  • Page 2 • RIGOL products are covered by P.R.C. and foreign patents, issued and pending. • RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at the company's sole decision. • Information in this publication replaces all previously released materials.

  • Page 3: Table Of Contents

    5.3.4 Test Record Form ........................18 5.4 Bandwidth Test ...........................19 5.4.1 Specification ...........................19 5.4.2 Test Connection Diagram ....................19 5.4.3 Test Procedures ........................19 5.4.4 Test Record Form ........................21 5.5 Timebase Accuracy Test ........................5.5.1 Specification ...........................21 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 4 5.5.2 Test Connection Diagram ....................21 5.5.3 Test Procedures ........................22 5.5.4 Test Record Form ........................23 6 Appendix: Test Record Form ..................24 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 5: List Of Tables

    List of Tables Table 2.1 Specifications ......................Table 5.1 Test Devices ......................11 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 6 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 7: Safety Requirement

    Do Not Insert Objects into the Air Outlet. Do not insert objects into the air outlet, as doing so may cause damage to the instrument. • Use Proper Fuse. Please use the specified fuses. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 8 Do Not Operate With Suspected Failures. If you suspect that any damage may occur to the instrument, have it inspected by RIGOL authorized personnel before further operations. Any maintenance, adjustment or replacement especially to circuits or accessories must be performed by RIGOL authorized personnel.

  • Page 9: Safety Notices And Symbols

    It calls attention to an operation, if not correctly performed, could result in damage to the product or other devices connected to the product. Safety Symbols on the Product: Hazardous Safety Warning Protective Earth Chassis Ground Test Ground Voltage Terminal Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 10: Specifications

    Specifications This chapter lists the technical specifications of the DS80000 series oscilloscope. The maximum sample rate of DS80000 series digital oscilloscope is 40 GSa/s, the highest bandwidth is 13 GHz. RIGOL's brand new self-developed core module guarantees the specifications to reach the advanced level in the industry, with up to 4 Gpts memory depth and 8-16 bits adjustable resolution.
  • Page 11 Specifications Overview of the DS80000 Series Technical Specifications Sampling Mode Real-time Sampling Max. Analog Channel Sample 40 GSa/s Rate Standard: 500 Mpts Max. Memory Depth Option: 4 Gpts Max. Waveform >500,000 wfms/s Capture Rate Vertical Resolution 8-16 bits (selectable) ± 2% Full Scale...

  • Page 12: Document Overview

    RIGOL DS80000 series digital oscilloscope. For the operation methods mentioned in the test procedures, refer to User Guide of this product. http:// For the latest version of this manual, download it from the official website of RIGOL ( www.rigol.com Publication Number...
  • Page 13 Full-channel : 40 DS81304 13 GHz GSa/s Full-channel : 40 DS80804 8 GHz GSa/s NOTE [1]: Whatever one or multiple channels are enabled, the maximum specifications of the instrument can be reached. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 14: Overview

    Make sure that the oscilloscope has been warmed up or operating for more than 30 minutes before the self-calibration. 1. Disconnect all the input channels. 2. In "Utility" menu, click or tap SelfCal, the following self-calibration interface is shown below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 15: Test Result Record

    It is recommended that users photocopy the test record form before each test and record the test results in the copy so that the form can be used repeatedly. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 16: Specifications

    Overview Specifications The specification of each test item is provided in this manual. For other technical DS80000 Data Sheet (available to download them from RIGOL parameters, refer to http://www.rigol.com website: All the specifications are only valid when the oscilloscope has been warmed up for more than 30 minutes.

  • Page 17: Performance Verification Test

    Performance Verification Test This chapter takes DS81304 as an example to illustrate the performance verification test methods and procedures of DS80000 series digital oscilloscope. The recommended test devices in this manual are shown below. You can also use other devices that fulfill the "Specification" in the following table.

  • Page 18: Test Connection Diagram

    Set the vertical scale of CH1 to 100 mV/div. 3. Turn on Fluke 9500B; set its impedance to 50 Ω and select the resistance measurement function. Read and record the resistance measured. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 19: Test Record Form

    [1]: Full scale = 8 × Current Vertical Scale. 1 mV/div and 2 mV/div are a magnification of 4 mV/div setting. For vertical accuracy calculations, use full scale of 32 mV for 1 mV/div and 2 mV/div vertical sensitivity setting. 5.2.2 Test Connection Diagram DS80000 Fluke 9500B Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 20: Test Procedures

    7. Enable the average measurement function. Read and record Vavg2. 8. Calculate the relative error of this vertical scale: |(Vavg1 - Vavg2) - (Vout1 - Vout2)|/ Full Scale × 100%. 9. Keep the other settings of the oscilloscope unchanged. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 21: Test Record Form

    10 mV/div ≤2% 20 mV/div ≤2% 50 mV/div ≤2% 100 mV/div ≤2% 200 mV/div ≤2% 500 mV/div ≤2% 1 V/div ≤2% 1 mV/div ≤2% 2 mV/div ≤2% 5 mV/div ≤2% 10 mV/div ≤2% Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 22: Dc Offset Accuracy Test

    5.3.1 Specification DC Offset Accuracy ≤200 mV/div (±0.1 div ± 2 mV ± 1.5% of the offset value) Specification >200 mV/div (±0.1 div ± 2 mV ± 1.0% of the offset value) Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 23: Test Connection Diagram

    Select "Average" for the Acquisition menu. Then click or tap the input field for the Averages menu item to set it by using the pop-up numeric keypad. Set the number of averages item to 16. Close the Horizontal system menu. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 24: Test Record Form

    50 mV/div -0.6 V 584.000 mV 616.000 V CH4, 500 MHz BW 500 mV/div -4.092 V -3.908 V 500 mV/div -52.000 mV 52.000 mV 500 mV/div -4 V 3.908 V 4.092 V Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 25: Bandwidth Test

    Connect the [RF 50 Ω] connector of DSG5000 to the input of the power splitter by using the N(M)-N(M) cable. b. Connect the power meter probe (power sensor) to the output of the power splitter. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 26 9. Check the "AC.RMS" result list at the right section of the screen. Read and record the data as Vout 10. Record the power meter reading P , and convert the power to V according to the following formula. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 27: Test Record Form

    [3]: For the number of years that the instrument has been used, please calculate according to the date in the verification certificate provided when the instrument leaves factory. 5.5.2 Test Connection Diagram DS80000 DSG5000 RF 50 Ω Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 28: Test Procedures

    Mode menu item, select "Manual" to enable the manual mode of cursor measurement. Measure the offset (ΔT) of the middle point of the signal (namely the crossing point of the rising edge of the current signal and the trigger level line) Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 29: Test Record Form

    [3]: For the number of years that the instrument has been used, please calculate according to the date in the verification certificate provided when the instrument leaves factory. [4]: Calculation Result = Test Result ΔT/1 ms. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 30: Appendix: Test Record Form

    Appendix: Test Record Form Appendix: Test Record Form RIGOL DS80000 Series Digital Oscilloscope Performance Verification Test Record Form Model: ________________ Tested by: ________________ Test Date: ________________ Impedance Test Record Form Channel Vertical Scale Test Result Limit Pass/Fail 100 mV/div 48.5 Ω to 51.5 Ω...
  • Page 31 -4 V 3.908 V 4.092 V 50 mV/div 0.6 V -616.000 V -584.000 mV CH2, 500 50 mV/div -7.000 mV 7.000 mV MHz BW 50 mV/div -0.6 V 584.000 mV 616.000 V Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 32 [3]: For the number of years that the instrument has been used, please calculate according to the date in the verification certificate provided when the instrument leaves factory. [4]: Calculation Result = Test Result ΔT/1 ms. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

This manual is also suitable for:

Ds80804Ds81304
