Razor W13110050026 Manual

Power a2 front fork - headset bearings

Table of Contents

Download this manual

Required Tools: (Not included)

A. Phillips screwdriver

B. Small Flat screwdriver

C. Long needle nose pliers

D. 3 mm Allen wrench

E. 5 mm Allen wrench

F. 36 mm wrench or a large adjustable wrench

WARNING

CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect

charger before conducting any assembly or maintenance procedures. Failure to follow these

steps in the correct order may cause irreparable damage.

Using a Phillips screwdriver, remove the screw located at

the very front of the deck. Pull the deck cover off from the

deck.

Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.

FRONT FORK - HEADSET BEARINGS

REPLACEMENT PROCEDURES

Disconnect the throttle cable from the controller.

POWER A2

PART # W13110050026

Table of Contents

Do you have a question about the W13110050026 and is the answer not in the manual?

Page 1 Disconnect the throttle cable from the controller. the very front of the deck. Pull the deck cover off from the deck. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 2 Using a 3 mm Allen wrench, remove the set screw at the folding mechanism pin. Slide the pin out from the frame. back of the folding knob while holding the knob. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 3 Using a 36 mm wrench or a large adjustable wrench, collar clamp and remove the stem from the fork. loosen the lock nut from the headset bearings. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 4 (2) screws from the fork limiter cover. limiter screw and slide the fork down. Step 13 Reverse the steps. ATTENTION: Charge battery 8 hours before using. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
