayed on the SIVISION monitor.
Page 182 4 Operation Sirona Dental Systems GmbH 4.13 Operation with a PC Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.13 Operation with a PC The treatment center can be connected to a PC via an Ethernet cable. The SIVISION and/or SIUCOM plus PC application enables communication between the treatment center and the PC.
Page 183 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.13 Operation with a PC 4.13.1 SIVISION program Various PC applications of the PC can be started and operated in the SIVISION program. You can select the PC applications to be operable via the treatment center in SIUCOM plus.
Page 184 4 Operation Sirona Dental Systems GmbH 4.13 Operation with a PC Operating Instructions SINIUS / SINIUS CS / SINIUS TS The treatment center starts the PC applications automatically. An orange square located in front of the respective PC application on the touchscreen indicates whether the application has been started and is ready for operation on the PC.
Page 185 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.13 Operation with a PC Communication with SIDEXIS 4.13.1.4 The SIDEXIS PC application enables you e.g. to display X-ray and intraoral camera images and transmit them to the SIVISION monitor. The live image of the SiroCam AF / AF+ intraoral camera is displayed in SIDEXIS and can be saved as a still image in the patient database.
Page 186 4 Operation Sirona Dental Systems GmbH 4.13 Operation with a PC Operating Instructions SINIUS / SINIUS CS / SINIUS TS Rotate image Rotates the image 90° counterclockwise or clockwise. With SIDEXIS 4, the image can be rotated 180° by pressing a key.
Page 187 USB interface, only units of type BF CAUTION Only type BF medical devices and applied parts according to IEC 60601-1, e.g. the Sirona XIOS XG USB module intraoral X-ray system, may be connected to the USB interface. USB interface, only units without power supply unit CAUTION USB devices with their own voltage supply (e.g., via a power supply unit)
Page 188 4 Operation Sirona Dental Systems GmbH 4.14 Configuration of the treatment center (setup) Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14 Configuration of the treatment center (setup) Various treatment center functions can be individually configured via the Setup settings. The treatment center can therefore be adapted to match each user's personal method of treatment.
Page 189 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14 Configuration of the treatment center (setup) 4.14.2 Configuring the EasyTouch user interface EasyTouch user interface ➢ Touch the key in the setup program.  The sub-screen opens.
Page 190 4 Operation Sirona Dental Systems GmbH 4.14 Configuration of the treatment center (setup) Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14.3 Setting the date and time Date and time ➢ Touch the key in the setup program.  The sub-dialog opens.
Page 191 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14 Configuration of the treatment center (setup) 4.14.4 Configuring control options Operation of the entire treatment center operation can be configured in this dialog. Control options ➢ Touch the key in the setup program.
Page 192 NOTICE The CDS 60 station may only be operated with a cleaning agent approved by Dürr Dental and Sirona, e.g., Orotol plus. IMPORTANT Also observe the installation and operating instructions for the CDS 60 from Dürr Dental.
Page 193 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14 Configuration of the treatment center (setup) Switching on/off the foot control function for intraoral camera focus 4.14.4.6 It is possible to enable the foot control to focus the SiroCam AF / AF+ intraoral camera.
Page 194 4 Operation Sirona Dental Systems GmbH 4.14 Configuration of the treatment center (setup) Operating Instructions SINIUS / SINIUS CS / SINIUS TS ➢ Change to the next setup program page. 4.14.4.9 Setting the hash key function on the assistant element Hash key...
Page 195 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14 Configuration of the treatment center (setup) ➢ Change to the next setup program page. 4.14.4.12 Linking the tumbler heater to the chair program A setting can be made so that the tumbler heater automatically switches off when the entry/exit position (0) chair program is activated.
Page 196 4 Operation Sirona Dental Systems GmbH 4.14 Configuration of the treatment center (setup) Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14.5 Configure instruments Instruments ➢ Touch the key in the setup program.  The sub-screen opens. Preselecting how instrument settings are to be saved 4.14.5.1...
Page 197 Sirona Dental Systems GmbH 4 Operation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14 Configuration of the treatment center (setup) Showing/hiding the key for the external HF surgical unit 4.14.5.3 External HF surgical units may interfere with the treatment center and external HF surgical SIVISION monitor.
Page 198 4 Operation Sirona Dental Systems GmbH 4.14 Configuration of the treatment center (setup) Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4.14.6 Configuring the network connection Network connection ➢ Touch the key in the setup dialog.Berühren Sie im Setup-Dialog die Taste Netzwerkverbindung.
Page 199 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.1 Basics Care, cleaning and maintenance by the practice team Basics Handling mainly involves the following steps: ● Cleaning ● Disinfection ●...
Page 200 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.1 Basics Operating Instructions SINIUS / SINIUS CS / SINIUS TS Clean the gold trap [ → 235] Cleaning the suction hoses [ → 227] Sterilize/disinfect the suction handpieces [ → 232] Purge the water lines (purge function) [ →...
Page 201 Approved care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona! For a continuously updated list of approved agents, please visit Care, cleaning, and disinfecting agents, with REF number "www.sirona.com"...
Page 202 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.1 Basics Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4. Immerse the tester in the filled container for 30 seconds.  The cardboard disk with the culture medium will now absorb 1 ml of the water sample.
Page 203 Sterilization Sterilization may be done for components that are marked accordingly. Sirona recommends sterilization in a steam sterilizer (autoclave) according to ISO 13060, Class B (e.g., DAC PREMIUM/DAC PROFESSIONAL). The sterilization must be carried out with a multiple fractionated suction system (Class B sterilizer).
Page 204 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.2 Surfaces Operating Instructions SINIUS / SINIUS CS / SINIUS TS Surfaces 5.2.1 Clean/disinfect surfaces The surfaces can be disinfected by spraying and wiping with surface disinfectants. NOTICE Surfaces, medication Drugs have a chemical reaction with the surface of the unit.
Page 205 NOTICE Care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona, see "Care, cleaning, and disinfecting agents" [ → 201]. Clean 1. Actuate the fixed key on the dentist element.
Page 206 Care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona, see "Care, cleaning, and disinfecting agents" [ → 201]. The handles on the dentist and assistant element can be spray, wipe and thermally disinfected.
Page 207 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.2 Surfaces Assistant element ➢ Press the button provided at the end of the handle.  This will release the locking mechanism and the handle can be detached.
Page 208 The tray can be removed to facilitate cleaning or thermal disinfection. NOTICE Care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona, see "Care, cleaning, and disinfecting agents" [ → 201]. Tray, Tray Holder CAUTION If the tray is not locked in place, it can disengage from the tray holder.
Page 209 5.2 Surfaces 5.2.5 Care for, clean, and disinfect upholstery Special care, cleaning, and disinfecting agents are recommended by Sirona for the care, cleaning, and disinfection of the upholstery. NOTICE Care, cleaning, and disinfecting agents, reference Approved care, cleaning, and disinfecting agents Use only agents approved by Sirona for the upholstery, see"Care,...
Page 210 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.2 Surfaces Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.2.7 Thermally disinfecting the instrument holder of the dentist element and sterilizing the silicone mat SINIUS and SINIUS TS dentist elements The instrument holder can be removed for cleaning and thermal disinfection.
Page 211 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.2 Surfaces Removing the holder 1. To do this, remove all instruments one after the other and allow them to hang down in front of the dentist element.
Page 212 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.2 Surfaces Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.2.8 Thermally disinfecting the instrument holder of the assistant element and sterilizing the silicone mat The instrument holder can be removed for cleaning and thermal disinfection.
Page 213 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.3 Instruments and instrument hoses Instruments and instrument hoses 5.3.1 Rinse water lines Microorganisms can grow in the water lines of the treatment center. Use a large amount of water for rinsing the lines prior to starting patient appointments.
Page 214 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.3 Instruments and instrument hoses Operating Instructions SINIUS / SINIUS CS / SINIUS TS Start  The sub-dialog is displayed. Purge function 2. Touch the key. Purge  The screen is displayed on the touchscreen.
Page 215 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.3 Instruments and instrument hoses Error message: Deposit instruments Deposit instruments If the display appears after the purge function has been started, the treatment center has detected that not all of the instruments have been placed in their holders.
Page 216 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.3 Instruments and instrument hoses Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.3.3 Automatically purge water lines (autopurge function) The autopurge function enables automatic purging of all water-carrying...
Page 217 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.3 Instruments and instrument hoses Autopurge function 2. Touch the key. Autopurge  The screen is displayed on the touchscreen.
Page 218 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.3 Instruments and instrument hoses Operating Instructions SINIUS / SINIUS CS / SINIUS TS ✔ Insert instruments in water unit display appears on the touchscreen. 1. Remove the SPRAYVIT sleeves from the valve bodies, the straight and contra-angle handpieces from the water-carrying instruments, and the suction tips from the suction hoses.
Page 219 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.3 Instruments and instrument hoses IMPORTANT Pinching the instrument hoses Be careful not to pinch the instrument hoses when inserting the instruments.
Page 220 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.3 Instruments and instrument hoses Operating Instructions SINIUS / SINIUS CS / SINIUS TS Following the purging process and suction hose cleaning, the display Deposit instruments appears. Displays in the event of incomplete purging process The autopurge program can determine whether the purge process for all instruments and the tumbler filling was completed.
Page 221 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.3 Instruments and instrument hoses  The autopurge procedure is finished. The treatment center is again ready for operation and can be prepared for the practice day.
Page 222 Care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona, see "Care, cleaning, and disinfecting agents" [ → 201]. Disconnect the mucosal electrode from the connection cable. The metal hook can be sterilized, and the connection cable can be disinfected by wiping.
Page 223 Care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona, see "Care, cleaning, and disinfecting agents" [ → 201]. 1. Remove the connection cable of the Mini LED by turning the 134°C 274°F...
Page 224 It can be wipe disinfected. NOTICE Care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona, see "Care, cleaning, and disinfecting agents" [ → 201]. NOTICE Intraoral camera, lens window The lens window is sensitive to scratches.
Page 225 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.3 Instruments and instrument hoses 5.3.5 Changing the cotton wool roll on the high-speed handpiece hose and oil collector Return air containing a small amount of turbine oil is emitted at the unit end of the turbine hose.
Page 226 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.3 Instruments and instrument hoses Operating Instructions SINIUS / SINIUS CS / SINIUS TS Oil collector The SINIUS CS dentist element is also equipped with an oil collector. It is located below the instrument connections and collects any liquids that leak out.
Page 227 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.4 Vacuum system Vacuum system 5.4.1 Cleaning the suction hoses The suction system is exposed daily to secretions, saliva, and blood that contain bacteria.
Page 228 ➢ Do not fill DENTOSEPT P disinfectant into the cleaning agent tank for chemical suction hose cleaning! Use only "Agents for the suction lines" approved by Sirona, see Care, cleaning and disinfecting agents" [ → 201]. 1. Open the maintenance flap on the base of the water unit. The cleaning agent tank for chemical suction hose cleaning is located on the left side.
Page 229 NOTICE Care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona, see "Care, cleaning, and disinfecting agents" [ → 201]. NOTICE Vacuum system, foaming cleaning agents Domestic cleaning agents foam up.
Page 230 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.4 Vacuum system Operating Instructions SINIUS / SINIUS CS / SINIUS TS Cleaning procedure 1. Pour 1 liter of cleaning solution into the cuspidor. 2. Remove the suction hoses from their holders and attach them to the side of the cleaning adapter as simultaneously as possible.
Page 231 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.4 Vacuum system Cleaning the suction system via external container 5.4.2.2 If the treatment center is not equipped with a cuspidor, the suction system must be cleaned using an external container.
Page 232 ➢ Do not under any circumstances use vaseline or silicone greases. ➢ Use only greases approved by Sirona. 1. Pull the handpiece of the spray aspirator, the saliva ejector and, if installed, the surgical suction device off of their suction hoses.
Page 233 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.4 Vacuum system 5.4.4 Cleaning and disinfecting the suction hoses The hoses of the spray aspirator and the saliva ejector as well as the...
Page 234 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.4 Vacuum system Operating Instructions SINIUS / SINIUS CS / SINIUS TS Assembly is performed in reverse order. Grease the O-rings Abefore reconnecting the suction hoses. Lubricants, see "Care, cleaning, and disinfecting agents"...
Page 235 Foaming cleaning agents often cause foam and water to be sucked into the dry suction system. This can cause damage to the suction machine. ➢ Use only care, cleaning and disinfecting agents approved by Sirona, see"Care, cleaning, and disinfecting agents" [ → 201].
Page 236 Use the same agent as for the suction lines. NOTICE Care, cleaning, and disinfecting agents Approved care, cleaning, and disinfecting agents Use only care, cleaning and disinfecting agents approved by Sirona, see "Care, cleaning, and disinfecting agents" [ → 201]. NOTICE Vacuum system, foaming cleaning agents Domestic cleaning agents foam up.
Page 237 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.5 Components of the water unit 2. Fill the cuspidor with the cleaning solution and leave it to take effect.
Page 238 Disinfectants for water lines Approved care, cleaning, and disinfecting agents Use only disinfectants which have been approved for water lines by Sirona for the disinfection system; see "Care, cleaning, and disinfecting agents" [ → 201]. 63 22 726 D3561 D3561.201.01.10.02 01.2016...
Page 239 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.5 Components of the water unit 5.5.5 Change the water and air filters If you notice any changes in media flows, check the water and air filters for permeability.
Page 240 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.5 Components of the water unit Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.5.6 Changing the amalgam rotor Amalgam residues and other solid particles are trapped in the amalgam rotor according to the centrifugal principle.
Page 241 6. Place the container in the special packaging and ship it for disposal or authorize a certified waste management company. Installing the amalgam rotor Use only original Sirona accessories. Never use a used or recycled amalgam rotor. To reorder the amalgam rotor, see "Spare parts and consumables"...
Page 242 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.5 Components of the water unit Operating Instructions SINIUS / SINIUS CS / SINIUS TS 4. Close the flap A. 5. In Germany: Document the exchange of the amalgam rotor in the "D3181 II amalgam separator operation log".
Page 243 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.5 Components of the water unit 5.5.7 Check the message system of the amalgam separator An electronic control monitors the function of the amalgam separator. It detects any mechanical blocking or failure of the drive motor.
Page 244 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.5 Components of the water unit Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.5.8 Emptying the sediment container In addition to other solid particles, a large proportion of the amalgam residues are trapped in the sediment container by gravitational force.
Page 245 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.5 Components of the water unit 2. Hold the sediment container B so that the latching noses of the bayonet catch are positioned transverse to the water unit. Rotate the sediment container B clockwise.
Page 246 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.5 Components of the water unit Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.5.9 Cleaning the filter insert of the wet suction device The automatic separator and amalgam separator or sediment container are not installed in the water unit for wet suction.
Page 247 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.5 Components of the water unit Removing and cleaning the filter insert NOTICE Wet suction The flushing and tumbler filling functions may not be activated when the filter housing is open.
Page 248 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.6 Foot control and connection box Operating Instructions SINIUS / SINIUS CS / SINIUS TS Foot control and connection box 5.6.1 Changing the battery of the wireless foot control The wireless foot control is powered by a battery.
Page 249 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.6 Foot control and connection box Replacing the battery (with battery compartment) 1. If the adjustable feet D sit close to the battery cover E, slide this small part outward.
Page 250 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.6 Foot control and connection box Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.6.2 Changing the fuse of the external device connection The inlet connector remains live even when the power switch is turned off.
Page 251 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.7 Sanitation Sanitation Sanitation effectively combats the reproduction of microorganisms in the water lines. If the disinfection system is set for operation with public drinking water supply, the sanitization must be guided using the sanitization screen, see "Interactively guided sanitation of the treatment center"...
Page 252 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.7 Sanitation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 2. Set all burr drives and the SIROSONIC TL scaler to the maximum water flow rate. max. 3. Put all instruments and suction hoses in place.
Page 253 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.7 Sanitation ● Warning triangle Check instrument or tumbler filling The top row of symbols indicates the instrument positions in the dentist element, while the bottom row indicates the instrument positions in the assistant element.
Page 254 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.7 Sanitation Operating Instructions SINIUS / SINIUS CS / SINIUS TS 2. If the adapters are not yet located in the receptacles of the water unit, insert them into the receptacles until they lock into place. The SPRAYVIT adapters can be inserted only into the two receptacles on the right side of the dentist element with the guide rib facing upward.
Page 255 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.7 Sanitation IMPORTANT Pinching the instrument hoses Be careful not to pinch the instrument hoses when inserting the instruments. If the hoses are pinched, the water flow will be obstructed during purging.
Page 256 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.7 Sanitation Operating Instructions SINIUS / SINIUS CS / SINIUS TS Sanitation phase 3 – Treating water lines with DENTOSEPT P disinfectant The water is pumped out of the water tank of the water unit via the tumbler filler.
Page 257 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.7 Sanitation Error message: Inserting instruments in the water unit If an instrument is accidentally deposited in its holder during the reaction...
Page 258 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.7 Sanitation Operating Instructions SINIUS / SINIUS CS / SINIUS TS Canceling the sanitizing process Sanitation can be canceled during some sanitation phases, e.g. if the treatment center must be switched back on before the 24 hours have Stop expired.
Page 259 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.7 Sanitation 5.7.3 Sanitizing the treatment center manually IMPORTANT The procedure described below regarding manual sanitation is only feasible if the treatment center is operated with a self-sufficient water supply.
Page 260 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.7 Sanitation Operating Instructions SINIUS / SINIUS CS / SINIUS TS Emptying the disinfectant tank and mixing tank Before manual sanitation, the disinfectant tank and mixing tank must be emptied using the SPRAYVIT.
Page 261 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.7 Sanitation 3. Remove the instruments one after the other from the holder and hold them over the cuspidor or over a watertight container with sufficient max.
Page 262 5 Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH 5.7 Sanitation Operating Instructions SINIUS / SINIUS CS / SINIUS TS  The warning triangle with error code 10 ("Flow at the SPRAYVIT M on the dentist element too low") appears again in the status bar of the touchscreen.
Page 263 Sirona Dental Systems GmbH 5 Care, cleaning and maintenance by the practice team Operating Instructions SINIUS / SINIUS CS / SINIUS TS 5.7 Sanitation 5.7.4 Biofilm removal by the service technician If the microbiological test of the water from the treatment center does not...
Page 264 6 Maintenance by the service engineer Sirona Dental Systems GmbH 6.1 Inspection and maintenance Operating Instructions SINIUS / SINIUS CS / SINIUS TS Maintenance by the service engineer Inspection and maintenance In order to ensure the operational safety and reliability of your treatment center and to avoid damage due to natural wear, annual inspection and maintenance must be performed on your treatment center.
Page 265 Sirona Dental Systems GmbH 6 Maintenance by the service engineer Operating Instructions SINIUS / SINIUS CS / SINIUS TS 6.3 Maintenance Manual Maintenance Manual Keep this Maintenance Manual near your treatment center. Any inspection and maintenance work as well as all safety tests are Documentation of the maintenance documented by the service engineer in the Maintenance Manual.
Page 266 7 Malfunctions Sirona Dental Systems GmbH 7.1 Error messages Operating Instructions SINIUS / SINIUS CS / SINIUS TS Malfunctions Error messages Any error states of the treatment center that cannot be immediately recognized by the user and must nevertheless be corrected are displayed on the touchscreen.
Page 267 Sirona Dental Systems GmbH 7 Malfunctions Operating Instructions SINIUS / SINIUS CS / SINIUS TS 7.1 Error messages Code Error Description Measure The flushing tank is empty It was detected that the flushing tank Change the water filter, see had not been filled. Flushing of the “Changing the water and air...
Page 268 7 Malfunctions Sirona Dental Systems GmbH 7.2 Remote diagnosis Operating Instructions SINIUS / SINIUS CS / SINIUS TS Remote diagnosis Functional description With remote diagnosis, you enable the staff of your dental depot or our Customer Service Center, see "Contact data", to connect to the PC of your treatment center.
Page 269 8 Spare parts and consumables Operating Instructions SINIUS / SINIUS CS / SINIUS TS Spare parts and consumables Use only original accessories and original spare parts from Sirona! Please order the materials listed below from a specialized dental dealer. Care, cleaning, and disinfecting...
Page 270 8 Spare parts and consumables Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS Miscellaneous Ball stopper, several devices Ball stopper For sealing the instrument holder of the SINIUS TS and SINIUS dentist elements REF 58 99 575...
Page 271 Sirona Dental Systems GmbH 9 Disposal Operating Instructions SINIUS / SINIUS CS / SINIUS TS Disposal In accordance with Directive 2012/19/EU and national disposal regulations regarding old electrical and electronic devices, please be advised that such items must be disposed of in a special way within the European Union (EU).
Page 272 9 Disposal Sirona Dental Systems GmbH 9.1 Battery disposal Operating Instructions SINIUS / SINIUS CS / SINIUS TS Battery disposal Note for disposal company: Battery in the wireless foot control Prior to disposal, remove the following batteries from the treatment center: ● Battery in the wireless foot control ●...
Page 273 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.1 Fixed keys Overview of all function keys The following contains a brief description of the fixed keys on the dentist For Instructions for Use...
Page 274 10 Overview of all function keys Sirona Dental Systems GmbH 10.1 Fixed keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS Composite function Switches the composite setting for the operating light on/off. This function is required to prevent the premature curing of composite materials.
Page 275 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.1 Fixed keys 10.1.2 Assistant element Tumbler filling Fixed keys on the assistant element on/off Flushing the cuspidor on/off Operating light / Composite function Switches the operating light on, for composite operation, or off.
Page 276 10 Overview of all function keys Sirona Dental Systems GmbH 10.2 Start program Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.2 Start program Chair program S Mouth rinsing position with last-position memory function (programmable) Chair program 0 Entry/exit position (programmable)
Page 277 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.2 Start program Extract residual water Extraction of residual water by wet suction before cleaning the filter Apex measurement with file clamp Activation of the ApexLocator for manual measurement with the file...
Page 278 10 Overview of all function keys Sirona Dental Systems GmbH 10.3 Instrument program Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.3 Instrument program Static speed quick setting keys Setting preset or intermediate speeds BL, BL ISO C and BL Implant motors: min. 90 rpm, max. 40,000 rpm BL ISO E motor: min.
Page 279 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.3 Instrument program Activate preselected coolant The coolants to be available for selection in the Instrument program can be set in the sub-screen of each individual instrument, see below.
Page 280 10 Overview of all function keys Sirona Dental Systems GmbH 10.4 Treatment program Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.4 Treatment program 10.4.1 Treatment selection Assigning the burr drive Display of assigned burr drive The assigned burr drive is marked with an orange circle. Any position marked with a gray circle also can be assigned.
Page 281 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.5 Other dialogs Memory key Stores the settings of an endodontic treatment 10.4.3 Endodontics administration Opening the sub-screen Treatment selection Access from the program.
Page 282 10 Overview of all function keys Sirona Dental Systems GmbH 10.5 Other dialogs Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.5.4 Tumbler filling settings screen Link tumbler filling to mouth rinsing position If the key is highlighted orange, the tumbler filling function will automatically be switched on for the duration of the preset filling time when the mouth rinsing position chair program (S) is activated.
Page 283 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.6 SIVISION program 10.6 SIVISION program 10.6.1 Media Player Start Media Player Media Player is started on the external PC. The keys corresponding to the...
Page 284 10 Overview of all function keys Sirona Dental Systems GmbH 10.6 SIVISION program Operating Instructions SINIUS / SINIUS CS / SINIUS TS Readiness for intraoral X-ray exposure Establishes readiness for an X-ray exposure. A SIDEXIS window then opens where the image type can be selected and the image can be described in detail.
Page 285 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.6 SIVISION program Smooth image To mitigate high-contrast or high-interference effects in images, the contrast between neighboring pixels is reduced or averaged. The overall definition of the image is reduced.
Page 286 10 Overview of all function keys Sirona Dental Systems GmbH 10.7 Setup program Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.7 Setup program 10.7.1 User interface Configuring the user interface User Interface Opens the setup program. Key tone A setting can be made to activate or deactivate an acoustic signal that sounds when the operator touches a key on the touchscreen.
Page 287 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.7 Setup program EasyMode Start instruments are each shown on separate screens. In the program operating mode, the patient chair and instrument functions that are most important for the treatment are shown together on the same screen.
Page 288 10 Overview of all function keys Sirona Dental Systems GmbH 10.7 Setup program Operating Instructions SINIUS / SINIUS CS / SINIUS TS Bell/hash (#) relay The relay of the bell and hash (#) key can be actuated as a push button or as a switch.
Page 289 Sirona Dental Systems GmbH 10 Overview of all function keys Operating Instructions SINIUS / SINIUS CS / SINIUS TS 10.7 Setup program Afterblow After an instrument is put in its holder, the cooling spray remaining in the instrument head or in the tip of the instrument is automatically blown out by briefly activating the chip blower.
Page 290 Index Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS Index Numerical Articulating headrest, 32, 71 Assistant element 4-way foot control plate, 59, 63 Instrument positions, 43 4-way foot switch, 193 Maximum load capacity, 148 Mini LED, 154, 223...
Page 291 Sirona Dental Systems GmbH Index Operating Instructions SINIUS / SINIUS CS / SINIUS TS Canadian Standard Association (CSA), 23 Default settings, 188 Capacitive sensor, 80, 82 Dental unit plugins ApexLocator distance display, 107 Care, cleaning, and disinfecting agents, 201 Dentist element...
Page 292 Index Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS Entry/exit position 0, 60, 72, 149 Foot control Error message, 57 Battery (wireless foot control), 58, 248 Examination light, 170 Cleaning, 212 External device connector, 47...
Page 293 Sirona Dental Systems GmbH Index Operating Instructions SINIUS / SINIUS CS / SINIUS TS Industry Canada, 24 Instruments Initial startup, 49 Clockwise/counterclockwise rotation , 59 Inspection and maintenance, 264 Switch on/control , 59 Installation Book, 264 Intended use, 13 Instrument light, 96...
Page 294 Index Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS Maintenance Certificate, 264 Network configuration, 198 Maintenance deadline, 264 Normen, 23 Maintenance Manual, 264 Maintenance Service, 13 Operating conditions, 26 Maintenance, cleaning, and disinfecting intervals, 199...
Page 295 Sirona Dental Systems GmbH Index Operating Instructions SINIUS / SINIUS CS / SINIUS TS Proportional valve, 119 SIVISION program, 183 Protection class, 25, 25 Sliding track, 80 Purge function, 213 Socket on external device connection, 47 Software version, 12, 188...
Page 296 Index Sirona Dental Systems GmbH Operating Instructions SINIUS / SINIUS CS / SINIUS TS Water connection external device, 47 Water quality, 16 Technical data, 25 Water Tempering, 87 Tempering Water unit Spray, 197 Amalgam separator, 240, 243 SPRAYVIT, 123 Cuspidor, 159...
Page 298 tÉ=êÉëÉêîÉ=íÜÉ=êáÖÜí=íç=ã~âÉ=~åó=~äíÉê~íáçåë=ïÜáÅÜ=ã~ó=ÄÉ=êÉèìáêÉÇ=ÇìÉ=íç=íÉÅÜåáÅ~ä=áãéêçîÉãÉåíëK «=páêçå~=aÉåí~ä=póëíÉãë=dãÄe=OMNS péê~ÅÜÉW ÉåÖäáëÅÜ mêáåíÉÇ=áå=dÉêã~åó aPRSNKOMNKMNKNMKMO MNKOMNS ûKJkêKW=121 758 páêçå~=aÉåí~ä=póëíÉãë=dãÄe `çåí~Åí=áå=íÜÉ=rp^W páêçå~=aÉåí~äI=fåÅK SP=OO=TOS=aPRSN c~Äêáâëíê~≈É=PN QUPR=páêçå~=aêáîÉ lêÇÉê=kç aJSQSOR=_ÉåëÜÉáã `Ü~êäçííÉI=k`=OUOTP dÉêã~åó ïïïKëáêçå~KÅçã...
