Puls PIANO Series Manual

PIANO-Series
G D
ENERAL ESCRIPTION
These PIANO series units are extraordinarily compact,
industrial grade power supplies that focus on the
essential features needed
applications. The excellent
presents many new and exciting opportunities without
compromising quality or reliability.
The mechanically robust housing is made of a high-
grade, reinforced molded material, which permits the
units to be used in surrounding temperatures up to
70°C.
The unit is equipped with a wide-range input voltage
stage, which makes the unit suitable for global use.
The addition of a DC-OK signal makes the unit suitable
for many industry applications such as: process,
automation and many other critical applications where
preventive function monitoring can help to avoid long
downtimes.
O N
RDER UMBERS
Power Supply PIC240.241D
Accessory YR2.DIODE
UF20.241
Feb. 2017 / Rev. 1.4 DS-PIC240.241D-EN
All parameters are specified at 24V, 10A, 230Vac, 50Hz, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
in today's industrial
cost/performance ratio
24-28V Standard unit
with DC-OK contact
Redundancy module
Buffer module
www.pulspower.com Phone +49 89 9278 0
24V, 10A, S
P S
OWER UPPLY
AC 100-240V Wide-range Input
Active PFC
Cost Optimized without Compromising Quality or
Reliability.
Width only 49mm
Efficiency up to 95.2%
Full Power Between -25°C and +55°C
DC-OK Relay Contact
3 Year Warranty
S - D
HORT FORM
Output voltage DC 24V
Adjustment range 24 - 28Vdc
Output current 10A
6.25A
8.6A
5.4A
Output power 240W
150W
Output ripple < 100mVpp
AC Input voltage AC 100-240V
Mains frequency 50-60Hz
AC Input current 2.17A / 1.18A
Power factor 0.98 / 0.93
AC Inrush current 14A / 26A peak at 120 / 230Vac,
Efficiency 94.0% / 95.2%
Losses 15.3W / 12.1W
Temperature range -25°C to +70°C
Derating 6W/°C
Hold-up time typ. 32ms/ 32ms at 120 / 230Vac
Dimensions 49x124x124mm WxHxD
Weight 540g / 1.2lb
M
ARKINGS
IND. CONT. EQ.
UL 508
Germany
PIC240.241D
P I
INGLE HASE NPUT
ATA
at 24V, amb <55°C
at 24V, amb <70°C
at 28V, amb <55°C
at 28V, amb <70°C
ambient <55°C
ambient <70°C
20Hz to 20MHz
±10%
±6%
at 120 / 230Vac
at 120 / 230Vac
40°C
at 120 / 230Vac
at 120 / 230Vac
operational
+55 to +70°C
UL 60950-1
EMC, LVD
1/21
