Pulsar DC/DC52115 Quick Start Manual

 The step up DC/DC converter
 Example of use: increasing voltage from 12 V to 52 V DC
power System for PoE switches
 The input voltage range: 9,528 V DC
 The output voltage range: 52 V DC
 The maximum load current 1,15 A (60 W)
 The PSU technical output indicating converter failure
triggered by:
 Short-circuit of the output
 Output overload
DC/DC 52V/1,15A Step up DC/DC converter
The module's features:
Example of use of the DC/DC52115 step up converter.
Schematic diagram of the converter operation.
DC/DC52115
v.1.0
Edition: 1 from 20.11.2020
Supercedes the edition: --------------
 Protections:
 Short-circuit protection SCP
 Overload protection OLP
 High efficiency: 97%
 Optical LED indication
 Warranty – 2 years from the production date
 Mounting:
 Mounting strip with adhesive tape
 Mounting screws
