PRODUCT NAME: Sunday Daybed with Cushion and Canopy
ITEM NUMBER: JM100
ASSEMBLED DIMENSIONS: 76"H x 82"W x 43 1/3"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 11-11-2020
DO NOT USE POWER TOOLS FOR ASSEMBLY
Over-tightening will strip wood and/or break parts.
Gently Hand Tighten Each Component Together
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN VIETNAM
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for Ballard Designs JM100
Summary of Contents for Ballard Designs JM100
- Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Sunday Daybed with Cushion and Canopy ITEM NUMBER: JM100 ASSEMBLED DIMENSIONS: 76”H x 82”W x 43 1/3”D DO NOT USE POWER TOOLS FOR ASSEMBLY Over-tightening will strip wood and/or break parts. Gently Hand Tighten Each Component Together Prevent accidentally discarding small parts or hardware.
- Page 2 Assemble in location for intended use. Ltr. Qty. Hardware Included REQUIRED TOOLS: Extra Large Screws (100mm) Allen Wrench (included), Rubber Mallet Large Screws (90mm) Medium Screws (50mm) -Assembly requires 2 people Small Screws (30mm) Connector Brackets DO NOT USE POWER TOOLS FOR ASSEMBLY Wooden Plugs Gently Hand Tighten...
- Page 3 Assemble in location for intended use. STEP 1: Orient Seat (H) and Back (I) as illustrated then insert Extra Large Screws (A) through Seat and into Back. Fully tighten using Allen Wrench (G). STEP 2: Orient and attach Left Assembly (J) to Seat/Back. Insert Large Screws (B) as illustrated and tighten using Allen Wrench (G).
- Page 4 STEP 3: Orient and attach Right Assembly (K) to Seat/Back. Insert Large Screws (B) as illustrated and tighten using Allen Wrench (G). Further secure using Medium Screws (C) inserted and tightened as illustrated. Next, attach Cross Bar (L) as illustrated and secure using Large Screw (B). Tighten using Allen Wrench (G).
- Page 5 STEP 5: COVER VISIBLE HOLES. Insert a Wooden Plug (F) into each hole on side of Right Arm (I) and Left Arm (J). NOTE: A Rubber Mallet may be required to gently tap and seat Plug. STEP 6: Insert Panel Rods (M) into pockets on edge of each Side Panel (N) (Fig. 1) then fit Rod ends into LOWER notches on top of Left and Right Assemblies (J,K) (Fig.
- Page 6 STEP 7: Insert remaining Panel Rods (M) into end pockets on Top Panel (O) (Fig. 1) then fit Rod ends into UPPER notches on top of Left and Right Assemblies (J,K) (Fig. 2) Fig. 1 Fig. 2 Hang Top Panel in UPPER NOTCH STEP 8: Place Cushion (P) onto Daybed.
