GIRBAU HS-6008 Service Manual
  1. Manuals
  2. Brands
  3. GIRBAU Manuals
  4. Dishwasher
  5. HS-6008
  6. Service manual
GIRBAU HS-6008 Service Manual

GIRBAU HS-6008 Service Manual

Hide thumbs Also See for HS-6008:

Advertisement

Quick Links

Download this manual
Mechanical Technical Assistance
Manual for washers
HS-6008 / EH020
MS-610 / EM025
GIRBAU, S.A.
Crta de Manlleu, km. 1
08500 VIC (Barcelona) • SPAIN
Tel. 34 93 8861100
Fax 34 93 8860785
girbau@girbau.es
www.girbau.com
For USA & CANADA:
CONTINENTAL GIRBAU Inc.
2500 State Road 44
WI 54904 Oshkosh • USA
Tel. 1(920) 231-8222
Fax 1(920) 231-4666
info@continentalgirbau.com
www.continentalgirbau.com
SERVICE
HS-6008 / EH020
MS-610 / EM025
1
Cod. 410548en
Rev. 00/1206

Advertisement

loading
Need help?

Need help?

Do you have a question about the HS-6008 and is the answer not in the manual?

Questions and answers

Related Manuals for GIRBAU HS-6008

Summary of Contents for GIRBAU HS-6008

  • Page 1 Mechanical Technical Assistance Manual for washers HS-6008 / EH020 MS-610 / EM025 SERVICE GIRBAU, S.A. Crta de Manlleu, km. 1 08500 VIC (Barcelona) • SPAIN HS-6008 / EH020 Tel. 34 93 8861100 Fax 34 93 8860785 MS-610 / EM025 girbau@girbau.es www.girbau.com...

  • Page 2: Safety Instructions

    Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 SAFETY INSTRUCTIONS WARNING ¡ INSPECTION ROUTINES, MAINTENANCE OR REPAIR • The actions described in these instructions are strictly reserved for Service Technicians who have been authorized by the manufacturer. Any actions carried out by personnel who are unauthorized by the manufacturer will be considered to be improper and will result in the automatic void of washer’s warranty.
  • Page 3 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 INDEX SAFETY INSTRUCTIONS 1. Preparation 1.1. Required tools. 1.2. Parts and materials. 1.3. Parts. 1.4. Emptying the residual bath. 2. Disassembly 2.1. Disassembling the covers 2.2. Disassembling the front panel of the washing machine 2.3.
  • Page 4 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 PREPARATION 1.1. Requiered tools. DISASSEMBLY TOOLS ASSEMBLY TORX 20 screwdriver Lower front and rear covers TORX 25 screwdriver Front panel of the washing Key for opening the top cover, supplied with the machine.
  • Page 5 1.3. Parts list NOTE The numbers on the drawing above correspond to those from machines parts list HS-6008 / EH020. The system for bearing replacement is the same regardless of any differences there may be between the different machine models HS / EH and MS / EM.
  • Page 6 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 2. DISASSEMBLY 2.1. Disassembling the covers • Rear central cover. Take fastening screws, move cover upwards and separate it from the machine (fig. 1). fig.1 • Lower front cover. Unscrew the three fastening screws at the base and separate it from the machine (fig.
  • Page 7 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 • Open the top cover lock and remove the top cover. • Open the control panel of the washing machine using the wrench 22mm ( 7/8 inch.). (fig. 5). fig.5 •...
  • Page 8 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 2.4. Disassembling the drum. • (It is advisable to have this operation performed by two people) • Remove the drum pulley belt. • Take the fastening screw out of the drum pulley.
  • Page 9 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 3.2. Changing the bearings. • Clean the bearings’ box, especially the area housing the bearings. • Lightly lubricate the bearing housing to make it easier to mount. • Lean the conical trunk end of the bearings’...
  • Page 10 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 4. BACK OF THE OUTER DRUM 4.1. Cleaning the back of the outer drum • This procedure should be carried out if the watertight seal is not to be changed.
  • Page 11 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 • Turn the separator. • Remove the old flexible joint. • Clean the surface well and spread a fine strip of silicone on the joint housing, replace the new flexible joint on the outer drum separator.(fig.19).
  • Page 12 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 4.5. Mounting the outer drum separator • Keep the outer drum separator fixed as shown in (fig. 23). • Remember that drain position is the bottom of the outer drum.
  • Page 13 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 • Fit the two new O rings inside the ring seal. (fig. 27). fig. 27 • Lubricate the shaft with soapy water and insert the ring seal into the shaft using the Y tool until fully tightened to the drum (fig.
  • Page 14 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 • Mount the pulley and tighten the fastening screw. • Check that the drum rotates freely. • Mount the belt. (fig.31). • Check the pressure transmitter tube isn’t damaged and can move freely on the inside of the bearing box leg.
  • Page 15 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 5.5. Assembling the covers. • Match up the front and side panels and fix with the top and bottom screws as indicated by the arrows. (fig. 34). IMPORTANT Fix the ground wire from the control panel together with the top left screw.
  • Page 16 Bearing and Seal replacement HS-6008 / EH020 MS-610 / EM025 • Position the rear cover beneath the rear panel and fix in place with the screws. (fig. 37). fig. 37 6. FINAL CHECKING 6.1. Checking the machine. Once ALL the washing machine covers are in place and fastened, check the operation and water tightness of the washing machine.

This manual is also suitable for:
