PowerTec 71959 Manual

Workbench table top routing jig kit
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Model No. 71959
Workbench Table Top Routing Jig Kit
Visit us on the web at www.powertecproducts.com
You will need this manual for safety instructions, operating procedures, and
warranty. Put it and the original sales invoice in a safe, dry place for future reference.
24-0404

Advertisement

loading
Need help?

Need help?

Do you have a question about the 71959 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PowerTec 71959

Summary of Contents for PowerTec 71959

  • Page 1 Model No. 71959 Workbench Table Top Routing Jig Kit Visit us on the web at www.powertecproducts.com You will need this manual for safety instructions, operating procedures, and warranty. Put it and the original sales invoice in a safe, dry place for future reference.

  • Page 2: Safety Warnings

    CONTENTS ITEM DESCRIPTION Template 23-1/32" x 11-11/16" x 5/16" Index Pins 3/4" Edge Pins 25/64" x 1-1/16" Lock Nut ø1-3/8" x 5/16"L UNPACKING Refer to Figure 1 Guide Bushing ø1"OD Check for shipping damage. Check x ø 7/8"ID x 45/64"L immediately whether all parts and Router Bit 3/4"...

  • Page 3: Specific Safety Warnings

    SPECIFIC SAFETY WARNINGS • Maintain accessories. Do not use WARNING damaged accessories. Only use accessories recommended by the Before using the Workbench Table Top manufacturer. Routing Jig Kit, user must read and • Always wear ANSI approved hearing, understand all safety instructions for this eye and respiratory protection.
  • Page 4 PREPARE PLUNGE ROUTER CAUTION Precise cuts are essential. Use a Plunge Router. Fixed Base Routers not recommended. 1. Insert 1" OD Guide Bushing (EE) into Router Base. 2. Hand twist to secure Lock Nut (DD) onto 1" OD Guide Bushing (EE)—tighten. 3.
  • Page 5 Before routing Position [1]—Insert four Edge Pins (CC) into Template (AA) as shown. Figure 5 • Set up a work station to suit the project at hand. • Secure material to be used with clamps (not included). • Place Template (AA) on bottom left corner of workpiece. •...
  • Page 6 Left Side Cutting Positions Right Side Cutting Positions • Position [1] consists of Row 1 & Row 2. • Position [5] consists of Row 6 & Row 7. Set up as shown. Rout two rows of 5 for Set up as shown. Rout two rows of 4 for 10 holes.
  • Page 7 Rout an Accessory Tray or Two Use the handle cutout as a template. material thickness. Use the 3/4" Router Mark this position. Secure in place with Bit (FF) and 1" OD Guide Bushing (EE) clamps and Index Pins (BB). Do not provided.

  • Page 8: Care And Maintenance

    Completed Portable Replaceable Multi-Functional Work Top Figure 11 CARE AND MAINTENANCE The 71959 Multi-function Routing Jig is designed for durability over a long period of time and requires minimum maintenance. Proper care and regular cleaning will extend the life of this product.
