W i r e l e s s H o m e L i g h t i n g C o n t r o l
RA-SVC, RB-SVC
12 V
50 / 60 Hz 100 mA
Setup and Installation Guide For a
RadioRA
Sivoia QED
Control
®
TM
A Comprehensive Step-by-Step Guide for Installing, Programming,
and Operating the Lutron RadioRA
Sivoia QED
Control
®
TM
Note: Please leave this manual with homeowner.
English
P/N 044-025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RadioRA RA-SVC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lutron Electronics RadioRA RA-SVC

Summary of Contents for Lutron Electronics RadioRA RA-SVC

  • Page 1 W i r e l e s s H o m e L i g h t i n g C o n t r o l RA-SVC, RB-SVC 12 V 50 / 60 Hz 100 mA Setup and Installation Guide For a RadioRA Sivoia QED Control...

  • Page 2: Important Application Notes

    • Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by Lutron Electronics Co. could void the user’s authority to operate this equipment. Operation is subject to the following: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Table Of Contents

    Table of Contents Section 1 - Overview Operation RadioRA Sivoia QED Control ......................4 Section 2 - Installation Installing a RadioRA Sivoia QED Control Installation ............................5 Section 3 - Start-Up Adding a RadioRA Sivoia QED Control Activating the Control ........................7 Changing Preset Levels ........................9 Master Control Button Programming Assigning a RadioRA Sivoia QED Control to Master Control Buttons ........10 Setting RadioRA Sivoia QED Presets for Master Control Buttons ..........12...

  • Page 4: Operation

    Operation RadioRA Sivoia QED Control Open Button Sivoia QED motorized window treatment(s) will open. Preset Buttons Sivoia QED motorized window treatment(s) will go to the preset position. Close Button Sivoia QED motorized window treatment(s) will close. Raise/Lower Buttons Sivoia QED motorized window treatment(s) will raise or lower to desired position.

  • Page 5: Installing A Radiora Sivoia Qed Control

    Installing a RadioRA Sivoia QED Control Installation Read all instructions completely before installation. Step 1 Find a suitable location for the Wiring Diagram RadioRA Sivoia QED Control The RadioRA Sivoia QED Control must be Sivoia QED Electronic Drive Unit (EDU) located within 30 feet of an RF Signal Repeater.
  • Page 6 Installing a RadioRA Sivoia QED Control Step 4 Step 6 Mount Control Test RadioRA Sivoia QED Control operation Attach wallplate adapter. Mount and align After setting the limits for each Sivoia QED control. Snap on Claro wallplate (purchased ® Electronic Drive Unit (see the Sivoia QED separately).

  • Page 7: Adding A Radiora Sivoia Qed Control

    Adding a RadioRA Sivoia QED Control Activating the Control The RadioRA Sivoia QED Control counts toward the RadioRA System maximum of 32 dimmers or local controls. Step 2 Step 1 Activate RadioRA Sivoia QED Begin Control activation Control Press and hold the ACTIVATE CONTROLS Press any button.
  • Page 8 Adding a RadioRA Sivoia QED Control Step 3 Step 4 Complete Control activation Verify that RadioRA Sivoia Control has been Press and hold the ACTIVATE CONTROLS activated button on any Repeater until the green ACTIVATE CONTROLS LED turns OFF Press and hold the FLASH button on any (approximately 3 seconds).

  • Page 9: Changing Preset Levels

    Adding a RadioRA Sivoia QED Control Changing Preset Levels Presets 1, 2, and 3 come preprogrammed to 75% open, 50% open, and 25% open respectively. To change them, complete the following steps. Step 1 Step 2 Begin programming presets Set preset position On the RadioRA Sivoia QED Control, use the Press and hold the preset button you wish to raise or lower buttons to adjust your window...

  • Page 10: Master Control Button Programming

    Master Control Button Programming Assigning a RadioRA Sivoia QED Control to Master Control Buttons Step 1 Step 3 Begin assigning RadioRA Assign a RadioRA Sivoia ® Sivoia QED Controls to Control to the button ROOM/SCENE buttons Assign RadioRA Sivoia QED Controls to the Master Control button by pressing the Open Simultaneously press and hold the 2nd and button.
  • Page 11 Master Control Button Programming Step 4 Step 5 Select next button Complete assigning RadioRA Sivoia QED Controls To assign a RadioRA Sivoia QED Control to Simultaneously press and hold the 2nd and another Master Control button, press and 4th buttons in the right most column of the release that button.

  • Page 12: Setting Radiora Sivoia Qed Presets For Master Control Buttons

    Master Control Button Programming Setting Sivoia QED Presets for Master Control Buttons Step 1 Step 3 Begin setting presets Select desired Sivoia QED preset Simultaneously press the 1st and 5th buttons Press the desired preset button on the in the right most column of the Master Control assigned RadioRA Sivoia QED Control.
  • Page 13 Master Control Button Programming Step 4 Step 5 Select next button Complete setting shade presets To set the preset level for another Master Simultaneously press the 1st and 5th buttons Control button, press and release that button. in the right most column until all LEDs begin Its LEDs will begin to blink.

  • Page 14: Additional Features

    Additional Features Setting a SCENE button as a Stop button This feature allows you to stop moving window treatments from a Master Control. Step 1 Step 3 Assign RadioRA Sivoia QED Select Stop button Control to Stop Button Press and release the button that you want to Assign the RadioRA Sivoia QED Control to program.
  • Page 15 Additional Features Step 4 Step 5 Set button as Stop Select next button To set another Master Control button as a Press and hold both the raise and lower Stop button, press and release that button. Its buttons together on the RadioRA Sivoia QED Control for approximately 3 seconds.

  • Page 16: Adding A Radiora Sivoia Qed Control To An All On Or All Off Button

    Additional Features Adding a RadioRA Sivoia QED Control to an ALL ON or ALL OFF button Step 1 Step 2 Begin the ALL ON or ALL OFF Press the ALL ON or ALL OFF button programming button Press the ALL ON or ALL OFF button on the On the Master Control you want to program, Master Control you are programming.
  • Page 17 Additional Features Step 3 Step 4 Add the RadioRA Sivoia QED Complete the ALL ON or ALL Control to the button OFF button programming Simultaneously press and hold the 2nd and Press the Open button on the RadioRA Sivoia 4th buttons in the right most column until all QED Control you want to add.

  • Page 18: Default Settings

    Default Settings Changing Default Settings Changing the default settings will allow you to choose whether the window treatments will remain unchanged when a SCENE is being raised, lowered, or toggled to OFF. Local presets may also be locked, so that they are not accidentally changed.
  • Page 19 Default Settings Step 3 Exit Default Settings Mode On the RadioRA Sivoia QED Control, press and hold the Open, Raise, and Lower buttons until the LEDs flutter (approximately 3 seconds). Setup Guide for the RadioRA Sivoia QED Control ®...

  • Page 20: Troubleshooting Guide

    Troubleshooting Guide Proper operation of the RadioRA Wireless Central Home Lighting Control System is based upon a complex series of radio frequency (RF) communications between system components. As such, it is highly dependent upon proper system installation and programming of controls. If you experience difficulties programming or operating your RadioRA system, please refer to this guide.
  • Page 21 Troubleshooting Guide Symptom Possible Cause Remedy The RadioRA Sivoia QED The Raise and Lower buttons are Double tap the ROOM/SCENE button that Control does not respond when not set to affect the you wish to control with the Raise and the Raise or Lower button on a ROOM/SCENE button you wish to Lower buttons.

  • Page 22: Returning To Default Factory Settings

    Returning to Default Factory Settings RadioRA Sivoia QED Control Returning a RadioRA Sivoia QED Control to Default Factory Settings will permanently delete all current programming information. Do not do this unless you are sure that it is necessary. For more information call the Lutron Technical Support Center at +1-800-523-9466.
  • Page 23 Notes Setup Guide for the RadioRA Sivoia QED Control ®...
  • Page 24 Lutron Electronics Co., Inc. year after purchase. For warranty service, return unit 7200 Suter Road to place of purchase or mail to Lutron Electronics Co., Coopersburg, PA 18036-1299 U.S.A. Inc. at 7200 Suter Rd., Coopersburg, PA 18036-1299, TOLL FREE: +1-800-523-9466 (U.S.A., Canada, and postage pre-paid.
