Electric Water Purifier
WATER
PURIFIER
User Manual
CP-TN100S
CP-TN100DS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-TN100S and is the answer not in the manual?

Questions and answers

Summary of Contents for Cuckoo CP-TN100S

  • Page 1 Electric Water Purifier WATER PURIFIER User Manual CP-TN100S CP-TN100DS...
  • Page 2: Dear Customers

    Features and Benefits of CUCKOO Electric Water Purifier Product Benefits Nano Positive Filtering System Application of CUCKOO Electric Water Purifier’s Nano Positive Filtering System produces clean and healthy water containing minerals. Healthy electric water purifier You may drink water, which has passed a filter in an instantaneous cooling, heating or purification method, as cold, hot or room temperature water.
  • Page 3: Table Of Contents

    CONTENTS Before Use Features and Benefits of CUCKOO Electric Water Purifier Warnings for Safe Use 4 ~ 7 Cautions for Safe Use 8 ~ 9 Part Names and Accessories 10 ~ 11 During Use Filtration Circuit / Filtration System How to Install the Product...
  • Page 4: Warnings For Safe Use

    Warnings for Safe Use ● Please comply with the “Safety Warnings” to ensure safe and proper use of the product and to avoid accidents or dangerous situations. ● The ‘Warnings for Safe Use’ section consists of “Warning” and “Caution” items, which are defined as follows. Warning This symbol indicates a potentially dangerous situation ●...
  • Page 5 Warnings for Safe Use About Power ! Warning Prohibited When unplugging the Use alternating current product, make sure to hold voltage of 220V-240V only. the Power Plug, not the Power Cord. This may cause electric shock and/or fire. ● Applying force to the Power Cord may cause electric shock or fire. The product will not work properly.
  • Page 6: About Installation

    Warnings for Safe Use About Installation ! Warning Prohibited Do not install where it may be Do not install the product in a exposed to moisture, place from which gas may be excessive dust, and splashing leaked or where an air water.
  • Page 7: During Use

    Warnings for Safe Use During Use ! Warning Prohibited Do not place chemicals, water bottles Do not use the product by or small metal materials on top of the placing an electric heating product. appliance such as a microwave, If any of it gets into the product, there is a risk ●...
  • Page 8: Cautions For Safe Use

    Must not use NON-Cuckoo Water Purifier filters. Do not lean the product at a 30-degree angle or more when moving the product. Use of a non-genuine filter other than a genuine CUCKOO filter may ● deteriorate the water purification performance, strange taste of the This may cause poor performance of the product.
  • Page 9 Cautions for Safe Use ! Caution Instructions Do not allow children to touch Prevent children from climbing packing material such as or hanging on the product. styrofoam and vinyl. This may cause the product to fall down, ● This may cause suffocation. ●...
  • Page 10: Part Names And Accessories

    Part Names and Accessories Part names <Top Side> Function Operation and Display < Front and Back > Cold Water, Hot Water and Room Temperature Select and Dispense Faucet Button Tap Water Supply Sink Faucet Sterilization Water Drain Cooling water Drain Power Cord...
  • Page 11 Part Names and Accessories Part names <Details about Display Panel> Time Display Panel Faucet Sterilization Button Energy Save/Setting Sterilization Water Button Sterilize/Timer Button Extra Hot Water Button Hot Temp. Button One Cup Select Button Half Cup Select Button Non-Stop/Lock(3 Sec) Button Hot Water (Lamp: WHITE) Select Button Room Temperature Water (Lamp: WHITE)
  • Page 12: During Use Filtration Circuit / Filtration System

    Filtration Circuit / Filtration System Filtration Circuit Filtration System Step1 Step2 Carbon Nano Positive Composite Filter Plus 3.0 Filter LEVEL Filter Name Filter Function Help filter out residual chlorine, volatile organic Carbon Composite Filter Level 1 compounds (VOCs), and fine particles Help filter out minute particles, colon bacillus, Nano Positive Plus 3.0 bacillus pyocyaneus, staphylococcus aureus and...
  • Page 13: How To Install The Product

    How to Install the Product How to Install the Product External Valve (Optional) Open ❸ Close ❶ Cold Water Pipe Tap Water Supply Valve Tap Water Supply Tube Cleansing Water Hose ❷ Sink Faucet Connection Hose Drain Hose ❷ Install the Tap Water Supply Valve and turn it to CLOSE. ❶...
  • Page 14: Use The Checklist Before Use

    Checklist Before Use Checklist Before Use Open the Tap Water Supply Valve. ❶ ▶ Open the Tap Water Supply Valve, and check if there is water leak on each connection part. · Tap Water Supply Valves and water (inlet) and drain of the product Open Turn the Close lever of the filter door on the right side of...
  • Page 15: How To Use 15

    How To Use To Set Functions Standby Mode ❶ ▶ It is the mode in which it waits for cold water, hot water, room temperature water or Sterilization water to be dispensed. The display lamp on the front section is turned on based on the selected function and also shows the current time.
  • Page 16 How To Use How to Set Cold Water Function If the Cold Water Function is turned off, press the [Cold Water] ❶ button for 3 seconds to turn the function on. While the [Cold Water] button is being pressed, the Voice Guide ▶...
  • Page 17 How To Use How To Use Room Temperature Water Press the [Room Temperature Water/Cold Water] button and ❶ select Cold Water. The Voice Guide will say "Room Temperature Water." ▶ How to Dispense Fixed Quantity ❶ select the desired quantity from among the buttons of "Half Cup," ▶...
  • Page 18 How To Use How to Use Hot Water (typical hot water temperature of 85 ℃ or below) Press the [Hot Water] button and select Hot Water. ❶ The Voice Guide will say "Hot Water." ▶ How to Dispense Fixed Quantity ❷...
  • Page 19 Sterilization water is not for drinking. Prevent anyone from drinking the Sterilization water. ※ (CUCKOO Sterilization water is being managed within the standard scope of the “Drinking Water Management Act” so do not worry about using it but try to avoid drinking it.) The sink faucet lever can be controlled to increase the concentration of the ※...
  • Page 20 How To Use How to Use Auto Sterilization Reservation Function If the [Sterilize/Timer] button display lamp is turned on in ❶ Standby Mode, the Auto Sterilization Reservation function is set as Use. While the [Sterilize/Timer] button display lamp is turned off, ❷...
  • Page 21 How To Use How To Use the Immediate Auto Sterilization Function This is the function that begins an auto Sterilization at a point desired by the user without having to use the auto Sterilization Reservation. The method and duration of Sterilization are identical to Reserved Sterilization. ▶...
  • Page 22 How To Use How to Use Power Save Function This is the function that reduces standby power and the brightness of the display lamps to save energy. While the [Energy Save/Setting] display lamp is turned off, press ❶ the [Energy Save/Setting] button. The [Energy Save/Setting] Display Lamp will be turned ON, and in one ▶...
  • Page 23 How To Use How to Set Filter Replacement Alarm Function Press the [Energy Save/Setting] button for 3 seconds in Standby Mode. ❶ The product will enter the User Setting mode. ▶ After entering the User Setting mode, press the [Sterilization Water] ❷...
  • Page 24 How To Use How to Change DIspensing Volume Press the [Energy Save/Setting] button for 3 seconds in Standby Mode. ❶ The product will enter the User Setting mode. ▶ After entering the User Setting mode, press the [Sterilization Water] ❷ button three times [One Cup Dispensing Volume] or four times [Half Cup Dispensing Volume].
  • Page 25 How To Use How To Use the Mood Lamp function Press the [Energy Save/Setting] button for 3 seconds in Standby Mode. ❶ The product will enter the User Setting mode. ▶ After entering the User Setting mode, press the [Sterilization Water] ❷...
  • Page 26 How To Use How To Use Time Notification Function Press the [Energy Save/Setting] button for 3 seconds in Standby Mode. ❶ The product will enter the User Setting mode. ▶ After entering the User Setting mode, press the [Sterilization Water] ❷...
  • Page 27 How To Use How to Use Filter Reset Function Press the [Energy Save/Setting] button for 3 seconds in Standby Mode. ❶ The product will enter the User Setting mode. ▶ After entering the User Setting mode, press the [Sterilization Water] ❷...
  • Page 28 How To Use How to Use Auto Filter Cleaning Function Press the [Energy Save/Setting] button for 3 seconds in Standby Mode. ❶ The product will enter the User Setting mode. ▶ After entering the User Setting mode, press the [Sterilization Water] ❷...
  • Page 29: How To Set Language

    How To Use How To Set Language Press the [Energy Save/Setting] button for 3 seconds in Standby Mode. ❶ The product will enter the User Setting mode. ▶ After entering the User Setting mode, press the [Sterilization Water] ❷ button fourteen times. ▶...
  • Page 30: How To Clean Tray / How To Clean Main Body

    How To Clean Tray / How To Clean Main Body How to Clean the Tray Detach the Tray ❶ Hold and pull the tray towards the front side of the ▶ product to separate it from the product. When you pull the tray, pull it slowly with both ※...
  • Page 31: How To Replace The Filters 31

    How To Replace the Filters How To Replace the Filters (Must not use non-CUCKOO Water Purifier filters.) The filter door detection sensor is in operation so, when replacing the filter, do not pull ※ the power cord. Turn the Close lever of the filter door on the right ❶...
  • Page 32 How To Replace the Filters Expec How To Replace the Filters (Must not use non-CUCKOO Water Purifier filters.) Lock the filter door as shown in the image. ❺ The groove at the bottom must be accurately aligned for · smooth installation.
  • Page 33: Expected Filter Replacement Cycle / Recommendations

    Expected Filter Replacement Cycle / Recommendations / Filter Arrangement Expected Filter Replacement Cycle The filter replacement cycle is determined based on usage of 10L per day in a common ▶ household, and may be affected by the state of the source water. Filter Name Expected Replacement Cycle Carbon Composite Filter...
  • Page 34: Before Asking For Support Please Check Before Asking For Support. 34

    Please check before asking for Support ▼ If you do not comply with this User Manual, the product may not work properly even if there is no malfunction. Please take the following measures accordingly if there is a problem with the product. If there is still a problem, please contact our Customer Service Center.
  • Page 35 • Remove the items on the product. or clock on the product? • Do you need to replace the filters? • Replace the Filter. (Do not use a Non-Cuckoo filter.) There are floating matters in the dispensed water. There are fine particles in •...
  • Page 36: Service Guide Product Specifications

    Product Specifications CUCKOO Electric Water purifier Product Name Model Name CP-TN100S (White Silver), CP-TN100DS (Dark Silver) Rated Voltage Single Phase AC 230 V / 50 Hz Power Consumption Cold water 0.6A, Hot water 2400W Filtration Nano Positive Filtration System Filter Carbon Composite Filter Nano Positive Plus 3.0 Filter...
