11.24 · Technische Änderungen vorbehalten · Technical amendments reserved · Modifications techniques réservées
!
Garten- und Wegeleuchte
Garden and pathway luminaire
Luminaire de jardin et d'allée
Projekt · Project · Projet
Standort · Location · Lieu
Gebrauchsanweisung
Anwendung
Freistrahlende Garten- und Wegeleuchte mit
Schutzgitter. Lichtaustritt 360°.
Mit mundgeblasenem dreischichtigem Opalglas
und angenehm gleichmäßiger Lichtwirkung.
Geeignet für Anlagen in privaten und
öffentlichen Bereichen mit geringer Gefahr der
mutwilligen Zerstörung.
Die Leuchte kann über eine geschaltete
Phase klassisch on/off sowie bei Dauerphase
entweder über die App BEGA Smart oder die
wibutler App gesteuert werden.
Für die wibutler-Einbindung ist zusätzlich der
wibutler pro (2. Gen.) erforderlich.
Leuchtmittel
Modul-Anschlussleistung
Leuchten-Anschlussleistung
Modul-Bezeichnung
LED-1559/83040
Farbwiedergabeindex
Bemessungstemperatur
Umgebungstemperatur
Die Farbtemperatur der Leuchte kann
wahlweise auf 3000 K oder 4000 K eingestellt
werden.
Betrieb bei Farbtemperatur
Modul-Lichtstrom
Leuchten-Lichtstrom
Leuchten-Lichtausbeute
Betrieb bei Farbtemperatur
Modul-Lichtstrom
Leuchten-Lichtstrom
Leuchten-Lichtausbeute
Einstellung der Farbtemperatur
Über die App BEGA Smart oder wibutler kann
wahlweise die Farbtemperatur auf 3000 K
oder 4000 K eingestellt und die Helligkeit der
Leuchte angepasst werden.
Im Auslieferungszustand sind 3000 K und
maximale Helligkeit voreingestellt.
Ø 110
Ø 110
Instructions for use
Application
Unshielded garden and path luminaire with
safety guard. Light exit 360°.
With hand-blown, three-ply opal glass and
pleasantly uniform light effect.
Suitable for private and public areas where
there is a low risk of vandalism.
The luminaire can be used with standard on/off
controls via a switched phase, or in continuous
phase using the apps BEGA Smart or wibutler.
A wibutler integration will additionally require
the installation of wibutler pro (2nd generation).
Lamp
3,9 W
Module connected wattage
4,8 W
Luminaire connected wattage
Module designation
CRI > 80
Colour rendering index
t
= 25 °C
Rated temperature
a
t
= 55 °C
Ambient temperature
a max
The colour temperature of the luminaire can be
set optionally to 3000 K and 4000 K.
Operation at colour temperature
3000 K
Module luminous flux
725 lm
Luminaire luminous flux
175 lm
Luminaire luminous efficiency
36,5 lm / W
Operation at colour temperature
4000 K
Module luminous flux
735 lm
Luminaire luminous flux
177 lm
Luminaire luminous efficiency
36,9 lm / W
Setting the colour temperature
The BEGA Smart or wibutler App can be
used to optionally set the color temperature to
either 3000 K or 4000 K and to adjust luminaire
brightness.
The factory settings are 3000 K and max.
brightness.
BEGA Gantenbrink-Leuchten KG · Postfach 31 60 · 58689 Menden · info @ bega.com · www.bega.com
Fiche d'utilisation
Utilisation
Luminaire de jardin et d'allée à diffusion libre
avec grille de protection.
Diffusion d'éclairage sur 360°.
Avec un verre opale triple couche soufflé à
la bouche créant un effet lumineux uniforme
agréable.
Ils conviennent tout particulièrement aux
espaces publics ou privés peu exposés au
risque de vandalisme.
Le luminaire peut être commandé de manière
classique on/off via une phase commutée, mais
aussi en phase continue via l'application BEGA
Smart ou l'application wibutler.
Pour l'intégration de wibutler, il faut en plus
disposer de wibutler pro (2e génération).
Source lumineuse
3.9 W
Puissance de raccordement du module 3,9 W
4.8 W
Puissance de raccord. du luminaire
LED-1559/83040
Désignation du module
CRI > 80
Indice de rendu des couleurs
t
= 25 °C
Température de référence
a
t
= 55 °C
Température d'ambiance
a max
La température de couleur des luminaires est
réglable sur 3000 K ou 4000 K au choix.
3000 K
Fonctionnement avec temp. de couleur 3000 K
725 lm
Flux lumineux du module
175 lm
Flux lumineux du luminaire
36,5 lm / W
Rendement lum. du luminaire
4000 K
Fonctionnement avec temp. de couleur 4000 K
735 lm
Flux lumineux du module
177 lm
Flux lumineux du luminaire
36,9 lm / W
Rendement lum. du luminaire
Réglage de la température de couleur
Via l'application BEGA Smart ou wibutler
la température de couleur peut être réglée
au choix sur 3000 K ou 4000 K et l'intensité
lumineuse être ajustée à votre convenance.
Une température de 3000 K et une luminosité
maximale sont préréglées à l'usine.
85 257
é
c
IP 65
DataMatrix
Code
4,8 W
LED-1559/83040
(IRC) > 80
t
= 25 °C
a
t
= 55 °C
a max
725 lm
175 lm
36,5 lm / W
735 lm
177 lm
36,9 lm / W
1 / 4
