Razor W15128785003 Replacement Instructions

Rambler 16 battery

Table of Contents

Download this manual

Required Tools: (Not included)

A. Phillips screwdriver

B. 4 mm Allen Wrench

WARNING

CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect

charger before conducting any assembly or maintenance procedures. Failure to follow these

steps in the correct order may cause irreparable damage.

Step 1

Using a Phillips screwdriver, remove the two (2) screws at

the back of the battery box.

Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.

RAMBLER 16 BATTERY

REPLACEMENT INSTRUCTIONS

Step 2

Using a Phillips screwdriver, remove the two (2) screws at

the front of the battery box.

PART # W15128785003

Table of Contents

Need help?

Do you have a question about the W15128785003 and is the answer not in the manual?

Page 1 Using a Phillips screwdriver, remove the two (2) screws at the back of the battery box. the front of the battery box. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 2 Unplug the power cord connector. Using a 4 mm Allen wrench, remove the two (2) screws from the top of the battery bracket (upper). Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 3 (lower). Step 10 Step 9 Replace new battery. Put the battery bracket (lower) and battery back onto the frame. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 4 (upper). bracket (lower). Step 13 Reverse the steps. ATTENTION: Charge battery 12 hours before using. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
