Customer Service: 800-367-2810
Online: www.ballarddesigns.com
PRODUCT NAME: Ceylon Loveseat
ITEM NUMBER: SO625
DIMENSIONS OF ITEM ASSEMBLED: 34 3/4"H x 54 1/5"W X 30"D
PRODUCTS ARE NOT INTENDED
MADE IN VIETNAM
FOR COMMERCIAL USE.
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ceylon Loveseat SO625 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ballard Designs Ceylon Loveseat SO625

  • Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Ceylon Loveseat ITEM NUMBER: SO625 DIMENSIONS OF ITEM ASSEMBLED: 34 3/4”H x 54 1/5”W X 30”D PRODUCTS ARE NOT INTENDED MADE IN VIETNAM FOR COMMERCIAL USE. Page 1 of 5...
  • Page 2 Ltr. Qty. Hardware Included 50mm Allen Screws 60mm Allen Screws TOOLS NEEDED: 2 Person assembly required. 90mm Allen Screws 70mm Allen Screws Screw Plugs Allen Wrench Ltr. Qty. Components Seat Wood Bolt Right Leg Left Leg Seat Back Back Cushions Seat Cushions Customer Service: 800-367-2810 Page 2 of 5...
  • Page 3 STEP 1: Attach the Leg (H) to the Seat (G) using the Allen Wrench (F) and 2 50mm Allen Screws (A). STEP 2: Attach the Wood Bolt (I) to the Leg (H) and Seat (G) using the Allen Wrench and 3 60mm Allen Screws (B).
  • Page 4 STEP 4: Use 4 90mm Allen Screws (C) and the Allen Wrench (F) to attach the Seat Back (L) to the Left (J) and Right (K) Leg. Then use 4 70mm Allen Screws (D) and the Allen Wrench (F) to attach the Seat Back (L) and Seat (G). STEP 5: Insert the Screw Plugs (E) in the Screw Holes1 Customer Service: 800-367-2810 Page 4 of 5...
  • Page 5 STEP 6: Put the Seat Cushions (N) on the Seat (G) and then put the Back Cushions (M) on. Clean & Care Please refer to the care instructions on the hang tag. Customer Service: 800-367-2810 Page 5 of 5 Online: www.ballarddesigns.com...
