PIANO-Series
P D
RODUCT ESCRIPTION
The PIM60.125 is a DIN-rail mountable single-phase-
input power supply,
stabilized and galvanically separated SELV/PELV/ES1
output voltage.
The output fulfils the requirements for a limited power
source according to NEC CLASS 2.
The device is equipped with screw terminals, which are
optimized for large wire sizes.
The mechanically robust housing is made of a high-
grade, reinforced molded material, which permits
surrounding temperatures up to +70°C.
The PIANO family is a compact industrial grade DIN-rail
power supply series that focus on the essential features
needed in today's industrial applications. The excellent
cost/performance ratio does not compromise quality or
reliability.
O N
RDER UMBERS
Order number:
Power Supply PIM60.125
Jan. 2020 / Rev 0.1 DS-PIM60.125-EN All figures are typical values at 230Vac 50Hz input voltage, 12V 5A output load,
25°C ambient temperature and after a 5 minutes run-in time unless otherwise noted.
PRELIMINARY
which provides a floating,
www.pulspower.com Phone +49 89 9278 0
12V, 5A, 60W, S
P S
OWER UPPLY
100-240V Wide-range Input

NEC CLASS 2 Compliant

 Cost Optimized without Compromising Quality or
Reliability
Width only 36mm

 Efficiency up to 90.7%
Low No-load Power Losses

Full Power Between -10°C and +60°C

 Large Screw Terminals
3 Year Warranty

S - D
HORT FORM
Output voltage DC 12V
Adjustment range 12 – 15V
Output current 5.0 – 4.0A
3.8 – 3.0A
Derate linearly between +60°C and +70°C
Input voltage AC AC 100-240V
Mains frequency 50-60Hz
Input current AC 1.0 / 0.6A
Power factor 0.55 / 0.47
Input inrush current 15 / 36A peak
Efficiency 90.2 / 90.7%
Losses 6.5 / 6.2W
Hold-up time 23 / 107ms
Temperature range -10°C to +70°C
Size (W x H x D) 36x90x91mm
Weight 225g / 0.5lb
M A
AIN PPROVALS
For details and a complete approval list see chapter 18.
IEC 62368-1
Ind. Cont. Eq.
IIEC 61010-2-201
planned
Germany
PIM60.125
P I
INGLE HASE NPUT
ATA
Nominal
Factory setting 12V
Below +60°C ambient
At +70°C ambient
±10%
±6%
At 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac, 40°C,
cold start
At 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac
Without DIN-Rail
NEC CLASS 2
planned
planned
