Puls PIANO Series Manual

PIANO-Series
P D
RODUCT ESCRIPTION
The PIANO series units are extraordinarily compact
industrial grade DIN-rail power supplies that focus on
the essential features needed in today's industrial
applications. The excellent
presents many new and exciting opportunities without
compromising quality or reliability.
The mechanically robust housing is made of a high-
grade, reinforced molded material, which permits the
units to be used in surrounding temperatures up to
+70°C.
The PIM90.241 is equipped with push-in terminals,
which are optimized for automated wiring.
The unit is designed as "Class of Protection" II unit and
fulfills the safety and EMC requirements without an
input PE connection. This saves wiring costs.
O N
RDER UMBERS
Power Supply PIM90.241
Nov. 2018 / Rev. 0.1 DS-PIM90.241-EN
25°C ambient temperature and after a 5 minutes run-in time unless otherwise noted.
P R E L I M I N A R Y
cost/performance ratio
All figures are typical values at 230Vac 50Hz input voltage, 24V 3.8A output load,
www.pulspower.com Phone +49 89 9278 0
24V, 3.8A, 90W, S
P S
OWER UPPLY
100-240V Wide Range Input
Cost Optimized without Compromising Quality or
Reliability
No PE connection required
Width only 36mm
Efficiency up to 93.8%
Low No-load Power Losses
Full Power Between -10°C and +60°C
Push-In Terminals
3 Year Warranty
S - D
HORT FORM
Output voltage DC 24V
Adjustment range 24 – 28V
Output current 3.8 – 3.2A
2.8 – 2.4A
Derate linearly between +60°C and +70°C
Input voltage AC AC 100-240V
Mains frequency 50-60Hz
Input current AC 1.45 / 0.95A
Power factor 0.58 / 0.45
Input inrush current 18 / 40A peak
Efficiency 92.1 / 93.8%
Losses 7.9 / 6.0W
Hold-up time 25 / 119ms
Temperature range -10°C to +70°C
Size (W x H x D) 36x90x91mm
Weight 270g / 0.6lb
M A
AIN PPROVALS
For details and a complete approval list see chapter 18.
Germany
PIM90.241
P I
INGLE HASE NPUT
ATA
Nominal
Factory setting 24.1V
Below +60°C ambient
At +70°C ambient
±10%
±6%
At 120 / 230Vac
At 120 / 230Vac
At 40°C 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac
At 120 / 230Vac
Without DIN-Rail
Ind. Cont. Eq.
1/19
