HAMPTON BAY FCS80231RST Use And Care Manual

HAMPTON BAY FCS80231RST Use And Care Manual

Belleville 4-piece deep seating set
Hide thumbs

Advertisement

Quick Links

Download this manual
Item # 658 977
Model # FCS80231RST
USE AND CARE GUIDE
BELLEVILLE 4-PIECE DEEP SEATING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
mpton Bay through the purchase of this deep seating set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

loading

Related Manuals for HAMPTON BAY FCS80231RST

Summary of Contents for HAMPTON BAY FCS80231RST

  • Page 1 Bay through the purchase of this deep seating set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............3 Product Caution ..............2 Safety Warnings ..............2 Chair Package Contents ............4 Warranty ................ 2 Glider Package Contents ......

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. NOTE: Hardware not shown to actual size. HARDWARE INCLUDED Part Description...

  • Page 4: Chair Package Contents

    Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Sling bucket Right arm t f e...

  • Page 5: Glider Package Contents

    Pre-Assembly (continued) GLIDER PACKAGE CONTENTS Part Description Quantity Sling bucket Right arm t f e Glider base HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 6 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity e l i Table rim Leg connector...

  • Page 7: Chair Assembly

    Chair Assembly Attaching the chair arms to the chair back Attach the sling bucket (A) to the left arm (C) using M6x20 combination bolts (AA) and M6x30 combination bolt (BB), as shown below. Place the back bar (D) into the left arm (C). Repeat this step for the right arm (B).
  • Page 8 Chair Assembly (continued) Securing the back bar Turn the chair right side up. Attach the back bar (D) to the chair arms (B and C) using M6x25 bolts (CC). NOTE : Loosely tighten all bolts using the hex wrench (GG). .
  • Page 9 Chair Assembly (continued) Tightening all bolts Tighten all the bolts. Check and ensure the chair is tightly assembled and stable before use. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.

  • Page 10: Glider Assembly

    Glider Assembly Connecting the glider arms to the glider seat Attach the right arm (F) to the front of the sling bucket (E) using M6x20 combination bolt (AA). Attach the right arm (F) to the back of the sling bucket (E) using M6x30 combination bolts (BB). Repeat this procedure to attach the left arm (G) to the sling bucket (E).
  • Page 11 Glider Assembly (continued) Connecting the arms to the connection bar Attach the glider base (H) to the glider arms (F and G) using M6x18 countersunk bolts (EE) and M6 plastic washers (FF) The front and back of the glider base (H) are different and will not assemble in reverse. NOTE: Loosely tighten the bolts using the hex wrench (GG).
  • Page 12 Glider Assembly (continued) Tightening all bolts Turn the glider right side up. Tighten all the bolts. Check and ensure the glider is tightly assembled and stable before use.
  • Page 13 Table Assembly Connecting the table legs Place the table rim (J) upside down on a soft surface. Attach each of the table legs (K) to the table rim (J) using M6x20 Combination bolts (AA). NOTE: Loosely tighten the bolts using the hex wrench (GG). . HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 14 Table Assembly (continued) Connecting the leg connector to the table legs Align the holes on the leg connector (L) with the holes on the inside of each table leg (K). Attach the leg connector (L) to the table legs (K) using M6x15 combination bolt (DD). Tighten all the bolts.

  • Page 15: Care And Cleaning

    Table Assembly (continued) Adding the tiles Turn the table right side up. Ensure all connections are secure. Carefully place the tiles (I) onto the table rim (J). Check and ensure the table is tightly assembled and stable before use. ò Care and Cleaning For best results, clean the frames with a damp cloth and dry thoroughly.
  • Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
