IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: _____________________
Installation & Operation Manual
Gas Fired
Full Jacket Steam Tilting Kettle
GLT-40FL
GLT-40FL
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
servicing this equipment.
CROWN FOOD SERVICE EQUIPMENT
A Middleby Company
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
www.crownsteamgroup.com
GAS FIRED FULL JACKET STEAM
M
R
ANUAL 10280-CW
EV 0 (10/24)
TILTING KETTLE
M
S
CO
ANUAL
ECTION
Advertisement
Table of Contents
Related Manuals for Middleby CROWN GLT-40FL
Summary of Contents for Middleby CROWN GLT-40FL
- Page 1 Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. CROWN FOOD SERVICE EQUIPMENT A Middleby Company 70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9 Telephone: 919-762-1000 www.crownsteamgroup.com...
-
Page 2: Safety Precautions
Safety Precautions Gas Fired Full Jacket Steam Tilting Kettle SAFETY PRECAUTIONS Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions. The following symbols, found throughout this manual, alert you to potentially dangerous conditions to the operator, service personnel, or to the equipment. -
Page 3: Table Of Contents
Gas Fired Full Jacket Steam Tilting Kettle Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Important Notes For Installation and Operation ..............2 Service Connections ......................4 Installation ..........................5 Operation ..........................8 Cleaning ..........................11 Maintenance ......................... -
Page 4: Service Connections
Service Connections Gas Fired Full Jacket Steam Tilting Kettle Service Connections SERVICE CONNECTIONS – GAS CONNECTION: Supply Gas through 3/4” pipe. A gas shut off valve must be installed in supply piping convenient and adjacent to appliance. – ELECTRICAL CONNECTION : Unless otherwise specified, field wire electrical connection to be 120 volts, 60 Hz, 1 phase with grounding wire. Unit furnished with 6’... -
Page 5: Installation
Gas Fired Full Jacket Steam Tilting Kettle Installation Installation Unpacking IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Immediately after unpacking, check for possible shipping damage. If the tilting braising pan is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Before installing, verify that the electrical service agrees with the specifications on the rating plate located on the left side panel as you face the front of the braising pan. -
Page 6: Water Connection
Installation Gas Fired Full Jacket Steam Tilting Kettle Purge the supply line to clean out any dust, dirt, or other foreign matter before connecting the line to the unit. It is recommended that an individual manual shut off valve be installed in the gas supply line to the unit. Use pipe joint compound which is suitable for use with LP gas on all threaded connections. -
Page 7: Performance Check
Gas Fired Full Jacket Steam Tilting Kettle Installation 2. 208/240 VAC - 60 Hz - Single and Three Phase Units with this electrical rating are factory equipped with a transformer. To connect supply wires, remove cover from right console. Route supply wires and ground wire through the hole in the console with a strain relief fitting. Connect wires to the terminal block in the rear of the right console. -
Page 8: Operation
Operation Gas Fired Full Jacket Steam Tilting Kettle Operation NOTICE Contact the factory, the factory representative or a local service company to perform maintenance and repairs should the appliance malfunction. CAUTION If you smell gas during the lighting procedure, immediately shut off the gas supply until the leak has been corrected. WARNING In the event of main burner ignition failure, a 5 minute purge period must be observed prior to re-establishing ignition source. -
Page 9: Daily Shutdown
Gas Fired Full Jacket Steam Tilting Kettle Operation Daily Shutdown 1. Turn power switch “OFF.” 2. Turn thermostat “OFF.” Complete Shutdown 1. Turn power switch “OFF.” 2. Turn thermostat “OFF”. 3. Turn power supply to unit “OFF”. 4. Remove front access panel on left side and turn dial on combination valve to “OFF”. 5. - Page 10 Operation Gas Fired Full Jacket Steam Tilting Kettle End User Tips For easier cleaning add cold water to the kettle immediately after removing contents. When preparing foods containing vinegar or tomatoes, or those which have a high salt content, clean the kettle immediately after using to prevent pitting.
-
Page 11: Cleaning
Gas Fired Full Jacket Steam Tilting Kettle Cleaning Cleaning Cleaning Instructions WARNING Disconnect the power supply to the appliance before cleaning or servicing. WARNING Never spray water into electric controls or components! CAUTION The equipment and its parts are hot. Use care when operating, cleaning and servicing. CAUTION Do not use cleaning agents that are corrosive. - Page 12 Cleaning Gas Fired Full Jacket Steam Tilting Kettle Dairy Draw-Off Valve Cleaning 1. Remove the plug by first removing the handle, then turn the plug to line up with the pin and pull with both hands. It is important to use both hands because the plug is heavy. 2.
-
Page 13: Stainless Steel
Gas Fired Full Jacket Steam Tilting Kettle Cleaning Stainless Steel To remove normal dirt, grease or product residue from stainless steel, use ordinary soap and water (with or without detergent) applied with a sponge or cloth. Dry thoroughly with a clean cloth. Never use vinegar or any other corrosive cleaner. -
Page 14: Maintenance
Maintenance Gas Fired Full Jacket Steam Tilting Kettle Maintenance NOTICE Contact the factory, the factory representative or a local service company to perform maintenance and repairs. WARNING Disconnect the power supply to the appliance before cleaning or servicing. Daily 1. Wash exposed cleanable areas. Monthly 1. -
Page 15: Pressure Switch
Gas Fired Full Jacket Steam Tilting Kettle Maintenance Thermostat The thermostat adjustment should not be changed. Check the following before changing the thermostat. 1. With kettle cold, the pressure on the pressure gauge should read in the green vacuum zone (25 to 30 inches Hg vacuum). -
Page 16: For Reference
Maintenance Gas Fired Full Jacket Steam Tilting Kettle Adding Water (Low Water Light Comes On.) It may be necessary to replenish water in the jacket when the low water indicator comes on. Do so as follows: 1. Unit should be completely cold and off. 2. -
Page 17: Troubleshooting
Gas Fired Full Jacket Steam Tilting Kettle Troubleshooting Troubleshooting Problem Look For Motor will not run. • No current. Check that power is being supplied to the unit. • Defective thermostat or pressure switch. • Defective motor. • Motor overload out. •... -
Page 18: Appendix A, Material Safety Data Sheet
Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24) - Page 19 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24) PAGE OF 28...
- Page 20 Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24)
- Page 21 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24) PAGE OF 28...
- Page 22 Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24)
- Page 23 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24) PAGE OF 28...
- Page 24 Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24)
- Page 25 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24) PAGE OF 28...
- Page 26 Material Safety Data Sheets Gas Fired Full Jacket Steam Tilting Kettle PAGE OF 28 INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24)
- Page 27 Gas Fired Full Jacket Steam Tilting Kettle Material Safety Data Sheets INSTALLATION & OPERATION MANUAL 10280 REV 0 (10/24) PAGE OF 28...
- Page 28 When service is needed, contact a Crown Steam Authorized Service Agency, or your dealer. To avoid confusion, always refer to the model number, serial number, and type of your appliance. CROWN FOOD SERVICE EQUIPMENT A Middleby Company 70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9 Telephone: 919-762-1000 www.crownsteamgroup.com...
