PRODUCT NAME: BW Kent Arbor
ITEM NUMBER: JM113
ASSEMBLED DIMENSIONS : 108"H x 92"W x 62"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 1-11-2022
DO NOT USE POWER TOOLS FOR ASSEMBLY
Over-tightening will strip wood and/or break parts.
Gently Hand Tighten Hardware and Components
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN VIETNAM
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BUNNY WILLIAMS JM113 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ballard Designs BUNNY WILLIAMS JM113

  • Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: BW Kent Arbor ITEM NUMBER: JM113 ASSEMBLED DIMENSIONS : 108”H x 92”W x 62”D DO NOT USE POWER TOOLS FOR ASSEMBLY Over-tightening will strip wood and/or break parts. Gently Hand Tighten Hardware and Components Prevent accidentally discarding small parts or hardware.
  • Page 2 Assemble in location for intended use. Ltr. Qty. Hardware Included REQUIRED TOOLS: Allen Screw Allen Wrench (included) M7 x 70mm -Two person assembly suggested. Allen Bolt Remove all parts, hardware and M6 x 55mm protective packaging from carton Allen Bolt and carefully arrange on a clean, M6 x 40mm level, padded surface.
  • Page 3 Assemble in location for intended use. STEP 1: Invert Arched Top (F) onto a level, padded surface and attach a Top Bracket (G) to each corner using four Allen Screws (A) as illustrated. Hand tighten until secured. (A) x 4 NOTICE: Steps 2 through 5 are repeated to create both LEFT and RIGHT Side Assemblies.
  • Page 4 Assemble in location for intended use. STEP 3: Place a Side Panel (M) onto a level, padded surface then orient Left Panel (H) as illustrated. Use four Allen Bolts (C) in the middle section and one Allen Bolt (B) at each end (top and bottom). Fully tighten all Bolts using Allen Wrench (E).
  • Page 5 STEP 5: Complete Side Assembly by adding Seat (O) and securing with six Allen Bolts (B), three on each side as illustrated. Add Top Side (N) and secure using two Allen Screws (D) on each side as illustrated. Fully tighten all Bolts and Screws using Allen Wrench (E). REPEAT STEPS 2 THROUGH 5 TO CREATE REMAINING SIDE ASSEMBLY.
