Item #0000 000 000
Model # FCS80382AS-2PK
USE AND CARE GUIDE
STATESVILLE SLING SCROLL DINING CHAIR - 2PK
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of these chairs. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY FCS80382AS-2PK
Summary of Contents for HAMPTON BAY FCS80382AS-2PK
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of these chairs. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
- Page 2 Table of Contents Table of Contents........2 Pre-Assembly.
- Page 3 Warranty 2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center.
- Page 4 Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M6x30 Combination Bolt M6x15 Combination Bolt M8x20 Combination Hex Bolt Hex Wrench Wrench PACKAGE CONTENTS Part Description Quantity Chair Bucket Left Arm Right Arm Support Bar Connection Bar Swivel Base...
- Page 5 Assembly Attaching The Left Arm To The Chair Bucket Place the left arm (B) upside down on a soft surface. Attach the left arm (B) to the chair bucket (A) using M6x30 combination bolts (AA). NOTE: Loosely tighten all the bolts using the hex wrench (DD). Attaching The Right Arm To The Chair Bucket Attach the right arm (C) to the chair bucket (A) using M6x30 combination bolts (AA).
- Page 6 Assembly (continued) Attaching The Connection Bar To The Arms Attach the connection bar (E) to the left arm (B) and right arm (C) using M6x15 combination bolts (BB). NOTE: Loosely tighten all the bolts using the hex wrench (DD). Attaching The Support Bar To The Chair Bucket Attach the support bar (D) to the chair bucket (A) using M8x20 combination hex bolts (CC).
- Page 7 Assembly (continued) Tightening All Bolts Once all of the bolts are in place, fully tighten the bolts using the hex wrench (DD) and wrench (EE). Insert the support bar (D) to the swivel base (F). Turn the chair right side up. Ensure all connections are secure before use.
- Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. For certification use only...
