- Page 1 9049 Tyler Blvd. • Mentor, Ohio 44060 Phone (440) 974-8888 • Fax (440) 974-0165 Toll-Free Fax 800-841-8003 • Buyersproducts.com PATENTS PENDING 3042233_B...
-
Page 2: Table Of Contents
This manual is for the professional installation of WARNING SnowDogg MDII and VMDII snowplows. Review all ® When using on a vehicle with air bags, DO NOT tamper instructions prior to installation. Installation related with, disable or remove any components related to the failures are not covered by warranty. -
Page 3: Moldboard/Lift Frame Assembly - Mdii
MDII Moldboard/Lift Frame Assembly Fig. 1 LIFT POINTS Bill of Materials ITEM QTY. PART NO. DESCRIPTION 16015004 MDII Lift Frame Assembly 16111638 Light Bar 16160700A Halogen Light Kit (Sold Separately) 16160800 LED Light Kit (Sold Separately) 16111520 Light Bar Fastener Kit 16122100 Blade Guide Kit (Set of 2) 16101110A... -
Page 4: Moldboard/Lift Frame Assembly - Vmdii
VMDII Moldboard/Lift Frame Assembly Fig. 3 LIFT FRAME 4.75 SHIPPING PALLET 4.00 Fig. 4 Bill of Materials 2. Attach both angle cylinders on the LIFT FRAME to ITEM QTY. PART NO. DESCRIPTION the MOLDBOARD as shown using the 7/8” clevis pins 16014004 VMDII Lift Frame Assembly and hardware (6). -
Page 5: Upper Lift Frame Assembly
Drop Foot Deployment For shipping the drop foot is in the transport position and the lift frame/Aframe are in stacking position. For mounting, the drop foot will need to be lowered to the deployed position so that the plow can be mounted. This step requires two people or a winch to rotate the lift frame. -
Page 6: Vehicle Side Installation
Fig. 7 Vehicle Side Installation Plowing is very hard on vehicles. For this reason any vehicle getting a plow mounted to it should be well main- tained. Before installing a plow, and on a regular basis after, have the following systems checked and repaired as necessary: •... - Page 7 Vehicle Side Electrical Installation The SnowDogg plow has separate harnesses for Hydraulic and Lighting for ease of installation and trouble- ® shooting. Either harness can be omitted without affecting the functionality of the other system. CAUTION Keep all connectors greased with dielectric grease on a regular basis to minimize corrosion & potential damage or wear to the pins.
- Page 8 1. Route the CONTROL HARNESS through the truck grill, by the battery, and through the firewall. If no avail- able opening exists, a ø7/8" hole will need to be drilled through the firewall. Check your truck Owner’s Manual for details on where this can be safely done. If the hole is drilled, it is critical that a grommet be used to prevent damage to the wire harness.
- Page 9 Light Harness Installation The light harness is split into a RELAY MODULE and a GRILL HARNESS to allow for easy installation. Connectors have been designed in such a way to prevent installation errors – but be sure to read all instructions. 1.
- Page 10 Switched Ground 16160102 RELAY HARNESS "B" LONG LEAD TO HEADLIGHT ADAPTER TURN SIGNAL CONNECTORS "A" SHORT LEAD TO HEADLIGHT ADAPTER BLACK WIRE TO GROUND 16160104 LIGHT/GRILL HARNESS ORANGE WIRE TO GRILL HARNESS WHITE/BLACK TO CONTROL HARNESS WHITE/BLACK TO ORANGE • Cut open the loom on the GRILL HARNESS near the 8-pin connector to locate the WHITE/BLACK wire. This wire has male and female connectors in line.
- Page 11 Plow Mounting And Checkout Your fully assembled plow is now ready to mount to the vehicle that you have prepared. Mount the plow using the instructions as shown. DROP FOOT CHAIN LIFT CHAIN LIFT JACK DISMOUNT (UP) JACK DISMOUNT (UP) SWITCH MOUNT (DOWN) SWITCH MOUNT (DOWN) DROP FOOT RELEASE...
-
Page 12: Light Aiming
Power on the plow controller and operate the plow through all functions CAUTION For safety reasons, the blade drops very slowly on the plow as shipped. To increase the drop speed of the blade, use a flat blade screwdriver to turn the lowering speed adjustment on the front of the hydraulic power unit counter clockwise. -
Page 13: General Information
NOTE: Snowplow installers must certify that installation conforms to federal motor vehicle safety standards. Your plow and truck are now ready for operation. The hydraulic system has been filled at the factory and should be fully operational. It is possible that agitation due to shipping has introduced some air into the oil. When oper- ating the plow for the first time some oil may exit the vent (by the coils). - Page 14 …damage to vehicle and/or frame of vehicle resulting from plow attachment. WARRANTY PROCEDURE If any part is proven to be defective within that warranty period, Buyers Products will, at its sole discretion, repair or replace said part at its expense FOB Cleveland, OH. Labor will be credited to authorized dealers as determined by published rate charts.
- Page 15 3042233_B...
- Page 16 9049 Tyler Blvd. • Mentor, Ohio 44060 Phone (440) 974-8888 • Fax (440) 974-0165 Toll-Free Fax 800-841-8003 • Buyersproducts.com 3042233_B...
