Page 1 Installation Manual ME70 / MS70 Scientific Multibeam Systems 110-0059233/C kongsberg.com/me70 kongsberg.com/ms70...
Page 3 For information about the practical use of the ME70 and MS70 systems, refer to the Reference Manual or the Operator Manual. You can also find information in the context-sensitive online help.
Page 4: Document Information
Kongsberg Discovery disclaims any responsibility for damage or injury caused by improper installation, use or maintenance of the equipment. Disclaimer Kongsberg Discovery AS endeavours to ensure that all information in this document is correct and fairly stated, but does not accept liability for any errors or omissions. Support information If you require maintenance or repair, contact your local dealer.
Page 5: Table Of Contents
Installation Manual Table of contents ABOUT THIS MANUAL..................9 KONGSBERG ME70 AND MS70..............11 Important........................11 ME70 – System description.................... 13 Key features......................14 MS70 – System description.................... 15 Key features......................16 System diagram......................18 System units........................19 Display – description................... 19 Computer –...
Page 6 Kongsberg ME70 and MS70 Tools, equipment and consumables required for installation........36 Personnel qualifications....................37 Installation principles......................37 Sonar room requirements....................41 About the sonar room..................41 Environmental requirements................41 Requirements for watertight integrity..............42 Size and access requirements................43 Requirements for insulation, heating and ventilation......... 43 Requirements for electrical installations, cables and communication....
Page 7 Prerequisites for cable installation..............111 Installing the topside cables................112 Installing the transceiver cables................ 114 Connecting the transducer cables to the transceiver........118 Setting up the ME70 and MS70 systems for synchronized operation....124 Connectors........................131 Processing Unit rear connectors (HTS41x11)............ 132 Moxa CP114EL-I overview.................... 133...
Page 8 Dimensional survey accuracy requirements..............160 Vessel coordinate system....................161 SETTING TO WORK..................164 Setting to work summary....................164 Inspecting the installation of the ME70 and MS70 systems......... 165 Common prerequisites for the ME70 and MS70 Installation Manual visual inspection procedures..................166 Inspecting logistic items..................167 Performing a visual inspection of the display............167...
Page 9 Installation Manual Making sure that all ME70 and MS70 system cables are properly connected.. 174 Turning on the ME70 and MS70 systems for the first time.......... 176 Turning on the ME70 and MS70 systems............176 Inserting the installation parameters................178 About the installation parameters..............178...
Page 10 Kongsberg ME70 and MS70 MS70 – Configuration settings................228 Power requirements..................... 229 Display – power requirements................229 Processing Unit – power requirements............. 229 Transceiver Unit – power requirements............229 Weights and outline dimensions.................. 231 Display – weight and outline dimensions............231 Processing Unit –...
Page 11: About This Manual
About this manual About this manual The purpose of this publication is to present the descriptions, procedures and basic drawings required to install the ME70 and MS70 Scientific multibeam echo sounder and sonar. Target audience The publication is intended for technical personnel such as skilled shipyard and factory workers, electricians, qualified engineers, and naval architects.
Page 12: Online Information
Note If required, all documents provided by the shipyard for the physical installation of the ME70 and MS70 systems must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. Such approval must be obtained before the installation can begin. The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval.
Page 13: Kongsberg Me70 And Ms70
When the ME70 and MS70 systems are not used When you do not use the ME70 and MS70 systems, turn it off. If you are using a drop keel, make sure to retract it. Note You must never turn off the ME70 and MS70 systems by means of the on/off switch on the Processing Unit.
Page 14 When you are docking your vessel You must never turn on the ME70 and MS70 systems when the ship is in dry dock. The transducer can be damaged if it transmits in the open air. To prevent inadvertent use of the ME70 and MS70 systems, pull out the mains plug on the Processing Unit whenever your vessel is in dry dock.
Page 15: Me70 - System Description
The ME70 is a high-resolution scientific multibeam echo sounder with very low sidelobe levels. It is designed for collection of data from the water column. The ME70 combines the large and flexible sampling volume of the multibeam swath with the accuracy of the quantitative scientific echo sounder.
Page 16: Key Features
Kongsberg ME70 and MS70 Installation Manual Key features The ME70 is a high-resolution scientific multibeam echo sounder with very low sidelobe levels. It offers unique features for modern research vessels and environmental monitoring installations that require high-quality scientific data. • Transceiver operation control •...
Page 17: Ms70 - System Description
Kongsberg ME70 and MS70 individual beams, you can also see split-beam information, such as fish size, from each individual beam. MS70 – System description The MS70 is a high-resolution scientific multibeam sonar with very low sidelobe levels. It is designed for collection of data from the water column. The MS70 offers a new dimension to fishery research.
Page 18: Key Features
Kongsberg ME70 and MS70 Installation Manual Key features The MS70 is a high-resolution scientific multibeam sonar with very low sidelobe levels. It offers unique features for modern research vessels and environmental monitoring installations that require high-quality scientific data. • Acoustic matrix containing 500 beams (25 horizontal and 20 vertical); each beam is 3°...
Page 19 Kongsberg ME70 and MS70 A typical screen capture is provided. An echogram view is provided on the left side of the presentation. A horizontal and vertical view of the fan is provided on the right side of the presentation. In the middle, a zoom view of the two fans is provided.
Page 20: System Diagram
Kongsberg ME70 and MS70 Installation Manual System diagram The system diagram identifies the main components of the ME70 and MS70 systems. Only the main connections between the units are shown. Detailed interface capabilities and power cables are not shown. Display (The second display is optional.)
Page 21: System Units
Transducer – description, page 21 Display – description A display is a required part of the ME70 and MS70 systems. For best readability, the display must be protected from glare and have the correct height and angle. Any commercial display can be used with the ME70 and MS70 systems, provided that the chosen display meets the minimum requirements.
Page 22: Transceiver - Description
The Processing Unit is designed for rugged maritime use. It has been customized by Kongsberg Discovery. Except for the fans, the computer contains no moving parts. The computer is based on a commercial design, but the software and hardware have been specified by Kongsberg Discovery to meet the ME70 and MS70 requirements.
Page 23: Transducer - Description
• Air circulation fans Transducer – description The Kongsberg ME70 and MS70 transducer is a short cylindrical container with 800 transducer elements. The transducer elements are located at the "bottom" of the transducer. The transducer cables are provided as 25 individual cables in three bundles.
Page 24 As an option, Kongsberg can provide the transducer with each cable in a protective hose. These hoses start inside the transducer. Protection can be used along the entire length of the cables, and all the way up to where the cables penetrate the bulkhead to where the transceiver is installed.
Page 25: Scope Of Supply
Additional optional items, page 26 Basic items provided with a standard delivery To assemble the complete ME70 and MS70 systems you need all the system units. The main units you need are provided with the standard delivery. Some items are optional.
Page 26: Additional Required Items
These items must be added to the ME70 and MS70 systems for full operational functionality. The additional items can be provided by Kongsberg Discovery. You can order them with the other basic ME70 and MS70 items. You can also purchase these items from your dealer, agent or local supplier.
Page 27: Global Positioning System (Gps)
: The output AC voltage must be a sine wave. Output form Global Positioning System (GPS) The ME70 and MS70 systems require input from a global positioning system (GPS) to determine the vessel's current geographical position and if necessary also speed information.
Page 28: Additional Optional Items
The ME70 and MS70 systems support the use of multiple displays, with a maximum of three. You may find it useful to have more than one display connected to the ME70 and MS70 systems. The number of displays must be chosen to fit the preferences of the crew.
Page 29: General Safety Rules
Observe and follow these safety precautions during all installation and maintenance work. WARNING The ME70 and MS70 systems operate on 115 VAC and/or 230 VAC at 50/60 Hz. This voltage is lethal! You must never work alone on high- voltage equipment!
Page 30: Installation Requirements
Navigation input requirements Observe the following input requirements from the ship navigation system to the ME70 and MS70 systems. The following input is required to achive the best performance of the ME70 and MS70 systems. • Position of the ship It can be provided both on serial line or network.
Page 31: Uninterruptible Power Supply (Ups) - Requirements
The Uninterruptible Power Supply (UPS) must have the capacity to independently maintain power to the ME70 and MS70 system for a minimum of 10 minutes. This allows you to turn off the ME70 and MS70 systems in a controlled manner in the event of a power failure.
Page 32: Transceiver Installation Requirements
Drawing file chapter in this manual. It can also be downloaded from our website. Compass deviation requirements ME70 and MS70 units that are installed on the bridge may have an effect on the compass. Once the installation is complete, the vessel must be swung with the ME70 and MS70 system in both operative and inoperative modes.
Page 33: Network Security
Kongsberg ME70 and MS70 Network security If the ME70 and MS70 systems are connected to a local area network, data security is important. Equipment manufactured by Kongsberg Discovery is often connected to a local area network (LAN). When you connect a computer to a local area network you will always expose the data on that computer.
Page 34: Support Information
Kongsberg ME70 and MS70 Installation Manual Support information If you need technical support for your ME70 and MS70, you must contact your local dealer, or one of our support offices. A list of all our offices and dealers is available on our website.
Page 35: Preparations
Preparations Preparations Installation summary Installation of the ME70 and MS70 systems is a demanding task that requires careful preparations, a number of specific procedures, wiring and required system settings. About this task An overall installation procedure is provided. This procedure does not describe any detailed tasks.
Page 36 62 Install the ME70 and MS70 system units. Note that some ME70 and MS70 system units may be commercial. Unless ordered specifically these are not included in the delivery, and must be purchased locally. Installing the system units...
Page 37 Cable layout and interconnections on page 104 Turn on the ME70 and MS70 systems for the first time, and set it to work. Note You must read and follow all the relevant procedures to turn on the ME70 and MS70 systems safely and correctly.
Page 38: About Installation Drawings
Note If required, all documents provided by the shipyard for the physical installation of the ME70 and MS70 systems must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. Such approval must be obtained before the installation can begin. The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval.
Page 39: Personnel Qualifications
Observe the relevant rules and regulations related to welding. Installation principles Basic installation principles apply for the ME70 and MS70 units. A drop keel is a superior platform for the ME70 and MS70 transducer. The other main units are...
Page 40 A. Transceiver The ME70 and MS70 Transceiver Unit is housed in a 19-inch instrument rack. Easy access to the front and rear of the rack is essential for smooth replacement of parts.
Page 41 The Uninterruptible Power Supply (UPS) must have the capacity to independently maintain power to the ME70 and MS70 systems for a minimum of 10 minutes. This allows you to turn off the ME70 and MS70 systems in a controlled manner in the event of a power failure.
Page 42 Kongsberg ME70 and MS70 Installation Manual G. Steel conduit H. At the bottom of the drop keel, the ME70 and MS70 transducer can be installed with the transducer face flushed with the horizontal plating. The mounting ring is welded to the hole prepared for the transducer. Screws through the clamping ring into the mounting ring secure the transducer in place.
Page 43: Sonar Room Requirements
Make sure that installation or maintenance of other equipment in the sonar room does not affect the ME70 and MS70 system units. The use of heavy tools in the sonar room must be avoided. This includes welding equipment, saws, hammers or similar hand or electrical equipment.
Page 44: Requirements For Watertight Integrity
Kongsberg ME70 and MS70 Installation Manual recommended that you keep the ambient temperature between +5 and +40°C, and the relative humidity less than 80%. The Mean Time Between Failure (MTBF) will increase if these limits are exceeded. Observe the environmental specifications related to each unit.
Page 45: Size And Access Requirements
Preparations Size and access requirements A well designed sonar room with a well fitted size and easy access reduces the risk of corrosion, and simplifies maintenance. This increases system reliability. Note The physical size of the sonar room must be limited, so that in the event of a major leak, the flooding of the room will not induce instability, or cause the vessel to capsize or sink.
Page 46: Requirements For Electrical Installations, Cables And Communication
Kongsberg ME70 and MS70 Installation Manual Insulation requirements The insulation in the sonar room should be the minimum equivalent of 50 mm of rock-wool. Piping passing through the space prone to condensation must be properly insulated. Heating requirements Heating is an effective method for reducing humidity. The heater in the sonar room must be dimensioned to maintain the equipment within its environmental tolerances.
Page 47: Requirements For Bilge Pump And Decking
Proper vessel ground must be provided. Cabling requirements The sonar room units are connected to other ME70 and MS70 units located in different compartments on the vessel. The units may also be connected to peripheral devices. If these cables pass through hatches or areas where they may be damaged, they must be run in conduits.
Page 48 Kongsberg ME70 and MS70 Installation Manual of the compartment, and/or in other locations where the water will gravitate to first. Inspect the bilge sensors periodically. Decking requirement Once the installation has been completed, the sonar room must be suitably decked without restricting access to the equipment and the cables.
Page 49: Where To Install The Transducer
Introduction to transducer position The type of scientific multibeam system determines the position of the transducer. In the ME70 system, the transducer must be installed so that the transducer face points down towards the sea bottom. In the MS70 system, the transducer face must point horizontally to the side.
Page 50: Flow Noise
At that depth, the water is free of air bubbles up, even during very high sea states. At the bottom of the drop keel, the ME70 and MS70 transducer can be installed with the transducer face flushed with the horizontal plating.
Page 51: Avoid Protruding Objects Near The Transducer
Preparations Related topics Installation summary on page 33 Installation principles on page 37 Where to install the transducer on page 47 Preparations on page 33 Sonar room requirements on page 41 Avoid protruding objects near the transducer Objects protruding from the hull will generate turbulence and flow noise. This will reduce the overall performance of your system.
Page 52: Keep The Transducer Far Away From The Propellers
Kongsberg ME70 and MS70 Installation Manual A. Turbulent flow B. Laminar flow C. Air bubbles Air bubbles absorb and reflect the sound energy, and they may in worst cases block the sound transmission altogether. The boundary layer increases in thickness when it becomes turbulent. The boundary layer is thin in the forward part of the vessel hull, and increases as it moves aft.
Page 53: Mount The Transducer At A Safe Distance From Bow Thruster(S)
When in operation, the noise and cavitation bubbles created by the thruster may make your ME70 and MS70 transducer useless, almost no matter where it is installed. When the bow thrusters are not in operation, the tunnel creates turbulence. If your vessel is pitching, the tunnel may be filled with air or aerated water in the upper position and release this in the lower position.
Page 54: Summary And General Recommendations
Kongsberg ME70 and MS70 Installation Manual Summary and general recommendations Some of the installation guidelines provided for transducer location may be conflicting. For this reason, each vessel must be treated individually in order to find the best compromise. In general, the most important factor is to avoid air bubbles in front of the transducer face.
Page 55: Acoustic Noise
Preparations Acoustic noise As with any other hydroacoustic systems, the quality of the ME70 and MS70 echo data and presentations are subject to unwanted acoustic noise. The echoes from any large and small target must be detected inside the noise.
Page 56 Kongsberg ME70 and MS70 Installation Manual during operation. As for the target properties, there is nothing any of us can do with those. The signal-to-noise ratio, however, can be improved by making the correct choices during installation. Signal-to-noise ratio (often abbreviated SNR or S/N) is a measure used in science and engineering that compares the level of a desired signal to the level of background noise.
Page 57: Self Noise
Preparations • Propeller noise • Flow noise • Acoustic noise from other hydroacoustic systems B. The transducer cable is long. Electric noise from generators, pumps, cooling systems and other electric or electromechanical devices is easily picked up. C. The preamplifiers are very sensitive. They can easily pick up electrical noise from internal and external power supplies.
Page 58: Propeller Noise
Kongsberg ME70 and MS70 Installation Manual International regulations and certifications are used to control and reduce this, but even these are limited if the electrical systems are poorly installed and/or maintained. Propeller noise Propeller noise is often the main source of noise at higher vessel speeds. Variable pitch propellers or fast moving propellers usually make more noise than fixed propellers or slow moving propellers.
Page 59 Preparations Turbulent flow Laminar flow Air bubbles Air bubbles absorb and reflect the sound energy, and they may in worst cases block the sound transmission altogether. The boundary layer increases in thickness when it becomes turbulent. The boundary layer is thin in the forward part of the vessel hull, and increases as it moves aft. The thickness depends on ships speed and on the roughness of the hull.
Page 60: Ambient Noise
Kongsberg ME70 and MS70 Installation Manual Related topics Installation summary on page 33 Installation principles on page 37 Preparations on page 33 Acoustic noise on page 53 Ambient noise Ambient noise is usually not a limiting factor to the performance of sonars and echo sounders.
Page 61: Electrical Self Noise
Preparations Related topics Installation summary on page 33 Installation principles on page 37 Acoustic noise on page 53 Preparations on page 33 Electrical self noise Electrical or electronic self noise is picked up or generated in any other part of the equipment than the transducer.
Page 62 Kongsberg ME70 and MS70 Installation Manual Reducing flow noise The shape of the transducer (or dome around it) must be as streamlined as possible. The hull plating in front of the transducer must be as smooth as possible. Important: Be especially aware of bilge keels and sacrificial anodes.
Page 63: Reducing Electrical Noise
(for example the K-Sync) should be considered. Reducing electrical noise These points must all be considered to reduce electrical noise in the ME70 and MS70 systems. • Place the transducer cables in a metal conduit all the way from the transducer to the transceiver.
Page 64: Installing The Transducer
Transducer description The Kongsberg ME70 and MS70 transducer is a short cylindrical container with 800 transducer elements. The transducer elements are located at the "bottom" of the transducer. When the transducer is mounted, the elements are facing down towards the seabed.The transducer cables are provided as 25 individual cables in three bundles.
Page 65 A mounting ring must be welded to the lower blister plate. A clamping ring is then inserted from the bottom and up. The transducer is secured with twelve -12- M12 bolts through the clamping ring, and fastened to the mounting ring. Both rings may be supplied with the ME70 and MS70 system delivery. Note An accurate measurement of the final position and angular orientation of the transducer is always required after installation.
Page 66: Sacrificial Anodes
Kongsberg ME70 and MS70 Installation Manual Sacrificial anodes The transducer is provided with three sacrificial zinc anodes. These are mounted on its top surface (lid). The sacrificial anodes must be replaced when 1/3 of their bodies have been spent. If it is difficult to access the zinc anodes after the transducer has been installed, additional anodes must be mounted inside the blister.
Page 67 Installing the transducer Rules for transducer handling Observe these transducer handling rules: • Do not activate the transducer when it is out of the water. • Do not expose the transducer to direct sunlight or excessive heat. • Do not use high-pressure water, sandblasting, metal tools or strong solvents to clean the transducer face.
Page 68: Transducer Installation Principles
It can also be mounted using a suitable hole in the hull plating. If your vessel is fitted with a drop keel, this is a superior platform for the ME70 and MS70 transducer. Drop keels are often used on larger research vessels. A drop keel will frequently protrude as far as three meters below the hull.
Page 69 A typical streamlined blister is shown as an example. A common blister can be used to contain both the ME70 and MS70 transducer as well as transducers for other acoustic systems. If many acoustic systems are used simultaneously, due care must be taken to prevent acoustic interference between the different instruments.
Page 70: Using A Drop Keel
Kongsberg ME70 and MS70 Installation Manual Using a drop keel A drop keel is a superior platform for the ME70 and MS70 transducer. Drop keels are often used on larger research vessels. A drop keel will frequently protrude as far as three meters below the hull.
Page 71 Installing the transducer Provide enough slack for maintenance and replacement purposes. Minimum two meters of cable must always be available for installation inside the Transceiver Unit. Once the transducer is positioned, the transducer cables - with the transceiver plugs - must be pulled through the steel conduit.
Page 72: Inclination Angle
As an option, Kongsberg can provide the transducer with each cable in a protective hose. These hoses start inside the transducer. Protection can be used along the entire length of the cables, and all the way up to where the cables penetrate the bulkhead to where the transceiver is installed.
Page 73 Installing the transducer Note The protective is hose is fitted to the transducer cables during the production. For this reason, the length of the hose must be specified when you order the transducer. The transducer cable must be properly fastened at the bottom of the drop keel. They must be fully supported while lowering and hoisting the drop keel.
Page 74: Transducer Installation Summary
Transducer installation summary The installation of the ME70 and MS70 transducer requires careful planning and preparations. It is a key task for successful use of the ME70 and MS70 systems. An overall installation procedure is provided. This procedure does not describe any detailed tasks.
Page 75 Installing the transducer • Vessel drawings • Best practice • Relevant literature • Shape and properties of vessel hull Make sure that all possible considerations are made to reduce noise. Installation principles with retractable keel Where to install the transducer Determine the installation method.
Page 76: Designing, Manufacturing And Mounting The Installation Blister
Kongsberg ME70 and MS70 Installation Manual Unpack the transducer from its transport crate. Unpacking the transducer from its transport crate on page 76 Position the mounting ring in the hole prepared for it, and weld it in place. Installing the mounting ring on page 79 Position the transducer under the mounting location.
Page 77 The installation shipyard must provide all necessary design and installation drawings, as well as the relevant work standards and mounting procedures. If required, all documents provided by the shipyard for the physical installation of the ME70 and MS70 systems must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society.
Page 78: Unpacking The Transducer From Its Transport Crate
62 Unpacking the transducer from its transport crate The ME70 and MS70 transducer is shipped in a wooden box. Prior to installation, the transducer must be unpacked from its box, and placed under the mounting location. Before you begin You must be equipped with a standard set of tools.
Page 79 Installing the transducer About this task The transport crate has two rooms. One room is used to house the transducer. The other room holds the cables. transducer is placed with its "face" facing down. It rests on a protective (CD010101_203_001) cushion The three M10 lifting eye bolts are inserted into these threaded holes.
Page 80 Kongsberg ME70 and MS70 Installation Manual A. Wooden protective plate (for the transducer face) B. Wooden beams with height minimum 15 cm C. Clamping ring Procedure Prepare a cart or any other type of suitable transport vehicle. 15 cm Ensure that all relevant protection is used to prevent damage to the transducer.
Page 81: Installing The Mounting Ring
The mounting ring has been designed to offer a reliable and maintenance friendly installation method for the ME70 and MS70 transducer. You can use the mounting ring in a suitable hole in a blister, in a keel box, through the hull plating, or in a drop keel.
Page 82 To ensure laminar flow, the transducer face must be tilted slightly upwards to meet the water flow. This allows the flowing water to meet the face directly, and reduces laminar noise. Recommended inclination angle for the ME70 and MS70 transducer face is: 2° (Approximately) Note Ensure that you do not mount the transducer with a negative inclination angle.
Page 83: Lifting The Transducer Up Towards Its Mounting Location
Installing the transducer Related topics Installing the transducer on page 62 Lifting the transducer up towards its mounting location Once the transducer has been unpacked, it must be safely transported to the mounting location under the hull. A secure location must be found for the transducer while the cables are pulled up through the steel conduit.
Page 84 Kongsberg ME70 and MS70 Installation Manual A. Wooden protective plate (for the transducer face) B. Wooden beams with height minimum 15 cm C. Screws through the clamping ring into the mounting ring secure the transducer in place. D. Clamping ring 15 cm E.
Page 85: Installing The Transducer Cables
Installing the transducer Installing the transducer cables When the transducer has been placed under the mounting location, the cables can be pulled through the steel conduit up to the transceiver. Before you begin Before you can do this task, the following prerequisites must be met: •...
Page 86 Kongsberg ME70 and MS70 Installation Manual A. Steel conduit B. Watertight seal C. The cables must be permitted to move freely when the drop keel is lowered and hoisted. Depending on the drop keel design, the cable slack can be kept on the outside of the drop keel, or inside.
Page 87: Installing The Transducer Into The Mounting Ring
Installing the transducer Make sure the steel conduits, cable ducts and/or pipes used to secure the cables do not have sharp edges or protruding items that may cause damage. Verify that enough slack is provided for the cables to allow for maintenance and replacements.
Page 88 Kongsberg ME70 and MS70 Installation Manual About this task This transducer is designed to be mounted using a clamping ring and a mounting ring. The mounting ring is welded to the hole prepared for the transducer. Screws through the clamping ring...
Page 89: Determining The Transducer Location And Installation Angles
Installing the transducer Mount the transducer using stainless steel bolts. Use bolts M12x55, stainless steel, A4 Class 80. Bolts and washers are included with the clamping ring. Apply Loctite 270 to secure the bolts. Use the following maximum torque: 76 Nm Once you have secured the transducer, conduct a thorough visual inspection of the plating around the transducer face.
Page 90 Kongsberg ME70 and MS70 Installation Manual system. Modest accuracy requirements apply when the ME70 and MS70 systems are only used to investigate objects in the water column. Determining the relative positions and orientations of the sensors and the transducer with high accuracy is important. This requires professional land surveying done by qualified and trained surveyors using proven survey equipment and methods.
Page 91: Painting The Transducer Face
The use of anti-fouling paint will reduce the acoustical performance of the transducer. The properties of the transducer face combined with the thickness of the anti-fouling paint can also affect the overall performance. Kongsberg Discovery cannot be held responsible for any negative consequences of the anti-fouling paint.
Page 92: Rules For Transducer Handling
Kongsberg ME70 and MS70 Installation Manual Abrade the transducer surface using a sanding paper with 240 inch grit size. Note Do not exceed a surface roughness (R ) of 35 microns as this can influence the transducer performance. Remove all dust.
Page 93: Approved Anti-Fouling Paints
The use of anti-fouling paint will reduce the acoustical performance of the transducer. The properties of the transducer face combined with the thickness of the anti-fouling paint can also affect the overall performance. Kongsberg Discovery cannot be held responsible for any negative consequences of the anti-fouling paint.
Page 94 Kongsberg ME70 and MS70 Installation Manual Important: Do not paint the transducer with traditional hull plating paint. Use only the correct type of approved paint specified. Do not use high-pressure water, sandblasting, metal tools or strong solvents to clean the transducer face.
Page 95: Installing The System Units
Installing the display A display is a required part of the ME70 and MS70 systems. For best readability, the display must be protected from glare and have the correct height and angle. The display is normally not included with the ME70 and MS70 systems delivery. A generic procedure is provided.
Page 96: Installing The Processing Unit
Kongsberg ME70 and MS70 Installation Manual Make sure that adequate ventilation is available to avoid overheating. Make sure that the installation method allows for the physical vibration, movements and forces normally experienced on a vessel. Note To allow future maintenance, you must mount the unit with its cables and connectors available for easy access.
Page 97 Installing the system units A. The bottom plate is mounted with six bolts through the computer chassis. B. Each rail provides two holes for mounting to a flat surface. C. Remove this bolt to release the rail from the bottom plate. About this task If you intend to mount the Enix Processing Unit in a 19”...
Page 98: Preparing The Transceiver Unit Installation
Preparing the transceiver unit installation The ME70 and MS70 Transceiver Unit is housed in a 19-inch instrument rack. Easy access to the front and rear of the rack is essential for smooth replacement of parts. In order to reduce the loss in the transducer cables, the Transceiver Unit must be located as close to the transducer as possible.
Page 99 Welding must only be done by a certified welder. If required, all documents provided by the shipyard for the physical installation of the ME70 and MS70 systems must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. Such approval must be obtained before the installation can begin.
Page 100 Kongsberg ME70 and MS70 Installation Manual A. U-shaped profiles B. Cable tray C. The grounding cable is a special braided wire that is physically connected to the cabinet. D. Bulkhead support bracket The Transceiver Unit must be connected to AC mains, and it must be properly grounded.
Page 101: Installing The Transceiver
Installing the system units • Make sure that the installation does not cause problems with existing cabling, ventilation ducts, piping, etc. • Make sure that enough space is made available for maintenance purposes. • Make sure that adequate ventilation is available to avoid overheating. •...
Page 102 Kongsberg ME70 and MS70 Installation Manual Before you can do this task, the following prerequisites must be met: • The U-shaped profiles are installed. • The cable tray is installed. Note Observe the installation principles. Installation principles with retractable keel About this task The Transceiver Unit is heavy.
Page 103: Installing The Uninterruptible Power Supply (Ups)
Uninterruptible Power Supply (UPS) must have the capacity to independently maintain power to the ME70 and MS70 systems for a minimum of 10 minutes. This allows you to turn off the ME70 and MS70 systems in a controlled manner in the event of a power failure.
Page 104 : The output AC voltage must be a sine wave. Output form Note Uninterruptible power supply units are not included in the standard ME70 and MS70 systems delivery. These items must be purchased locally. Procedure Prepare the location and the necessary tools.
Page 105 Installing the system units • Make sure that the installation method allows for the physical vibration, movements and forces normally experienced on a vessel. Make sure that the chosen location meets the installation requirements. For a complete installation procedure, refer to the relevant documentation provided by the manufacturer.
Page 106: Cable Layout And Interconnections
Drawings are generally not provided for standard commercial cables. Cables fall into three categories. System cables System cables are provided by Kongsberg Discovery as a part of the delivery. Shipyard cables Shipyard cables must be provided by the shipyard doing the installation, or the shipowner.
Page 107 Observe the relevant regulations and work standards. Always leave enough cable slack close to system units and cabinets to allow for maintenance. Only skilled and authorized personnel can install the ME70 and MS70 cables. Kongsberg Discovery accepts no responsibility for damage to the system, or reduced operational performance, when this is caused by improper wiring.
Page 108: List Of Cables
Kongsberg ME70 and MS70 Installation Manual List of cables A set of cables is required to connect the system units to each other, and to the relevant power source(s). Cable Signal From/To Minimum requirements AC Power cable From uninterruptible power 2 x 1.5 mm...
Page 109 Comments The ME70 and MS70 systems are often a part of a project delivery. For such deliveries, specific project cable drawings are established to show all the main cables, and how the various products are connected. In such project cable drawings, the ME70 and...
Page 110: Cable Plans
AC mains power, and to external devices. The sonar room cables include those used to connect the ME70 and MS70 units to AC mains power, as well as the control cables between the units.
Page 111 From computer to external device(s) Cables identified with an asterisk (*) are system or commercial cables. These cables are supplied with the ME70 and MS70 delivery. It is very important that a high-quality Ethernet cable is used. You must use Cat 5e STP (Shielded Twisted Pair) quality or better.
Page 112: Sonar Room Cable Plan
Kongsberg ME70 and MS70 Installation Manual Sonar room cable plan The sonar room cables include those used to connect the ME70 and MS70 units to AC mains power, as well as the control cables between the units. Two high capacity Ethernet cables connect the computer to the transceiver.
Page 113: Ip Addresses In The Me70 And Ms70 Systems
Cable layout and interconnections IP addresses in the ME70 and MS70 systems The communication between the ME70 and MS70 units is made using high speed Ethernet. Each port on each system unit has a dedicated IP address. Processing Unit •...
Page 114: Installing The Topside Cables
Only skilled and authorized personnel can install the ME70 and MS70 cables. Kongsberg Discovery will not accept any responsibility for errors, malfunctions or damage to system or personnel caused by improper wiring.
Page 115 Cable layout and interconnections Rear panel connections PC Ground cable Connect the video cable from the computer to the display. (C7) The display cable is often physically attached to the display, and terminated in the “computer end” with a male connector. If the cable is not attached, it is normally provided with the display.
Page 116: Installing The Transceiver Cables
111 Installing the transceiver cables The transceiver cables include those used to connect the ME70 and MS70 units to AC mains power, as well as the control cables between the units. Two high capacity Ethernet cables connect the computer to the transceiver.
Page 117 Cable layout and interconnections Procedure Connect the ground cable. Connect the cable with a M8 ring lug to the bolt on the side panel of the cabinet. These cables must be provided by the installation shipyard. Ground cable on page 142 Connect the power cable from each Power Supply Unit to the power outlet on the uninterruptible power supply (UPS).
Page 118 Kongsberg ME70 and MS70 Installation Manual Connect the 230 V L and N to the white circuit breaker from the input side on the lower end, and connect PE to the PE bar inside the circuit breaker box. Connect the Ethernet cable from the Processing Unit to the network patch box in the Transceiver Unit.
Page 119 As an option, Kongsberg can provide the transducer with each cable in a protective hose. These hoses start inside the transducer. Protection can be used along the entire length of the cables, and all the way up to where the cables penetrate the bulkhead to where the transceiver is installed.
Page 120: Connecting The Transducer Cables To The Transceiver
Kongsberg ME70 and MS70 Installation Manual Connecting the transducer cables to the transceiver The transducer cables are permanently connected to the transducer. On the other end, each cable is terminated with a large connector. The connectors are plugged in on the transducer interface boards on the rear side of each TRXU subrack.
Page 121 Cable layout and interconnections cable pair is colour-coded.It is very important that the transducer cables are connected to the correct sockets! Pair Pin numbers Cable colours White Brown Green Yellow Grey Pink Blue Black Violet Grey/Pink Red/Blue White/Green Brown/Green White/Yellow Yellow/Brown White/Grey Grey/Brown...
Page 122 Kongsberg ME70 and MS70 Installation Manual Pair Pin numbers Cable colours White/Grey Grey/Brown White/Pink Pink/Brown White/Blue Brown/Blue Related topics Installing the ME70 and MS70 cables on page 111 Termination The transducer cables are permanently connected to the transducer. On the other end, each cable is terminated with a large connector.
Page 123: Cable Limitations
(logical) It is very important that the transducer cables are connected to the correct sockets! Related topics Installing the ME70 and MS70 cables on page 111 Cable limitations You must always handle the transducer cable with great care. Observe the physical limitations.
Page 124 Each tool must be provided in various sizes. We recommend that all tools are demagnetized to protect your equipment. About this task The transducer cables are provided with the ME70 and MS70 delivery. The transducer cables are numbered 001 to 025. 110-0059233/C...
Page 125 Cable layout and interconnections Procedure For each transducer cable, locate the identification number. Pull the transducer cables carefully up through the bottom of the Transceiver Unit cabinet. Note You must always handle the transducer cable with great care. Observe the physical limitations.
Page 126: Setting Up The Me70 And Ms70 Systems For Synchronized Operation
Setting up the ME70 and MS70 systems for synchronized operation on page 124 Synchronization modes The purpose of the synchronization modes are to set up the ME70 and MS70 systems to operate alone, or as a "master" or "slave" in a synchronized system. 110-0059233/C...
Page 127 • Master Master mode is used if the ME70 and MS70 systems shall operate as the controlling unit in a synchronized system. Any peripheral hydroacoustic system(s) are only permitted to transmit when enabled by the ME70 and MS70 systems. The ME70 and MS70 systems send trigger signals to the peripheral system(s).
Page 128 The message is processed and will - if the previous ping has been finished - send a new ping. To acknowledge the trigger, the ME70 and MS70 systems set the Ready To Send (RTS) signal to a logic "low" before the ping. This indicates that the ME70 and MS70 system is "busy". 110-0059233/C...
Page 129: Master Mode
Synchronizing ME70 and MS70 systems by means of a serial port If you want to use the ME70 and MS70 systems as a master or slave in a synchronized system, you must set it up for such operation. To do this, you must select which communication port to use for the synchronization interface, and you must select the requested synchronization mode.
Page 130 • One of the acoustic systems is set up as "master", and controls the transmissions on the other systems. The ME70 and MS70 systems offer functionality for remote transmit synchronization. It can be set up to operate in either Master or Slave mode.
Page 131 Port. • Slave The Slave mode is used if the ME70 and MS70 systems shall transmit only when permitted by a peripheral system. When the Slave mode is selected, the ME70 and MS70 systems will not transmit ("ping") unless an external trigger appears on the chosen synchronization port.
Page 132 • Master In Master mode, the ME70 and MS70 systems wait for the delay time after the external trigger signal has been sent to the slaves before transmitting the ping. This is often referred to as a pre-trigger.
Page 133: Connectors
(RTS)/pin 7 The ME70 and MS70 will output the RS232 logical "0" signal when the transmit/ receive cycle starts. Logical representation Transmit/receive period Related topics Setting up the ME70 and MS70 systems for synchronized operation on page 124 Connectors 110-0059233/C...
Page 134: Processing Unit Rear Connectors (Hts41X11)
Kongsberg ME70 and MS70 Installation Manual Processing Unit rear connectors (HTS41x11) The rear panel of the Processing Unit holds all the connectors used by the computer to communicate with external devices. It also holds the power input socket and a mains power switch.
Page 135: Moxa Cp114El-I Overview
Cable layout and interconnections Related topics Connectors on page 131 Moxa CP114EL-I overview The Processing Unit is equipped with a Moxa CP114EL-I serial adapter board. The serial adapter offers four serial ports. The Moxa CP114EL-I serial adapter supports RS-232, RS-422 and RS-485 (both 2 and 4-wire). The connections to the board are made using a converter cable with four 9-pin male D-subminiature connectors.
Page 136: Moxa Cp114El-I Connectors
Kongsberg ME70 and MS70 Installation Manual Moxa CP114EL-I connectors The serial lines are provided as a large D-Subminiature connector on the rear side of the computer. Adapter A dedicated adapter cable is provided with the ME70 and MS70 delivery. The adapter splits the large circuit board connector to four 9-pin D- Subminiature connectors.
Page 137: Moxa Cp114El-I Serial Line Adapter
Cable layout and interconnections Moxa CP114EL-I Serial line adapter The Processing Unit is equipped with a Moxa CP114EL-I serial adapter board. The serial adapter offers four serial ports. The serial lines are provided as a large D-Subminiature connector on the rear side of the computer. The Moxa CP114EL-I serial adapter supports RS-232, RS-422 and RS-485 (both 2 and 4-wire).
Page 138 Kongsberg ME70 and MS70 Installation Manual specifications for the actual "shunt capacitance". A common figure is 47.5 pF/m, which gives a maximum cable length of about 50 meters. Even though a standard exist for RS-232 pin configuration, certain manufacturer may still choose their own connector pins for the various signals used.
Page 139: Setting Up The Moxa Cp114El-I Serial Ports
Note This information is intended for certified maintenance technicians and service engineers from Kongsberg Discovery, or from a certified dealer, distributor or agent. It is assumed that you are familiar with the Windows ® operating systems, computer technology, and interface principles.
Page 140 Kongsberg ME70 and MS70 Installation Manual Choose the settings to fit your requirements. Unless you a familiar with interface parameters offered, change only parameter to the required format. Leave the other settings Interface with their default values. Select repeatedly to save the chosen settings and exit.
Page 141: Cable Drawings And Specifications
Cable layout and interconnections Cable drawings and specifications Topics AC power cable using IEC C13 inline socket, page 140 Ground cable, page 142 RJ45 High speed Ethernet cable (1000Base-t), page 143 RS-232 serial line connection using three wires, page 144 RS-232 serial line connection using five wires, page 145 RS-422 serial line connection using five wires, page 146 RS-232 used as synchronization trigger (input or output), page 147...
Page 142: Ac Power Cable Using Iec C13 Inline Socket
Kongsberg ME70 and MS70 Installation Manual AC power cable using IEC C13 inline socket This cable is used to connect any unit or device to AC mains supply. The power cable is commercial. It is normally used for 115 and 230 VAC. The inline socket and the plug both comply to the IEC60320 standard.
Page 143 Cable layout and interconnections Note There are substantial differences between countries nomenclature related to power plugs and sockets. Observe local standards and regulations. Minimum cable requirements • : 2 x 1.5 mm + 1.5 mm Ground Conductors • : None Screen •...
Page 144: Ground Cable
Kongsberg ME70 and MS70 Installation Manual Ground cable Correct grounding is essential for safe operation and maximum performance. Ground tag on unit Vessel ground GROUND TAG The ground connection is made using a thick stranded (or braided) cable making a solid connection between the cabinet and the bulkhead.
Page 145: Rj45 High Speed Ethernet Cable (1000Base-T)
Cable layout and interconnections RJ45 High speed Ethernet cable (1000Base-t) Most high speed data connections between the system units are made using Ethernet cables. These cables are also often used between the system and peripheral equipment. (White/Orange) Bi-directional A+ Bi-directional A+ (Orange) Bi-directional A- Bi-directional A-...
Page 146: Rs-232 Serial Line Connection Using Three Wires
Kongsberg ME70 and MS70 Installation Manual RS-232 serial line connection using three wires An RS-232 serial line connection using NMEA datagrams is a common way to connect the system to external devices. GROUND GROUND Local connection Connection on remote device For more information, refer to the end-user documentation provided by the manufacturer.
Page 147: Rs-232 Serial Line Connection Using Five Wires
Cable layout and interconnections RS-232 serial line connection using five wires An RS-232 serial line connection using NMEA datagrams is a common way to connect the system to external devices. GROUND GROUND Local connection Connection on remote device For more information, refer to the end-user documentation provided by the manufacturer.
Page 148: Serial Line Connection Using Five Wires
Kongsberg ME70 and MS70 Installation Manual RS-422 serial line connection using five wires An RS-422 serial line connection can transmit data at rates as high as 10 million bits per second, and may be sent on cables as long as 1500 meters.
Page 149: Used As Synchronization Trigger (Input Or Output)
RS-232 used as synchronization trigger (input or output) An RS-232 serial line connection using the Request To Send (RTS) and Clear To Send (CTS) signals is common way to connect the ME70 and MS70 system to external devices for synchronization purposes.
Page 150: Basic Cable Requirements
Kongsberg ME70 and MS70 Installation Manual Basic cable requirements It is very important that all systems cables are installed correctly. All cables must be properly supported and protected, and all relevant precautions must be made to prevent unwanted noise. Related topics...
Page 151: Radio Frequency Interference
Cable layout and interconnections physical damage. Suitable shields must be provided where cables are installed in the vicinity of heat sources. Unless it is absolutely unavoidable, cables should not be installed across the vessel's expansion joints. If the situation is unavoidable, a loop of cable having a length proportional to the possible expansion of the joint must be provided.
Page 152: Physical Protection Of Cables
Kongsberg ME70 and MS70 Installation Manual Related topics Basic cable requirements on page 148 Physical protection of cables Cables exposed to the risk of physical damage must be enclosed in a steel conduit or protected by a metal casing unless the cable's covering (for example armour or sheath) is sufficient to protect it from the damage risk.
Page 153: Cable Connections And Terminations
Cable layout and interconnections Cable connections and terminations All cable connections are shown on the applicable cable plan and/or interconnection diagrams. Where the cable plan shows cable connections outside an equipment box outline, the connections are to be made to a plug or socket which matches the plug or socket on that particular item of equipment.
Page 154: About Cable Glands
There are many different types of cable gland on the market. The cable glands are not supplied with the system. Note Even though the cabinets from Kongsberg Discovery may be prepared for specific types of cable glands, the installation shipyard will be responsible for selecting cable gland types and installing them.
Page 155 There are many different types of cable gland on the market. This procedure describes the types used (now and previously) as standard in the units manufactured by Kongsberg Discovery. Even though the cabinets from Kongsberg Discovery may be prepared for specific types, the installation shipyard will be responsible for selecting cable gland types and installing them.
Page 156: Securing And Terminating Cables
Kongsberg ME70 and MS70 Installation Manual Note The outer insulation on the cable will extend into the cable gland to a point approximately 5 mm outside the outer surface of the cabinet wall. Carefully remove the outer insulation from the required cable length.
Page 157: Using Multi-Diameter Cable Sealing
Cable layout and interconnections Related topics Basic cable requirements on page 148 Using multi-diameter cable sealing Cable sealing systems are available from several manufacturers, and multi-diameter types are becoming increasingly popular due to their ease of use. Before you begin Electrical installations can only be done by certified electricians.
Page 158 Kongsberg ME70 and MS70 Installation Manual Illustration: Roxtec steps (Image from Roxtec website) The Roxtec system is available with a large number of various modules and compression units. The system complies with current screening and EMC requirements. Procedure Cut an opening in the structure (bulkhead, cabinet etc) you wish to penetrate.
Page 159: Dimensional Surveying And Alignment
Modest accuracy requirements apply when the ME70 and MS70 systems are only used to investigate objects in the water column.
Page 160 The installation engineers from Kongsberg Discovery are neither equipped nor trained to do dimensional surveying. The information provided by the dimensional survey is entered into the ME70 and MS70 software as installation parameters.
Page 161: Surveying The Transducer And The Navigation Sensors
Sufficient time and satisfactory work conditions must be given to the survey work. The installation engineers from Kongsberg Discovery are neither equipped nor trained to do dimensional surveying.
Page 162: Dimensional Survey Accuracy Requirements
If existing sensors have been replaced, or new sensors have been installed, a new calibration is required if the trawl door installation offset values are not available. A new calibration may also be required if the ME70 and MS70 software is updated. Refer to the software release note.
Page 163: Heading Sensor
Dimensional surveying and alignment • : ±0.02° Roll • : ±0.05° Heading Heading sensor • : ±0.1° Heading Global Positioning System (GPS) (Antenna) • : ±0.05 m Horizontal position (x,y) • : ±0.005 m Vertical position (z) Waterline reference mark •...
Page 164 Kongsberg ME70 and MS70 Installation Manual In order to establish a system to measure the relative distance between sensors, a virtual coordinate system is established. This coordinate system uses three vectors; X, Y and Z. A. The X-axis is the...
Page 165 Dimensional surveying and alignment Defining the physical location of each sensor By means of the vessel coordinate system, the physical location of every sensor can be defined using three numerical values for X, Y and Z. These values must define the vertical and horizontal distances from a single reference point;...
Page 166: Setting To Work
Setting to work Setting to work summary Once all the hardware units have been installed, and all the cables have been connected, the ME70 and MS70 systems can be turned on for the first time and set to work. Before you begin...
Page 167: Inspecting The Installation Of The Me70 And Ms70 Systems
Setting to work Insert the relevant installation parameters. To allow the ME70 and MS70 system to provide correct data, you must define and insert the location of each navigation and motion sensor, as well as the location of the transducer. Configure the ME70 and MS70 systems for operational use by inserting the relevant installation parameters.
Page 168: Common Prerequisites For The Me70 And Ms70 Installation Manual Visual Inspection Procedures
• All the relevant items must be available for inspection. • The ME70 and MS70 systems have been set up with its hardware units connected as specified in the Installation Manual. Neither tools nor instruments are required. For connections and communication parameters, see the relevant end-user documentation from the sensor manufacturer.
Page 169: Inspecting Logistic Items
A visual inspection of the display is required to verify that the unit has not been physically damaged during the installation. Before you begin The ME70 and MS70 systems are installed as specified in this manual. The ME70 and MS70 systems are turned off. You need the following equipment: • Multimeter...
Page 170 Related topics Setting to work summary on page 164 Inspecting the installation of the ME70 and MS70 systems on page 165 Common prerequisites for the ME70 and MS70 Installation Manual visual inspection procedures on page 166 110-0059233/C...
Page 171: Visual Inspection Of The Computer
Before you begin You need the following equipment: The ME70 and MS70 systems are installed as specified in this manual. The ME70 and MS70 systems are turned off. You need the following equipment: • Multimeter...
Page 172: Visual Inspection Of The Transceiver
A visual inspection of the transceiver is required to verify that the unit has not been physically damaged during the installation. Before you begin The ME70 and MS70 systems are installed as specified in this manual. The ME70 and MS70 systems are turned off. You need the following equipment: • Multimeter...
Page 173 Related topics Setting to work summary on page 164 Inspecting the installation of the ME70 and MS70 systems on page 165 Common prerequisites for the ME70 and MS70 Installation Manual visual inspection procedures on page 166 110-0059233/C...
Page 174: Environmental Inspection Of The Transceiver
Transceiver Unit. An environmental inspection of the Transceiver Unit is required to verify the quality of the sonar room. Before you begin The ME70 and MS70 systems are installed as specified in this manual. You need the following equipment: • Thermometer •...
Page 175: Inspecting The Transducer Installation
Measure the relative humidity in the room. 30 minutes after the ME70 and MS70 systems were turned on and put to normal operation, measure the relative humidity one more time. Make sure that neither the room itself nor any of the system units have been subjected to corrosive attacks.
Page 176: Making Sure That All Me70 And Ms70 System Cables Are Properly Connected
Making sure that all ME70 and MS70 system cables are properly connected The ME70 and MS70 systems rely on communication between each unit, and between the ME70 and MS70 systems and external devices. It is very important that all cables 110-0059233/C...
Page 177 Before you begin The ME70 and MS70 systems are installed as specified in this manual. • All system cables are installed. • All cable connections are made.
Page 178: Turning On The Me70 And Ms70 Systems For The First Time
Turning on the ME70 and MS70 systems When the entire installation has been inspected, and all the cables have been checked, the ME70 and MS70 systems can be started. It is very important that this does not take place while the vessel is in dry dock.
Page 179 Active Tx Mode to Max. Tx Power to On. Ping Verify that echoes are shown on the ME70 and MS70 presentation. 10. Operate the ME70 and MS70 in a normal manner, and verify that the system responds as expected. 110-0059233/C...
Page 180: Inserting The Installation Parameters
Ship point (the Ship Origin) in a dedicated coordinate system for the ME70 and MS70 systems. It is common practice to place the Ship Origin at the same position as the Navigational Reference Point (NRP).
Page 181 Setting to work Vessel coordinate system, installation parameters and rotation angles The position of all sensors on a vessel is defined in the vessel coordinate system. The rotation angle in all three axis directions equally describes the orientation of each sensor.
Page 182: Inserting The Installation Parameters For The Transducer
Kongsberg ME70 and MS70 Installation Manual Inserting the installation parameters for the transducer The physical location and the installation angles of the transducer are critical for the echo data accuracy. Incorrect angles will greatly reduce the data accuracy. About this task The physical location and the installation angles of the transducer are critical for the echo data accuracy.
Page 183: Inserting The Installation Parameters For Navigation Sensors
Restart the ME70 and MS70 systems. Note This procedure requires a full restart of the ME70 and MS70 systems. This includes the transceiver and the ME70 and MS70 software application. Inserting the installation parameters for navigation sensors The ME70 and MS70 require input from navigation sensors.
Page 184 Installation When you have finished editing: Restart the ME70 and MS70 system. Note This procedure requires a full restart of the ME70 and MS70 systems. This includes the transceiver and the ME70 and MS70 software application. 110-0059233/C...
Page 185: Setting Up The Interfaces To Peripheral Devices
ME70 and MS70 systems. You can also define manual values in case a sensor is unserviceable, or not installed. Before you begin The new sensor is physically connected to the ME70 and MS70 systems using a serial or network cable. About this task...
Page 186: Setting Up The Serial And Ethernet (Lan) Port Parameters
Setting up the serial and Ethernet (LAN) port parameters For any sensor interface to work, the communication parameters must be set up correctly. The ME70 and MS70 software automatically scans the Processing Unit to locate and identify the available communication ports. Once the software has established a list of valid interfaces, you can set up and control the communication parameters.
Page 187 Setting to work • You know how to set up the parameters for serial and local area network (LAN) communication. • The relevant communication parameters required for the sensor interface are known. About this task page provides two lists; one for serial ports and one for Ethernet I/O Setup (LAN) ports.
Page 188: Configuring The Sensor Interface
Sensor Configuration priority, so that the information from the "most reliable" sensor is used by the ME70 and MS70 systems. You can also define manual values in case a sensor is unserviceable, or not installed.
Page 189: Setting Up The Input From A Navigation System (Gps)
Installation Setting up the input from a navigation system (GPS) For the ME70 and MS70 systems to use and offer correct navigational information, one or more external sensors must be connected. Typical sensors are those providing navigational information (heading, speed or geographical position). To select which sensors to install, use the page.
Page 190 In the list of valid datagram formats, select the format(s) to be accepted by the ME70 and MS70 systems. For each relevant sensor you must insert the offset values that define the its physical location relative to the vessel’s coordinate system.
Page 191 Setting to work If you want to check that the peripheral system is transmitting data to the ME70 and MS70 system, select Monitor dialog box provides one text box for incoming messages ( Port Monitor Rx Data and one for outgoing messages ( ).
Page 192: Setting Up The Input From A Sound Speed Sensor
• The ME70 and MS70 systems are turned on and operates normally. • The new sensor is physically connected to the ME70 and MS70 systems using a serial or network cable. The sensor is turned on and in normal operation.
Page 193: Setting Up A Serial Or Lan (Ethernet) Port For Annotation Input
You cannot make any changes here. To change the communication parameters, use the page. I/O Setup If you want to check that the peripheral system is transmitting data to the ME70 and MS70 system, select Monitor dialog box provides one text box for incoming messages (...
Page 194 Select the port you want to use (serial or LAN). If you want to check the communication parameters, select Inspect Port If you want to check that the peripheral system is transmitting data to the ME70 and MS70 systems, select Monitor...
Page 195: Setting Up The Interface Between The Me70 And Ms70 And The Kongsberg Td50
Setting up the interface between the ME70 and MS70 and the Kongsberg TD50 The ME70 and MS70 can be set up to communicate with the Kongsberg TD50 3D Visualization Software. In this context, the ME70 and MS70 is regarded as the "source system".
Page 196: Setting Up Interface To The Me70/Bo Processing Unit
Seafloor Information System (SIS) Setting up the input from the Simrad ITI This procedure explains how the ME70 can be set up to receive ITI and FS information on a serial port. About this task Communication with the Simrad ITI (Integrated Trawl Instrumentation) and Simrad FS70 is based on NMEA and proprietary telegrams.
Page 197: Setting Up The Input From A Motion Reference Unit (Mru)
• The ME70 and MS70 systems are turned on and operates normally. • The new sensor is physically connected to the ME70 and MS70 systems using a serial or network cable. The sensor is turned on and in normal operation.
Page 198 ME70 and MS70. An unserviceable - or inaccurate - sensor will render the scientific data useless. Due to the importance of the motion sensor data, the ME70 and MS70 systems will stop "pinging"’ if the information from the sensor is lost. For more detailed information about datagrams and file formats, refer to the Interface Specifications publication.
Page 199: Related Topics
Setting up the ME70 and MS70 systems for synchronized operation If you want to use the ME70 and MS70 systems as a master or slave in a synchronized system, you must set it up for such operation. To do this, you must select which communication port to use for the synchronization interface, and you must select the requested synchronization mode.
Page 200 The amount of jitter depends on the quality of the converter. GROUND GROUND A. Local connection on the computer B. Connection on remote device Turn on the ME70 and MS70 systems and set them to normal use. Open the menu. Setup On the...
Page 201 • Master In Master mode, the ME70 and MS70 systems wait for the delay time after the external trigger signal has been sent to the slaves before transmitting the ping. This is often referred to as a pre-trigger.
Page 202: Checking The Data Transfer On An External Interface Line
This delay will only work when the synchronization is set up using a serial port. • Slave In Slave mode, the ME70 and MS70 systems wait for the delay time after the external trigger signal has arrived before transmitting the ping. This is often referred to as a post-trigger.
Page 203 Make sure that there is data traffic on the input port (shown in the Rx Data box). In order to see this data traffic, your ME70 and MS70 systems must be active and transmitting information to the peripheral system. If you are unable to see any data traffic on the communication port, we suggest the following: Make sure that the peripheral system has been turned on.
Page 204: Testing The Operating Functionality Of The Me70 And Ms70 Systems
Testing the operating functionality of the systems Recording raw data Use the raw data recording functionality provided by the ME70 and MS70 systems to save echo data using the format. You can save the data to the hard disk, or onto *.raw...
Page 205 Matrix each of the channels and transducer elements in the ME70 and MS70 systems. The presentation is provided on a matrix corresponding to the element locations in the transducer.
Page 206 Kongsberg ME70 and MS70 Installation Manual • No response indicate a problem with the +12 VDC supply voltage to the digital circuitry. • A failure in the +75 VDC supply voltage can only be detected in the transmit test. Procedure...
Page 207 Matrix each of the channels and transducer elements in the ME70 and MS70 systems. The page offers a good tool for testing the transmitter and receiver circuitry. The...
Page 208 Kongsberg ME70 and MS70 Installation Manual About this task When you move the cursor over the matrix presentation of the transceiver channels, each element in the transducer can be clearly identified as a rectangle. If you place the cursor on top of one of these rectangles, a small yellow tool-tip will identify key information.
Page 209 Setting to work to Height 24 pixels and Width 12 pixels. Element size in pixel to Current. Transmit pulse Observe the average of the samples starting from sample 20. Read the bottom text line under the Matrix presentation, and verify the deviation between neighbouring elements in the transmit pulse.
Page 210 The start sample and the number of samples to be displayed are selectable. Before you begin The ME70 and MS70 systems are installed as specified in this manual. • The ME70 and MS70 systems are turned on and operates normally. • The vessel is berthed or at sea.
Page 211 Before you begin The ME70 and MS70 systems are installed as specified in this manual. • The ME70 and MS70 systems are turned on and operates normally. • The vessel is berthed or at sea.
Page 212 Follow the procedure exactly as described in the steps. Incorrect settings in these dialog boxes may cause the ME70 and MS70 to become unstable. Procedure Open the menu.
Page 213 Low noise is a key factor for high quality and reliable measurements. The performance of the ME70 and MS70 systems will always be limited by different noise sources.The noise is measured while the ME70 and MS70 systems operate in Passive mode with the transmit pulses disabled.
Page 214 The transducer can be damaged if it transmits in the open air. • All relevant external sensors are connected to the ME70 and MS70. The sensors are turned on and operate normally. • The vessel is berthed or at sea.
Page 215 164 Making a noise/speed curve to determine vessel noise The performance of the ME70 and MS70 systems will always be limited by different noise sources. During this test, noise measurements are done for different vessel speeds. The weather and sea conditions for the noise measurements will be those at the time of the test.
Page 216 Kongsberg ME70 and MS70 Installation Manual • The water must be as deep as possible. • There must be no other vessels in the vicinity. • The vessel must lie still in the water. • As much machinery as possible must be turned off. It is particularly important to turn off electrical motors, as well as cooling systems and hydraulic pumps that may cause electric noise.
Page 217 Setting to work If possible, verify the vessel speed on the top bar. In the Numerical view, read the noise level estimates for the centre beam (beam 3) and from one of the outer beams (beam 0). Record the values in the result table. In the Echogram view, for the centre beam (beam 3) and for one of the outer beams (beam 0), estimate the range to where the noise becomes visible.
Page 218 Kongsberg ME70 and MS70 Installation Manual to Current. Transmit pulse 16. Make a screen capture of the page. Matrix Save the screen capture using a unique file name that identifies context, date, time and vessel. Attach the image file to the electronic copy of the test report.
Page 219 Setting to work Speed/Noise Speed Noise level (dB) Range (m) Centre beam Outer beam Centre beam Outer beam Beam mode: Sea state: Water depth: Alternatively, you can type the values straight into a spreadsheet. Test requirements Results A noise/speed curve is created. Date/Signature: Use the following plot to record the noise values.
Page 220 Kongsberg ME70 and MS70 Installation Manual +90 dB Noise/speed curve for 0° bearing and maximum gain Stable speed +86 dB Acceleration Retardation (CD015047E) +82 dB +78 dB +74 dB +70 dB +66 dB +62 dB +58 dB +54 dB +50 dB...
Page 221: Creating A Computer Image On A Usb Flash Drive Using The Acronis True Image Program
ME70 and MS70 system. Before you begin You need the bootable USB flash drive provided with the ME70 and MS70 system. You can also use any commercial USB flash drive. It must be formatted as a bootable device by the Acronis True Image program.
Page 222: Creating A Bootable Usb Flash Drive Using The Acronis True Image Program
A bootable USB flash drive is required for backup purposes. The software used is Acronis True Image. The software is installed on the computer. It is also copied onto the USB flash drive that is provided with the ME70 and MS70 system. Before you begin To create a bootable USB flash drive you will need the actual device.
Page 223: Upgrading The Processing Unit To Windows 10
Upgrading the Processing Unit to use Microsoft Windows 10 is done by restoring ® ® the operating system from an image. To get information about how to upgrade the Processing Unit to Windows 10, contact Kongsberg Discovery. • • www.kongsberg.com/no/maritime/support/km-support-app KM-Support App • www.kongsberg.com/os Website •...
Page 224: Installation Remarks
Kongsberg ME70 and MS70 Installation Manual Installation remarks Use this page to write down comments and remarks related to the ME70 and MS70 installation. When the installation has been fully completed, and all functional tests have been made to full satisfaction, representatives from each party must sign.
Page 225: Technical Specifications
Introduction to technical specifications These technical specifications summarize the main functional and operational characteristics of the ME70 and MS70 Scientific multibeam echo sounder and sonar. They also provide information related to power requirements, physical properties and environmental conditions. Note At Kongsberg Discovery, we are continuously working to improve the quality and performance of our products.
Page 226: Me70 - Operational Performance
Kongsberg ME70 and MS70 Installation Manual ME70 – Operational performance Swath width • : 2.2 - 60 ° Nominal • : 150 ° (With reduced sidelobe suppression) Maximum Stabilization • : ≤ 10 ° Roll stabilisation 110-0059233/C...
Page 227: Me70 - Configuration Settings
• 2,4 cm - 1,5 m (@ Sound speed 1500 m/s) Related topics Performance specifications on page 223 Technical specifications on page 223 ME70 – Configuration settings Frequency Band • : 70 - 120 kHz Upper Frequency • : 70 - 120 kHz Lower Frequency •...
Page 228 Kongsberg ME70 and MS70 Installation Manual Reference beams • : 0 - 2 Number of reference beams • : 70 - 120 kHz Frequency • Opening angle • : 2.2 - 20 ° Athwartship • : 2.2 - 20 °...
Page 229: Related Topics
Technical specifications Related topics Performance specifications on page 223 Technical specifications on page 223 MS70 – Operational performance Stabilization • : ≤ 10 ° Roll stabilisation Sidelobe levels • : -35 ° (Alongship) Horizontal • : -25 dB Vertical Transmission / Reception •...
Page 230: Ms70 - Configuration Settings
Kongsberg ME70 and MS70 Installation Manual • : ≤ 2 Hz Ping rate Sampling rates • : 62,5 kHz Complex sampling (Before decimation) Output sampling rate • : 1.2 cm (Minimum) Output sample length Related topics Performance specifications on page 223...
Page 231: Power Requirements
Transceiver Unit – power requirements, page 229 Display – power requirements Not applicable. The display is not a part of the ME70 and MS70 scope of supply. It is not manufactured by Kongsberg Discovery. For more information, refer to the end-user documentation provided by the manufacturer.
Page 232 Kongsberg ME70 and MS70 Installation Manual • : 20% of nominal voltage, recovery time 3 seconds Maximum transient • : 1500 VA (Approximately) Power consumption Related topics Technical specifications on page 223 Power requirements on page 229 110-0059233/C...
Page 233: Weights And Outline Dimensions
Weights and outline dimensions: Transducer, page 232 Display – weight and outline dimensions Not applicable. The display is not a part of the ME70 and MS70 scope of supply. It is not manufactured by Kongsberg Discovery. For more information, refer to the end-user documentation provided by the manufacturer.
Page 234: Weights And Outline Dimensions: Transducer
: 2029 mm Height • : 230 kg Weight Note Earlier versions of the ME70 and MS70 Transceiver Unit have had different heights. All dimension values include wire dampers. Related topics Technical specifications on page 223 Weights and outline dimensions: Transducer Transducer •...
Page 235 Technical specifications • Minimum bend radius • : 95 mm Static • : 243 mm Dynamic • : 3000 N Tensile strength • : Polyurethane (Outer sheet) Material Related topics Technical specifications on page 223 110-0059233/C...
Page 236: Environmental Requirements
Transducer – environmental requirements, page 235 Display – environmental requirements Not applicable. The display is not a part of the ME70 and MS70 scope of supply. It is not manufactured by Kongsberg Discovery. For more information, refer to the end-user documentation provided by the manufacturer.
Page 237: Transducer - Environmental Requirements
Technical specifications Maximum temperature gradation: 10° C/hour • : -40 to 65 °C Storage temperature • Relative humidity • : 10 to 80% relative non-condensing Operation • : 8 to 95% relative non-condensing Storage Related topics Technical specifications on page 223 Environmental requirements on page 234 Transducer –...
Page 238: Compass Safe Distance
Transceiver – compass safe distance , page 236 Display – compass safe distance Not applicable. The display is not a part of the ME70 and MS70 scope of supply. It is not manufactured by Kongsberg Discovery. For more information, refer to the end-user documentation provided by the manufacturer.
Page 239: Minimum Display Requirements
Technical specifications Minimum display requirements Unless specifically ordered, the ME70 and MS70 system is not provided with a display. The display must then be purchased locally. You can use one or two displays on your computer depending on personal and/or operational preferences.
Page 240: Index
Kongsberg ME70 and MS70 Index accuracy requirements (continued) Special Characters dimensional survey measurements of global (D)GPS positioning system ........161 interface requirements ........ 26 dimensional survey measurements of heading sensor ...........161 Numerics dimensional survey measurements of motion 1000Base-T reference unit ......... 160 Ethernet cable .........
Page 241 Installation Manual cable gland (continued) preparing cable for termination ....152 B-Scan cable glands ........... testing the receiver and transmitter channels ..208 about ........... 152 backup image procedures ..........151 Creating a backup image on a USB flash drive ..219 cable grounding ..........
Page 242 Kongsberg ME70 and MS70 cavitation (continued) connecting ............. transducer ..........50 transducer cables ........122 classification society ......... connection approval ..........30 Ethernet cable ......... 143 approval (installation drawings) ....10, 36 connections ........... classification society approval ......AC power cable ........140 requirements ..........30...
Page 243 ..........231 RS-232 serial line connection using five wires ..145 document downloads ........RS-232 serial line connection using three wires .. 144 www.kongsberg.com ........10 RS-232 used as synchronization trigger (input or documentation ..........output) ..........147 downloading ..........10 RS-422 serial line connection using five wires ..
Page 244 Kongsberg ME70 and MS70 environmental requirements (continued) monitor ..........234 handling (rules) ..........Processor Unit ......... 234 transducer ........12, 65, 90 sonar room ..........41 heading sensor technical specifications ......234 accuracy requirements for dimensional survey transceiver ..........234 measurements ........
Page 245 ............106 rules for transducer handling ....12, 65, 90 interface ............When the ME70 and MS70 system is not used ..11 setting up GPS interface ......188 When you are docking your vessel ....12 setting up navigation sensor interface ..... 188...
Page 246 Kongsberg ME70 and MS70 Kongsberg Discovery ME70 and MS70 support ...........32 diagram ..........18 measuring ............. noise in passive mode ........ 212 noise/speed ..........213 laminar flow ........... mechanical drawings description ..........49 downloading ..........36 LAN (Local Area Network) ports minimum requirements ........
Page 247 Installation Manual noise (continued) flow noise ........... 48, 55 passive mode interference ..........55 measuring noise ........212 machinery noise ........55 Performing a visual inspection of the display ..167 measuring ..........212 personnel ............propeller noise ........50, 55 qualifications ..........
Page 248 BITE rattle noise ............ Matrix functionality ........203 acoustic noise ........... 55 turning on the ME70 and MS70 systems ..176 raw data ............unpacking the transducer from its transport crate 76 recording ..........202 using multi-diameter cable sealing ....
Page 249 Installation Manual required items RS-232 used as synchronization trigger (input or not provided with the delivery ....... 24 output) ........... requirements ..........description ..........147 AC mains power ........229 RS-422 cable connections ........151 Moxa CP114EL-I serial adapter ......133 cable grounding ........150 RS-422 serial line connection using five wires ..
Page 250 Kongsberg ME70 and MS70 Serial Port ............sources ............synchronization ........131 acoustic noise ........... 53 serial ports noise ............53 setting up ..........185 specification setting to work ..........AC power cable ........140 summary ..........164 specifications ..........Setting to work summary ....... 164 compass safe distance (CSD) ......236...
Page 251 Installation Manual survey requirements (continued) transceiver (continued) accuracy requirements for dimensional survey Compass Safe Distance (CSD) .......236 measurements of motion reference unit ..160 environmental requirements ......234 accuracy requirements for dimensional survey installation requirements ......30 measurements of transducer ....... 160 outline dimensions ........
Page 252 Kongsberg ME70 and MS70 transducer cables (continued) vessel coordinate system (continued) length ..........64, 232 alternative origin ........162 specifications ........64, 232 description ..........161 transducer handling .......... origin ............162 rules ..........12, 65, 90 vessel coordinate system alternative origin ....

This manual is also suitable for:

Ms70

Kongsberg ME70 Installation Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Kongsberg ME70

Summary of Contents for Kongsberg ME70

This manual is also suitable for:

Table of Contents
