Item # 000 000
Model # FCS80231-ST
USE AND CARE GUIDE
BELLEVILLE 4-PIECE DEEP SEATING SET
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this deep seating set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BELLEVILLE FCS80231-ST and is the answer not in the manual?

Questions and answers

Related Manuals for HAMPTON BAY BELLEVILLE FCS80231-ST

Summary of Contents for HAMPTON BAY BELLEVILLE FCS80231-ST

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this deep seating set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Chair Package Contents ............4 Warranty ................ 2 Glider Package Contents ......

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...

  • Page 4: Chair Package Contents

    Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Chair bucket Right chair arm Left chair arm Back bar...

  • Page 5: Glider Package Contents

    Pre-Assembly (continued) GLIDER PACKAGE CONTENTS Part Description Quantity Glider bucket Right glider arm Left glider arm Glider base HOMEDEPOT.CA Please contact 1-877-527-0313 for further assistance.
  • Page 6 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Glass Table rim Leg connector Table leg...

  • Page 7: Chair Assembly

    Chair Assembly Connecting the chair arms to the chair bucket Attach the chair bucket (A) to the left chair arm (C) using M6x18 bolts (AA), M6x30 bolts (BB) and M6 washers (GG). Place the back bar (D) into the left chair arm (C). Repeat this step for the right chair arm (B).
  • Page 8 Chair Assembly (continued) Securing the back bar Turn the chair right side up. Attach the back bar (D) to the chair arms (B and C) using M6x25 bolts (CC). NOTE : Loosely tighten all bolts using the hex wrench (II).
  • Page 9 Chair Assembly (continued) Tightening the bolts Tighten all the bolts. Ensure the chair is tightly assembled and stable before use. HOMEDEPOT.CA Please contact 1-877-527-0313 for further assistance.

  • Page 10: Glider Assembly

    Glider Assembly Connecting the glider arms to the glider bucket Attach the right glider arm (F) to the front of the glider bucket (E) using M6x18 bolts (AA) and M6 washers (GG). Attach the right glider arm (F) to the back of the glider bucket (E) using M6x30 bolts (BB) and M6 washers (GG). Repeat this procedure to attach the left glider arm (G) to the glider bucket (E).
  • Page 11 Glider Assembly (continued) Connecting the arms to the connection bar Attach the glider base (H) to the glider arms (F and G) using M6x18 countersunk bolts (FF) and M6 plastic washers (HH). The front and back of the glider base (H) are different and will not assemble in reverse. NOTE: Loosely tighten the bolts using the hex wrench (II).
  • Page 12 Glider Assembly (continued) Tightening the bolts Turn the glider right side up. Tighten all the bolts. Ensure the glider is tightly assembled and stable before use.
  • Page 13 Table Assembly Connecting the table legs Place the table rim (J) upside down on a soft surface. Attach each of the table legs (L) to the table rim (J) using M6x15 bolts (DD) and M6 washers (GG). NOTE: Loosely tighten the bolts using the hex wrench (II). HOMEDEPOT.CA Please contact 1-877-527-0313 for further assistance.
  • Page 14 Table Assembly (continued) Connecting the leg connector to the table legs Align the holes on the leg connector (K) with the holes on the inside of each table leg (L). Attach the leg connector (K) to the table legs (L) using M6x20 bolts (EE) and M6 washers (GG). Once all of the bolts are in place, fully tighten the bolts.

  • Page 15: Care And Cleaning

    Table Assembly (continued) Adding the glass Turn the table right side up. Ensure all connections are secure. Carefully place the glass (I) onto the table rim (J). Ensure the table is tightly assembled and stable before use. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly.
  • Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.CA Retain this manual for future use.
