Vuly QUEST 1 PRO Assembly Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
DISREGARD OTHER FRAME MANUAL
MINIMUM OF THREE PEOPLE REQUIRED TO
ASSEMBLE THIS PRODUCT.
ATTENTION!
SAFETY INFORMATION, INSTALLATION, CARE AND MAINTENANCE
INSTRUCTIONS. READ PRIOR TO ASSEMBLING AND USING THE PRODUCT.
Vuly cares about safety.
Adult supervision is required at all times whilst equipment is in use.
If you have any feedback regarding our instructions, feel free to email
instructions@vulyplay.com
so that we can continue to improve.
2-246642
QUEST 1 PRO
Assembly Manual
FULL ASSEMBLY PG.14
RETROFIT ASSEMBLY PG.52
XL
Scan this QR code
or visit vulyplay.us/install for
step-by-step video instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the QUEST 1 PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vuly QUEST 1 PRO

Summary of Contents for Vuly QUEST 1 PRO

  • Page 1 QUEST 1 PRO Assembly Manual DISREGARD OTHER FRAME MANUAL FULL ASSEMBLY PG.14 RETROFIT ASSEMBLY PG.52 MINIMUM OF THREE PEOPLE REQUIRED TO ASSEMBLE THIS PRODUCT. ATTENTION! SAFETY INFORMATION, INSTALLATION, CARE AND MAINTENANCE INSTRUCTIONS. READ PRIOR TO ASSEMBLING AND USING THE PRODUCT.
  • Page 2 Products subject to the following conditions: • Three adults required for assembly. To the maximum extent permitted by the law, Vuly, its • Strong winds and wild weather can cause employees, directors and agents will not be liable to the...
  • Page 3 Contents Read and follow all instructions in this manual before using your system, and do not use it in any way that is not described in this manual. Responsibility rests with the owner and supervisors of the product to make sure that all users are aware of the practices specified in this manual.
  • Page 4 • Ensure that moving steel components remain well COMPONENTS WILL DETERIORATE OVER TIME. lubricated. • Use only parts and accessories recommended by Vuly. Record your date of purchase: 1.2. Rust and corrosion • Be aware of, and check, areas that are particularly prone to rusting: º...
  • Page 5 • Install the system on level ground and in a well- lit area, Vuly cares about safety. no less than 2 m (6 ft) from any structure or obstruction – such as a fence, garage, house, overhanging branches, laundry lines, or electrical wires.
  • Page 6 3.0. Pre-assembly 3.1. Size Reference 3.2. Tips & Tricks 3.2.1. Joiner Fitting To align the joiner holes with the holes in the frame tube, take the large 6mm Allen key and insert it into the top hole in the joiner tube then twist until the holes align.
  • Page 7 3.2.2. Uneven Ground Ensure that ground at the installation location is level and clear of obstructions. Installing on an uneven surface can cause misallignment and instability. 2-246642...
  • Page 8 FULL ASSEMBLY GO TO: PAGE 14 IF YOU HAVE ASSEMBLED A QUEST FRAME GO TO: PAGE 52...
  • Page 9 3.3. Parts and components BOX A A2 x2 A3 x2 A4 x2 A5 x2 A6 x2 A7 x3 2-246642...
  • Page 10 BOX B B2 x3...
  • Page 11 BOX C C2 x4 BOX E x2 2-246642...
  • Page 12 BOX F x2 BOX H H2 x2 H3 x4...
  • Page 13 BOX SHADE COVER XL1 x2 XL2 x2 SHADE COVER 2-246642...
  • Page 14 BOX I...
  • Page 15 BOX J 2-246642...
  • Page 16 4.0. Assembly Instructions 4.1. Full Assembly Instructions...
  • Page 17 WARNING! ONLY HAND TIGHTEN BOLTS AND ENSURE THEY ARE VERY LOOSE! You may need to rotate some Monkey Bars to fit into the remaining Climbing Rail. WARNING! Ensure Straight Climbing Bars A7 are in the middle; and Angle Climbing Bars A4, A5, A6 are on either ends of the Climbing Rails as indicated.
  • Page 18 WARNING! ONLY HAND TIGHTEN BOLTS AND ENSURE THEY ARE VERY LOOSE! If having difficulties to get the Climbing Bars into the Climbing Rails, double check all bolts done in Step 3 are very loose.
  • Page 19 NOTE: Once all of the Climbing Bars are loosely threaded into the Climbing Rails, tighten all of the bolts to make sure the climbing section is secure. 2.36” 2-246642...
  • Page 20 WARNING! Ensure all bolts are securely fastened before procceeding to the next step. WARNING! Minimum of three people required for this step. Lift with straight back!
  • Page 21 ENTRY NOTE: Pay attention to Overpass Entry. Ensure Pull Handles on Overpass Platform faces up. 2-246642...
  • Page 22 WARNING! Ensure holes on I2 Tubes are facing the same direction. Ensure to connect Tube I2 with Long Grub Screw on Joiner I8. Pay attention to orientation of Joiner.
  • Page 23 NOTE: For best results, push tube through overpass loops using a twisting action WARNING! Ensure to connect Tube I2 with Long Grub Screw on Joiner. Pay attention to orientation of Joiner. If having difficulties with joiner orientation, swap position of Grub Screws as shown. 2-246642...
  • Page 24 OPTIONAL CARGO NET ACCESSORY OPTIONAL WARNING! Pay close attention to the Entry of Overpass. The Overpass can only be intsalled as shown in diagram, not the opposite.
  • Page 25 WARNING! Pay close attention to the Entry of Overpass. The Overpass can only be intsalled as shown in diagram, not the opposite. 2-246642...
  • Page 26 HIDEOUT...
  • Page 27 OPTIONAL FLYING FOX OPTIONAL FLYING FOX 2-246642...
  • Page 28 NOTE: Ensure Accessory Joiners are roughly equal distance apart before tightening. If you have Flying Fox installed, skip the highlighted Accessory Joiners. NOTE: Only finger tighten C4 at this step.
  • Page 29 NOTE: Ensure the Joiners are positioned as shown and secure the F3 assembly to the frame using the Short Grub Screw. “HORIZONTAL FRAME SPAN” NOTE: Ensure the holes on the E1 of the Horizontal Frame Span are aligned in the same direction. 2-246642...
  • Page 30 “HORIZONTAL FRAME SPAN” NOTE: Ensure Nylon Nut on Accessory Joiners are oriented outside of the frame. Also, ensure the Horizontal Frame Span aligns with the Long Grub Screw. NOTE: Ensure Accessory Joiners are roughly equal distance apart before tightening. Also, ensure the holes on the E1 are aligned in the same direction.
  • Page 31 2-246642...
  • Page 32 “HORIZONTAL FRAME SPAN” NOTE: Holes on E1 Tubes faces the same direction. Ensure Overpass Loops are secured through Safety Net Button Holes before looping Horizontal Frame Span through.
  • Page 33 NOTE: Ensure Nylon Nut on Accessory Joiners are oriented outside of the frame. NOTE: Ensure holes on Horizontal Frame Span align with hole on Joiners to receive Long Grub Screws. 2-246642...
  • Page 34 NOTE: Only undo grub screw enough to insert tube J2.
  • Page 35 2-246642...
  • Page 36 NOTE: Slide Joiners in direction of arrow to tension Hideout assembly, tighten Grub Screw to lock in place. NOTE: Pay attention to direction of Eye Bolts. Attach the Velcro straps at each corner.
  • Page 37 I 11 Shade Cover 2-246642...
  • Page 39 2-246642...
  • Page 40 NOTE: Ensure Shade Cover is fully tensioned before proceeding to the next step. OPTIONAL NOTE: If having difficulties connecting Turn Buckle to D Shackle, use the PP Webbing Loop provided as shown.
  • Page 41 2-246642...
  • Page 42 NOTE: Ensure this H-Frame assembly includes Joiner as indicated. If you have Cargo net accessory skip this step. B6 x 4...
  • Page 43 OPTIONAL NOTE: Ensure this H-Frame assembly includes Joiner as indicated. If you don’t have Cargo net accessory skip this step. 2-246642...
  • Page 44 NOTE: Only finger tighten Grub Screw on J6 Joiners. WARNING! Minimum of three people required for this step. Lift with straight back!
  • Page 45 WARNING! Ensure Joiners a located in between the two Frame Bolts. WARNING! Minimum of three people required for this step. Lift with straight back! 2-246642...
  • Page 46 WARNING! Minimum of three people required for this step. Lift with straight back! WARNING! Ensure Joiners are located in between the two Frame Bolts.
  • Page 47 2-246642...
  • Page 49 2-246642...
  • Page 51 2-246642...
  • Page 52 NOTE: Ensure all components and fasteners are securely installed.
  • Page 53 CONGRATULATIONS! You have assembled your Quest 1 Pro playset! 2-246642...
  • Page 54 4.2. Retrofit Assembly Instructions NOTE: Always use a ladder throughout the entire assembly process for safety.
  • Page 55 NOTE: If you already have Flying fox installed, do not install the hideout on the same side. 2-246642...
  • Page 56 NOTE: Only loosen Grub Screw enough to remove tube.
  • Page 57 2-246642...
  • Page 59 2-246642...
  • Page 61 Accessory Joiner Accessory Joiner NOTE: Ensure to remove all Accessory Joiners before proceeding to the next step. ENTRY NOTE: Pay attention to Overpass Entry. Ensure Pull Handles on Overpass Platform faces up. 2-246642...
  • Page 62 NOTE: If having difficulties looping the tube through, try twisting it while feeding.
  • Page 63 NOTE: Ensure the Joiners are positioned as shown. NOTE: Ensure Grub Screws on the highlighted Joiners are loosened. 2-246642...
  • Page 64 NOTE: Push the frame apart as shown. WARNING! Pay close attention to the Entry of Overpass. The Overpass can only be intsalled as shown in diagram, not the opposite.
  • Page 65 NOTE: Adding Accessory Joiner is optional. NOTE: Ensure the Accessory Joiner is positioned in the middle of the tube and all highlighted Joiners are fully tightened. 2-246642...
  • Page 66 NOTE: Holes on I2 Tubes faces the same direction.
  • Page 67 NOTE: Ensure Safety Net is secured to Overpass before looping the tube through, and Nylon Nut on Accessory Joiners are oriented outside of the frame. 2-246642...
  • Page 68 NOTE: Only finger tighten the Accessor Joiners at this step. NOTE: If having difficulties, start with the opposite corner.
  • Page 69 NOTE: Ensure Accessory Joiners are roughly equal distance apart before tightening. 2-246642...
  • Page 70 NOTE: Only undo grub screw enough to insert tube J2.
  • Page 71 NOTE: Slide Joiners in direction of arrow to tension Hideout assembly, tighten Grub Screw to lock in place. 2-246642...
  • Page 72 NOTE: Pay attention to direction of Eye Bolts. I 11...
  • Page 73 Shade Cover 2-246642...
  • Page 75 NOTE: To tension the shade cover, move the nut further away from the tube OPTIONAL NOTE: If having difficulties connecting Turn Buckle to D Shackle, use the PP Webbing Loop provided as shown. 2-246642...
  • Page 77 2-246642...
  • Page 79 2-246642...
  • Page 81 NOTE: Tension Cargo Net by push down on Joiners, then tighten Grub Screw to secure the assembly. NOTE: Ensure all components and fasteners are securely installed. 2-246642...
  • Page 82 CONGRATULATIONS! You have assembled your Quest 1 Pro playset!
  • Page 83 7.1.1. Second-hand purchases Vuly offers half-price replacement parts to all customers Vuly warranties apply only for the original purchaser, to a for the lifetime of their purchase through the Half-Price product purchased from Vuly Play or an Authorised Reseller.
  • Page 84 Warranty Claim will not be assessed. This warranty will be void if the product is used for any other Vuly may take up to 7 days to process Warranty Claims activity besides those for which it was intended, or used in upon a completed submission.
  • Page 85 - to a refund for the unused portion, or to compensation for its reduced value. 8.0. Missing parts If a customer believes that a Vuly product does not include all necessary parts, they must immediately lodge a Missing Parts Claim at VulyPlay.us/support.
  • Page 86 See vulyplay.us/terms for the most recent Vuly warranty policies, terms and conditions.
