Required Tools: (Not included)
A. 3 mm Allen wrench
B. 8 mm wrench
C. Phillips screwdriver
WARNING
CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect
charger before conducting any assembly or maintenance procedures. Failure to follow these
steps in the correct order may cause irreparable damage.
Step 1
Using a 3 mm Allen wrench and a 8 mm wrench, loosen
and remove the bolt and lock nut at the back of the
headlamp.
Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
RAMBLER 16 HEADLIGHT HOLDER
REPLACEMENT INSTRUCTIONS
PART # W15128785133/W15128701133
Step 2
Using a Phillips screwdriver, remove the two (2) screws that
hold the headlamp holder onto the front fork.
1
Advertisement
Table of Contents
Related Manuals for Razor W15128785133
Summary of Contents for Razor W15128785133
- Page 1 Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
- Page 2 Step 3 Reverse the steps. ATTENTION: Charge battery 12 hours before using. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
