User's Guide
MSPM0 MCUs Development Guide
This document is a good resource for finding important information about MSPM0
This application note can serve as a reference, a starting guide, a self-learning tool, or an application-
development guide.
1
Overview..................................................................................................................................................................................4
Selection........................................................................................................................................................5
Instructions......................................................................................................................................7
Setup...............................................................................................................................................................7
3.2 MSPM0-SDK Setup...........................................................................................................................................................
3.3 SysConfig Setup..............................................................................................................................................................
3.4 IDE Quick Start................................................................................................................................................................
Instructions.............................................................................................................................................43
4.1 Obtaining a MSPM0 Package..........................................................................................................................................
4.3 Schematic and PCB Attentions........................................................................................................................................
5 Mass Production Instructions.............................................................................................................................................
5.1 Generate Production Image.............................................................................................................................................
5.2 Program Software Tools Quick Start................................................................................................................................
5.3 Program Hardwares Quick Start......................................................................................................................................
Instructions.....................................................................................................................................59
6.1 Quality and Reliability Material Entrance.........................................................................................................................
7 Common Development Questions......................................................................................................................................
7.1 Unlock MCU.....................................................................................................................................................................
Failure..................................................................................................................................................64
7.3 Reprogram with SWD Disabled.......................................................................................................................................
7.4 MCU Performs Differently in Debug and Free Run..........................................................................................................
Password..........................................................................................................................................................65
Questions....................................................................................................................................................67
Questions.................................................................................................................................................67
7.9 Keil Common Questions..................................................................................................................................................
8 Summary...............................................................................................................................................................................
9 Technical Documentation Resources.................................................................................................................................
9.1 Technical Reference Manuals..........................................................................................................................................
9.2
Subsystems......................................................................................................................................................................70
Designs...........................................................................................................................................................71
9.4 Hardware EVM User's Guides.........................................................................................................................................
9.5 Application Notes and Others..........................................................................................................................................
10 Revision History.................................................................................................................................................................
Figure 1-1. MSPM0 Ecosystem...................................................................................................................................................
Figure 2-1. MSPM0 Device List...................................................................................................................................................
Figure 2-2. MSPM0 Important Document List.............................................................................................................................
Figure 2-3. Device Comparison Table.........................................................................................................................................
Figure 2-4. Ordering and Quality Part View.................................................................................................................................
SLAAED1E - JUNE 2023 - REVISED MARCH 2025
Submit Document Feedback
ABSTRACT

Table of Contents

Sysconfig................................................................................................................................46
Guidance.....................................................................................................59
Mode............................................................................................................................67
List of Figures
Copyright © 2025 Texas Instruments Incorporated
Table of Contents
™
microcontrollers (MCUs).
MSPM0 MCUs Development Guide
9
14
20
