Summary of Contents for boblov M5
-
Page 3: Table Of Contents
CONTENT PREFACE PART 1 STRUCTURE DIAGRAM PART 2 LCD INDICATION PART 3 BASIC OPERATION 3.1 How to charge the device 3.2 Power On/Off/Standby Mode 3.3 Take Photo 3.4 Video & Audio Recording 3.5 Night Vision 3.6 What is Stealth Mode? 3.7 Files View /Playback 3.8 File Deletion 3.9 File Transfer/Connecting Computer... -
Page 4: Preface
PREFACE We sincerely thank you for using our company’ s product. This manual is the introduction of the M5 body police camera which includes its functions, features, external structure, operation, and caution items. Before using the product, please read the user manual carefully and keep it properly. - Page 5 PTT Button/Alarm Button White Light Red and Blue Flashing Light Laser light Infrared lights Lens Video Button/Snapshot USB interface & Reset hole Power On/Off Button Speaker Hole LCD Display Down/Playback/Zoom Out/Fast Forward Button Return Button Up/Mark Key/Zoom In/Rewind Button Menu/OK Button support@boblov.com...
-
Page 6: Part 2 Lcd Indication
2021-02-08 09:32:05 11:20:35 Status Indicate(not displayed in standby mode, displays a red dot and flashes in video mode) Video Resolution Memory Capacity Available Police ID System Date System Time Battery Level Audio Status Device ID Remaining Video Recording Time support@boblov.com... -
Page 7: Part 3 Basic Operation
(Power off state to charge). Charging Tips: Use the standard cable and 5V-1A charger plug to charge for about 6 hours(Power off state to charge). When charging, in power-on status the working indicator light shows green, the power indicator light support@boblov.com... -
Page 8: Power On/Off/Standby Mode
(camera standby mode) and the green indicator steady on. Start video recording for 5min, without other operations, then it automatically enters the LCD Auto Off mode and the red indicator keeps flashing.(LCD Auto Off mode can be set to off/5min). support@boblov.com... -
Page 9: Take Photo
-on state, press and hold the button (This button is on front of the camera, below the BOBLOV logo.) for 3 seconds to take a picture and auto save it There will be a"click"sound during the picture. Every press and hold will take one picture. The picture is named after the date and time, and the suffix is JPG. -
Page 10: Video & Audio Recording
During the recording process, long press button (This button is on front of the camera, below the BOBLOV logo.) for 3 seconds to take a picture and save it auto. The video recording will not be interrupted during this process. - Page 11 During the video recording, click the button to lock the current video and click the button again to release/cancel the lock, then press the video button support@boblov.com...
-
Page 12: Audio Recording
The zoom in and zoom out can be adjusted in the range of 1.00X-128.00X. 3.4.5 Audio Recording In the power-on state, tap the button; OR long press and hold the button for 3 seconds in the support@boblov.com... -
Page 13: Night Vision
"IR Filter" to "Auto". Then the camera can be switched to the night vision mode according to the brightness of the environment. 3.6 What is Stealth Mode? Menu 000000 Police ID Off Password Protection Change Password Stealth Mode Off IR Filter Manual support@boblov.com... -
Page 14: Files View /Playback
Auto power off will save the camera battery. 3.7 Files View /Playback a. In the standby mode, short press the button to enter the playback menu, and use the button button to select the desired option, as shown in the figure below: support@boblov.com... - Page 15 When playback the video files, short press the button in order is rewind play, short press button act as fast forward. Short press the button once to increase the speed two times. The fast forward and rewind can be adjusted in the range of 2X-128X. support@boblov.com...
-
Page 16: File Deletion
Video/ Photo/ Audio file need to delete, click button to the playback file list. Long press button to the password verify page, insert the default password(000000) if first use(otherwise, enter the password you have support@boblov.com... - Page 17 “YES” or “ NO” , then click button to confirm. After deleting the file, the camera goes back to the previous playback file list Video Video Photo Audio 2022-05-26 15:26:04 00:00:05 Login Delete Selected File? 6 Character Password 000000 support@boblov.com...
-
Page 18: File Transfer/Connecting Computer
After turning on the "Password Protection", the below circumstance need to verify the password, including but not limited to: 1. When connecting the camera to the PC side; 2. Try to delete the files on the camera; 3. Choose to change the camera password, need to support@boblov.com... - Page 19 IR Filter Manual How to change the password? Short press button in the standby mode, then turn to "Change Password" section in the menu. Before changing, you need to insert the default password: 000000 first. Then click button again support@boblov.com...
-
Page 31: Part 9 Gps Function(Optional)
"GPS" section. Click button again, then use button to choose the "On" option and click button again to save the change. Menu Off Anti-Virus Time Zone GMT+08:00 File Brower Mode Photo mode Device ID 8888888 support@boblov.com... - Page 32 Please use the camera in an open area to collect the GPS information. If in buildings, a traffic jam in the viaduct or tunnel, the GPS signal will be weakened. In addition, if there is metal shielding around the camera, the weaken will be more obvious. support@boblov.com...
- Page 39 A: The camera enters the LCD Auto Off mode in default without 5 minutes operation. If you want the display is always on, please enter the menu to set LCD Auto Off option to Off. LCD Auto Off option can be set to off/5 min. support@boblov.com...
- Page 40 A: Please check whether the Auto Power Off option in the menu is on. If you want the camera to stay power-on state, please enter the menu to set Auto Power Off to Off. Auto Power Off mode can be set to off/1min/3min/5min/10min. support@boblov.com...
-
Page 41: Part 12 Package List
PART 12 PACKAGE LIST M5 Body Short Clip Long Clip Police Camera USB Cable Car Suction Bracket Car Charger l : M a n u U s e User Manual *Please note: Accessories maybe updated without prior notice, please refer to the actual receipt of the items. -
Page 42: Part 13 Customer Service
PART 13 CUSTOMER SERVICE BOBLOV is dedicated to offer the best service to our valuable customer. PART 9 PACKAGE LIST To reach BOBLOV customer service, please e-mail us: Official Email address: Support@boblov.com Official Website: www.boblov.com Facebook : www.facebook.com/BOBLOVGlobal/ Tel: +1(213)905-9206...
