Item # 000 000
Model # FCS80198-ST
USE AND CARE GUIDE
BELLEVILLE 7-PIECE C-SPRING DINING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BELLEVILLE FCS80198-ST and is the answer not in the manual?

Questions and answers

Related Manuals for HAMPTON BAY BELLEVILLE FCS80198-ST

Summary of Contents for HAMPTON BAY BELLEVILLE FCS80198-ST

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this dining set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Product Caution............... 2 Hardware Included ..............3 Safety Warnings............... 2 Chair Package Contents ............4 Warranty ................. 2 Table Package Contents ............5 What is Covered ...............2 Chair Assembly ............

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to complete the assembly of this product. HARWARE INCLUDED NOTE: Hardware not shown to actual size.

  • Page 4: Chair Package Contents

    Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Chair bucket Right chair arm Left chair arm Back bar...
  • Page 5 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table leg Table rim Leg connector Glass HOMEDEPOT.CA Please contact 1-877-527-0313 for further assistance.

  • Page 6: Chair Assembly

    Chair Assembly Connecting the chair back to the chair arms Attach the chair back (A) to the right chair arm (B) using M6x18 bolts (AA), M6x30 bolts (BB), and M6 washers (EE). Place the back bar (D) into the right chair arm (B). Repeat this step for the left chair arm (C).
  • Page 7 Chair Assembly (continued) Securing the back bar Turn the chair right side up. Attach the back bar (D) to the chair arms (B and C) using M6x25 bolts (CC). NOTE: Loosely tighten all bolts using the hex wrench (FF). HOMEDEPOT.CA Please contact 1-877-527-0313 for further assistance.

  • Page 8: Tightening The Bolts

    Chair Assembly (continued) Tightening the bolts Tighten all the bolts. Ensure the chair is tightly assembled and stable before use.
  • Page 9 Table Assembly Connecting the table legs Place the table rim (F) upside down on a soft surface. Attach each of the table legs (E) to the table rim (F) with M6x16 bolts (DD) and M6 washers (EE). NOTE: Loosely tighten all bolts using the hex wrench (FF). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 10 Table Assembly (continued) Connecting the leg connector to the table legs Align the holes of the leg connector (G) with the holes on the inside of each table leg (E). Attach the leg connector (G) to the table legs (E) using M6x16 bolts (DD) and M6 washers (EE). Once all of the bolts are in place, fully tighten the bolts.

  • Page 11: Care And Cleaning

    Table Assembly (continued) Adding the glass Turn the table right side up. Ensure all connections are secure. Carefully place the glass (H) onto the table rim (F). Care and Cleaning For the best results, clean the dining set with a damp cloth, and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
  • Page 12 Questions, problems, missing parts? Before returning to the store call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.CA Retain this manual for future use.
