PIANO-Series
P
D
RODUCT
ESCRIPTION
These PIANO series units are extraordinarily compact, industrial
grade power supplies that focus on the essential features
needed in today's industrial applications. The excellent
cost/performance ratio presents many new and exciting
opportunities without compromising quality or reliability.
The mechanically robust housing is made of a high-grade,
reinforced molded material, which permits the units to be used
in surrounding temperatures up to 70°C.
Since typical industrial applications do not require multiple
mains inputs, the reduction to a regional input voltage range (AC
200-240V) simplifies the circuitry and has significant advantages
for reliability, efficiency and cost.
The addition of a DC-OK signal makes the unit suitable for many
industry applications such as: process, automation and many
other critical applications where preventive function monitoring
can help to avoid long downtimes.
O
N
RDER
UMBERS
Power Supply
PIC120.241C
PIC120.242C
Accessory
YR2.DIODE
UF20.241
Jun. 2023 / Rev. 1.7 DS-PIC120.241C-EN
All parameters are specified at 24V, 5A, 230Vac, 50Hz, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
with DC-OK relay contact
without DC-OK relay contact
Redundancy Module
Buffer Module
www.pulspower.com Phone +49 89 9278 0 Germany
PIC120.241C, PIC120.242C
24V, 5A, 120W, S
P
S
OWER
UPPLY
 AC 200-240V Regional Input
 Cost Optimized without Compromising Quality or Reliability.
 Width only 39mm
 Efficiency up to 90.5%
 Low No-load Power Losses
 Full Power Between -10°C and +55°C
 DC-OK Relay Contact Included
 3 Year Warranty
S
-
D
HORT
FORM
ATA
Output voltage
DC 24V
Adjustment range
24 - 28V
Output current
5 - 4.3A
3.1 - 2.7A
Derate between +60°C and +70°C
AC Input voltage
AC 200-240V
Mains frequency
50-60Hz
AC Input current
1.06A
Power factor
0.54
AC Inrush current
28A peak
Efficiency
90.5%
Losses
12.6W
Temperature range
-10°C to +70°C
Hold-up time
33ms
Dimensions
39x124x124mm
Weight
350g
M
A
AIN
PPROVALS
For details and the complete approval list, see chapter 19
UL 61010-2-201
P
I
INGLE
HASE
NPUT
nominal
factory setting 24.1V
below +60°C ambient
at +70°C ambient
±10%
±6%
at 40°C, cold start
Without DIN rail
Marine
Marine
1/22
