- Page 1 ® DakTicker KE-1010 Series GEN II Installation/Operation Manual ED-15353 Rev 1 27 April 2007 Website: www.daktronics.com Tel 866-343-3122 Fax 605-697-4444 331 32 Ave PO Box 5128 Brookings SD 57006...
- Page 2 – graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems – without written permission of the publisher. ® ™ DakTicker and DataStreamer are trademarks of Daktronics, Inc.
-
Page 3: Table Of Contents
Table of Contents Section 1: Introduction......................... 1 Display Overview ........................1 Drawing References........................2 Safety Precautions........................2 Section 2: Mechanical Installation ....................3 Support Structure Design ......................3 Display Mounting ........................4 Ceiling Mount ........................4 Wall Mount........................4 Mounting Multi-section Tickers ..................5 Section 3: Power Installation....................... 7 Power Requirements ......................7 Power Cord - Grounding .......................8 Section 4:... - Page 4 Daktronics Exchange and Repair & Return Program ............25 Exchange Program......................25 Repair & Return Program.....................26 Appendix A: Reference Drawings ....................27 Appendix B: Signal Converter .......................29 Appendix C: Ethernet Configuration.....................35 Table of Contents...
- Page 5 List of Figures Figure 1: KE-1010 Display ........................1 Figure 2: Basic Display Setup.........................1 Figure 3: Front of 16 x 40 Module......................2 Figure 4: Drawing Label..........................2 Figure 5: Mounting Options........................3 Figure 6: Ceiling Mount...........................4 Figure 7: Wall Mount..........................4 Figure 8: Master-Echo Installation Detail....................5 Figure 9: 16 and 24 High DakTickers Power Connection ..............7 Figure 10: 16 High Twin DakTicker Power Connection................7 Figure 11: Power Cord Connection ......................8...
-
Page 7: Introduction
Later sections include diagnostic and parts replacement information, along with the instructions for obtaining parts from Daktronics Customer Service. Definitions of terms are provided in Section 5.3. A DakTicker display is shown in Figure 1. -
Page 8: Drawing References
Read and understand these instructions before installing. • Be sure that the display is properly grounded. • Disconnect power when servicing the display. • Do not modify the display structure or attach any panels or coverings to the display without the written consent of Daktronics. Introduction... -
Page 9: Mechanical Installation
• Daktronics engineering staff must approve any changes made to the displays. If any modifications are made, detailed drawings of the changes must be submitted to Daktronics for evaluation and approval or the warranty may be void. -
Page 10: Display Mounting
Remember to have all mounted displays inspected by a qualified structural engineer. Ceiling Mount Splice bars, provided by Daktronics, have 3/8"-16 UNC holes that can be used to secure the ticker displays from a ceiling or other overhead structure. Use the middle hole only when using the splice bars for mounting. -
Page 11: Mounting Multi-Section Tickers
Display Distance From Display Top To Bottom Bracket Attachment Point KE-1010-16x***-7.62 0’-10 ¼” (260 mm) KE-1010-24x***-7.62 0’-13 ¼” (337 mm) KE-1010-2-16x***-7.62 0’-17 ¼” (438 mm) Mounting Multi-section Tickers The echo sections are shipped without end caps. Remove the left outer end cap from the master ticker and attach it to the left-most echo ticker (refer to Figure 8). -
Page 13: Power Installation
Section 3: Power Installation • Only a qualified individual should terminate power and signal cable at this Daktronics display. • All proposed changes must be approved by Daktronics engineering staff or the warranty will be rendered null and void. Reference Drawings:... -
Page 14: Power Cord - Grounding
Power Specifications for Tickers with Multiple Sections # of Phases 16 and 24 High Twin 16 High Amps Per Line 6.9 (Sum of 3 Sections) 13.8 (Sum of 3 Sections) (100-240VAC) Max Watts 825 Watts (Sum of 3 Sections) 1650 Watts (Sum of 3 Sections) Voltage –... -
Page 15: Signal Installation
Section 4: Signal Installation To display messages on a KE-1010 display, signal is sent from the computer to the ticker via one of two possible network systems: RS-422 or Ethernet. Signal is received by the controller board inside the master section of the ticker. The controller board processes the data and relays it to the shift card. The shift card relays signal to the modules, then the appropriate LEDs create the messages which scroll across the ticker display. - Page 16 RS-422 Pin-outs The controller’s RS-422 jacks have the following pin-outs: INPUT (J4) RJ11 Function N.C. D1OUT-P D1OUT-N D1IN-P D1IN-N N.C. OUTPUT (J5) RJ11 Function N.C. D2OUT-N D2OUT-P D2IN-N D2IN-P N.C. Signal Converter Pin-outs The signal converter has two RS-422 output jacks, with the following pin-out: OUTPUT RJ45 Function...
-
Page 17: Ethernet Connections
Ethernet Connections For DakTickers using an Ethernet system for communication, a network connection will be made from the network hub or switch to the master section. The Cat-5/Cat-5E cable has a typical maximum length of 100 meters (approximately 300 feet). The controller has an onboard Ethernet port with a default address that will need to be reconfigured to an address on the local network. -
Page 18: Section To Section Connections
5. The connection for a master to one echo is shown in Figure 15. Repeat steps 1 though 3 to connect and hang each consecutive echo ticker. All other internal wiring between modules has been done by Daktronics. Figure 15: Master to Echo Connection... -
Page 19: Installation Checklist
4. Turn power ON to the outlet(s). Boot Up Sequence Each time the KE-1010 is powered up, the following information is shown on the display face. The Xs represent numbers that will change according to the specific installation. DakTicker by Daktronics • ED10288 •... -
Page 21: Maintenance & Troubleshooting
Section 5: Maintenance and Troubleshooting This section covers the basic maintenance needed to keep the display operating effectively. Also included are diagnostic and troubleshooting information to pinpoint display problems and provide solutions. Following this are definitions of terms used in the manual. •... -
Page 22: Visual Structural Inspection
Visual Structural Inspection At least once a year, check the display to make sure that the structure and components are in good condition. Inspect the paint and cabinet for corrosion. Make sure that fasteners are tight; if not, tighten or replace as required. Troubleshooting This chart lists some symptoms that may be encountered with the ticker displays. -
Page 23: Definitions
Shift Board: Relays the signal from the controller board to the first module and then between ticker sections. Signal Converter: A Daktronics supplied unit that converts the data from RS-232 to RS-422. The signal converter is connected to the control PC via a straight through serial cable. -
Page 25: Parts Replacement
Shop Drawings..................... Listed in Appendix A Schematics....................Listed in Appendix A Replacement Parts List The following part labeling formats might be found on various Daktronics drawings. These part numbers can be used when requesting replacement parts from Daktronics Customer Service. - Page 26 Consult this list for the Daktronics part number for basic display components. Refer to Section 6.4 for instructions on obtaining parts from Daktronics. Part Description Daktronics Part # Controller Board (16-high, RS-422 Input) 0P-1182-0011 Controller Board (16-high, RS-422 or Ethernet Input)
-
Page 27: Removing The Face Panel
Removing the Face Panel The internal components of the KE-1010 displays may be accessed after the face panel and modules are removed. Refer to Figure 19 for a visual diagram of the steps involved in removing the face panel. Never attempt to lift the entire display or carry the face panel using the suction cups. -
Page 28: Instructions For Replacing Parts
Instructions for Replacing Parts LED Module Replacement To remove and replace an LED module: 1. Disconnect the main supply power to the section being serviced. 2. Remove the face panel as described in Section 6.2. 3. Each module is held in place by 5/16”hex nuts at six locations. -
Page 29: Power Supply Replacement
Power Supply Replacement Power to the LED modules is provided by +5 VDC power supplies. To remove a power supply: 1. Disconnect the main supply power to the section requiring service. 2. Remove the face panel per Section 6.2. 3. Remove the LED module in front of the failed power supply. Refer to the appropriate Component Layout Drawing for the location of the power supplies. -
Page 30: Controller Replacement
Controller Replacement The controller is mounted inside the master display on the back of the cabinet (Figure 24). It is typically located behind the second module from the right end. The display controller receives information from the ticker input, interprets it, and activates the corresponding LEDs. -
Page 31: Controller Address
Program and a Repair & Return Program. Exchange Program Daktronics unique Exchange Program is a quick service for replacing key parts in need of repair. If a part requires repair or replacement, Daktronics sends the customer a replacement, and the customer sends the defective part to Daktronics. This decreases display downtime. -
Page 32: Repair & Return Program
Repair & Return Program For items not subject to exchange, Daktronics offers a Repair & Return Program. To send a part for repair, follow these steps: 1. Call or fax Daktronics Customer Service:... -
Page 33: Appendix A: Reference Drawings
Appendix A: Reference Drawings Drawings are inserted here according to this list, with generic drawings first, followed by Component Layout, Schematic, and Shop Drawings. Under each category, drawings are inserted by matrix size. General Drawings Mounting Drawing, Ceiling, KE-1010-16x***-2.1........... Drawing A-118572 Shop DWG, Mounting, GEN II, Splice Bar, KE-1010 .......... -
Page 57: Appendix B: Signal Converter
Appendix B: Signal Converter Signal Converters and Loop-back Testing for Direct Connections The following table gives the typical state of the signal converter when the LEDs are either on or off. Refer to Figure 25 for an illustration of the signal converter and the location of the various components. -
Page 58: Figure 25: Rs-232 To Rs-422 Signal Converter
RS-422 Wire Signal Converter The following tables list the jack pin outs for a wire signal converter: J4 and J5 – Phoenix OPERATIO RX-P (in) RX-N (in) TX-P (out) TX-N (out) J2 and J3 – RJ/11 OPERATION TX-N (out) Figure 25: RS-232 to RS-422 Signal TX-P (out) Converter RX-N (in) -
Page 59: Figure 26: Flipped Cable (Reversed)
RS-422 Loop-Back Test (Indoor/Outdoor Displays) All indoor displays and some outdoor displays (AE-3010, AF-3010, AF-3020, and X-1000) use RJ11 plugs or connectors. In those cases, a “Network Cable Tester” is provided to conduct the test. The network cable tester is used to test for two things: •... - Page 60 Electrical and Signal Information WARNINGS: • Never install telephone wiring during a lightning storm. • Never touch uninsulated telephone wires or terminals unless the telphone line has been disconnected at the network interface. • Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electrical shock from lightning.
-
Page 61: Mounting Instructions
Mounting Instructions The signal converter can be either wall or table mounted. Do not mount the signal converter from the ceiling or the underside of a table. To mount the signal converter, refer to drawing B-200645. Secure the signal converter using a screw through the mounting holes at the back of the enclosure.
