Sea Acceptance Test
MS70
Scientific Multibeam Sonar
395234/K
kongsberg.com/ms70
373441/C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS70 and is the answer not in the manual?

Questions and answers

Related Manuals for Kongsberg MS70

Summary of Contents for Kongsberg MS70

  • Page 1 Sea Acceptance Test MS70 Scientific Multibeam Sonar 395234/K kongsberg.com/ms70 373441/C...
  • Page 3 The purpose of this Sea Acceptance Test is to verify the operational functionality of the MS70 system that can only be fully tested with the vessel at sea. The test assumes that the Harbour Acceptance Test has been previously done and accepted on the same MS70 system.

  • Page 4: Document Information

    Kongsberg Discovery disclaims any responsibility for damage or injury caused by improper installation, use or maintenance of the equipment. Disclaimer Kongsberg Discovery AS endeavours to ensure that all information in this document is correct and fairly stated, but does not accept liability for any errors or omissions. Support information If you require maintenance or repair, contact your local dealer.

  • Page 5: Table Of Contents

    TEST PROCEDURES..................13 Common prerequisites for the MS70 Sea Acceptance Test procedures......14 Turning on the MS70 Scientific multibeam sonar to start the test......... 14 Verifying the communication with a navigation system (GPS)........16 Verifying the communication with a synchronization system........17 Verifying the communication with the motion reference unit (MRU)......19...
  • Page 6 Kongsberg MS70 SECONDARY PROCEDURES................46 373441/C...

  • Page 7: Introduction

    The purpose of this Sea Acceptance Test is to verify the operational functionality of the MS70 system that can only be fully tested with the vessel at sea. The test assumes that the Harbour Acceptance Test has been previously done and accepted on the same MS70 system.

  • Page 8: Personnel And Location

    Referenced documents The installation and use of the MS70 is described in several documents and end user manuals. This list is not complete. Additional documents and end user manuals may be available for the MS70.
  • Page 9 Introduction Customer acceptance test procedures • : 110-0077914 Factory Acceptance Test • : 373439 Harbour Acceptance Test • : 373441 Sea Acceptance Test 373441/C...

  • Page 10: Hardware And Software Registration

    Verification of previously tested items Neither user interface software nor hardware units have been changed on this MS70 system since the Harbour Acceptance Test. For this reason, the registration tables have not been filled out.

  • Page 11: Software Items

    Hardware and software registration Software items Every software program provided as a part of the MS70 system delivery must be identified. Part number and software version must be identified. When the MS70 system delivery includes software media (USB flash drive, CD, DVD, etc.), you must register the part number of the media and the software version it contains.

  • Page 12: Hardware Items

    Display (Make and model) Part number Serial number Record the make, model and serial number for each unit provided with the MS70 delivery. If applicable, add the order number. You must write down the make, model, part number and serial number.
  • Page 13 Hardware and software registration Revision Serial number Transceiver Part number MS70 Transceiver 388547 The unit contains circuit boards or modules that you must identify separately. Observe the relevant hardware registration tables. This is the part number on the unit label.
  • Page 14 Kongsberg MS70 Sea Acceptance Test Transceiver boards Part number Revision Serial number (From right) Transceiver board (Type): LPT32 Transceiver board Ethernet switch Revision Serial number Make and model (Make and model) Part number You must write down the make, model, part number and serial number.

  • Page 15: Test Procedures

    Topics Common prerequisites for the MS70 Sea Acceptance Test procedures, page 14 Turning on the MS70 Scientific multibeam sonar to start the test, page 14 Verifying the communication with a navigation system (GPS), page 16 Verifying the communication with a synchronization system, page 17...

  • Page 16: Common Prerequisites For The Ms70 Sea Acceptance Test Procedures

    These are the common prerequisites for the MS70 Sea Acceptance Test procedures: • The MS70 system is installed as specified in the Installation Manual. • The sensor is connected to a communication port on the MS70 system. • The interface port is set up with the correct communication parameters.
  • Page 17 To detect unserviceable transducer elements and/or transceiver boards, you must compare the rectangles. During normal operation at sea the colours will be homogeneous. When operating the MS70 system in port, the colours will be less homogeneous due to the environmental noise and the shallow depth.

  • Page 18: Verifying The Communication With A Navigation System (Gps)

    (GPS) Accurate and reliable information from navigation systems are vital to the MS70 operation. The information provided by the navigation systems is used by the MS70 software. Navigational data are also included in the raw data export formats. The information from the navigation sensors are shown on the top bar.

  • Page 19: Verifying The Communication With A Synchronization System

    It can be set up to operate in either Master or Slave mode. Synchronization is required in order to avoid interference if the MS70 system is used simultaneously with other hydroacoustic instruments within the same frequency range. You do not need to do this test if the MS70 shall only operate in Standalone mode.
  • Page 20 Select Synchronisation Select synchronization mode. Select the synchronization delay. Make sure that the MS70 operates normally when triggered by the remote synchronization system. Make sure that the MS70 operates while additional hydroacoustic systems (sonars, echo sounders) are in synchronized operation.

  • Page 21: Verifying The Communication With The Motion Reference Unit (Mru)

    About this task The motion reference unit (MRU) measures the roll and pitch movements of the vessel. The information provided by the motion sensor is used by the MS70 system to stabilize the beams. This interface test was made during the Harbour Acceptance Test. However, that test was limited due to the static information provided by the sensor.

  • Page 22: Verifying The Communication And Data Import From A Fixed Sound Speed Sensor

    Baud rate Sound speed (fixed) Requirements Results The sensor is connected to a communication port on the Processing Unit. Sensor data is provided to and accepted by the MS70. Relevant communication parameters are recorded in the result table. Date/Signature: 373441/C...

  • Page 23: Verifying The Data Import From A Deployed Sound Speed Sensor

    Once the information has been collected, it is transferred to the Processing Unit on a suitable medium. Before you begin The MS70 system is turned on and operates normally. A CTD (conductivity, temperature and depth) sensor is available. For the relevant procedures, refer to the end-user documentation provided by the manufacturer.

  • Page 24: Recording Raw Data

    Sensor data is provided to and accepted by the MS70. Date/Signature: Recording raw data Use the raw data recording functionality provided by the MS70 systems to save echo data using the format. You can save the data to the hard disk, or onto an *.raw...

  • Page 25: Testing The Receiver Channels With The Bite Matrix Functionality

    Matrix each of the channels and transducer elements in the MS70 systems. The presentation is provided on a matrix corresponding to the element locations in the transducer. For receiver testing, the MS70 systems must be operational, and both operational and BITE parameters must be known.
  • Page 26 Kongsberg MS70 Sea Acceptance Test About this task When you move the cursor over the matrix presentation of the transceiver channels, each element in the transducer can be clearly identified as a rectangle. If you place the cursor on top of one of these rectangles, a small yellow tool-tip will identify key information.

  • Page 27: Testing The Transmitter Channels With The Bite Matrix Functionality

    Matrix functionality page allows you to monitor the average signal values or signal phases from Matrix each of the channels and transducer elements in the MS70 systems. The page Matrix offers a good tool for testing the transmitter and receiver circuitry. The presentation is provided on a matrix corresponding to the element locations in the transducer.
  • Page 28 Kongsberg MS70 Sea Acceptance Test About this task When you move the cursor over the matrix presentation of the transceiver channels, each element in the transducer can be clearly identified as a rectangle. If you place the cursor on top of one of these rectangles, a small yellow tool-tip will identify key information.
  • Page 29 Print the image in colour if the report is submitted on paper. Results Requirements Results The information presented by the page verifies that the MS70 is Matrix fully operational. The difference between neighbouring elements is less than 6 dB. Weak elements A screen capture of the page is archived.

  • Page 30: Testing The Receiver And Transmitter Channels With The Bite B-Scan Functionality

    The start sample and the number of samples to be displayed are selectable. Before you begin The MS70 systems are installed as specified in this manual. • The Harbour Acceptance Test has been done, and is approved. • The MS70 systems are turned on and operates normally.
  • Page 31 Print the image in colour if the report is submitted on paper. Results Requirements Results The information presented by the page verifies that the MS70 B-Scan system is fully operational. All elements are operational in both transmit and receive. The maximum number of bad elements is: 4.

  • Page 32: Recording Element Data

    Follow the procedure exactly as described in the steps. Incorrect settings in these dialog boxes may cause the MS70 to become unstable. 373441/C...
  • Page 33 Open the parameters in the dialog box. SMS BeamFormer Parameter Browser Press the key, and double-click the Kongsberg logo on the MS70 top Shift bar. Observe that the dialog box opens. Object Inspector Scroll down the list on the left side of the...

  • Page 34: Verifying Ms70 Operation With Different Beam Configurations

    The MS70 is provided with several pre-made beam configurations. Additional beam configurations can be created during normal use of the MS70 to fit specific survey requirements. It must be verified that the MS70 can operate satisfactory with the pre-made beam configurations.
  • Page 35 Results Beam Mode Results Comments Example 1 Section Uniform Weighting Test requirements Results The MS70 is operating satisfactory with all tested beam configurations. The tested beam configurations are recorded in the result table. No error messages are presented. Date/Signature: 373441/C...

  • Page 36: Verifying The Performance Of The Ms70 Scientific Multibeam Sonar Using The Calibration Functionality

    Kongsberg Discovery can supply a dedicated calibration sphere with suspension for TS calibration of the MS70 system. Note This task does not call for a complete calibration of the MS70. The calibration functionality is only used to test the MS70 performance. The following limitations are applied: •...
  • Page 37 Use the calibration functionality to test the performance of the MS70 Scientific multibeam sonar. This task does not call for a complete calibration of the MS70. The calibration functionality is only used to test the MS70 performance. The following limitations are applied: •...

  • Page 38: Verifying The Ms70 Accuracy

    The Sa correction is within range: ±2 dB Date/Signature: Verifying the MS70 accuracy The MS70 is designed for accuracy. To verify the accuracy for the calibrated beam configuration, the sphere is positioned at different locations, and the target strength is measured.

  • Page 39: Measuring Noise In Passive Operating Mode

    The Sa correction is within range: ±2 dB Date/Signature: Measuring noise in passive operating mode Low noise is a key factor for high quality and reliable measurements. The performance of the MS70 systems will always be limited by different noise sources.The noise is 373441/C...
  • Page 40 You must never set the MS70 system to ping unless the transducer is submerged in water. The transducer can be damaged if it transmits in the open air. • All relevant external sensors are connected to the MS70. The sensors are turned on and operate normally. • The vessel is at sea.

  • Page 41: Making A Noise/Speed Curve To Determine Vessel Noise

    Making a noise/speed curve to determine vessel noise The performance of the MS70 system will always be limited by different noise sources. During this test, noise measurements are done for different vessel speeds. The weather and sea conditions for the noise measurements will be those at the time of the test.
  • Page 42 Kongsberg MS70 Sea Acceptance Test If you record all the raw data during the noise test, you can repeat the test later using the replay file. You may then use more than five noise samples for each vessel speed to make a more accurate curve.
  • Page 43 Test procedures In the Numerical view, estimate the ranges to where the noise becomes visible. Record the values in the result table. Ask the bridge to set the next speed. Stop the recording. Save the data using a unique file name that identifies context, date, time and vessel.
  • Page 44 Kongsberg MS70 Sea Acceptance Test to 500. Start Averaging to 100. Averaging Range to Automatic. Scale to Height 24 pixels and Width 12 pixels. Element size in pixel to Current. Transmit pulse 16. Make a screen capture of the page.
  • Page 45 Test procedures Test requirements Results A noise/speed curve is created. Date/Signature: Use the following plot to record the noise values. 373441/C...
  • Page 46 Kongsberg MS70 Sea Acceptance Test +90 dB Noise/speed curve for 0° bearing and maximum gain Stable speed +86 dB Acceleration Retardation (CD015047E) +82 dB +78 dB +74 dB +70 dB +66 dB +62 dB +58 dB +54 dB +50 dB...

  • Page 47: Customer Acceptance Form

    Customer acceptance form Customer acceptance form Fill in and sign this form for formal acceptance of the MS70 Scientific multibeam sonar. The MS70 system is (tick relevant column): Accepted Accepted with comments Not accepted Vessel/Customer Place/Date Comments Test done by...

  • Page 48: Secondary Procedures

    The end user and technical documentation for the MS70 contains several procedures that are also applicable for this Sea Acceptance Test. These procedures are not part of the Sea Acceptance Test. For more information, refer to the MS70 Reference Manual and/or the MS70 On-line help.
  • Page 50 ©2025 Kongsberg Discovery AS...
