CW-3Ai, CW-3Ai-KFC1, CW-3Ai-KFC2 & W-43Vi
WARNING: California Residents Only. This product can expose you to chemicals including chromium
which is known to the State of California to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65Warnings.ca.gov.
WARNING: Improper installation, operation, service or maintenance can cause property
damage, injury or death. Read and understand these instructions thoroughly before
positioning, installing, maintaining or servicing this equipment.
This manual includes material related to installation, use , cleaning, and care. Exploded view[s], as well as any
available parts list[s] and wiring diagram[s] pertaining to the unit[s] covered by this manual are also included.
This manual must be read and understood by all persons using or installing this appliance. Contact your APW
Wyott dealer if you have any questions concerning installation, use, or maintenance of this equipment.
DO NOT DISCARD THIS MANUAL.
APW Wyott Food Service Equipment Company is a wholly owned subsidiary of Standex International Corporation.
(800) 527-2100
COUNTERTOP FULL SIZE 12 X 27 WARMER
\Click & Mortar Program\APW_Star_
Toastmaster_Wells_Click-Brick_
Dealer-Kits
MODEL #CW-3Ai Shown
APW Wyott Food Service Equipment Company
265 Hobson St. • Smithville, TN 37166
is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved.
DESIGNED SMART.
BUILT SOLID.
MODELS:
OWNERS MANUAL
2M-Z24873 REV - (02-22)
2M-Z24873 REV - (02-22)
®
apwwyott.com
Advertisement
Table of Contents
Related Manuals for Middleby APW Wyott CW-3Ai
Summary of Contents for Middleby APW Wyott CW-3Ai
- Page 1 265 Hobson St. • Smithville, TN 37166 APW Wyott Food Service Equipment Company is a wholly owned subsidiary of Standex International Corporation. (800) 527-2100 apwwyott.com is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved. 2M-Z24873 REV - (02-22)
-
Page 2: General Installation
TABLE OF CONTENTS ITEM PAGE ITEM PAGE Owner’s Information ..... . 2 Service Information ..... . . 3 General Installation . -
Page 3: Specifications
SPECIFICATIONS Installation: Follow General Operating Instructions on previous page. MODEL VOLTAGE WATTAGE AMPS 3PH_L1 CW-3Ai 208/240 1200/1600 5.7/6.6 CW-3Ai-120 1800 15.0 CW-3Ai-KFC1 1500 12.5 CW-3Ai-KFC2 208/240 1200/1600 5.7/6.6 W-43Vi 208/240 1200/1600 5.7/6.6 W-43Vi-120 1500 12.5 Operation: Infinite Control 1. Turn infinite control to “HI” position and preheat for approximately 10 minutes. 2. -
Page 4: Street Address
2. Phone number of person calling. 3. Business name. 4. Street address. 5. City, State, Zip. 6. Model Number (from serial plate). 7. Serial Number (from serial plate). 8. Date purchased (if serial number indicates date of manufacture is over 13 months old you will be asked to supply proof of purchase) 9. -
Page 5: Indicator Light
WIRING DIAGRAM – CW-3Ai WIRE NUT HEATING ELEMENT INDICATOR LIGHT WIRE NUT THERMOSTAT WIRING DIAGRAM- CW-3Ai-KFC1, CW-3Ai-KFC2 CORD HEATING ELEMENT BLACK WIRE 12.00 TOP FRONT OF UNIT INDICATOR TOGGLE SWITCH LIGHT THERMOSTAT SWITCH KEY SLOT LOCATED AT BOTTOM BLACK WIRE 15.00 BOTTOM FRONT OF UNIT... - Page 6 WIRING DIAGRAM – W-43Vi INDICATOR LIGHT INFINITE CONTROL HEATING ELEMENT LIMITING THERMOSTAT...
- Page 7 EXPLODED VIEW- CW-3Ai...
- Page 8 PARTS LIST- CW-3Ai * DENOTES PARTS NOT DEPICTED IN EXPLODED VIEW ITEM # PART # DESCRIPTION D8-WM0001 WELL PAN ASY 12X27 W/W D8-WM0002 WRAP, CW-3Ai/43Vi WELDASY D8-21872017 SIDE MOUNT D8-21872015 ELEMENT COVER,CW 12X27 2N-55441 CW-3Ai & CW-3Ai-KFC2 ELEMENT; 208/240V 1200/1600 2N-55466 CW-3Ai-120 ELEMENT;...
- Page 9 PARTS LIST- W-43Vi Item # Part # Title D8-WM0001 WELL PAN ASY 12X27 W/STUDS D8-WM0002 WRAP, CW-3Ai/43Vi WELDASY D8-21872017 SIDE MOUNT D8-21872014 ELEMENT COVER 2N-55441 W-43Vi ELEMENT, 1200/1600W 208/240V 2N-56322 W-43Vi-120 ELEMENT; 115V 1500W MIL W D8-21872013 ELEMENT HOLDER 2T-69106 THERMOSTAT, LIMITING 345 F D8-57607 COVER, BOTTOM FOOT ASSY.
- Page 10 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or Parts, this information is required. Model Number Serial Number Date Purchased Notes...
- Page 11 LIMITED EQUIPMENT WARRANTY WARRANTY EXCLUSIONS APW warrants to the original purchaser of new APW's products to be THE FOLLOWING WILL NOT BE COVERED UNDER WARRANTY. free from defects in material or workmanship, under normal and proper APWs’ sole obligation under this warranty is limited to either repair use and maintenance service as specified by APW and upon proper or replacement parts, subject to the additional limitations installation and start-up in accordance with the instructions...
- Page 12 Printed in the U.S.A. • 2M-Z24873 • Rev - (02-22) Specifications are subject to change without notice. 265 Hobson St. • Smithville, TN 37166 is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved. Telephone: (800) 527-2100...
