Rekluse RadiusX Installation Manual page 20

If the Free Play Gain is not optimal, the installed gap needs to be
adjusted.
The installed gap should be fine-tuned in small increments and
then recheck Free Play Gain. Refer to the table below to set the
proper installed gap based on your Free Play Gain.
Note: If you are unable to obtain the correct Free Play Gain or
you are nearly out of cable adjustment after performing the
adjustment, your cable may be worn or stretched from wear or
use. If this is the case, the cable should be replaced.
Symptom
· Too much Free Play
Gain: Clutch lever
moves in too far
· Clutch has
excessive drag or
stalls
· It is difficult to fully
override the clutch
with the lever
· Too little Free Play
Gain: Clutch lever
only moves slightly
or does not move at
all
· Clutch slips
· Bike seems to lose
power
Pg. 20
Reason
Installed gap is
too small
Installed gap is
too large
Doc ID: 191-6305A
Doc Rev: 091020
Solution
Tighten the cable by
turning the adjuster
nut to increase the
Installed Gap.
Recheck Free Play
Gain.
Loosen the cable by
tuning the adjuster nut
to reduce the Installed
Gap.
Recheck Free Play
Gain.
