Summary of Contents for Cuckoo CP-QN1401SW/WHCBMYCI

Page 1 User Manual CP-QN1401SW/WHCBMYCI CUCKOO Electric Water Purifier...
Page 2 Merits of CUCKOO Water Purifier 4-Step Filtering System The 4-step filtering system of CUCKOO Water Purifier dispenses clean and healthy water. Stainless Steel Water Tank We have increased the cleanliness in the water filtration process and the Tank by making the Water Tank with stainless steel.
Page 3: Table Of Contents
CONTENTS Before Use Warnings for Safe Use Cautions for Safe Use Name of Parts/Components Information How to Use Filtration Circuit/ Water Filtration System Details to Check before Installation How To Install the Product Details To Check before Use 13~14 How To Use 14~17 How To Clean the Cold Water Tank 18~20...
Page 4 Warnings for Safe Use Please comply with the 'Warnings for Safe Use' as they are provided to ensure safe and proper use of the product and prevent accidents and dangerous situations. The 'Warnings for Safe Use' are made of 'Warning' and 'Caution', which mean the following respectively: •...
Page 5 Warnings for Safe Use About Power Supply Warning Do not Pull the Power Plug by Use only one for the alternating current holding the Power voltage of 220V- 240V. Plug itself, not the Power Cord. • This may cause electric shock or fire.
Page 6 Warnings for Safe Use Installation Issues Warning Do not Do not install the Please avoid the area product where gas where there is high may leak or moisture and dust. somewhere near to • If you do not do so, an air conditioner or a it m ay cause electric shock heater.
Page 7 Warnings for Safe Use Warning Do not Do not put an electric Do not put drugs, water heating appliance such bottle, small metal things, etc. on the product. as a microwave oven and an electric oven • If those things go into the toaster or inflammables product, it m ay cause a danger such as candlelight, gas...
Page 8: Before Use 4~7
Please use only CUCKOO Filter (genuine) water, and drain the water completely again • If you use any filter other than the genuine CUCKOO filter, it before use. may cause a decrease in water purifying performance, an • When you drain the water from inside the Cold Water Tank, abnormal taste of water, water leak, and a malfunction of about 10.1 L of water will come out.
Page 9: Name Of Parts/Components Information
Name of Parts / Components Information Name of Parts < Front > < Back > Hot Water Indicater Energy Save Indicater Cold Water Indicater “Energy Save” Button Water Level Indicater “Cold” Button “Hot” Button Select Lever Cold Water Faucet Cold Water Lever Hot Water Faucet Hot Water Lever Child Lock Button...
Page 10: Filtration Circuit/ Water Filtration System
Removes general germs, viruses, minute particles, Step 4 Nano Positive Filter and some sorts of heavy metal (mercury, iron, aluminum). ※ If CUCKOO Filter (genuine) is not used or used for a prolonged period, it may show reduced performance.
Page 11: Details To Check Before Installation
Details to Check before Installation Details to Check before Installation Cautions when installing the Product Avoid direct sunlight and electric heating appliances. ▶ They may cause fire or discolouration of the product. They may cause fire or discolouration of the product. ▶...
Page 12: How To Install The Product
How To Install the Product How To Install the Product ❸ Open ❶ Closed Cold Water Cold Water Pipe Tap Water ❺ Supplying Valve External Valve (for sale) Tap Water Input Tap Water(Blue) External Outlet(Orange) External Outlet ❷ ❶ Install the Tap Water Supplying Valve to the Cold Water Pipe. ※Caution •...
Page 13: Details To Check Before Use 13~14
Details to Check before Use Caution Do not turn ON the "Cold" and "Hot" buttons when there is no water inside the tank. (It may cause a malfunction of the product). • Fill the Tank with water up to the Full Water Level, and then turn on the "Cold" and "Hot" buttons. •...
Page 14 Details to Check before Use/How To Use Details to Check before Use Empty the Tray on a regular basis. Replace and manage the Filter on a regular basis. ▶ In order to drink clean water frequently, you need to replace and clean the Filter on a regular basis.
Page 15: How To Use 14~17
How to Use How to Use Cold Water Press the “Cold” button for about 3 seconds to turn it on. The product needs time to run the Heater, which will take about 60 minutes.(The blue lamp will be turned on) ▶...
Page 16 How to Use How to Use Energy Save Function This function saves energy by reducing the standby power and the brightness of the indicator. While the [Energy Save] indicator is off, press the [Energy Save] button. ▶ The [Energy Save] indicator lights up, and after 1 second all the indicators are dimmed.
Page 17 How to Clean the Cold Water Tank How to Use Setting the temperature Setting the temperature of hot water:Press the [Energy Save] button for 3 seconds. ▶ Enter the hot and cold water temperature setting mode. [Initial Setting : Level 3] ▶...
Page 18: How To Clean The Cold Water Tank 18~20
How to Clean the Cold Water Tank How to Clean the Cold Water Tank First, close the Tap Water Supplying Valve. Closed Turn OFF the "Cold" and "Hot" buttons. ▶ With the "hot" and "cold" lights on, Press the "hot" and "cold" buttons for 3 seconds. ▶...
Page 19 How to Clean the Cold Water Tank How to Clean the Cold Water Tank Separate the Top Cover of the product. ▶ You need a Phillips screwdriver. Separate the Cover of the Cold Water Tank. ▶The top part of the Cold Water Tank is a little lukewarm as purified water and hot water steam meet there.
Page 20 How to Clean the Cold Water Tank How to Clean the Cold Water Tank Reassem ble the Separator to the Cold W ater Tank. ▶ Turn it prevent the Separato r from breaking away. If the Separator is not fixed and breaks away, the driving time of the Compressor will get longer and cause noise.
Page 21: How To Clean Tray
How to Clean Tray How to Clean Tray Separation of Tray ▶ Hold the Tray, lift it upward, and separate the Tray. Separation of Tray Grill ▶ Separate the Tray, hold and lift the hole of the Grill at the top of the Tray, and separate the Tray Grill. Cleaning of Tray ▶...
Page 22: How To Replace The Filter 22 ~24
How To Replace the Filter How To Replace the Filter (Use only the genuine CUCKOO Filter) Close the Tap W ater Supplying Valve. Closed R em ove the residual pressure from the Pipe. ▶ Put a cup under the Cold Water Faucet, and drain about three to four cups (500 cc) of water.
Page 23 How To Replace the Filter How To Replace the Filter (Use only the genuine CUCKOO Filter) Separate the connecting tube at the top of the Filter to be replaced from the Fitting, and replace the Filter. ▶ Use a proper tool (Fitting Separator) when separating the connecting tube from the Fitting.
Page 24 How To Replace the Filter How To Replace the Filter (Use only the genuine CUCKOO Filter). Fix the Side Cover at the front bottom of the product again. ▶ You need to accurately fit the groove at the bottom to smoothly mount it.
Page 25: Expected Filter Replacement Cycle
Expected Filter Replacement Cycle / Recommendations/Filter Arrangement Expected Filter Replacement Cycle ▶ The filter replacement cycle is determined with the use of 10 L per day at home as the standard, and may be affected by the condition of tap water. Filter Name Expected Sediment Filter...
Page 26 There is bad smell. • Isn't it the time to replace the Filter? • Replace the Filter (the genuine CUCKOO Filter). • Has it been a long time since you last used hot • Drain the water in the Hot Water Tank with the Hot Water...
Page 27: Please Check Before Asking For Support
• Hasn't the filter replacement cycle passed? • Replace the Filter (the genuine CUCKOO Filter). • Is the floor where the product is installed flat? • Install the product on a flat and firm surface.
Page 28: Product Specifications
Product Specification Electric Water Purifier Product Name Stand Type Category CP-QN1401SW/WHCBMYCI Model Single Phase. AC 220-240V / 50Hz Rated Voltage Cold:0.9A / Hot:500W Power Nanopositive Filter System Water Filtration Method Materials: Polypropylene Sediment Filter (Replacement Cycle : 4 months) Materials: Compressed charcoal Filter Category Pre-Carboon Block 2.0 Filter...
Page 29 MEMO...
Page 30 Cuckoo International (MAL) Sdn. Bhd. L16, Menara Bangkok Bank, Laman Sentral Berjaya, Jalan Ampang Kuala Lumpur 50450 Malaysia Careline : 1-800-88-8181 10384-0008A0 REV.0...
