WATER
PURIFIER
USER MANUAL
CP-QN1401SW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-QN1401SW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cuckoo CP-QN1401SW

Summary of Contents for Cuckoo CP-QN1401SW

  • Page 1 WATER PURIFIER USER MANUAL CP-QN1401SW...
  • Page 2 Using a stainless steel water tank improves the water quality and cleanliness. Economical Eco-Friendly Water Filtration System The Eco-friendly CUCKOO Nano Positive filter helps filter out contaminants but does not waste any water during the filtration process. External Valve (for separate sale) The external valve allows for an additional connection to the filtered water supply.

  • Page 3: Table Of Contents

    CONTENTS Before Use Warnings for Safe Use 4 ~ 7 Cautions for Safe Use Name of Parts/Components Information How to Use Filtration Circuit/ Water Filtration System Details to Check before Installation How To Install the Product 12 ~ 13 Details To Check before Use 14 ~ 15 How To Use 15 ~18...

  • Page 4: Warnings For Safe Use

    • To replace the damaged power cord or plug, please visit input, it may cause heating, fire and electric shock. CUCKOO website and contact Customer Service to prevent Please check the condition of the power outlet frequently. dangerous situations.
  • Page 5 Warnings for Safe Use About Power Supply Warning Do not Do not pull the power Use 120V power input cord when unplugging only. the product. • This may cause electric shock or fire. • The product will not operate properly. •...
  • Page 6 Warnings for Safe Use Installation Issues Warning Do not Do not place it in an Do not place the product area with potential for in a place with high gas leak or near a moisture or dust. heating product. • This may cause electric shock or fire.
  • Page 7 This will cause lukewarm water to be extracted. Please contact Cuckoo website or certified • This may lead to burns or accidents. distributor .

  • Page 8: Cautions For Safe Use

    • Approximately 4.0L of water (Stand Type) will be drained from the hot water tank. Approximately 14.1L of water will be drained • Use of any filter other than a genuine Cuckoo filter may when hot water is drained before cold water. Drain cold water cause a decrease in water filtration performance, an abnormal taste of water, water leak, or a malfunction.

  • Page 9: Name Of Parts/Components Information

    Name of Parts / Components Information Name of Parts < Front > < Back > Hot Water Indicater Energy Save Indicater Cold Water Indicater “Energy Save” Button Water Level Indicater “Cold” Button “Hot” Button Select Lever Cold Water Faucet Power Cord Cold Water Lever Hot Water Faucet Hot Water Lever...

  • Page 10: Filtration Circuit/ Water Filtration System

    Helps filter out general germs, viruses, minute particles, Step 4 Nano Positive Filter and some sorts of heavy metal ( iron, aluminum). ※ If CUCKOO Filter (genuine) is not used or if the filter is used for a prolonged period, its performance could decrease.

  • Page 11: Details To Check Before Installation

    Details to Check before Installation Details to Check before Installation Cautions when installing the Product Do not place the product in direct sunlight or near a heating product. ▶ This may cause color changes or fire. Allow installation space. ▶ To allow convenient replacement of the filters, make sure the product is placed 8 inch away from the wall and that the distance of the water...

  • Page 12: How To Install The Product 12

    How To Install the Product How To Install the Product ❸ Open ❶ Closed Cold Water Pipe ❺ Tap Water Supply Valve External Valve (for sale) Tap Water Input Tap Water(Blue) External Outlet(Orange) External Outlet ❷ ❶ Turn off cold water supply to the sink •...
  • Page 13 How To Install the Product ❻ Connect 1/4" Water Line to T-valve • Attached 1/4" water line to the quick connect adapter on the T-valve, push the 1/4" line fully onto the quick connect fitting nub. After pressing the water line fully onto the quick connect nub, make sure to use the locking nut properly to secure the 1/4"...

  • Page 14: Details To Check Before Use 14

    • If you press the power button without water in the tank, the safety feature will activate, so the hot water heater will not be heated. This will cause lukewarm water to flow. Then, visit CUCKOO website for more information.
  • Page 15 Details to Check before Use/How To Use Details to Check before Use Empty the tray regularly. Replace and manage the Filter regularly. ▶ You need to regularly replace the filters to ensure clean water. ▶ Refer to page 26 for the filter replacement cycle.

  • Page 16: How To Use 15 ~18

    How to Use How to Get Cold Water Press the “Cold” button for about 3 seconds to turn it on. It takes 60 minutes for the cooler (condenser) to cool the water. (The blue lamp will be turned on) ▶ Before turning on the“Cold”button, make sure the water supply is available and the tap water supply valve is open.
  • Page 17 How to Use How to Use Energy Save Function This function saves energy by reducing the standby power and the brightness of the indicator. While the [Energy Save] indicator is off, press the [Energy Save] button. ▶ The [Energy Save] indicator lights up, and after 1 second all the indicators are dimmed.
  • Page 18 How to Use Setting the temperature Setting the temperature of hot water:Press the [Energy Save] button for 3 seconds. ▶ Enter the hot and cold water temperature setting mode. [Initial Setting : Level 3] ▶ Press the hot water button to set the temperature. [The higher Level means the higher temperature] ※...

  • Page 19: How To Clean The Cold Water Tank 19

    How to Clean the Cold Water Tank How to Clean the Cold Water Tank First, close the Tap Water Supply Valve. Closed Press the “Hot” & “Cold” button for 3 seconds to turn them off. ▶ Make sure that the "hot" and "cold" lights are turned off.
  • Page 20 How to Clean the Cold Water Tank How to Clean the Cold Water Tank Remove the lid cover of the product. ▶ Requires a phillips head “+” screwdriver. Remove the cover from the cold water tank. ▶The upper part of cold water tank is slightly warm because it contains ambient water and hot water steam.
  • Page 21 How to Clean the Cold Water Tank How to Clean the Cold Water Tank Reassemble the Separator to the Cold Water Tank. ▶ Cautiously press the separator into place. If it is not placed properly, the operation of the compressor will be effected, which can cause noise. Please make sure place the separator properly.

  • Page 22: How To Clean Tray

    How to Clean Tray How to Clean Tray Separation of Tray ▶ Hold and move the tray upwards to separate the tray. Separation of Tray Cover ▶ After removing the tray, pull from the hole of the cover on the top of the tray to separate the tray cover. Cleaning of Tray ▶...

  • Page 23: How To Replace The Filter 23

    How To Replace the Filter How To Replace the Filter (CUCKOO Filter (genuine) must be used) Close the Tap Water Supply Valve. Closed Remove the remaining pressure inside the pipe. ▶ Drain approximately 3~4 cups (500cc) of water from the cold water faucet.
  • Page 24 How To Replace the Filter How To Replace the Filter (CUCKOO Filter (genuine) must be used) Before replacing the filter, detach the connecting tube of the filter you wish to replace. ▶ Detach the connecting tube using an appropriate tool (fitting separator). Damage to the fitting and/or connecting tube may cause water leak.
  • Page 25 How To Replace the Filter How To Replace the Filter (CUCKOO Filter (genuine) must be used) Place the lower front cover again and fasten it with screws. ▶ Find the accurate place of the screws to ensure the cover to be fastened properly.

  • Page 26: Expected Filter Replacement Cycle

    Expected Filter Replacement Cycle Sediment 3.0 Filter 1800~2400L /6~8 months Pre-Carbon Block 2.0 Filter 1800L / 6 months CP-QN1401SW Natural 2.0 Filter 3600L / 12 months Nano Positive Filter 3600L / 12 months ※ Note: the above replacement cycles are estimates only and may vary depending on feed water condition.

  • Page 27: Please Check Before Asking For Support 27

    • Is it the time to replace the Filter? • Replace the filter (with a genuine filter of CUCKOO). • Have you not used hot water for a long time? • Drain the water from the hot water tank through the hot water drain tube from the back.
  • Page 28 • Is it time to replace the filter? • Replace the filter with Cuckoo Filter (genuine). • Did you place the product on a flat area? • Place the product on an even and sturdy area.

  • Page 29: Product Specifications

    Product Specification Product Name Drinking Water Coolers Category Stand Type Model CP-QN1401SW Rated Voltage Single Phase. AC 120V / 60Hz Power Consumption Hot : 465W(3.9A)/ Cold : 107W(1.8A) / TOTAL : 572W(5.7A) Nano Positive Filter System Water Filtration Method Materials : Polypropylene, Activated Carbon Sediment 3.0 Filter...
  • Page 30 MEMO...
  • Page 31 MEMO...
  • Page 32 http://www.cuckooamerica.com We provide satisfying consultstion and services concerning your complaints, suggestions, and recommendations upon receiving your troubled product model name, status, and contact information. ♣ After reading this manual, keep it in a place easily accessible to the user for future reference. ♣...
