THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive to continually create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
Warranty 3 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for three years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED Its remains the customer’s responsibility for freight and packaging charges to and from our service center.
Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M6x15 Combination Bolt M6x30 Combination Bolt 16+1 M6x25 Bolt Hex Wrench PACKAGE CONTENTS Part Description Quantity Left Arm Right Arm Sling Bucket Connector Bar Support Bar...
Assembly Attaching the Sling Bucket, Connector Bar and Support Bar to the Right Arm Place the right arm (B) on a soft surface. Attach the sling bucket (C) to the right arm (B) using M6x30 combination bolts (BB), as shown below. Attach the connector bar (D) to the right arm (B) using M6x15 combination bolts (AA).
Page 6
Assembly (continued) Securing the Support Bar Turn the chair right side up. Tighten the support bar (E) to the left arm (A) and right arm (B) using M6x25 bolts (CC). Do not tighten all bolts at this step. Tightening all Bolts Once all of the bolts are in place, fully tighten all the bolts using hex wrench (DD).
Care Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach or solvents. Store the chairs in a dry sheltered place when not in use.
Page 8
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. For certification use only...
