- Page 1 9049 Tyler Blvd. • Mentor, Ohio 44060 Phone (440) 974-8888 • Fax (440) 974-0165 Toll-Free Fax 800-841-8003 • snowdoggplows.com PATENTS PENDING 16992400 Rev C...
-
Page 2: Table Of Contents
Hydraulic Power Unit ......pg. 13 snowplow. 9. Troubleshooting ........pg. 15-16 CAUTION 10. Snow Plowing Tips ........pg. 16 SnowDogg VX plows are designed for use on trucks intended for plowing. Vehicle application VX Installation/Reference Manual recommendations are based on the following: WARNING •... -
Page 3: Owner's Information
Welcome! Congratulations on your purchase of a SnowDogg plow! The SnowDogg plow by Buyers Products is a heavy-duty, professional grade plow built for your toughest plowing applications. By using this manual for maintenance and safety instructions, you can be sure to optimize the life of your plow. -
Page 4: Snowplow Mounting/Dismounting
Mount Push Bar Jack Plate Chain Lift Lock Pin Lift Frame Stowed Jack Jack Foot Pedal Lock Pin Mount Pin <--- Reciever Hitch Cross Bar Lift Frame Prop MOUNTED PLOW DISMOUNTED PLOW Mount/Dismount Instructions Snowplow Mounting (fig. above) jack may also be stored in the truck for added theft 1. -
Page 5: Mechanical Installation
Installation SnowDogg snowplows are shipped almost completely assembled to minimize the amount of time from box to plowing. The illustrations are representative only and may differ from your hardware. Please see the parts diagrams for specific part numbers. iteM QtY. PaRt no. -
Page 6: Snowplow Assembly
Snowplow Assembly 1. Attach the moldboards to the lift frame kit using the hinge pin, washer, and cotter pin as shown. Check that the moldboards rotate freely around the hinge pin. 2. Install the two cylinder rods to each moldboard half with the clevis pins, washers and cotter pins as shown. -
Page 7: Harness Installation
HARneSS InSTAllATIon The SnowDogg has two separate harnesses for ease of installation and troubleshooting – a control harness and a light harness. They can be mounted separately. In the case of trucks with central hydraulics or exist- ing auxiliary lights, either harness can be omitted without affecting the functionality of the other system. CAUTION Keep all connectors greased with dielectric grease on a regular basis to minimize corrosion &... -
Page 8: Light Harness
small terminal of the MOTOR RELAY. The other is connected directly to vehicle/chassis ground. 5. The large (4 gage) BLACK WIRE on the CONTROL HARNESS must be connected directly to the NEGATIVE (-) battery terminal. A BATTERY TERMINAL ADAPTER may be required. 6. - Page 9 the 16160300 harness. Connect the other wires as shown. It is recommended that heat shrink tubing be put over these connections once complete to seal against corrosion. STANDARD HEADLIGHTS SWITCHED GROUND HEADLIGHTS (SEE APP GUIDE FOR ASSISTANCE) RELAY HARNESS CONTROL HARNESS RELAY HARNESS CONTROL HARNESS WHITE/BLK...
-
Page 10: Removal From Storage
Light aiming Diagram Align with Vehicle Vertical Centerline Centerline Screen Located Ahead of Right Headlight 25' from Headlights High Intensity Zones For Type 2 (Sealed Beam) Headlights on Low Beam Distance Between Headlight Centers SToRAge 1. Before disconnection the plow from your vehicle, fully compress the lift cylinder 2. -
Page 11: Parts Diagram And Bom
Linkage Detail Diagram Lift Frame Diagram 17 19 a-Frame Diagram 16992400 Rev C... -
Page 12: Moldboard
Moldboard Diagram harness Diagram 16992400 Rev C... -
Page 13: Hydraulic Power Unit
hydraulic Power Unit Diagram hydraulic Power Unit Wiring Diagram BLU/WHT BLU/BLK GRN/WHT ORG/WHT BLU/WHT RESERVOIR SIDE MOTOR SIDE BLU/WHT MOTOR BLU/WHT ALL COILS GROUNDED TO NEGATIVE MOTOR TERMINAL 16992400 Rev C... -
Page 14: Parts List
Parts list iteM PaRt no. QtY. DesCRiPtion iteM PaRt no. QtY. DesCRiPtion 1610 FASTENERS / HARDWARE 16120172 Deflector, PS VX85 16101200 Trip Spring 16120178 Deflector, PS VX95 16101210 Spring Mount Eye Bolt Kit (set of 4) 16120270 Clamp Strip, Deflector (VX85) 16102144 Clevis Pin Kit, Trip Angle 16120272... -
Page 15: Troubleshooting
Troubleshooting Symptom Check Result Pump motor not running Check voltage at MOTOR If voltage present - MOTOR is Replace MOTOR when UP, LEFT or RIGHT terminals with UP, LEFT, pressed or RIGHT buttons pressed Check cable continuity If no continuity, check cable, Replace/repair cable or connections between MOTOR RELAY connections, and replace if... -
Page 16: Snow Plowing Tips
9049 Tyler Blvd. • Mentor, Ohio 44060 Phone (440) 974-8888 • Fax (440) 974-0165 Toll-Free Fax 800-841-8003 • snowdoggplows.com Plow won't lift Check voltage at S1A If no voltage present, check Replace/repair cable or connections VALVE coil cable and connections Confirm BLUE wire at S1A VALVE Check S1A VALVE for Poppet must move freely, and...
