Razor W15128050043 Manual

Rsf350 throttle replacement

Download this manual

Required Tools: (Not included)

• Phillips screwdriver

• 10 mm wrench

• Wire cutters

• 3 mm Allen wrench

• Small flat screwdriver

WARNING

CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect

charger before conducting any assembly or maintenance procedures. Failure to follow these

steps in the correct order may cause irreparable damage.

Step 1

Using a Phillips screwdriver, loosen and remove seven

(7) screws from the battery cover on the side with the

charger port.

Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.

THROTTLE REPLACEMENT

Step 2

Using a 10 mm wrench, loosen and remove the two (2)

lock nuts under the seat. Lift and remove the seat from

the frame and set aside.

RSF350

PART # W15128050043

Need help?

Do you have a question about the W15128050043 and is the answer not in the manual?

Page 1 (7) screws from the battery cover on the side with the lock nuts under the seat. Lift and remove the seat from charger port. the frame and set aside. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 2 The second regular screw main frame. is located on the opposite side of the unit, not shown. Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
Page 3 ATTENTION: Charge battery 12 hours before using. and remove the grip and the throttle. 250417_R Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
