PRODUCT NAME: Ceylon Garden Bench
ITEM NUMBER: JC365
ASSEMBLED DIMENSIONS : 36 1/4"H x 60"W x 23 1/2"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 10-1-2020
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN VIETNAM
Page 1 of 4
Advertisement
Related Manuals for Ballard Designs Ceylon JC365
Summary of Contents for Ballard Designs Ceylon JC365
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Ceylon Garden Bench ITEM NUMBER: JC365 ASSEMBLED DIMENSIONS : 36 1/4”H x 60”W x 23 1/2”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete. PRODUCTS ARE NOT INTENDED MADE IN VIETNAM FOR COMMERCIAL USE.
- Page 2 Assemble in location for intended use. REQUIRED TOOLS: DO NOT USE POWER TOOLS FOR ASSEMBLY Allen Wrench (included) Over-tightening will strip wood and/or break parts. Gently Hand Tighten Each Component Together -Two person assembly suggested. Ltr. Qty. Hardware Included Remove all parts, hardware and protective packaging from carton Screw (M7 x 60mm) and carefully arrange on a clean,...
- Page 3 STEP 1: Attach Back (G) to Seat (H) as illustrated using three Screws (A). Fully tighten using Allen Wrench (F). STEP 2: Attach Left Arm Assembly (I) to Seat (H) using three Screws (B) as illustrated. Next, attach Back (G) to Left Arm Assembly using Bolt (C). Fully tighten all using Allen Wrench (F). Customer Service: 800-367-2810 Online: www.ballarddesigns.com Page 3 of 4...
- Page 4 STEP 3: Attach Right Arm Assembly (J) to Seat (H) using three Screws (B) as illustrated. Next, attach Back (G) to Right Arm Assembly using Bolt (C). Fully tighten all using Allen Wrench (F). STEP 4: Gently tip and place Bench on its back as illustrated. Complete attachment of both Arm Assemblies by inserting two Screws (D) into each and fully tightening using Allen Wrench (F).
