Razor W15128001106 Manual

Rsf350 charger port replacement

Download this manual

Required Tools: (Not included)

• Phillips screwdriver

• Flathead screwdriver

WARNING

CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect

charger before conducting any assembly or maintenance procedures. Failure to follow these

steps in the correct order may cause irreparable damage.

Step 1

Using a Phillips screwdriver, loosen and remove seven

(7) screws from the battery cover on the side with the

charger port.

Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.

• 19 mm wrench

• Small pointy object

CHARGER PORT REPLACEMENT

PART NUMBER: W15128001106

Step 2

Pull the battery cover off and set aside.

RSF350

Need help?

Do you have a question about the W15128001106 and is the answer not in the manual?

Page 1 Pull the battery cover off and set aside. (7) screws from the battery cover on the side with the charger port. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 2 Step 7 Install the new charger port, then reverse steps 1 through 6. ATTENTION: Charge battery 12 hours before using. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time. 250430...
