PowerTec 80002 Instruction Sheet

INSTRUCTION SHEET
UNIVERSAL ANGLE TEMPLATE TOOL

TO USE

1. Loosen the four locking knobs.
2. Pull apart the long arms.
3. Guide the short arms into the desired shape or angle to create a template to
be used on wood, laminate, tile, brick, stone, lumber and other materials. The
template can be used to:
• create bullseyes, arches and plumb cuts
• cut birds mouth rafters
• mark flooring for cutting
• measure distances for corbels
• use as a 10 mm guage for standard brick joints
• draw circles
• create unlimited templates, take measurements or use in any application
imaginable, this tool is only limited to the imagination
4. When desired shape or angle is reached tighten the locking knobs.
Long Arm
Short Arm
Long Arm
NOTE: The tool may be assembled with the short arms on the bottom and the
long arms on the top, if needed. Remove the locking knobs, place the long arms
on top of the short arms and replace the locking knobs.
Page size 100 mm x 140 mm FOLDS to 100 mm x 35 mm
Model No. 80002/80003
QUESTION...
1•847•780•6120
Locking Knob
Short Arm
Templates for bullseyes and arches
Make a template to cut birds mouth rafters
