BEGA 85 250 Instructions For Use

Garden and pathway luminaire

Advertisement

Quick Links

06.24 · Technische Änderungen vorbehalten · Technical amendments reserved · Modifications techniques réservées
!
Garten- und Wegeleuchte
Garden and pathway luminaire
Luminaire de jardin et d'allée
Projekt · Project · Projet
Standort · Location · Lieu
Gebrauchsanweisung
Anwendung
Freistrahlende Garten- und Wegeleuchte mit
rotationssymmetrischer Lichtstärkeverteilung.
Geeignet für Anlagen im privaten und
öffentlichen Bereich, in denen keine Gefahr der
mutwilligen Zerstörung besteht.
Die Leuchte kann über eine geschaltete
Phase klassisch on/off sowie bei Dauerphase
entweder über die App BEGA Smart oder die
wibutler App gesteuert werden.
Für die wibutler-Einbindung ist zusätzlich der
wibutler pro (2. Gen.) erforderlich.
Hierbei kann die Farbtemperatur wahlweise
auf 3000 K oder 4000 K eingestellt und die
Helligkeit der Leuchte angepasst werden.
Im Auslieferungszustand sind 3000 K und
maximale Helligkeit voreingestellt.
Leuchtmittel
Modul-Anschlussleistung
Leuchten-Anschlussleistung
Modul-Bezeichnung
LED-1559/83040
Farbwiedergabeindex
Bemessungstemperatur
Lebensdauerkriterien
Betrieb bei Farbtemperatur
Modul-Lichtstrom
Leuchten-Lichtstrom *
Leuchten-Lichtausbeute *
Betrieb bei Farbtemperatur
Modul-Lichtstrom
Leuchten-Lichtstrom *
Leuchten-Lichtausbeute *
* vorläufige Daten
Ø 110
Ø 110
Instructions for use
Application
Unshielded garden and path luminaire with
rotationally symmetrical light distribution.
Suitable for private and public areas in which
there is no risk of vandalism.
The luminaire can be controlled via a switched
phase classically on/off or with a continuous
phase either via the BEGA Smart app or in
combination with the wibutler pro (2. Gen.) with
the wibutler app.
The colour temperature can be set optionally
to 3000 K and 4000 K, and the luminaire
brightness can be adjusted.
The default factory settings are 3000 K and
maximum brightness.
Lamp
3,9 W
Module connected wattage
4,8 W
Luminaire connected wattage
Module designation
CRI > 80
Colour rendering index
t
= 25 °C
Rated temperature
a
50 000 h / L
Service life criteria
70
3000 K
Operation at colour temperature
725 lm
Module luminous flux
463 lm
Luminaire luminous flux *
96,5 lm / W
Luminaire luminous efficiency *
4000 K
Operation at colour temperature
735 lm
Module luminous flux
466 lm
Luminaire luminous flux *
97,1 lm / W
Luminaire luminous efficiency *
* preliminary data
BEGA Gantenbrink-Leuchten KG · Postfach 31 60 · 58689 Menden · info @ bega.com · www.bega.com
Ø 65
Ø 65
Fiche d'utilisation
Utilisation
Luminaire de jardin et d'allée à diffusion libre,
répartition lumineuse symétrique circulaire.
Ils conviennent tout particulièrement aux
espaces publics ou privés dans lesquels il
n'existe aucun risque de vandalisme.
Le luminaire peut être commandé de manière
classique on/off par une phase commutée ou
bien par une phase continue via l'app BEGA
Smart ou en combinaison avec wibutler pro (2.
Gen.) avec l'app wibutler.
La température de couleur des luminaires est
réglable sur 3000 K ou 4000 K au choix tout
comme la luminosité qui peut être ajustée à
votre convenance.
Une température de 3000 K et une luminosité
maximale sont préréglées à l'usine.
Source lumineuse
3.9 W
Puissance de raccordement du module 3,9 W
4.8 W
Puissance de raccord. du luminaire
LED-1559/83040
Désignation du module
CRI > 80
Indice de rendu des couleurs
t
= 25 °C
Température de référence
a
50 000 h / L
Critères relatifs à la durée de vie
70
3000 K
Fonctionnement avec temp. de couleur 3000 K
725 lm
Flux lumineux du module
463 lm
Flux lumineux du luminaire *
96,5 lm / W
Rendement lum. du luminaire *
4000 K
Fonctionnement avec temp. de couleur 4000 K
735 lm
Flux lumineux du module
466 lm
Flux lumineux du luminaire *
97,1 lm / W
Rendement lum. du luminaire *
* données provisoires
85 250
é
c
IP 65
QR-Code
QR Code
Code QR
4,8 W
LED-1559/83040
(IRC) > 80
t
= 25 °C
a
50 000 h / L
70
725 lm
463 lm
96,5 lm / W
735 lm
466 lm
97,1 lm / W
1 / 5
