Tektronix MSO4 Series Help Manual

Hide thumbs Also See for MSO4 Series:

Installation and safety (73 pages)

,

Quick start manual (65 pages)

,

Manual (43 pages)

page of 768

/ 768
Bookmarks

Advertisement

Quick Links

Download this manual

4/5/6 Series MSO

MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB,

MSO58LP, and LPD64

Help

Register now!

Click the following link to protect your product.

tek.com/register

*P077130327*

077-1303-27

March 2025

Advertisement

Need help?

Need help?

Do you have a question about the MSO4 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Tektronix MSO4 Series

Page 1 4/5/6 Series MSO MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB, MSO58LP, and LPD64 Help Register now! Click the following link to protect your product. tek.com/register *P077130327* 077-1303-27 March 2025...
Page 2 Copyright © 2024 Tektronix 2024. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specifications and price change privileges reserved.
Page 3 Contents Contents List of Figures....................................19 List of Tables....................................21 Welcome to the instrument embedded Help..........................22 TEKTRONIX END USER LICENSE AGREEMENT......................25 Open Source GPL License Notice............................26 Product support and feedback............................. 26 Documentation..................................27 Options......................................28 Install option upgrade licenses.............................28 Uninstall (return) an option license............................29 Drive names for system and USB memory devices......................29...
Page 4 Contents Mount TekDrive..................................78 Unmount a network drive from a standard instrument......................79 Unmount a network drive from the Windows 10 instrument....................79 Unmount a TekDrive................................79 Connect the oscilloscope to a PC using a USB cable......................79 Remote access from a Web browser........................... 80 Remote access to a Windows 10 instrument........................81 Install TightVNC on the Windows 10 instrument......................81 Install TightVNC on a PC..............................
Page 5 Contents Change waveform view settings............................109 Display and configure cursors............................109 Display and configure Multi-source cursor readouts......................112 Using Default Setup................................114 Using FastAcq..................................114 Add a callout to a view............................... 115 Delete a Callout..................................116 Acquiring digital signals................................117 Connect and set up digital signals............................117 Add a serial bus to the Waveform view..........................
Page 6 Contents Edit mask segments using the Mask Definition menu....................... 161 Waveform histogram ................................164 Create a waveform histogram............................164 Edit histogram on the screen............................. 164 Waveform Histogram guidelines............................165 Zoom in on waveforms................................166 Turn on Zoom mode................................166 Using Wave Inspector front-panel controls for zoom......................167 Zoom mode and Searches..............................167 Measurement configuration...............................169 Label a measurement................................
Page 7 Contents Measurement Table configuration menu........................215 Navigation on Bar Graph and Harmonics Results Table.....................217 Peak Marker results table configuration menu......................217 Results Tables operations overview..........................218 Save As configuration menu (Measurement Results Table)..................218 Search Results table menu............................219 Save As configuration menu (Bus Decode Results table)..................220 Save As configuration menu, Custom Results Table....................220 Save As configuration menu (Peak Marker results table)...................221 AFG configuration menu..............................
Page 8 Contents SMBus serial bus configuration menu........................266 SpaceWire serial bus configuration menu........................267 SPI serial bus configuration menu..........................268 SPMI serial bus configuration menu........................... 269 SVID serial bus configuration menu..........................270 USB serial bus configuration menu..........................271 Cursor configuration menu..............................273 Date and Time configuration menu............................ 275 DDR measurement configuration menu overview......................275 Configure panel (DDR measurement configuration menu)..................276 DDR measurement name panel (Measurement configuration menu)................
Page 9 Contents Add Variable menu (math Equation Editor).........................325 Create/Edit filter configuration menu...........................326 Equation Editor (Math configuration menu)........................ 327 Math configuration menu............................328 Measurement configuration menu overview........................331 Clock Recovery- Advanced Settings configuration menu................... 332 Clock Recovery panel (Measurement configuration menu)..................332 Configure panel (Measurement configuration menu)....................336 Filter/Limit Results panel (Measurement Settings menu)...................
Page 10 Contents Histogram plot configuration menu..........................395 Inductance Curve configuration menu (Magnetic Analysis power measurement)............396 I vs (integral of) V plot configuration menu (Magnetic Analysis power measurement)..........397 Impedance plot configuration menu..........................398 Math FFT plot configuration menu (Math waveform)....................398 Overlapped Recovery plot configuration menu......................401 Phasor Diagram plot configuration menu (IMDA-DQ0)....................402 Phasor Diagram plot configuration menu (IMDA-Power Quality)................404...
Page 11 Contents CAN serial bus search configuration menu (when using a .dbc symbol definition file)..........459 CAN serial bus search configuration menu (when not using a .dbc symbol definition file).........461 CPHY serial bus search configuration menu......................463 CXPI serial bus search configuration menu........................465 Configure custom pattern editor..........................467 Configure pattern editor..............................
Page 12 Contents Pass/Fail Testing panel (Spectrum measurement configuration menu)..............550 Spectrum Measurements Name panel (Measurement configuration menu).............. 550 Spectrum View menus............................... 551 Frequency Vs. Time badge menu..........................551 Magnitude Vs. Time badge menu..........................551 Phase Vs. Time badge menu............................552 Spectrum badge menu............................... 553 Selected Trace configuration menu (Spectrum View)....................555 Spectrum View Cursors menu............................
Page 13 Contents Gating panel (WBG-DPT measurement configuration menu)..................641 Pass/Fail Testing panel (WBG-DPT measurement configuration menu)..............641 Reference Levels panel (WBG-DPT measurement configuration Menu)..............642 Waveform acquisition................................643 Acquisition concepts................................643 Acquisition hardware..............................643 Sampling process............................... 643 Real-Time sampling..............................643 Interpolated Real-Time sampling..........................643 Waveform record................................
Page 14 Contents Hamming window................................662 Kaiser-Bessel FFT window..............................662 Math waveforms.................................662 Math waveform sources..............................663 Math waveform elements..............................663 Math waveform editor syntax............................. 663 Math waveform differentiation............................664 Math waveform offset, position, and scale......................... 664 Measurement variables..............................665 Missing or out-of-range samples............................667 Rectangular window................................667 Tek-Exponential window..............................668 User Defined Filter ................................
Page 15 Contents tJIT(per) (DDR)................................686 tJIT(cc) (DDR)................................687 tERR(n) (DDR)................................687 tERR(m-n) (DDR)................................687 tDQSCK (DDR)................................687 tCKSRE..................................688 tCKSRX..................................688 tCMD-CMD................................. 688 DPM Power sequence analysis algorithm......................... 688 Overshoot................................... 688 Undershoot................................. 688 DC Rail Voltage................................688 Turn on Overshoot..............................688 DPM Ripple analysis measurement...........................688 Ripple..................................688 DPM Transient analysis measurement algorithm......................
Page 16 Contents DCD.................................... 703 DDJ.....................................703 Differential Crossover measurement algorithm......................703 DJ....................................703 Dual Dirac deterministic jitter............................703 F/2 measurement algorithm............................703 F/4 measurement algorithm............................703 F/8 measurement algorithm............................704 ISI measurement algorithm............................704 J2....................................704 J9....................................704 Jitter Summary measurement.............................704 NPJ..................................... 704 Pattern Length measurement algorithm ........................704 PJ....................................704 Phase noise................................
Page 17 Contents algorithm................................. 716 DS(on) Power measurements: Magnetic Analysis algorithms......................716 Inductance algorithm..............................717 I vs (integral of) V algorithm............................717 Magnetic Loss algorithm.............................717 Magnetic Property algorithm............................717 Power measurements: Output Analysis algorithms......................719 Line Ripple algorithm..............................719 Switching Ripple algorithm............................719 Efficiency algorithm..............................719 Turn On Time ................................720 Turn Off Time ................................
Page 18 Contents Capacitance Analysis Algorithm..........................734 Reverse Recovery Analysis Algorithms........................735 Switching Parameter Analysis Algorithms........................736 Switching Timing Analysis Algorithms........................737 WBG Auto Level Determination Algorithm........................738 WBG-DPT Deskew Algorithm............................. 739 References....................................742 DPM badge error and warning messages......................... 742 Power badge error and warning messages........................742 Spectrum badge error and warning messages........................
Page 19 List of Figures List of Figures Figure 1: Connecting probes to the 4 Series MSO........................36 Figure 2: Connecting probes to the 5 Series MSO........................36 Figure 3: Connecting probes to the MSO58LP........................... 36 Figure 4: Connecting probes to the 6 Series MSO........................37 Figure 5: Connecting SMA cables to the LPD64.........................37 Figure 6: 4 Series B MSO Controls.............................38 Figure 7: 5 Series B MSO controls..............................39...
Page 20 List of Figures Figure 33: Multi-rail example with different HSS loads (point of loads)..................689 Figure 34: This transition is for 4 pole pairs motor........................696 Figure 35: Jitter map - Spectral Only............................701 Figure 36: Jitter map - Spectral + BUJ............................702 Figure 37: B-H curve.................................
Page 21 List of Tables List of Tables Table 1: Probe errors...................................61 Table 2: Common touchscreen UI tasks with mouse equivalents....................68 Table 3: Spectrum View RF vs Time, Acquisition time vs Span....................147 Table 4: Spectrum View panel, fields and controls........................446 Table 5: Other panel fields and controls............................447 Table 6: 1-Wire search menu, fields, and controls........................
Page 22 Welcome to the instrument embedded Help Welcome to the instrument embedded Help This Help supports the 4 Series MSO (MSO44, MSO46), 4 Series B MSO (MSO44B, MSO46B), 5 Series MSO (MSO54, MSO56, MSO58, MSO58LP), 5 Series B MSO (MSO54B, MSO56B, MSO58B), 6 Series MSO (MSO64), 6 Series B MSO (MSO64B, MSO66B, MSO68B), and the 6 Series Low Profile Digitizer (LPD64) instruments.
Page 23 Optional serial triggering features enable you to isolate protocol-level events of interest in common aerospace, audio, automotive, computer, and embedded serial buses. See the Serial bus and trigger options topic in the instrument Help, or the Serial Triggering and Analysis Applications Datasheet (Tektronix part number 48W-61353-X) for more information. •...
Page 24 Optional serial triggering features enable you to isolate protocol-level events of interest in common aerospace, audio, automotive, computer, and embedded serial buses. See the Serial bus and trigger options topic in the instrument embedded Help, or the 6 Series MSO Serial Triggering and Analysis Applications Datasheet (Tektronix part number 48W-61353-x) for more information...
Page 25 4/5/6 Series MSO Help, version 20250404-10:00 for Firmware v2.16 and above. TEKTRONIX END USER LICENSE AGREEMENT Go to www.tek.com/en/eula to read the Tektronix End User License Agreement. 4/5/6 Series MSO MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB, MSO58LP, and LPD64 Help...
Page 26 Please note that we may charge you a fee to cover the cost of performing this distribution. Product support and feedback Tektronix values your feedback on our products. To help us serve you better, please send us your suggestions, ideas, or comments on your instrument, application, or product documentation.
Page 27 Welcome to the instrument embedded Help • Please indicate if you would like to be contacted by Tektronix about your suggestion or comments. Application specific information • Software version number • Description of the problem such that technical support can duplicate the problem •...
Page 28 A floating license enables you to install an upgrade option on any equivalent instrument, but only one instrument at a time can use the license. You must uninstall a floating license from one instrument, and log it back into the Tektronix AMS, before checking it out for use on another instrument.
Page 29 Floating licenses can be used on any compatible instrument, but can only be checked out to use on one instrument at a time. This process removes the option license from the instrument so that you can check (return) it back into the Tektronix TekAMS system.
Page 30 Options Drive name Drive letter Drive or physical USB port location MSO44B and MSO46B Root drive User-accessible memory on the oscilloscope. Front panel USB 2.0 (top) USB 2.0 (middle) USB 2.0 (bottom) Rear panel USB 3.0 (left) USB 3.0 (right) Drive name Drive letter Drive or physical USB port location...
Page 31 Options Drive name Drive letter Drive or physical USB port location Root drive User-accessible memory on the oscilloscope. Front panel USB 3.0 (left) USB 2.0 (right) Rear panel USB 2.0 (top) USB 2.0 (bottom) USB 3.0 (top) USB 3.0 (bottom) Instruments with Windows OS Root drive User-accessible memory on the oscilloscope.
Page 32 The optional SSD assembly installs in the bottom of the instrument. To remove a previously installed SSD, reverse these steps. Contact your nearest Tektronix, Inc., Service Center or Tektronix Factory Service if you need any installation assistance. Prerequisite: Wear an anti-static wrist strap connected to the instrument chassis while installing this drive.
Page 33 Activating Windows The Windows operating system shipped from Tektronix is in a "deferred activation" state. The first time you power on an instrument with a newly installed Windows drive, the operating system may attempt to activate itself, depending on whether the instrument is connected to a network.
Page 34 Getting acquainted with your instrument • The instrument may attempt to activate and fail. You may see a screen message saying that Windows is not activated and the Windows user settings may be disabled. • Verifying Windows activation on page 34 to check the activation status of the instrument. •...
Page 35 Getting acquainted with your instrument • You can use the Application menu to access installed applications. Updating the Windows TekScope application software The Windows TekScope application does not automatically update when newer versions are released. You will need to manually download and install the newer software.
Page 36 Getting acquainted with your instrument Connecting probes or signals to the instrument Probes connect the instrument to your device under test (DUT). Use a probe or cable that best matches your signal measurement needs. Figure 1: Connecting probes to the 4 Series MSO Figure 2: Connecting probes to the 5 Series MSO Figure 3: Connecting probes to the MSO58LP...
Page 37 Figure 5: Connecting SMA cables to the LPD64 Connecting Probes (all instruments except LPD64) Connect TPP Series, TekVPI+, TekVPI, or other supported Tektronix analog probes by pushing them into a FlexChannel connector. The probe base latch locks with a 'click' when the probe is fully seated.
Page 38 To use a Low Profile instrument on a bench, purchase and install the 5 Series MSO MSO58LP/6 Series Low Profile Digitizer LPD64 Benchtop Conversion kit (Tektronix part number 020-3180-xx). The kit includes chassis feet and a handle, and lets you stack Low Profile instruments on a bench.
Page 39 Getting acquainted with your instrument Figure 7: 5 Series B MSO controls Figure 8: 6 Series B MSO controls Acquisition and Cursors controls: 4/5/6 Series MSO MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB, MSO58LP, and LPD64 Help...
Page 40 Getting acquainted with your instrument • Run/Stop starts and stops waveform acquisition. The button color indicates the acquisition status (green = running and acquiring; red = stopped). When stopped, the oscilloscope shows waveforms from the last completed acquisition. The Run/Stop button on the screen also shows the acquisition status.
Page 41 Getting acquainted with your instrument The Level knob is disabled when the trigger type requires two level settings or other trigger qualifiers (set from the Trigger configuration menu). Push the knob to set the threshold level to 50% of the peak-to-peak amplitude range of the signal. •...
Page 42 Getting acquainted with your instrument • If two or more Math waveforms are displayed, pushing the button cycles through selecting each math waveform. • Ref button adds or selects a Reference (saved) waveform on the Waveform view. • If no Reference waveform exists, pushing the Ref button opens the Browse Waveform Files configuration menu. Navigate to and select a waveform file (*.wfm) and tap Recall to load and display the reference waveform.
Page 43 Getting acquainted with your instrument • If a File > Save or File > Save As operation has occurred since the last instrument startup, pushing Save saves the file types to the location last set in the Save As configuration menu. •...
Page 44 Getting acquainted with your instrument Figure 9: 4 Series MSO Figure 10: 5 Series MSO 10. Aux In is auxiliary trigger input connector. A connector to which you can connect an external trigger input signal. Use the Aux In trigger signal with the Edge trigger mode.
Page 45 Getting acquainted with your instrument The MSO58LP front panel ® 1. FlexChannel probe connectors: FlexChannel connectors support all TekVPI+ and TekVPI measurement probes, BNC passive ® probes, the TLP058 FlexChannel Logic Probe, and BNC cables. You connect most probes simply by pushing them into the connector until the probe seats with a click.
Page 46 Getting acquainted with your instrument You can also use the ground connector to attach an anti-static wrist strap, to reduce the chance of electrostatic damage (ESD) while you handle or probe the DUT. 4. USB Host ports: USB ports are located at the lower right corner of the front panel. Connect USB flash drives to which you can save or recall data (such as instrument firmware updates, waveforms, settings, and screen captures), or connect peripheral devices such as a mouse or keyboard.
Page 47 Getting acquainted with your instrument • Yellow - Standby mode • Blue - Powered on Rear panel connections The rear panel connections supply power to the instrument and provide connectors for network, USB devices, video, reference signals, and the AFG output. 4 Series B MSO 1.
Page 48 Getting acquainted with your instrument 1. LAN connector (RJ-45) connects the instrument to a 10/100/1000 Base-T local area network. 2. USB 2.0 Device port lets you connect to a PC to remotely control the instrument using USBTMC protocol. 3. USB 2.0 Host ports let you connect a USB memory device, keyboard, or mouse. 4.
Page 49 Getting acquainted with your instrument 1. Power cord connector. Use only the power cord specified for this product and certified for the country of use. 2. Ref In lets you connect a high-precision 10 MHz reference signal to the oscilloscope for more accurate measurements. 3.
Page 50 Getting acquainted with your instrument User interface screen The touch screen user interface contains waveforms and plots, measurement readouts, and touch-based controls to access all oscilloscope functions. 1. The Menu bar provides menus for typical operations including: • Saving, loading, and accessing files •...
Page 51 Getting acquainted with your instrument • The Results Table button adds a Measurement or Bus Results table to the screen. The Measurement Results table displays all measurements present in the Results bar. The Bus Results table displays bus decode information for displayed bus waveforms. Each table is contained within its own view window, which can be moved within the display area.
Page 52 Getting acquainted with your instrument User interface elements Each area of the user interface has a specific function that helps manage information or controls. This topic shows and describes the key user interface elements. The Waveform Record View is a graphical high-level view of the overall waveform record length, how much of the record is on the screen (shown in brackets), the location of key time events including the trigger event, and the current position of waveforms cursors.
Page 53 Getting acquainted with your instrument The Zoom icon (in upper right corner of Waveform and Plot views) toggles zoom on and off. The front panel Zoom button and knobs also turn on zoom mode and change the position and horizontal size of the Zoom Box. The Trigger Level Indicator icon(s) shows the trigger level on the trigger source waveform.
Page 54 Getting acquainted with your instrument The markers are displayed, for about three seconds, after any Offset, Position, or Scale control change that leaves the channel dynamic range limits within the acquisition window. After about three seconds the markers become short lines at the left edge of the graticule.
Page 55 Getting acquainted with your instrument Measurement badges Measurement badges are located in the Results bar. They show measurements or search results. The badge title also shows the measurement source or sources. To add a Measurement badge, tap the Add New Measurement button and select a measurement. Double-tap a Measurement badge to open its configuration menu to change or refine settings.
Page 56 Getting acquainted with your instrument Click Cancel to change the current badge state to the previous badge state. For RDS(on), click Cancel to cancel the acquistion and move to the result badge. It also cancel the connected generator automation. Results badge: There are two ways to delete Wizard badges.
Page 57 Getting acquainted with your instrument Some Measurement badges also have Navigation buttons, shown by single-tapping the badge. The < (Previous) and > (Next) buttons center the waveform in the display at the position of the previous or next measurement point in the record (for measurements that take more than one measurement per acquisition).
Page 58 Getting acquainted with your instrument • Flick the badge off the right edge of the display to remove it from the Results bar. Flicking left from the right edge of the Results bar recovers the badge. Badge recovery is only possible within 10 seconds of removal. Mask Test badge The mask test results and measurement statistics are displayed in the Mask Test badge in the Results bar.
Page 59 Getting acquainted with your instrument The histogram badge displays the measurements which are checked in the Result Badge menu. To add more histogram measurements to the badge refer Waveform Histogram Result Badge menu on page 629. You can drag the badge to change its position in the Results bar and open the badge right-click menu to access a quick-action menu. There are two ways to delete Waveform Histogram badges.
Page 60 Getting acquainted with your instrument Some searches also provide Min and Max navigation buttons that open the Zoom mode and center the waveform in the display at the minimum or maximum value for that search event in the current acquisition. Search badges are listed in the order created.
Page 61 Unsup Accessory is unsupported. Prb Fault Critical accessory fault. Please re-attach the accessory. If the problem persists, contact Tektronix service. Over Rng The signal voltage or current is over range. Please reduce the signal amplitude. Temp The probe has experienced an over temperature condition. Please remove the probe from the high temperature area.
Page 62 Description S-param Error during S-parameter transfer. Please reattach the probe. If the problem persists, contact Tektronix Service. History badge The History badge is shown in the Results bar. Navigate the history acquisitions by using the Previous/Next or Play/Pause buttons. Timestamp shows the time difference between the previous acquisition and the selected acquisition.
Page 63 Getting acquainted with your instrument The Reference acquisition readout shows the timestamp when the acquisition occurred in time in history. It also displays the delta between the Selected acquisition and the Reference acquisition timestamps. There are two ways to delete the History badge. •...
Page 64 Getting acquainted with your instrument Action Result Example Flick Flick the badge off the bottom edge of the display to remove it from the Settings bar. Flick the badge off the right edge of the display to remove it from the Results bar. Flick from the right or bottom edge to recover a removed badge.
Page 65 Getting acquainted with your instrument Moving badges in the measurement Results Bar • A Measurement or Search badge can only be moved within the Results Bar. • Dragging a badge to a new location causes the non-selected badges to move to create the position at which to insert the badge. •...
Page 66 Getting acquainted with your instrument • Use standard touch and menu interactions to select and change individual badge settings. • You can drag and move badge groups the same way as individual badges. • The order of badges or badge groups (left to right) determines the order of slices in the display (top to bottom). •...
Page 67 Getting acquainted with your instrument Tap anywhere outside a configuration menu to close it. To open Help content for a configuration menu, tap the question mark icon in the upper right corner of the menu. Zoom user interface Use the zoom tools to magnify waveforms to view signal details. 1.
Page 68 Getting acquainted with your instrument on the waveform to draw a box waveform. You can continue to draw zoom boxes until you single tap anywhere on the screen or open a menu. To toggle between Zoom mode, Visual Trigger mode, and Mask mode, double-tap the DRAW-A-BOX button and select one of the options.
Page 69 Getting acquainted with your instrument Task Touchscreen UI action Mouse action Close a configuration menu. Some Tap anywhere outside the menu or dialog. Click anywhere outside the menu or dialog. dialog boxes will not close until you click an OK, Close, or other button in the dialog.
Page 70 Getting acquainted with your instrument From the help browser, select one of the following tabs: • Contents Tab. Click any entry to display information on the subject. • Search Tab. Type in the keyword you are looking for; then click List Topics. Every topic that contains the keyword will be displayed. Select a topic, and click Display to open the topic.
Page 71 IP address in a web browser. To remotely set a control or run this task on a Low Profile instrument, see the instrument Programmer Manual (Tektronix part number 077-1305-xx) for the correct command or commands to use.
Page 72 Configure the instrument Tap the Timing Measurements panel in the Add Measurements configuration menu. Double-tap the Frequency button to add the frequency measurement to the Results bar. Check that the Frequency measurement reads 1 kHz. 10. Repeat these steps to check the other channels on the oscilloscope. Make sure that you set the source in the Add Measurement configuration menu to use the correct channel before adding the Frequency measurement.
Page 73 If the SPC fails, write down any error message text. Make sure that all probes and cables are disconnected (except for the LPD64) and run the SPC again. If the SPC still fails, contact Tektronix Customer Support. 4/5/6 Series MSO MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB, MSO58LP, and LPD64 Help...
Page 74 IP address in a web browser. To remotely set a control or run this task on a Low Profile instrument, see the instrument Programmer Manual (Tektronix part number 077-1305-xx) for the correct command or commands to use.
Page 75 IP address in a web browser. To remotely set a control or run this task on a Low Profile instrument, see the instrument Programmer Manual (Tektronix part number 077-1305-xx) for the correct command or commands to use.
Page 76 Configure the instrument Note: Probe compensation does not apply to the LPD64 instrument. A passive probe is only adjusted for one channel at a time. If you move a passive probe to another channel, you must compensate that probe to that channel. 1.
Page 77 Configure the instrument Mount a network drive from a standard instrument Use this procedure to mount (map) a network Linux mount point or Windows shared directory on a standard (non Windows OS) instrument. Prerequisites: The oscilloscope must be connected to a network that has access to the directories to mount or unmount. See Connect to a network (LAN) on page 76.
Page 78 Mount TekDrive TekDrive is a collaborative T&M data workspace provided with the purchase a supported Tektronix product. Before you begin This mounting procedure is applicable for both Windows and LINUX platforms. You must have internet connectivity access to perform this procedure.
Page 79 Configure the instrument 5. Select the required Auto Disconnect option. 6. Tap Connect to TekDrive to display the window with the QR and numeric code for TekDrive activation. 7. Browse to drive.tekcloud.com/activate to login using your credentials and enter the numeric code displayed in the Mount Drive window. Register and create a new account if you are a new user.
Page 80 Configure the instrument 4. Connect a USB cable from the PC to the USB Device port on the instrument. 5. If using the USB connection to remotely control the oscilloscope using GPIB commands, set the GPIB Talk/Listen Address for your configuration (0 - 30).
Page 81 Configure the instrument 4. Paste the text into the Clipboard field. 5. Press Ctrl-Alt-Shift to close the browser Clipboard menu. 6. Use e*Scope to open the instrument menu to which to paste content, and position the cursor in the field where you want to paste the text.
Page 82 IP address in a web browser.To remotely set a control or run this task on a Low Profile instrument, see the instrument Programmer Manual (Tektronix part number 077-1305-xx) for the correct command or commands to use.
Page 83 Configure the instrument Connect all probes that you want to deskew to the oscilloscope. Connect up to four probe tips and ground leads to the Probe Compensation connector (maximum of four channels at a time). Turn on all the channels of the first four channels that you want to deskew. Push the Autoset button.
Page 84 Configure the instrument Connect a keyboard or mouse The instrument supports most standard USB-connected keyboards and mice, and wireless-connected keyboards and mice (using a USB-connected dongle). Connect a keyboard and/or mouse by connecting their USB cable, or USB dongle, into any available USB Host port. The keyboard or mouse should work immediately.
Page 85 Analog channel operating basics Analog channel operating basics Acquiring a signal After acquiring a signal you can take measurements and plot the results. Use the following procedure to set the scale and position parameters for analog signal acquisition. 1. Press the Default Setup button. 2.
Page 86 Analog channel operating basics When using the Overlay Display mode, the instrument adjusts the horizontal and trigger settings of the trigger source channel to display a triggered waveform for that channel. Vertical scale and position adjustments for all active channels in Overlay Display mode are controlled by the Autoset in Overlay Display Mode Optimizes selection in the Autoset panel of the User Preferences menu.
Page 87 Analog channel operating basics 2. Use the menu selections to set horizontal parameters. 3. Tap the Help icon on the menu title for more information on these settings. How to trigger on a signal Use this procedure to open the Trigger menu to select and configure the trigger event type and conditions. 1.
Page 88 Analog channel operating basics To trigger on a bus, you must first add the bus to the Waveform view. See Add a math, reference, or bus waveform on page 94. Note: Triggering on buses other than Parallel requires purchasing and installing serial trigger and analysis options. 3.
Page 89 Analog channel operating basics Start and stop an acquisition Acquisition controls the start and stop of waveform acquisition. 1. To start an acquisition, double-tap the Acquisition badge and tap Run/Stop in the Acquisition configuration menu. You can also push the Run/Stop button on the front panel. 2.
Page 90 Analog channel operating basics 2. Tap an Inactive Channel button (in the Settings bar) of a connected channel. The selected channel is added to the Waveform View and a Channel badge is added to the Settings bar. 3. Continue tapping Inactive Channel buttons to add more channels (digital or analog). Channels are displayed from lowest-numbered channel at the top, to highest-numbered channel at the bottom of the view, regardless of the order they were added (in stacked mode).
Page 91 Analog channel operating basics Field or control Description Display Enables (On) or disables (Off) displaying the channel waveform in the Waveform View window. Invert Reverses the amplitude polarity of each sample point. When On, Invert adds a down arrow symbol to the channel badge.
Page 92 Analog channel operating basics Field or control Description Bandwidth Filter Optimized Tap to select a bandwidth filter that is optimized for flatness or step response. This selection is only available on 6 Series MSO instruments. Flatness selects a brick-wall filter optimized for flatness within band with a sharp rolloff. Flatness filtering is not compatible with Peak Detect and Envelope acquisition modes.
Page 93 Analog channel operating basics Field or control Description Deskew Allows setting the channel deskew value. Set to 0 Sets the channel deskew to 0. Multi-Channel Brings up the Deskew configuration menu. External Attenuation Allows setting an external attenuation for the channel. As one field is edited, the other field changes to reflect the corresponding value.
Page 94 Analog channel operating basics Field or control Description Probe Displays the probe name or a drop-down list to select the probe connected to the To Source. Propagation Delay Displays the propagation delay of the probe shown in the Probe control. OK, Deskew Uses the deskew values to adjust the horizontal delay between channels 5.
Page 95 Analog channel operating basics 5. Double-tap a math, reference, or bus badge to check or change the waveform settings. See Configure channel or waveform settings. 6. Tap the Help icon on a configuration menu title for more information on math, reference, and bus waveform settings. 7.
Page 96 Analog channel operating basics Add a measurement Use this procedure to select and add measurements. Acquire the channel(s) and/or waveform(s) on which you want to take measurements. Note: Waveforms do not need to be displayed to be used for measurements, as long as the channel or waveform badge is on the Settings bar and is acquiring the signal to measure.
Page 97 Analog channel operating basics Select a measurement category panel, such as Amplitude Measurements or Timing Measurements, to display measurements for those categories. Some optional measurement packages are available in this menu as well like PWR, DJA, DBDDR3, DPM, IMDA, and WBG-DPT. Select a measurement and tap Add to add the measurement to the Results bar.
Page 98 Analog channel operating basics 11. Tap the Help icon on the menu title for more information on settings. Configure a measurement Use this procedure to add statistical readouts to the measurement badge, display plots for the measurement, and refine measurement parameters (configuration, global versus local scope of settings, gating, filtering, and so on).
Page 99 Analog channel operating basics Delete a Measurement or Search badge Use this procedure to remove a Measurement or Search badge from the Results bar. 1. Touch and hold the Measurement or Search badge that you want to delete. The instrument opens a right-click menu. 2.
Page 100 Analog channel operating basics The following shows adding a Histogram plot. You can add more than one plot to measurements (to different measurements or the same measurement). For example, you can add two histogram plots for the same measurement, set one to display the X-Axis with a Logarithmic scale, and the other plot to display the X-Axis with a Linear scale.
Page 101 Analog channel operating basics 4. Double-tap within a Plot view to open a configuration menu to set display characteristics. Tap the Help icon on the configuration menu title for more information on that menu's settings. Tap outside the menu to close the menu. Display a Histogram plot Use this procedure to display a histogram plot.
Page 102 Analog channel operating basics Display a Time Trend plot Use this procedure to display a time trend plot. To display a time trend plot you must be taking a measurement. 1. Double-tap a measurement badge. The Measurement configuration menu is displayed. 2.
Page 103 Analog channel operating basics 7. Tap Add. The plot is displayed in a separate Plot view. 8. Double-tap in the Plot view to open a configuration menu for that plot. Display an Eye Diagram plot Use this procedure to display an eye diagram of a waveform. Prerequisite: An active signal for which you want to plot an eye diagram.
Page 104 Analog channel operating basics 3. Double-tap in the Plot view to open the configuration menu for that plot. Add Mask Testing to an Eye Diagram plot Use this procedure to add mask test segments to an eye diagram plot and display the mask segment hits information in the Results bar. Prerequisites: An eye diagram plot is on the screen.
Page 105 Analog channel operating basics 1. Tap Add New Math to create a math waveform and open the Math configuration menu. 2. Tap Source and select the signal source from the list. 3. Set Math Type to FFT. The FFT of the waveform is displayed in an FFT Math waveform view. 4.
Page 106 Analog channel operating basics 3. Set the voltage and current sources for the measurement. 4. Tap the Switching Analysis panel. 5. Select the SOA measurement and tap Add. The SOA measurement adds a Power measurement badge to the Results bar, and automatically adds the SOA plot to the screen. 6.
Page 107 Analog channel operating basics 3. Double-tap in the Plot view to open the configuration menu for that plot. Display a Power Supply Rejection Ratio plot Use this procedure to display a Power Supply Rejection Ratio plot for a power measurement. To display a Power Supply Rejection Ratio power measurement and plot: 1.
Page 108 Analog channel operating basics 2. Use the configuration menu fields to set the search criteria in the same way that you would set for a trigger condition (select the Search Type, Source, and conditions on which to search). Note: You cannot search for sequential events (there is no Sequence search type). 3.
Page 109 Analog channel operating basics Change waveform view settings Use this procedure to change the waveform display mode (Stacked or Overlay), waveform trace interpolation algorithm, waveform persistence, style and intensity, and graticule style and intensity. 1. Double-tap on an open graticule area to open the Waveform View configuration menu. 2.
Page 110 Analog channel operating basics 3. Use Multipurpose Knobs A and B to move the cursors, or touch and drag a cursor. Cursors show readouts that show position and difference measurements between the cursors. 4. To move the cursors to a different channel or waveform, just tap in that waveform graticule. 5.
Page 111 Analog channel operating basics The cursor configuration menu in an XY plot. 6. To split the cursors between two waveforms, tap the Source field and select Split and select the source for each cursor. The cursors are moved to the specified waveforms. 4/5/6 Series MSO MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB, MSO58LP, and LPD64 Help...
Page 112 Analog channel operating basics 7. Tap the Help icon on the menu title for more information on the menu settings. 8. To stop showing cursors, push the front panel Cursor button, press and hold to open the right-click menu and turn cursors off, or open the Cursors configuration menu and set Display to Off.
Page 113 Analog channel operating basics 6. Tap the Help icon for more information on the menu settings. 7. To stop displaying cursors, a. push the front panel Cursor button, b. press and hold to open the right-click menu and turn cursors off, or c.
Page 114 Analog channel operating basics • The first section of the badge shows the delta time information. • The second section of the badge shows the time and amplitude values associated with Cursor A. • The third section of the badge shows the time and amplitude values associated with Cursor B. •...
Page 115 Analog channel operating basics 3. View the waveform to find glitches, transients, or other random events. When you have identified an anomaly, use the advanced trigger system to capture the event of interest for further analysis. If FastAcq mode is on and you attempt to activate a feature that conflicts with this mode, FastAcq will be disabled. When the conflicting feature is turned off, FastAcq will resume in most cases.
Page 116 Analog channel operating basics Callout Type Description Note Adds a callout as a text. Arrow Adds a callout text with an arrow. Rectangle Adds a callout text with an arrow pointing to a rectangle. The rectangle can be dragged to any position. Bookmark Adds a callout text with a bookmark added for either Waveform view (ch, math, ref), Spectrum view (freq domain traces, rf vs time domain traces), or Time Trends.
Page 117 Connect the FlexChannel digital logic probe to the instrument. The digital signal waveforms display on the screen. Connect the probe to the signal sources. Use the accessories in the Tektronix Probe Accessory Kit (shipped with the probe) to connect to your DUT.
Page 118 Acquiring digital signals 11. To set all bit thresholds to the same value, enter a threshold value in the lower threshold field and tap Set All Thresholds. Add a serial bus to the Waveform view Use this procedure to add a serial bus to the Waveform view. This instrument supports decoding parallel buses (standard with the instrument) and several serial buses options.
Page 119 Acquiring digital signals The decoded bus is updated on the screen as you make changes to the settings. 4. Tap outside of the Bus configuration menu to close it. 5. Double-tap the Trigger badge and use the Trigger configuration menu to trigger on a specific condition in the bus. 6.
Page 120 Acquiring digital signals 2. If setting up a clocked bus: a. Set Clocked Data to Yes. b. Tap the Clock Source field and select the source for the parallel bus clock signal. c. Tap the Polarity and Threshold controls and set the clock signal transition to detect and threshold level, respectively. 3.
Page 121 Acquiring digital signals 4. Use the rest of the fields and controls in the configuration menu to set up the parallel bus parameters (label, position, display and decode formats). 5. Tap outside of the Bus configuration menu to close it. 6.
Page 122 Advanced triggering Advanced triggering You can check the advanced trigger status in the trigger menu. The menu indicates the trigger type and then shows sources, levels, or any other parameters that are important for the particular trigger type. Triggering concepts User selected trigger conditions are used to capture waveforms for measurement and analysis.
Page 123 Advanced triggering 4. Tap Trigger When and select the pulse width condition on which to trigger (> Limit, < Limit, = Limit, ≠ Limit, Outside Range, and Inside Range). 5. Set the pulse width time constraints: a. For all trigger when conditions except Outside Range or Inside Range, tap the Time Limit field and use the assigned multipurpose knob to set the pulse width time condition to meet.
Page 124 Advanced triggering 5. Tap the Threshold field and use the assigned multipurpose knob (or double-tap the field and use the keypad to enter a value) to set the threshold value that determines when the signal is high or low. 6. Tap the Time Limit field and use the assigned multipurpose knob (or double-tap the field and use the keypad to enter a value) to set the maximum time that a signal can stay high or low before transitioning to the opposite state.
Page 125 Advanced triggering 4. Tap Trigger When and select the condition on which to trigger. 5. Tap the Upper Threshold field and use the assigned multipurpose knob to set the threshold value that defines the upper limit that the signal must cross to be a valid signal transition (or double-tap the field and use the keypad to enter a value). 6.
Page 126 Advanced triggering Trigger on a signal window event Use Window triggering to trigger when a signal enters or exits a specified threshold range (window), or remains inside or outside the window for a specified time limit. To trigger on a window event: Double-tap the Trigger badge to open the Trigger configuration menu.
Page 127 Advanced triggering 9. Tap Define Logic and set the logic condition that must occur with all specified signals to cause a trigger event. Trigger on a setup-hold event Use the Setup & Hold trigger to trigger on a waveform when a data signal changes state inside of a specified setup and hold time, relative to a clock edge.
Page 128 Advanced triggering Trigger on a rise or fall time event Use the Rise/Fall Time trigger to trigger when the rise or fall time of a signal is less than, greater than, equal to, or not equal to a specified time limit To trigger on a Rise/Fall event: 1.
Page 129 Advanced triggering 8. Use the Slope controls to set the signal transition direction to detect. (rising, falling, or either direction). 9. To further refine the trigger conditions, set Logic Qualification to On and tap the Define Inputs button to define the logic conditions of other signals that must be true at the same time as the setup and hold event.
Page 130 Advanced triggering g. Tap anywhere outside the A Trigger Event menu to close it. 4. Set up the B Trigger Event: a. Tap the B Trigger Event button in the main Trigger configuration menu to open the B Trigger Event menu. b.
Page 131 IP address in a web browser. To remotely set a control or run this task on a Low Profile instrument, see the instrument Programmer Manual (Tektronix part number 077-1305-xx) for the correct command or commands to use.
Page 132 Advanced triggering Edit visual trigger areas on the screen Use the touchscreen or a mouse to directly edit an area, including moving, changing size, duplicating an area, moving individual vertices, adding and deleting vertices, and rotating the area. 1. To move a visual trigger area, touch and drag the area to a new position. Note: You cannot drag a visual trigger area from one waveform slice to another while in Stacked display mode.
Page 133 Advanced triggering b. Touch and drag a vertex to move it to a new position. c. To exit move vertex mode, tap outside the visual trigger area. The instrument returns to normal operation. 6. To rotate a visual trigger area: a.
Page 134 Advanced triggering b. Tap the Source field. c. Select a new source channel. The area moves to the selected source. If the selected source is not displayed, the instrument does not display that channel when the area is changed to that source. d.
Page 135 Advanced triggering b. Tap the Flip Vertical button. The area immediately flips vertically around its center position. c. Tap outside the menu to exit. To flip an area horizontally using the Area menu: a. Double-tap on the area to edit. b.
Page 136 Advanced triggering RF vs Time trigger Use the Time Domain Traces available in the Spectrum View tab to trigger a time domain signal. Select the Magnitude or Frequency control to enable these sources in the Trigger Settings menu. Below is the example of trigger on an amplitude modulated signal with carrier 1 GHz modulated with a 20 KHz square wave. 1.
Page 137 Advanced triggering 6. Change the horizontal scale to 10 us/div to view 2 periods of the modulation signal. 7. Open the Magnitude vs. Time menu and adjust the Vertical Scale and Position until you view the Magnitude vs. Time trace on Oscilloscope UI.
Page 138 Advanced triggering...
Page 139 Using Spectrum View Using Spectrum View Spectrum View provides a time domain view of the frequency components of a signal. Spectrum View concepts Typical oscilloscope displays show electrical signals as a graph of time on the x-axis versus amplitude on the y-axis (time domain). A spectrum trace shows the same electrical signals as a graph of frequency on the x-axis versus amplitude on the y-axis (frequency domain).
Page 140 Using Spectrum View FFT and Spectrum View Most modern oscilloscopes provide a Math FFT function to display the frequency-domain spectrum of a signal. The typical approach to creating an FFT is to use the same data acquisition used for the time-domain waveform (1), process it through an FFT, and display that data in a separate area or window (2).
Page 141 Using Spectrum View The Spectrum View feature in 4/5/6 Series instruments solves this problem by using a separate hardware path in the acquisition engine of each channel to acquire the frequency-domain data in parallel with the time-domain data. This frequency-domain data is processed, transformed, and displayed in a separate Spectrum View window (3) that is optimized to display and adjust spectrum traces independently of the time-domain waveform.
Page 142 Using Spectrum View This trace provides three different ways to calculate and present RF magnitude: • Linear Power: Direct use of linear power • Linear Amplitude: Square root of the linear power values • Log Power (dB) Frequency Vs. Time The Frequency Vs.
Page 143 Using Spectrum View This trace can help characterize phase modulation and phase drift. Changes in phase are not visible in the spectrum trace, and can be difficult to locate in the time-domain signal. Display a spectrum trace Spectrum traces are initially set up from each channel's badge menu. Display the channel signal for which you want a spectrum trace.
Page 144 Using Spectrum View Enable the spectrogram Use this procedure to display the spectrogram. Spectrogram is initially set up from each channel's badge menu. 1. Display the channel signal for which you want a spectrogram. 2. Double-tap the channel badge. 3. Tap the Spectrum View panel. 4.
Page 145 Using Spectrum View Figure 12: The Spectrum View window elements The trace handle. See Spectrum trace handle and trace types on page 150. The Reference level. The vertical scale (V/div) setting of the source time-domain waveform sets the spectrum trace reference level as follows: Source vertical Trace reference...
Page 146 Using Spectrum View The Amplitude (magnitude) scale. The vertical scale setting of the spectrum trace (pinch/expand actions on the touch screen, or the Vertical Scale knob on the front panel) sets the scale values. The Max Hold trace shows the maximum data values that are accumulated and displayed over multiple acquisitions of the Normal trace.
Page 147 Using Spectrum View The Spectrum Time width (amount of the acquisition record) is determined by the FFT Window factor divided by Resolution Bandwidth (RBW). Changing the FFT window type and/or the RBW parameters changes the Spectrum time width. The Spectrum Time position can be moved through the time domain acquisition using a variety of methods including tapping and dragging it, using the Wave Inspector Pan knob, or with the Spectrum Time position control in the Spectrum configuration menu.
Page 148 Using Spectrum View Oscilloscope 6 Series / 6 Series B 6 Series B 5 Series 4 Series 25 GS/s 12.5 GS/s 6.25 GS/s 6.25 GS/s Span Max RFvT (seconds) Max RFvT (seconds) Max RFvT (seconds) Max RFvT (seconds) 312.5 MHz 0.687 0.344 0.172...
Page 149 Using Spectrum View Using cursors in the Waveform View, the measured time from power-up to when the SS clock signal is stable was 4.847 seconds. Spectrum Time guidelines • Spectrum Time can be as long as, but never longer than, the RF acquisition time. •...
Page 150 Using Spectrum View Spectrum trace handle and trace types The spectrum trace handle provides details on the trace reference level, the source channel for the trace, and which trace types are displayed and selected. Figure 13: The Spectrum View trace handle elements 1.
Page 151 Using Spectrum View Spectrum peak markers Automatic peak markers assist with quickly identifying the frequency and amplitude of peaks in the spectrum trace. Access the marker settings by double-tapping in a spectrum trace slice window (Stacked mode) or trace (Overlay mode) to open the Spectrum View menu. Figure 14: The spectrum peak markers 1.
Page 152 Using Spectrum View • The Vertical Position knob controls the vertical position of the currently selected spectrum. This is a display function to visually position the spectrum trace. • Pushing the Vertical Position knob resets the vertical position such that the spectrum reference level is at the top of the slice (Stacked mode) or the top of the display (Overlay mode).
Page 153 Using Spectrum View The spectrum Span, RBW (resolution bandwidth), and (FFT) Window settings apply to all spectrum traces. The Center Frequency and Spectrum Time can be set for each Spectrum trace. See the Spectrum badge menu on page 553. Spectrum View Time Domain trace badges The Spectrum View Time Domain traces (Magnitude Vs.
Page 154 Using Spectrum View Each time domain trace has its own badge for each channel, and each badge has its own configuration menu. Open a badge menu by double-tapping on the badge.
Page 155 Using Spectrum View Save and recall spectrum traces You can save spectrum trace data to a file, and recall the trace to use as a reference trace or for other analysis purposes. Recalled spectrum traces are shown in the Spectrum View window. Save a spectrum trace Use the File >...
Page 156 Setting waveform display parameters Setting waveform display parameters Use waveform display controls to set the display mode, persistence, style, and intensity display parameters, and graticule style and intensity. Set waveform display mode (Stacked or Overlay) Use this procedure to change the waveform display mode (Stacked or Overlay). 1.
Page 157 Setting waveform display parameters 4. Tap the Waveform Intensity field and use the multipurpose knob to set the brightness of all waveforms. Set the graticule style and intensity Use this procedure to set the graticule (display grid) style and intensity. 1.
Page 158 Mask testing waveforms Mask testing waveforms Mask testing determines how well your signals conform to expected signal quality and provides instant automated statistical analysis. A mask defines a portion of the instrument display that a signal must not enter. Mask testing is supported for analog channels, analog math waveforms, analog reference waveforms, and RF vs.
Page 159 Mask testing waveforms 3. To resize a mask segment: a. Single-tap a segment to enable resize segment mode. Resize mode draws resize points on all four sides and the corners of a boundary area that contains the segment. b. Touch and drag a top, bottom, left, or right resize point to resize the segment vertically or horizontally. c.
Page 160 Mask testing waveforms b. Touch and drag a vertex to move it to a new position. c. To exit move vertex mode, tap outside the mask segment. The instrument returns to normal operation. 6. To rotate a mask segment: a. Tap four times in the segment to enable rotate segment mode. b.
Page 161 Mask testing waveforms Edit mask segments using the Mask Definition menu The Mask Definition menu allows you to edit the mask, including moving, changing size, moving individual vertices, adding and deleting vertices, and rotating the segment. You have the choice to edit a mask by segments or waveform tolerance with the Mask Defined By options in the Mask Settings panel.
Page 162 Mask testing waveforms a. Double-tap on the segment to edit. b. Select Segments under the Mask Defined By options. c. Tap the Flip Horizontal button. The segment immediately flips horizontally around its center position. To rotate a segment using the Mask Settings menu: a.
Page 163 Mask testing waveforms b. Select Waveform Tolerances under the Mask Defined By options. c. Tap the Vertical Tolerance field and enter the tolerance value as units of the current channel settings (volts, amps, and so on). Or double-tap on the field and use the A knob to change the value. d.
Page 164 Waveform histogram Waveform histogram Histograms visually shows the distribution of how many sample points fall in selected section of waveform record. Waveform Histogram provides you tool to statistically analyze the waveforms using histograms in the graticule. This helps you to quickly determine how your device is responding to the inputs at discrete intervals of time and make the right decisions to change the device parameters.
Page 165 Waveform histogram b. Touch and drag a top, bottom, left, or right resize point to resize the histogram vertically or horizontally. c. Touch and drag a corner resize point to resize length and height of the histogram in a direction. Note: You cannot move a histogram while in resize mode.
Page 166 Zoom in on waveforms Zoom in on waveforms Use the zoom tools to magnify waveforms to view signal details. Turn on Zoom mode Zoom mode lets you look at a portion of your waveform in greater detail. Enable Zoom mode and touch and drag on-screen to select the area to zoom.
Page 167 Zoom in on waveforms a. To use Zoom once enabled, tap the zoom icon touch and draw a box around an area of interest in the Waveform or Plot view to immediately display the zoomed waveform and the Zoom Overview window. b.
Page 168 Zoom in on waveforms Search tables and Zoom mode • When you select a row in the Search Results Table, Zoom mode adjusts the position of the zoom window to place the selected search event in the middle of the zoom window. •...
Page 169 Measurement configuration Measurement configuration After adding a measurement, you can customize the measurement for more precise results. To customize measurements, double-tap a Measurement badge in the Results bar to open the measurement configuration menu. Label a measurement Use this procedure to add a custom label to a measurement. Measurement labels appear on the Measurement badge and can be added to Results tables.
Page 170 Measurement configuration • Local causes changes in this panel to only effect this measurement. When switching from Local to Global, all fields will update to the current Global parameters. 4. Tap Set Levels In and select either % or Absolute. •...
Page 171 Measurement configuration • Screen takes measurements on that portion of the waveform shown in the display. When Zoom is on, the display is the zoom window. • Cursors takes measurements on that portion of the waveform between the cursors. Selecting Cursors opens cursors on the measurement source.
Page 172 Measurement configuration If you select a filter other than None, tap the LPF Freq (F2) field and set the frequency using the assigned multipurpose knob. Or double-tap the field and use the virtual keypad to enter a value. 6. Tap anywhere outside the Measurement configuration menu to close it. Set measurement limits Use this procedure to set measurement limits.
Page 173 Save a waveform or spectrum trace to a file Use this procedure to save channel waveform (analog or digital) data to a comma-separated values (csv) or Tektronix waveform data (wfm) file, for later analysis or inclusion in reports. You can also save Spectrum View traces to files.
Page 174 Save instrument settings to a file Use this procedure to save instrument settings to a Tektronix setup (.set) file. 1. Tap the File menu and select Save As. The Save As configuration menu opens.
Page 175 Saving and recalling information • If Auto Increment File Name is enabled the Count defaults to 000 if there are no files at the specified location and file name that already use incremented file names. If there are files at the save location that already use the specified file name, and have already been saved using count increments, the Count field shows the next count value that will be added to the file name when the file is saved.
Page 176 Saving and recalling information Save sessions Use this procedure to save a session file. A session file contains instrument setup information, measurements, reference waveforms of active signals, plots, and eye diagram masks if enabled. 1. Tap the File menu and select Save As. The Save As configuration menu opens.
Page 177 Saving and recalling information As you navigate the folders, the files list area shows all files that match the file type selected in the Files of Type field. 6. Select the file to recall, using one of the following methods: •...
Page 178 Saving and recalling information 3. Tap Files of Type: and select the file type from the list. The files list updates to show any files that match the selected file type. 4. Navigate to the folder that contains the file to recall, using one of the following methods: •...
Page 179 Menus and dialog boxes Menus and dialog boxes All of the menus on your instrument and the available settings within each menu. Acquisition configuration menu Use this configuration menu to set which data points are used to acquire waveforms, and enable automatically saving acquisitions to files. The Acquisition menu fields and controls To open the Acquisition menu, double-tap the Acquisition badge on the Settings bar.
Page 180 Menus and dialog boxes Field or control Description Acquisition Mode Sample creates a record point by saving one or more samples during each acquisition interval. Sample mode is the default acquisition mode. The instrument does no post processing of the acquired samples in this mode.
Page 181 Menus and dialog boxes Field or control Description Summary Frame Enables or disables creating and displaying a summary frame at the end of the frame record. When the current acquisition mode is either Sample or High Res, the Summary Frame shows an average of all frames.
Page 182 Menus and dialog boxes Field or control Description Selected Frame Shows the selected frame in all displayed waveforms (analog, digital, and math). Use Multipurpose A knob to scroll through and select specific frames. To enter a specific frame number to display, use the Selected Frame field in the Fast Frame configuration menu.
Page 183 Menus and dialog boxes Field or control Description Overlay Frames Overlays all acquired frames for each displayed source (analog, digital, and math). If you have enabled overlay mode, the current frame's waveform is highlighted in blue in all displayed waveforms (analog, digital, and math). Selected Frame Sets or shows the current Selected frame number, and also shows the associated frame waveform in the Waveform View.
Page 184 Menus and dialog boxes Field or control Description Include Reference Enables or disables a Reference acquisitions readout in the History badge. A Reference acquisition Acquisitions in Badge readout shows the difference between Selected acquisition and the Reference acquisition. It also displays the delta between the Selected acquisition and the Reference acquisition timestamps.
Page 185 Menus and dialog boxes Guidelines to save History acquisitions • When you saves a setup, no channel data is stored (only reference waveforms are saved with setups). • When you saves a session, all History/Fast Frame data is stored with the session. •...
Page 186 Menus and dialog boxes History Timestamp Time Trend plot configuration menu fields and controls Field or control Description AutoScale Toggles AutoScale On or Off. Default is On. Turn AutoScale off to set the X and Y-axis range to view an area of interest. When AutoScale is Off (unchecked), the Plot view zoom mode enables and a small Zoom window appears in the plot.
Page 187 Menus and dialog boxes Timestamp Results Table menu Field or control Description Column Visibility panel Acquisition Number Sets the acquisition number for each acquisition. Datestamp Sets the acquisition datestamp for each acquisition. Timestamp Sets the acquisition timestamp for each acquisition. Delta time Sets the delta time to display the deltas.
Page 188 Menus and dialog boxes Field or control Description Browse Tap to open the Browse Save As Location dialog, to navigate to and select the location to which to save the file. See Browse Save As Location configuration menu on page 351. File Name The file name assigned to the file.
Page 189 Menus and dialog boxes Field or control Description Event Type Select the event type as Discrete Events or Timer Events for saving screen capture, measurement result statistics logging, and saving waveforms. Note: The Timer events does not work with Single/sequence. It runs for Run/Stop sequencing only.
Page 190 Menus and dialog boxes The Add Measurements configuration menu always opens on the Standard measurement tab. The listed tabs and measurements depend on the installed measurement options and the selected signal source. To add a measurement, select the measurement type tab, select the input source or sources, select the measurement, and either tap the Add button or double-tap the measurement.
Page 191 Menus and dialog boxes Add Measurement tab Description Power Advanced Power Analysis (option). Provides measurements for electrical analysis, output analysis, amplitude analysis, timing analysis, and switching analysis. See The Power tab on page 201. Digital Power Management Analysis (option). Provides measurements for ripple analysis, transient analysis, power sequence analysis, jitter and eye analysis.
Page 192 Menus and dialog boxes Measurement Description Mean The arithmetic mean of all data points over the measurement region. You can take this measurement on each cycle in the waveform record or on the entire waveform record. Minimum The minimum data point value. You can take this measurement on each cycle in the waveform record or on the entire waveform record.
Page 193 Menus and dialog boxes Measurement Description The difference in time between an edge in the source waveform and the corresponding edge in a recovered reference clock signal. The measurement is made on each waveform edge in the measurement region. See also Measurement configuration menu overview on page 331 Spectrum Measurements panel...
Page 194 Menus and dialog boxes To add a measurement to the Results bar: 1. Select the signal Source. 2. Select a measurement. 3. Tap Add. You can also double-tap a measurement to add it immediately to the Results bar. Spectrum Measurements panel Measurement Description Channel Power...
Page 195 Menus and dialog boxes See also Spectrum measurements configuration menu overview on page 547 Configure panel (Spectrum measurements configuration menu) on page 548 Pass/Fail Testing panel (Spectrum measurement configuration menu) on page 550. The Standard measurements tab The Standard tab lists the default set of amplitude, Timing, and jitter measurements that are included with the instrument. To open the Standard measurements tab, tap the Add New...
Page 196 Menus and dialog boxes Timing Measurements panel Measurement Description The duration of a series of adjacent crossings of the Mid reference level. Bursts are separated by a Burst Width specified idle time. The measurement is taken on each burst in a waveform record. Data Rate is the reciprocal of Unit Interval.
Page 197 Menus and dialog boxes Measurement Description The time difference (phase shift) between the specified signal edges of waveform source 1 and Phase waveform source 2. The measurement is expressed in degrees, where 360° comprise one waveform cycle. This measurement requires two sources. The measurement is taken on each cycle of the waveform record.
Page 198 Menus and dialog boxes The Jitter tab (Advanced Jitter and Eye Analysis) The Jitter tab lists advanced jitter, eye, amplitude, and timing measurements that you can add to the Results bar. The Jitter tab is only shown if you have purchased and installed the Advanced Jitter and Eye Analysis option. To open the Jitter measurements tab: 1.
Page 199 Menus and dialog boxes Measurement Description The total jitter at a bit error rate of 2.5e-3 (TJ@2.5e-3). The measurement is taken on the entire record. CC-Jitter Cycle to Cycle Jitter measures the clock period change between any two adjacent cycles. The measurement is taken on the entire record.
Page 200 Menus and dialog boxes Measurement Description Eye Low The amplitude of a low (zero) bit measured at a specified location within the recovered unit interval. The measurement is taken on each low bit in the waveform record. Eye Width The minimum horizontal eye opening at the center of the recovered unit interval. The measurement is taken on the entire waveform record.
Page 201 Menus and dialog boxes Timing Measurements panel Measurement Description Data Rate Data Rate is the reciprocal of Unit Interval. This measurement is the same as Data Rate measurement under Standard category time panel. Pattern Length Number of symbols that constitute one full repetition of a sequence within a signal. SSC Freq Dev The spread spectrum clock frequency deviation.
Page 202 Menus and dialog boxes Input Analysis Measurements panel Measurement Description Power Quality Measures the Frequency, RMS values of the voltage and current, Crest Factors of the voltage and current, Real Power, Reactive Power, Apparent Power, Power Factor, and Phase Angle of the signal. Harmonics Plots the signal amplitudes at the fundamental line frequency and its harmonics.
Page 203 Menus and dialog boxes Measurement Description Negative Pulse Width The time the signal remains below the Mid-reference level. This measurement is taken on each cycle of the waveform record or measurement region. Switching Analysis Measurements panel Measurement Description Switching Loss The mean instantaneous power and energy in the turn-on, turn-off, and conduction regions of a switching device.
Page 204 Menus and dialog boxes Note: You should take the Turn On Time and Turn Off Time measurements independently. Turn On Time and Turn Off Time measurements use the Power Preset function to optimize the settings and trigger to measure the DUT power-on signal, which may result in inaccurate measurements for other measurement types.
Page 205 Menus and dialog boxes Electrical Analysis Measurements panel Measurement Description Power Quality Measures the operating Frequency, RMS values of the voltage and current, Crest Factors of the voltage and current, Real Power, Reactive Power, Apparent Power, Power Factor, and Phase Angle of the AC signal.
Page 206 Menus and dialog boxes Measurement Description System Efficiency Measures the total efficiency of the motor drive system. System Efficiency is also known as Electro-Mechanical efficiency. It indicates how much electrical energy is converted to mechanical energy. It is measured as the ratio of mechanical power to the input electrical power.
Page 207 Menus and dialog boxes Measurement Description Undershoot Undershoot is the difference between Minimum and Base, divided by the Amplitude. This measurement can be made across the entire record or on each cycle in the record. Turn on Overshoot Turn on Overshoot computes the maximum amplitude value of the dc rail output voltage during turn ON of the DUT.
Page 208 Menus and dialog boxes Measurement Description EYEWIDTH Eye Width is the minimum horizontal eye opening at the user-specified reference level. This measurement is made across the entire record. User can specify the jitter frequency and BW limit for each rail in the measurement configuration. The measurement supports Eye diagram and Histogram plots per rail.
Page 209 Menus and dialog boxes Amplitude Measurements panel Measurement Description The total area of the signal above the specified reference level. The total area of the signal below the specified reference level. Vix(ac) The differential input cross-point voltage measured from the actual crossover voltage and its complement signal to a designated reference voltage.
Page 210 Menus and dialog boxes Measurement Description tJIT(cc) The absolute difference in clock period between two consecutive clock cycles. tERR(n) The cumulative error across multiple consecutive cycles from tCK(avg). It measures time difference between the sum of clock period for a 200-cycle window to n times tCK(avg). tERR(m-n) The cumulative error across multiple consecutive cycles from tCK(avg).
Page 211 Menus and dialog boxes Switching Parameter Analysis measurements panel Measurement Description Measures the energy dissipated in the Power Device during 'on' region using the configured levels. Eoff Measures the energy dissipated in the Power Device during 'off' region using the configured levels. Vpeak Measures the peak voltage of the Power Device in the 'off' region.
Page 212 Menus and dialog boxes Add Plot configuration menu Use this configuration menu to select and plot the amplitude and time relationship of two (XY) or three (XYZ) signals, which can be sourced from channel, math, or reference waveforms, or plot a TIE measurement eye diagram. These plots differ from the Measurement plots (added from a Measurement configuration menu), which plot that measurement's value, not the signal source value(s).
Page 213 Menus and dialog boxes Field or control Description Search Display a table of all defined searches with each search shown on its own tab. Bus Decode Display a table of the bus decode results. Harmonics/Custom Displays a table of the Harmonics measurement results. Custom displays a table of the Frequency Response Analysis measurement results.
Page 214 Menus and dialog boxes If there are multiple bus decode results tables, each bus has a tab in the table. Tap the tab of the bus to display and/or configure, and then double-tap anywhere in that table to open the configuration menu for that table. Bus Decode Results table menu Field or control Description...
Page 215 Menus and dialog boxes • If multiple harmonics results tables are displayed, each result is in a separate tab. Tap the harmonics tab of interest to open that table, and then double-tap in the Harmonics results table area to open that table's configuration menu. •...
Page 216 Menus and dialog boxes Field or control Description Show tabs with all The measurement results table becomes tabbed, with a tab for each measurement. measurement occurrences The contents of the current measurement results table are shown on the first tab "Statistics". This tab is always shown first.
Page 217 Menus and dialog boxes • To resize a column width, use the mouse to position the cursor on the column name border to change, then click and drag the column border to resize that column. • You cannot sort the contents of a column. Navigation on Bar Graph and Harmonics Results Table 1.
Page 218 Menus and dialog boxes Results Tables operations overview Results tables list summaries of all active measurements, bus decode activity, and search results in a spreadsheet format. Use Results tables to quickly compare values or save the results to a report. Results Table - general operations •...
Page 219 Menus and dialog boxes Field or control Description File Name The file name assigned to the file. The default file name is Tek000. The file name increments on the next save (Tek001, Tek002, and so on). Tap on the file name and use a keyboard to enter a new file name. Or double-tap on the file name to open the on-screen keyboard and enter a file name.
Page 220 Menus and dialog boxes • To scroll up and down in a results table, tap the table and use Multipurpose knob A to scroll and select table rows. • To move a column, touch and drag the column title to a new position in the table. •...
Page 221 Menus and dialog boxes 1. Double-tap anywhere in the Custom Results Table to open the Custom Results Table configuration menu. 2. Tap the Save panel. 3. Tap the Save Table button. Save As configuration menu, Custom Results Table Field or control Description Save Location Sets the location to save the file.
Page 222 Menus and dialog boxes Field or control Description File Name The file name assigned to the file. The default file name is Tek000. The file name increments on the next save (Tek001, Tek002, and so on). Tap on the file name and use a keyboard to enter a new file name. Or double-tap on the file name to open the on-screen keyboard and enter a file name.
Page 223 Menus and dialog boxes Field or control Description Symmetry Sets the symmetry of the ramp using the keypad or multipurpose knob. Available when the Waveform Type is Ramp. Width Sets the width of the pulse using the keypad or multipurpose knob. Available when the Waveform Type is Pulse.
Page 224 Menus and dialog boxes Analog Channel configuration menu Use the Analog Channel configuration menu to set up analog channel vertical settings, probe settings, deskew settings, external attenuation, alternate units for analog channel inputs, and enable the Spectrum View for the channel. To open an analog Channel configuration menu, double-tap an analog Channel badge.
Page 225 Menus and dialog boxes Field or control Description Other Use to adjust signal delay to align signal arrival at the oscilloscope between probes and/or cables. on page 229. Other panel (Channel configuration menu) Deskew configuration menu (Other panel, Channel configuration menu) Use the Deskew configuration menu to make display and measurement adjustments for analog probes that have differing propagation delays.
Page 226 Menus and dialog boxes See also Probe Compensation configuration menu (analog channels Probe Setup panel) on page 226 Other panel (Channel configuration menu) on page 229 on page 82 Deskew analog input channels Deskew analog input channels - quick visual method Invert channel guidelines This topic describes how the channel Invert function interacts with other instrument settings.
Page 227 Menus and dialog boxes Probe Compensation dialog Available fields and controls vary with the type of probe that is attached. For more information, consult the probe documentation. Read the information on the menu before starting the probe compensation process. Field or control Description Compensate Probe Tap to compensate the attached probe.
Page 228 Menus and dialog boxes Probe error messages are also displayed in this setup panel, see Error Messages and Badges on page 61. See also Unsupported Probe dialog on page 230 Probe Compensation configuration menu (analog channels Probe Setup panel) on page 226 Other panel (Channel configuration menu) on page 229 Deskew configuration menu (Other panel, Channel configuration menu)
Page 229 Menus and dialog boxes Field or control Description Time Domain Traces Selects the RF vs. Time trace(s) to display. Selecting a check box adds a corresponding waveform slice to the Waveform View and an RF vs. Time badge to the Settings bar. Magnitude plots how the signal magnitude (amplitude) varies with time.
Page 230 Menus and dialog boxes See also Unsupported Probe dialog on page 230 Probe Compensation configuration menu (analog channels Probe Setup panel) on page 226 on page 225 Deskew configuration menu (Other panel, Channel configuration menu) Unsupported Probe dialog This dialog tells you that you have attached an unsupported probe. To open the Unsupported Probe dialog: 1.
Page 231 Menus and dialog boxes Bus configuration menu Use the Bus menu to select the bus type to display, configure the input sources, and set how to display the bus on the screen. To open the Bus configuration menu: • For an existing bus, double-tap the Bus badge in the Settings bar. •...
Page 232 Menus and dialog boxes PCIe serial bus configuration menu on page 259 RS232 serial bus menu on page 262 SDLC serial bus configuration menu on page 263 SENT serial bus configuration menu on page 264 SMBus serial bus configuration menu on page 266 SpaceWire serial bus configuration menu on page 267...
Page 233 Menus and dialog boxes Other bus types Other serial bus types are available as purchasable options. Once purchased and installed, the new bus types are shown in the Bus Type menu. The serial bus options also add corresponding bus trigger capabilities (when supported) to the Trigger menu. See the configuration menu on page 231 for links to all serial bus configuration menus.
Page 234 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 on page 450 8b10b serial bus search configuration menu ARINC 429 serial bus menu Use the ARINC 429 bus menu to set up and decode a ARINC 429 avionics network serial data bus waveform. To set up the ARINC 429 avionics serial data bus: •...
Page 235 Menus and dialog boxes Other bus types Other serial bus types are available as purchasable options. Once purchased and installed, the new bus types are shown in the Bus Type menu. The serial bus options also add corresponding bus trigger capabilities (when supported) to the Trigger menu. See the configuration menu on page 231 for links to all serial bus configuration menus.
Page 236 Menus and dialog boxes Field or control Description Frame Sync Set the signal source, logic level threshold, and polarity for the frame sync signal. Data Bits per Channel Set the number of data bits per audio channel. Clock Bits per Channel Set the number of clock bits per audio channel.
Page 237 Menus and dialog boxes Auto Ethernet serial bus menu fields and controls Field or control Description Display Turns on or off displaying the bus on the Waveform view. Label Enter a label for the bus. The default label is the selected bus type. To enter label text, double-tap the field and enter label using the virtual keyboard, or tap the field and enter text from an attached keyboard.
Page 238 Menus and dialog boxes Auto Ethernet serial bus search configuration menu on page 451 CAN serial bus configuration menu Use the CAN bus menu to set up and display a CAN (Controller Area Network) or CAN FD (CAN Flexible Datarate) serial bus waveform. •...
Page 239 Menus and dialog boxes Field or control Description SD Bit Rate Sets the SD (Standard/Arbitration) bit rate of your CAN FD serial bus data. To enter a custom bit rate, select Custom and enter the custom bit rate in the Custom Rate input box. This control is available when CAN Standard is set to CAN FD (ISO), CAN 2.0 + FD (ISO) + XL, or CAN FD (non-ISO).
Page 240 Menus and dialog boxes Field or control Description Decode Format Sets the decode format used to display the bus information. Formats are Hex, Binary, Mixed Hex, and Symbolic. Selecting Symbolic lets you navigate to and load a dbc decode label file for the current CAN waveform.
Page 241 Menus and dialog boxes Field or control Description Label Enter a label for the bus. The default label is the selected bus type. To enter the label text, double-tap the field and enter label using the virtual keyboard, or tap the field and enter the text from an attached keyboard.
Page 242 Menus and dialog boxes CXPI serial bus menu fields and controls Field or control Description Display Turns on or off displaying the bus on the Waveform view. Label Enter a label for the bus. The default label is the selected bus type. To enter the label text, double-tap the field and enter label using the virtual keyboard, or tap the field and enter the text from an attached keyboard.
Page 243 Menus and dialog boxes Field or control Description Position Sets the vertical position of the bus waveform. The default position is vertically centered in a slice (in Stacked mode), or center screen in Overlay mode. The unit of position is screen divisions. Set to 0 Sets the vertical position to 0 divisions (centered vertically in a slice or on the screen).
Page 244 Menus and dialog boxes Field or control Description Label Enter a label for the bus. The default label is the selected bus type. To enter the label text, double-tap the field and enter label using the virtual keyboard, or tap the field and enter the text from an attached keyboard.
Page 245 Menus and dialog boxes Ethernet serial bus menu Use the Ethernet bus menu to set up and display an Ethernet 10BaseT or 100BaseT serial bus waveform. To use the Ethernet serial bus menu: To create a new Ethernet bus waveform, tap the Add New Bus button on the Settings bar. Open the bus configuration menu by double •...
Page 246 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 on page 481 Ethernet serial bus search configuration menu EtherCAT serial bus configuration menu Use the EtherCAT bus menu to set up and display an EtherCAT serial bus waveform. To set up a EtherCAT serial bus: •...
Page 247 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 EtherCAT serial bus search configuration menu on page 483 eUSB serial bus configuration menu Use the Embedded USB bus menu to set up and display an eUSB 2.0 (Embedded Universal Serial Bus) waveform. To set up a eUSB serial bus: •...
Page 248 Menus and dialog boxes Field or control Description Threshold Set the threshold level. Data Threshold Set the data threshold for D+ signal and D- signal. Only available when Signal Type = Single Ended. High Threshold Set the high threshold for D+ signal and D- signal. Low Threshold Set the low threshold for D+ signal and D- signal.
Page 249 Menus and dialog boxes Field or control Description Set to 0 Sets the vertical position to 0 divisions (centered vertically in a slice or on the screen. Bus Type Set to FlexRay. Signal Type Select the FlexRay signal type being measured. Channel Type Set to A or B channel.
Page 250 Menus and dialog boxes Field or control Description Position Sets the vertical position of the bus waveform. The default position is vertically centered in a slice (in Stacked mode), or center screen in Overlay mode. The unit of position is screen divisions. Set to 0 Sets the vertical position to 0 divisions (centered vertically in a slice or on the screen.
Page 251 Menus and dialog boxes Field or control Description Position Sets the vertical position of the bus waveform. The default position is vertically centered in a slice (in Stacked mode), or center screen in Overlay mode. The unit of position is screen divisions. Set to 0 Sets the vertical position to 0 divisions (centered vertically in a slice or on the screen.
Page 252 Menus and dialog boxes Field or control Description Source Set the signal source from available analog or digital channels. Threshold Set the threshold level to define a logic high level. Polarity Select the polarity to match the LIN bus being acquired. LIN Standard Select the standard to match the LIN bus being acquired.
Page 253 Menus and dialog boxes Field or control Description Set to 0 Sets the vertical position to 0 divisions (centered vertically in a slice or on the screen). Bus Type Set to Manchester. Set the edge for bit '0' Set the edge for bit 0. Data Rate Set the data rate for the manchester bus.
Page 254 Menus and dialog boxes MDIO serial bus configuration menu Use the MDIO bus menu to set up and display an MDIO (Management Data Input Output) serial bus waveform. To set up the MDIO serial bus: To create a new MDIO bus waveform, tap the Add New Bus button on the Settings bar. Open the bus configuration menu by double •...
Page 255 Menus and dialog boxes • To change the settings on an existing FlexRay serial bus waveform, double-tap the Bus waveform badge and make necessary changes. MIL-STD-1553 serial bus menu fields and controls Field or control Description Display Turns on or off displaying the bus on the Waveform view. Label Enter a label for the bus.
Page 256 Menus and dialog boxes 3. Configure the NFC bus menu. • To create a new NFC waveform, tap the Add New Bus button on the Settings bar. Open the bus configuration menu by double clicking on the badge. Set the Bus Type to NFC. •...
Page 257 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 NFC serial bus search configuration menu on page 512 NRZ serial bus configuration menu Use the NRZ bus menu to set up and display an NRZ serial bus waveform. To set up a NRZ serial bus: •...
Page 258 Menus and dialog boxes Bus Search configuration menus on page 457 NRZ serial bus search configuration menu on page 513 Parallel Bus configuration menu Use this menu to set up and display a parallel bus waveform. Parallel bus decoding and triggering is included with the oscilloscope. To set up the parallel bus: •...
Page 259 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 Parallel bus search configuration menu on page 514 Parallel Bus - Define Inputs menu Use this menu to select the signal sources and order for the parallel bus waveform To access the Parallel Bus - Define Inputs menu, double-tap a Parallel Bus badge to open the configuration menu, and tap the Define Inputs button.
Page 260 Menus and dialog boxes 1. To create a new PCIe bus waveform, tap the Add New Bus button on the Settings bar. Open the bus configuration menu by double clicking on the badge. Set the Bus Type to PCIe. 2. To change the settings on an existing PCIe serial bus waveform, double-tap the Bus waveform badge on the Settings bar to open the configuration menu, and make necessary changes.
Page 261 Menus and dialog boxes PSI5 serial bus configuration menu Use the PSI5 bus menu to set up and display an PSI5 (Peripheral Sensor Interface) serial bus waveform. To set up the PSI5 serial bus: To create a new PSI5 bus waveform, tap the Add New Bus button on the Settings bar. Open the bus configuration menu by double •...
Page 262 Menus and dialog boxes Field or control Description Data Format • Nibble • Byte Only available when Direction = ECU to Sensor . Display Format Sets the waveform view to show just the decoded bus information, or the decoded bus plus the source signal waveforms.
Page 263 Menus and dialog boxes Field or control Description Bit Rate Sets the data bit rate. To enter a custom bit rate, select Custom and enter the custom bit rate in the Custom Rate input box. Data Bits Set the number of bits that define a data packet for your RS232 bus. Source Set the signal source from available analog or digital channels.
Page 264 Menus and dialog boxes SDLC serial bus menu fields and controls Field or control Description Display Turns On or Off. Displays the decode bus on the waveform view, when the Display is set to On. Label Enter a label for the bus. The default label is the selected bus type. To enter label text, double-tap the field and enter label using the virtual keyboard, or tap the field and enter text from an attached keyboard.
Page 265 Menus and dialog boxes Field or control Description Label Enter a label for the bus. The default label is the selected bus type. To enter label text, double-tap the field and enter label using virtual keyboard, or tap the field and enter text from an attached keyboard.
Page 266 Menus and dialog boxes Bus Search configuration menus on page 457 SENT serial bus search configuration menu on page 529 SMBus serial bus configuration menu Use the SMBus menu to set up and display a SMBus serial bus waveform. To set up the SMBus serial bus menu: •...
Page 267 Menus and dialog boxes SpaceWire serial bus configuration menu Use the SpaceWire bus menu to set up and display an SpaceWire serial bus waveform. To set up a SpaceWire serial bus: 1. To add a new SpaceWire bus waveform, tap the Add New Bus button on the Settings bar. Open the bus configuration menu by double-tapping the badge.
Page 268 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 on page 537 SpaceWire serial bus search configuration menu SPI serial bus configuration menu Use the SPI bus menu to set up and display an SPI (Serial Peripheral Interface) synchronous serial bus waveform. To set up the SPI serial bus: 1.
Page 269 Menus and dialog boxes Field or control Description MOSI Input Select the channel source and threshold level for the MOSI (Master In Slave Input) input. Set the Polarity to use Active High or Active Low logic for the MOSI signal. Available when Data Inputs = Two, and Framing = SS/Idle.
Page 270 Menus and dialog boxes Field or control Description Label Enter a label for the bus. The default label is the selected bus type. To enter label text, double-tap the field and enter label using the virtual keyboard, or tap the field and enter text from an attached keyboard.
Page 271 Menus and dialog boxes Field or control Description Label Enter a label for the bus. The default label is the selected bus type. To enter label text, double-tap the field and enter label using the virtual keyboard, or tap the field and enter text from an attached keyboard.
Page 272 Menus and dialog boxes Field or control Description Display Turns on or off displaying the bus on the Waveform view. Label Enter a label for the bus. The default label is the selected bus type. To enter label text, double-tap the field and enter label using the virtual keyboard, or tap the field and enter text from an attached keyboard.
Page 273 Menus and dialog boxes Field or control Description Display Format Sets the waveform view to show just the decoded bus information. Decode Format Sets the decode format used to display the bus information. Available options are: For USB 1.0/1.1/2.0 speed signal: Hex, Binary, Mixed ASCII, and Mixed Hex •...
Page 274 Menus and dialog boxes Field or control Description Readout Location Tap to set where to display cursor readouts. Graticule displays the cursor readouts on the screen cursor bars (default method). You can move the readouts on cursors by touching and dragging them along the cursor bar. Badge removes the screen cursor readouts and displays the cursor information in a Cursors badge in the Results bar.
Page 275 Menus and dialog boxes Field or control Description Cursor A Y-Position Tap to set a specific Y-axis position for Cursor A using the multipurpose knob, or double-tap to set the position using the keypad. Available when Cursor Type is H Bars or V&H Bars. Cursor B Y-Position Tap to set a specific Y-axis position for Cursor B using the multipurpose knob, or double-tap to set the X-Position using the keypad.
Page 276 Menus and dialog boxes DDR Measurement configuration menu fields, controls, and panels Field, control, or panel Description Show Statistics in Badge Adds the listed statistical measurement readouts to the measurement badge readout. (Measurement name panel) Plots (Measurement name Buttons that open Plot views of the measurement. Available plots depend on the measurement. Plot panel) types include Time Trend, Histogram, and Spectrum.
Page 277 Menus and dialog boxes on page 277 Gating panel (DDR measurement configuration menu) DDR measurement name panel (Measurement configuration menu) The DDR measurement name panel (the name of the measurement) provides controls for adding display statistics to the measurement badge and opening plots of the measurement. To open and configure a DDR measurement, double-tap a DDR measurement badge.
Page 278 Menus and dialog boxes Reference Levels panel (DDR measurement configuration Menu) Use the Reference levels panel to set the scope of the reference level settings (global or local), the measurement reference levels (High, Mid, and Low), the units used to take measurements, and the method used to calculate the Top and Base waveform values. You can set the reference levels to be the same or different for rising and falling edges.
Page 279 Menus and dialog boxes DPM measurement configuration menu overview Use this configuration menu to add a measurement and change measurement settings including source, scope (global or local), and reference levels. To open the DPM (Digital Power Management) measurement configuration menu for a measurement, double-tap a DPM measurement badge in the Results bar.
Page 280 Menus and dialog boxes DJ, PJ, RJ, and TIE measurements configure panel Field or control Description Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard. Power Rail Sets the power rail source(s) used to take the measurement.
Page 281 Menus and dialog boxes Field or control Description Power Rail Sets the power rail source(s) used to take the measurement. Tap the field to show the list of available sources. Select the current source. Jitter Frequency Sets the jitter frequency required for the power rail autoset. Bandwidth Limit Tap to select the bandwidth limit from the drop-down list.
Page 282 Menus and dialog boxes Field or control Description Frequency Ranges to Suppress From Victim Signal Center Frequency Configure the notch filter with center frequency that needs to be suppressed from the victim signal. Span Sets the span of the notch filter. The span is an absolute value which specifies spread of notch filter around the center frequency.
Page 283 Menus and dialog boxes Field or control Description Power Rail Preset Sets the oscilloscope with the configured inputs to acquire the signals of interest with a single acquisition. After performing a Power Preset, press the Run/Stop button on the front panel and then power Off/On the device under test.
Page 284 Menus and dialog boxes Connection setup for Digital Power Management (DPM) measurements Figure 15: Connection setup for Digital Power Management (DPM) measurements DPM Measurement Name panel (Measurement configuration menu) The DPM Measurement Name panel (the name of the measurement) provides controls for opening plots of the measurement. To open the DPM measurement name panel, double-tap a DPM Measurement badge.
Page 285 Menus and dialog boxes on page 341 Reference Levels panel (Measurement configuration menu) Power Rail Autoset Sets the oscilloscope acquisition system for optimal measurement results for DPM measurements. Use the following steps to run a Power Rail Autoset on applicable DPM measurements: 1.
Page 286 Menus and dialog boxes b. Press Single Seq on the front panel and Turn Off/On the DUT. 5. Follow the instructions on the Measurement badge to take the DPM measurement. Reference Levels panel (DPM measurement configuration Menu) Use the Reference Levels panel to set the scope of the reference level settings (global or local), the measurement reference levels (High, Mid, and Low), the units used to take measurements, and the method used to calculate the Top and Base waveform values.
Page 287 Menus and dialog boxes Field or Control Description Source Select the channel source from the drop-down list and configure the Center Frequency value. Only available when Lock Center Frequency Across All Channels is unselected. Center Frequency Set the center frequency value. Span Set the Span to a factor of Center Frequency.
Page 288 Menus and dialog boxes DVM configuration menu fields and controls Field or control Description Display Tap to toggle the DVM badge On and Off. Autorange Tap to toggle autoranging On and Off. Autorange is not available when the oscilloscope is triggering on the same channel that is being measured.
Page 289 Menus and dialog boxes Field or control Description FastAcq Palette Tap and select the desired FastAcq Palette from the drop-down list. Temperature uses color-grading to indicate frequency of occurrence, with hot colors like red/yellow indicating frequently occurring waveform data points, and colder colors like blue/green indicating rarely occurring data points.
Page 290 Menus and dialog boxes Field or control Description Position Tap to set the trigger Position using the assigned multipurpose knob or double-tap to set the Position using the virtual keypad. When horizontal Delay is on, the time from the trigger point to the horizontal reference (center of waveform record) is the horizontal delay.
Page 291 Menus and dialog boxes 5. Configure REF levels based on noise on the acquired signals. 6. Configure gating to place cursors at the integral cycles. IMDA Measurement configuration menu fields, controls, and panels for Motor Analysis Field, control, or panel Description Plots (Measurement name Adds Phasor plot by default when Power Quality and DQ0 is added.
Page 292 Menus and dialog boxes Figure 17: 3V3I 3Phase3Wire Figure 18: 3V3I 3Phase4Wire Figure 19: 1V1I 1Phase2Wire Figure 20: 3 phase motor system, as 2V2I Efficiency measurement using 3 Phase motor setup The voltage probes that is used is THDP0100/0200 and current probe that is used is TCP0030A.
Page 293 Menus and dialog boxes Where, a,b,c is for Input Analysis x,y,z is for Output Analysis Drive system is for Ripple measurements. Connection setup for Speed and Direction measurements Connection setup for Torque measurement using Sensor method 4/5/6 Series MSO MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB, MSO58LP, and LPD64 Help...
Page 294 Menus and dialog boxes Connection setup for Torque measurement using Current method Configure panel (IMDA measurement configuration menu) - Motor Analysis Use the configure panel to add a custom name (label) for the measurement and other parameters. To open the Configure panel for a IMDA measurement: 1.
Page 295 Menus and dialog boxes Field or control Description Source Type Toggle between voltage source or current source. Units Sets the unit as Degree or Radians. Offset Angle Sets the offset angle. Configure the offset (electrical) angle: • To adjust if there is any position misalignment of the mounted encoder/sensors. •...
Page 296 Menus and dialog boxes Harmonics measurement: Configure panel Field or control Description Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard. Line Frequency Sets the line frequency of the power signal source.
Page 297 Menus and dialog boxes For Speed configuration panel, refer on page 298. Speed measurement: Configure panel Other measurement configuration panels Reference Levels panel (Measurement configuration menu) on page 341 IMDA Measurement Name panel (Measurement configuration menu) on page 300 Configure panel (Measurement configuration menu) on page 336 Gating panel (IMDA measurement configuration menu) on page 299...
Page 298 Menus and dialog boxes Field or control Description Ripple Frequency Sets the ripple frequency of the voltage/current source. Input signal is used to compute ripple in the configured source. Default is 50 Hz. Custom Frequency Custom Frequency Sets the custom frequency of the power signal source. Available only when Ripple Frequency = Custom.
Page 299 Menus and dialog boxes Field or control Description Cutoff Frequency (Fc) Sets the cutoff frequency for LPF. Default value is 500 Hz. Available when Torque Method is Current. Units Sets the unit for torque as N-m, Oz-inch, ft-lb, or inch-lb. •...
Page 300 Menus and dialog boxes 3. Connect the input signals to the instrument and confirm the waveforms are correct and not clipping. 4. Double-tap the IMDA measurement result badge for which you want to take a measurement. 5. Tap the IMDA Autoset button for the measurement and wait for the busy indicator to disappear. The instrument has now been optimized for that measurement.
Page 301 2. Select Harmonics measurement. 3. Select the limits as Custom. 4. Click Load Limits. 5. Browse to C:\Users\Public\Tektronix\TekScope\Applications\Power\HarmonicsLimits path. 6. Select IECStdClassALimits.csv. This is a sample file provided by default by the installer. Figure 21: Harmonics with custom limits Modify custom limits To modify the custom limits: 1.
Page 302 Menus and dialog boxes Figure 22: Harmonics with custom limits 2. Edit the limits value by adding the custom limits or you can save as another file as '...sample_custom.csv' and recall this file. Source Setup panel - Motor Analysis Field or control Description Source Setting Configure the Global or Local input or output, source, filter, and LL-LN conversion settings.
Page 303 Menus and dialog boxes Field or control Description Output Wiring Select the output wiring configuration from the drop-down: • 1 Phase-2 Wire (1V1I) • 1 Phase-2 Wire DC (1V1I) • 3 Phase-3 Wire (2V2I) • 3 Phase-3 Wire (3V3I) • 3 Phase-4 Wire (3V3I) LL to LN Conversion Converts Line-to-Line into Line-to-Neutral using mathematical equation when Wiring = 3 Phase-3 Wire...
Page 304 Menus and dialog boxes Field or control Description Gear Ratio Sets the gear ratio to increase or decrease the motor shaft speed compared to rotor speed. Edge Qualifier Configure the best source (with less noise) to extract the proper edges from the PWM source. Note: Edge qualifier is not available for Wiring = 1 Phase-2 Wire DC (1V1I).
Page 305 Menus and dialog boxes Jitter Measurement configuration menu fields, controls, and panels Field, control, or panel Description Measurement Statistics A list of measurement statistics related to the measurement. You can add these to a measurement badge by selecting the Show Statistics in Badge control. (Measurement name panel) Show Statistics in Badge Adds the listed statistical measurement readouts to the measurement badge readout.
Page 306 Menus and dialog boxes Gating panel (Jitter measurement configuration menu) on page 316 Filter/Limit Results panel (Jitter measurement configuration menu) on page 316 Pass/Fail Testing panel (Jitter measurement configuration menu) on page 317 Configure panel (Jitter measurement configuration menu) Use the configure panel to add a custom name (label) for the measurement and other parameters. To open the Configure panel for a Jitter measurement: 1.
Page 307 Menus and dialog boxes DC Common Mode measurements: Configuration panel Field or control Description Source 1 Select the input signal channel from the Source 1 fields. Source 2 Select the input signal channel from the Source 2 fields. Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard.
Page 308 Menus and dialog boxes Field or control Description Measure at % of the Unit Set the horizontal position where the measurement is taken as a percentage of the unit interval. Interval Double-tap in the field to change the value using a connected keyboard or the virtual keyboard. Available when Set Levels In is %.
Page 309 Menus and dialog boxes Field or control Description Measure at 'X' voltage Sets the vertical position where the measurement is taken in terms of volts. Available when Analysis Method is Histogram and Set Levels In is Absolute. Width Sets the window around the set level to search for the maximum eye width. Available when Analysis Method is Histogram.
Page 310 Menus and dialog boxes Field or control Description Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard. Bit Type Sets the waveform bit types as Trans, Non-Trans, or All.
Page 311 Menus and dialog boxes Field or control Description Pattern Length Enter the pattern length. Default length is 2 UI. When Pattern Detection is Auto, this field shows the detected pattern length. When Pattern Detection is Manual, this control must be set to match the actual pattern length.
Page 312 Menus and dialog boxes Field or control Description Pattern Type Set the pattern type as Repeating or Arbitrary. If the data signal is repeating pattern of N bits, then Repeating pattern type should be selected. If the data signal is non-repeating pattern or unknown then Arbitrary pattern type should be selected. Available when Pattern Detection is Auto.
Page 313 Menus and dialog boxes Field or control Description Window Length Enter the window length. Default length is 10 UI. Determines the number of unit intervals over which pattern correlation effects are analyzed. The window should be set to a large enough value that the impulse response of the serial data transmitter and channel have settled.
Page 314 Menus and dialog boxes Phase Noise measurement: Configure panel Field or control Description Source 1 Select the input signal channel from the Source 1 fields. Source 2 Select the input signal channel from the Source 2 fields. Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard.
Page 315 Menus and dialog boxes TIE measurement: Configuration panel Field or control Description Source 1 Select the input signal channel from the Source 1 fields. Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard.
Page 316 Menus and dialog boxes SSC Modultion Rate measurement: Configure panel Field or control Description Source 1 Select the input signal channel from the Source 1 fields. Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard.
Page 317 Menus and dialog boxes on page 317 Pass/Fail Testing panel (Jitter measurement configuration menu) Jitter Measurement Name panel (Measurement configuration menu) The Jitter Measurement Name panel (the name of the measurement) provides controls for adding display statistics to the measurement badge and opening plots of the measurement.
Page 318 Menus and dialog boxes Reference Levels panel (Jitter measurement configuration menu) Use the Reference Levels panel to set the scope of the reference level settings (global or local), the measurement reference levels (High, Mid, and Low), the units used to take measurements, and the method used to calculate the Top and Base waveform values. Hysteresis settings are critical for PWM edge extraction.
Page 319 Menus and dialog boxes Mask Settings panel fields and controls Field or control Description Mask Defined By Define the way you edit the mask. The default option is Segments. Shape Lists the current shape type, and also lets you change the current shape to a specified shape. Changing a shape defines the minimum rectangle that includes all vertices of the current segment, and then does a best-fit approach to create the specified shape.
Page 320 Menus and dialog boxes Field or control Description Horizontal Center Sets the segment horizontal center, as time units, as the point halfway between the leftmost vertex and rightmost vertex. Flip Horizontal Flips the segment horizontally around its Horizontal Center value. Rotate Rotates the segment in units of degrees, from 0°...
Page 321 Menus and dialog boxes Field or control Description Insert Point Inserts a new row above the selected row and creates a new vertex on the segment shape. The new vertex is halfway between the vertices defined in the prior row and the following row in the table. Delete Point Deletes the currently selected point, keeps the row selected, and moves all rows below it up one row.
Page 322 Menus and dialog boxes Test Settings panel fields and controls Field or control Description Mask Test Turns the mask test On or Off. Mask Display Turns the mask display On (default) or Off. Label The text field to add a label to the mask test badge. By default, this field is blank. When you recall a mask from a file, the name of the file is automatically displayed in the label field.
Page 323 Menus and dialog boxes 1. Double-tap a Math waveform badge on the Settings bar. If no Math badge is present, tap the Add New Math button to add a Math waveform and open the configuration menu. 2. Set Math Type to Advanced. 3.
Page 324 Menus and dialog boxes Button Description Natural antilog. Inserts the text EXP( into the math expression. The EXP function produces the natural antilog of the argument. FFT Magnitude. Inserts the text FftMag( into the math expression. Select one of the waveforms as an argument to the function.
Page 325 Menus and dialog boxes Button Description Arc sine. Inserts the text ASIN( into the math expression. Arc cosine. Inserts the text ACOS( into the math expression. Arc tangent. Inserts the text ATAN( into the math expression. Degrees. Inserts the text DEG( into the math expression. The function expresses the value of the expression in degrees.
Page 326 Menus and dialog boxes Create/Edit filter configuration menu Use the create/edit filter menu to design IIR or FIR filter for a given signal. This menu also allows you to save the configured filter into a file and recall in the future. To access the Create/Edit Filter menu: 1.
Page 327 Menus and dialog boxes Field or Control Description Symbols Enter the number of symbols in the text field by which the filter span. Symbols value is >0. Default value is 1. Available only when Filter Type is Raised Cosine or Root-Raised Cosine Symbol Duration Enter the symbol duration value in the text field.
Page 328 Menus and dialog boxes 2. Set Math Type to Advanced. 3. Tap Edit to open the Equation Editor. Equation Editor menu fields and controls Field or control Description Sources Lists all available sources that you can add to an equation. Tap a source icon to add it to the cursor position in the Math x = input box.
Page 329 Menus and dialog boxes Math configuration menu fields and controls Field or control Description Display Turns the math waveform or FFT plot On or Off. Vertical Scale Sets the vertical graticule scale units. Tap the arrows to change the value, tap and use the assigned multipurpose knob to change values, or double-tap to open the virtual keypad to enter a specific value.
Page 330 Menus and dialog boxes Field or control Description Source, Source1, Source 2 Defines the signal source or sources for a Basic, FFT or Filter math waveform. Basic, FFT, and Filter math waveforms are created from analog channels only (Ch, Math, or Ref). Available when Math Type is Basic, FFT, or Filter.
Page 331 Menus and dialog boxes • You can Zoom on math waveforms. Measurement configuration menu overview Use this configuration menu to add statistics to a measurement badge readout, plot a measurement, and change measurement settings including source, scope (global or local), reference levels, gating, clock recovery, bandwidth filters, results limits, and pass/fail testing. To open a Measurement configuration menu for a measurement, double-tap a Measurement badge in the Results bar.
Page 332 Menus and dialog boxes Clock Recovery- Advanced Settings configuration menu Sets advanced clock recovery settings such as defining a nominal data rate or basing clock recovery on a known data pattern. To open the Clock Recovery-Advanced Settings configuration menu: 1. Double-tap a measurement that requires clock recovery information (such as jitter measurements). 2.
Page 333 Menus and dialog boxes Measurement configuration menu, Clock Recovery panel Field or control Description Clock Recovery Global sets whether the Clock Recovery settings defined in this panel apply to all measurements with clock recovery settings that are set to global (the default setting). Local sets the Clock Recovery parameters to apply to just this measurement.
Page 334 Menus and dialog boxes Field or control Description Clock Frequency Sets the clock frequency to use in Fixed mode. The clock in the waveform is ignored; the instrument uses the specified frequency, with the clock phase determined by best fit. Note: This method typically results in a closed eye.
Page 335 Menus and dialog boxes Field or control Description JTF BW Displays or sets the Jitter Transfer Function bandwidth that has been configured based on the current standard. Available when Method is Explicit Clock and Mode is Explicit Clock - PLL and PLL Model is Type II. Damping Sets the damping factor for the PLL.
Page 336 Menus and dialog boxes Gating panel (Measurement configuration menu) on page 338 Filter/Limit Results panel (Measurement Settings menu) on page 337 Pass/Fail Testing panel (Measurement Settings menu) on page 340 Configure panel (Measurement configuration menu) Use the Configure panel to set the measurement source(s), add a custom name (label) for the measurement, and other parameters. To open the Configure panel: 1.
Page 337 Menus and dialog boxes Filter/Limit Results panel (Measurement Settings menu) Use these settings to apply a High Pass and/or Low Pass filter to block specified frequency band components when taking measurements. Use the limit controls to set range of measurement values to measure, and the number of measurements to take (population). To open the Filter/Limit Results panel: 1.
Page 338 Menus and dialog boxes Gating panel (Measurement configuration menu) Use Gating to confine a measurement to a certain part of a waveform. To open the Gating panel: 1. Double-tap a Measurement badge in the Results bar to open the Measurement configuration menu. 2.
Page 339 Menus and dialog boxes • If the measurement has more than one source, gate bars are drawn on both sources. • Time gates can be placed anywhere. They can precede acquisition start value and extend beyond the acquisition value. • The Time Gating bars are shown in both the overview and zoomed view when zoom is on.
Page 340 Menus and dialog boxes Pass/Fail Testing panel (Measurement Settings menu) Use these settings to test measurement values against a specified limit and set actions for the instrument to take on failure. To open the PASS/FAIL TESTING panel: 1. Double-tap a Measurement badge. 2.
Page 341 Menus and dialog boxes Reference Levels panel (Measurement configuration menu) Use the Reference Levels panel to set the scope of the reference level settings (global or local), the reference levels (High, Mid, and Low), the units used to take measurements, and the method used to calculate the Top and Base waveform values. You can set the levels to be the same or different for rising and falling edges.
Page 342 Menus and dialog boxes Field or control Description Base Top Method Sets the method to calculate the waveform Base and Top values, which is then used to calculate the High, Mid, and Low reference levels. Auto is the default method, and automatically determines the best Base Top method to use. Most commonly sets the Top Base method to Histogram Mode.
Page 343 Menus and dialog boxes Menu bar overview The Menu bar provides access to file, utility, and help functions. The Menu bar Field or control Description File Provides typical system file management operations such as opening, saving, moving, and renaming files. See the links after this table for more information. Recall configuration menu (File menu) on page 344.
Page 344 2. In the How do you want to open this file? window select Always use this app to open <filetype> files box and tap More apps > Look for another app on this PC. 3. Navigate to path C:\Program Files\Tektronix\TekScope\scopeapp.exe and tap Open. •...
Page 345 Menus and dialog boxes Recall configuration menu fields and controls Field or control Description Look in: Shows the current directory path to the location of a file. Tap on the file path and use a keyboard to enter a new save location. Or double-tap on the file name to open the virtual keyboard and enter a path.
Page 346 Menus and dialog boxes Field or control Description File name Lists the selected file name. Files of type Use to select the file format you want to open. The drop-down list shows all file extension types that the instrument can read for the selected file type. Cancel Cancels the file open action and closes the configuration menu.
Page 347 Menus and dialog boxes Drive name Drive letter Drive or physical USB port location Rear panel USB 2.0 (top) USB 2.0 (bottom) USB 3.0 (top) USB 3.0 (bottom) Instruments with Windows OS Root drive User-accessible memory on the oscilloscope. USB ports Dynamic port letter If Windows operating system is installed, the Windows operating system assigns assignment...
Page 348 Menus and dialog boxes Drive name Drive letter Drive or physical USB port location Rear panel USB 2.0 (top) USB 2.0 (bottom) USB 3.0 (top) USB 3.0 (bottom) Save As configuration menu (File menu) Use this menu to configure saving screen captures, waveforms, oscilloscope setups, reports, and session files. To access the Save As configuration menu, tap File on the menu bar and select Save As..
Page 349 Menus and dialog boxes Field or control Description File Name The file name assigned to the file. The default value is either the user-entered name used to last save this file type, or a numeric value calculated by the instrument if this file type has not previously been saved with a custom file name.
Page 350 Menus and dialog boxes Field or control Description Save As Type Lists the available formats to which you can save files. The available save formats are set by the type of file being saved. Tap the field and select the graphic save format. Source Sets the waveform source to save.
Page 351 Menus and dialog boxes Field or control Description Save As Type Lists the available formats to which you can save files. The available save formats are set by the type of file being saved. Tap the field and select the report save format (PDF or Single File Web Pages). Append Report Appends a report to an existing report file.
Page 352 Menus and dialog boxes Browse Save As Location configuration menu fields and controls Field or control Description File path field Shows the current directory. Tap on the file path and use a keyboard to enter a new path. Or double-tap on the file name to open the virtual keyboard and enter a path.
Page 353 Menus and dialog boxes USB port drive names and locations Use the following table to determine which drive to select when navigating to and/or selecting a file on system memory or a connected USB memory device. Drive name Drive letter Drive or physical USB port location MSO44B and MSO46B Root drive...
Page 354 Menus and dialog boxes Drive name Drive letter Drive or physical USB port location MSO58LP without Windows OS Root drive User-accessible memory on the oscilloscope. Front panel USB 3.0 (left) USB 2.0 (right) Rear panel USB 2.0 (top) USB 2.0 (bottom) USB 3.0 (top) USB 3.0 (bottom) Instruments with Windows OS...
Page 355 Menus and dialog boxes Note: Oscilloscope supports File Name with unicode characters for Screen Capture, Report, Mask, Setup, Session, and Waveform files. File Utilities configuration menu fields and controls Field or control Description File path field Shows the current directory. Tap on the file path and use a keyboard to enter a new save location.
Page 356 Menus and dialog boxes Field or control Description Use the arrow buttons to navigate the file directory. The left arrow navigates back to the previously visited folder. The Right arrow navigates forward to the previously visited folder. The Up arrow navigates up one level from the current folder. Use to create a new directory (folder) at the current location.
Page 357 Menus and dialog boxes Drive name Drive letter Drive or physical USB port location Front panel USB 2.0 (top) USB 2.0 (middle) USB 2.0 (bottom) Rear panel USB 2.0 (left) USB 2.0 (right) Drive name Drive letter Drive or physical USB port location MSO54, MSO56, MSO58, MSO54B, MSO56B, MSO58B, MSO64, LPD64, MSO64B, MSO66B, and MSO68B without Windows OS Root drive User-accessible memory on the oscilloscope.
Page 358 Menus and dialog boxes Drive name Drive letter Drive or physical USB port location USB ports Dynamic port letter If Windows operating system is installed, the Windows operating system assigns assignment the first available drive letter (typically E:) to the first USB device attached to the oscilloscope, regardless of which port the USB device is plugged into.
Page 359 Menus and dialog boxes Field or control Description Path The path to the network drive. Double-tap the field and enter the network drive path information. User Name If the drive you are mounting is password-protected, use this field to enter the user name associated with the drive.
Page 360 Menus and dialog boxes Undo, Redo (Edit menu) The Edit menu lets you Undo or Redo recent actions. Tap Undo or Redo. Not all oscilloscope actions can be undone. If the Undo or Redo menu items are grayed out, then the last action cannot be undone or redone. Application (Menu bar) Use this menu to access installed software applications.
Page 361 Menus and dialog boxes Field or control Description Displayed Colors Tap and select either Normal or Inverted colors to set how the instrument displays waveforms and plots. Normal shows waveforms and plots in color with a back background. Inverted makes the waveform background white, with graticule markings in black. Inverted does not change the Menu bar, Results bar, or Settings bar colors.
Page 362 Menus and dialog boxes • All analysis and measurements abort immediately when an Autoset is started, and then restart upon Autoset completion. Measurements panel fields and controls Field or control Description Shared Reference Levels Tap to select either Global or Per Source reference levels. Global applies the same reference levels to all measurement sources.
Page 363 Menus and dialog boxes • The vertical lines denotes the start and end of the cycle and the waveform record. • The horizontal dotted lines correspond to the voltage levels found by the base-top method. Miscellaneous • The measurement annotations are associated with only analog source waveforms (Ch/Math/Ref). •...
Page 364 Menus and dialog boxes Field or control Description DDJ Separation Model Tap to select Spectral Domain or Time Domain. Spectral Domain approach measures the DDJ for waveforms using a spectral approach. Time Domain approach the DDJ value is calculated in Time domain as max{DDJn} – min{DDJn} for a waveform with a repeating pattern having N edges per pattern cycle.
Page 365 When the check box is enabled in Enabled Connected Scope dialog: You agree that the software may contact Tektronix servers periodically. You also agree that the instruments model and serial number and status of the enabled check boxes will be sent to Tektronix.
Page 366 The application provides preconfigured limits files for many combinations of standards and speed grades. These preconfigured DDR limits files are located at C:\Users\Public\Tektronix\TekScope\Applications\DDR\Limits. You can create a limit file by specifying limits for any of the result parameters such as Mean, Std Dev, Max, Min, peak-to-peak, population, MaxPosDelta, and MinPosDelta.
Page 367 Menus and dialog boxes Define Custom Colors menu fields and controls Field or control Description Normal Display Colors Use this menu to change the waveform colors to use when the instrument is in Normal display mode. Channels sets the colors used to display instrument channels. Maths sets the colors used to display math waveforms.
Page 368 Menus and dialog boxes Entering and applying LAN network changes When first opening the I/O menu LAN panel or LAN SFP+ panel, the Network Address is set to Auto (default setting) and the Apply Changes button is grayed out (inactive) in the LAN panel. When you select any editable input box and start entering data, the Apply Changes button becomes active, and the characters being entered are bolded and italicized.
Page 369 Menus and dialog boxes e*scope Remote Access panel fields and controls This panel is available for standard (non-Windows 10) instruments only. This setting are not supported on MSO44 and MSO46 (non-B version) instruments. Field or control Description e*Scope Remote Access Tap to toggle e*Scope remote access On or Off.
Page 370 You can type in more queries and view more results using this Telnet session window. You can find the syntax for relevant commands, queries and related status codes in the Programmer Manual that is available at the Tektronix website. Note: Do not use the backspace key on the keyboard during an Windows Telnet session with the oscilloscope.
Page 371 Menus and dialog boxes For more information on High Speed Interface, refer tek.com/en/solutions/application/test-automation/instrument-high-speed-interface. LAN and LAN SFP+ Reset configuration menu (Utility > I/O menu) Use this menu to reset the Local Area Network (LAN) settings to the listed default settings. To open the LAN Reset dialog: 1.
Page 372 Calibrated. If an instrument becomes uncalibrated, this displays an Uncalibrated status and a red Warning message bar is shown at the top of the screen in the Menu bar area. Contact your nearest Tektronix Service Center for assistance.
Page 373 Menus and dialog boxes Field or control Description Run SPC Signal path Compensation (SPC) corrects for internal DC inaccuracies caused by temperature variations and/or long-term drift in circuits. Note: SPC takes five or more minutes per channel to run. Allow the instrument to warm up for 20 minutes before running SPC. Remove all probes, cables, and adapters from the input connectors before running SPC.
Page 374 Menus and dialog boxes Field or control Description Password-protect these Opens the menu to enable the password protection for the oscilloscope security options. Set Password settings Change Password Opens the Change Password menu. This menu option is available after a password has been set. Tap to save the configured settings.
Page 375 For instruments running on the embedded OS, TekSecure is a shortcut for overwriting the SSD from the recovery partition. For instruments running on the Windows 10 OS, TekSecure deletes files in following locations: • C:\Users\<USER>\Tektronix\TekScope • C:\Users\<USER>\AppData\Local\Tektronix TekSecure will also remove the password protection in the Security configuration menu.
Page 376 Menus and dialog boxes TekSecure does not erase calibration constants or instrument firmware. Save any important waveform, screen capture, instrument setup, report, and session files to external memory before running TekSecure. The instrument will reboot after TekSecure completes. Demo (Utility menu) Use this menu to access demonstrations of key oscilloscope features.
Page 377 Description System information Provides system-related information such as model, bandwidth, serial number, Host ID, and installed firmware version. Provide this information when communicating with Tektronix to purchase option licenses or communicate with Customer Support. Probes Detected Lists probes connected to the instrument. TekVPI probes will list the probe model, serial number, and installed probe firmware version.
Page 378 Menus and dialog boxes Location to Save Exit Key configuration menu fields and controls Field or control Description Look in Shows the current directory path at which to save the exit key file. Tap on the file path and use a keyboard to enter a new path. Or double-tap on the file name to open the on-screen keyboard and enter a path.
Page 379 Menus and dialog boxes 1. Tap Help > About... on the menu bar. 2. Tap Install License button to open the Browse License Files configuration menu. Browse License Files configuration menu fields and controls Field or control Description Look in Shows the current directory path and file name.
Page 380 Menus and dialog boxes More (DRAW A BOX Menu) Use this menu to toggle the Waveform view box draw mode between Zoom area mode, Visual Trigger area mode, and Mask segment mode. To use the More (DRAW A BOX) menu: 1.
Page 381 Menus and dialog boxes on page 415 Trajectory plot configuration menu (Switching Loss power measurement) Acq (Acquisition) Trend plot configuration menu Use the Acq Trend configuration menu to set the acq trend plot waveform vertical scale and position, as well as add a label. To open the Acq Trend configuration menu, double-tap the Acq Trend badge in the Measurement badge.
Page 382 Menus and dialog boxes Acq Trend configuration menu fields and controls Field or control Description Auto Scale Enables or disables the Auto Scale mode. Auto Scale uses the signal data to dynamically set the vertical scale units. Plot Display Available values are •...
Page 383 Menus and dialog boxes Bathtub plot configuration menu Use this menu to change settings of a displayed jitter versus BER (bathtub) plot. To open the Bathtub plot configuration menu, double-tap anywhere in the Bathtub plot view. To close a plot view, tap the X in the upper right corner of the view. Deleting the Measurement badge that opened the plot also closes the plot.
Page 384 Menus and dialog boxes Deleting the Measurement badge that enabled the plot also closes the plot. BH curve configuration menu (Magnetic Analysis power measurement) Use this menu to change the settings of a displayed BH curve plot (Magnetic Property measurement). To open the BH curve plot configuration menu, double-tap anywhere in a BH curve Plot view.
Page 385 Menus and dialog boxes Field or control Description Save Plot Data Tap to open the Save As menu. Navigate to the location where you want to save the plot data. Enter a file name in the File Name field. Tap OK to save the plot data as a comma-separated values (.csv) file. It saves the selected standard limits and computed Harmonic values.
Page 386 Menus and dialog boxes Save panel fields and controls Use the Save panel controls to save the plot image or date to a file for inclusion in reports or further analysis in other applications. Field or control Description Save Plot Image Tap to open the Save As menu.
Page 387 Menus and dialog boxes Field or control Description Eye Rendering Fast Eye Rendering shows the UIs (Unit Intervals) that define the boundaries of the eye along with a user specified number of surrounding UIs for added visual context. Complete Eye Rendering shows all valid UIs (Unit Intervals). Plot Data Sets the measurement data from the drop-down list to be displayed on plot.
Page 388 Menus and dialog boxes Field or control Description Mask File Lists the path and file name of the mask file to load. You can directly enter the path of the mask file, or use the Browse button to navigate to a mask file. The field also has a drop-down list of recently selected files from which you can also select a mask file to load.
Page 389 Menus and dialog boxes Field or control Description Mask Hit Ratio The Mask Hit Ratio is the ratio between total UI hits across all mask segments and total number of UI's rendered on an eye diagram. The Mask Hit Ratio is unit-less. When Auto Fit Mask to Minimize Hits box is checked, the Mask Hit Ratio is measured as the ratio between the total number of sample hits and the total number of rendered samples.
Page 390 Menus and dialog boxes Save panel fields and controls Use the Save panel controls to save the plot image or date to a file for inclusion in reports or further analysis in other applications. Field or control Description Save Plot Image Tap to open the Save As menu.
Page 391 Menus and dialog boxes Field or control Description The Drive column lists the accessible directories, opening at the root (/) level. Use to quickly navigate to a location. Tap a name in the Drive list to show the contents of the directory in the Name pane. Double-tap an item to display the directory and any subdirectories under it.
Page 392 Menus and dialog boxes Fast Frame Timestamp plot configuration menu fields and controls Field or control Description AutoScale Toggles AutoScale On or Off (Default is On). Turn AutoScale off to set the X and Y-axis range to view an area of interest. When AutoScale is Off (unchecked), the Plot view zoom mode enables and a small Zoom window appears in the plot.
Page 393 Menus and dialog boxes Harmonics Bar Graph plot configuration menu (IMDA) Use this menu to change settings of a displayed harmonics bar plot (IMDA Harmonics measurement). Settings panel (Harmonics Bar Graph configuration menu) fields and controls Field or control Description Wiring: 3 Phase-3 Wire (2V2I) Set to measure 2V2I or 3V3I for 3P3W and 3P4W based on motor configuration.
Page 394 Menus and dialog boxes Deleting the Measurement badge that opened the plot also closes the plot. Harmonics Bar Graph plot configuration menu Use this menu to change settings of a displayed harmonics bar plot (Power Harmonics measurement). To open the Bar Graph plot configuration menu, double-tap anywhere in a harmonics Plot view. Settings panel (Harmonics Bar Graph configuration menu) fields and controls Field or control Description...
Page 395 Menus and dialog boxes Histogram plot configuration menu Use this menu to change settings of a displayed Histogram plot. To open the Histogram plot configuration menu, double-tap anywhere in a Histogram Plot view. Settings panel (Histogram plot configuration menu) fields and controls Field or control Description AutoScale...
Page 396 Menus and dialog boxes Closing a plot view To close (delete) a Plot view, tap the X in the upper right corner of the view. Deleting the Measurement badge that enabled the plot also closes the plot. Inductance Curve configuration menu (Magnetic Analysis power measurement) Use this menu to change settings of a displayed Inductance curve plot (Inductance measurement).
Page 397 Menus and dialog boxes I vs (integral of) V plot configuration menu (Magnetic Analysis power measurement) Use this menu to change settings of a displayed I vs. ∫V plot (I vs. ∫V measurement). To open the I vs. ∫V plot configuration menu, double-tap anywhere in the I vs. ∫V Plot view. Settings panel (I vs.
Page 398 Menus and dialog boxes Impedance plot configuration menu Use this menu to change the settings of a displayed Impedance plot (Impedance measurement). To open the Impedance configuration menu, double-tap anywhere in a Impedance Plot view. Settings panel (Impedance plot configuration menu) fields and controls Field or control Description AutoScale...
Page 399 Menus and dialog boxes Plot Settings panel (Math FFT plot configuration menu) fields and controls Field or control Description Auto Scale Toggles auto scaling of the plot on or off. When AutoScale is off, a small Zoom window appears in the plot.
Page 400 Menus and dialog boxes Field or control Description Vertical Units Sets the vertical scale to Degrees, Radians, or Group Delay. Note: The Vertical Units set when FFT Type = Phase override the Y-Axis scale setting in the Plot Settings panel. Only available when FTT Type set to Phase.
Page 401 TekExp The Tek Exponential window was invented at Tektronix. In Use this window for impulse-response testing where the the time domain, it is not asymmetrical bell shape as is 20% position is the zero phase reference point.
Page 402 Menus and dialog boxes Field or control Description Display Sets the Display as Vectors or Dots. X-Axis (Time) Scale From, To Sets the beginning and end scale range to display in the plot for the X-Axis scales. These values also define the horizontal area shown in the small Zoom window. Available when Auto Scale is unchecked.
Page 403 Menus and dialog boxes Field or control Description Wiring Allows to measure selected input or output wiring. Plot Display Select the plot display. • All: Displays both DQ0 and ABC components. • ABC/XYZ: Displays 3 phase voltage and current components. •...
Page 404 Menus and dialog boxes Field or control Description Save Plot Image Tap to open the Save As menu. Navigate to the location where you want to save the plot image. Enter a file name in the File Name field. Select the image file format (PNG, BMP, or JPG). Tap OK to save the plot image.
Page 405 Menus and dialog boxes Field or control Description Wiring Allows to measure 2V2I or 3V3I for 3P3W and 3P4W based on motor configuration. They can also use Line-to-Line and Line-to-Neutral for mathematical conversion. • 1 Phase-2 Wire (1V1I) • 1 Phase-3 Wire (2V2I) •...
Page 406 Menus and dialog boxes Closing a plot view To close (delete) a Plot view, tap the X in the upper right corner of the view. Deleting the Measurement badge that opened the plot also closes the plot. Phase Noise plot configuration menu Use this menu to change settings of a phase noise plot.
Page 407 Menus and dialog boxes Plot XY configuration menu Use this menu to change settings of a displayed XY plot. To open the XY plot menu, double-tap anywhere in the XY Plot view. Settings panel (Plot XY configuration menu) fields and controls Field or control Description X-Axis...
Page 408 Menus and dialog boxes Settings panel (Power Supply Rejection Ratio plot configuration menu) fields and controls Field or control Description AutoScale Toggles AutoScale On or Off. Turn AutoScale of to manually set the X and Y-axis range to view an area of interest.
Page 409 Menus and dialog boxes Power plots and cursors Use cursors in I vs. ∫V and B-H curve plots to take measurements at any point on these power measurement plot waveforms. Cursor readouts display the voltage and current values at their position and the difference (delta) between the cursors. You can display cursors in I vs.
Page 410 Menus and dialog boxes Save As configuration menu (plot Save panel, Save Plot Image button) fields and controls Field or control Description Save Location Lists the location where the file will be saved. The default value is the last location to which a file was saved.
Page 411 Menus and dialog boxes Field or control Description Browse Opens the Browse Save As Location configuration menu to navigate to and select a location at which to save the file. File name The file name assigned to the file. The default value is either the user-entered name used to last save this file type, or a numeric value calculated by the instrument if this file type has not previously been saved with a custom file name.
Page 412 Menus and dialog boxes Field or control Description Save Plot Image Tap to open the Save As menu. Navigate to the location where you want to save the plot image. Enter a file name in the File Name field. Select the image file format (PNG, BMP, or JPG). Tap OK to save the plot image.
Page 413 Menus and dialog boxes Field or control Description X-Axis From, To Sets the beginning and end scale range to display in the plot for the X-Axis scales. These values also define the horizontal area shown in the small Zoom window. Available when AutoScale is off.
Page 414 Menus and dialog boxes Field or control Description Vertical Scale Shows the vertical scale setting (when Auto Scale is on), or sets the vertical scale (when Auto Scale is off). Use the up and own arrow buttons to set the vertical scale value when Auto Scale is turned off. You can also use the multipurpose knob or screen keypad to change the value.
Page 415 Menus and dialog boxes Deleting a time trend plot To delete a Time Trend plot, touch and hold the Time Trend badge to open the right-click menu, and select Delete Time Trend. Deleting the Measurement badge that enabled the plot also closes the plot. Trajectory plot configuration menu (Switching Loss power measurement) Use this menu to change settings of a displayed SWL (Switching Loss) Trajectory plot.
Page 416 Menus and dialog boxes Transient Response plot configuration menu Use this menu to change settings of a displayed Transient Response plot. This plot is available for impedance measurement. To open the Transient Response plot configuration menu, double-tap anywhere in the Phase Response view. Settings panel (Transient Response plot configuration menu) fields and controls Field or control Description...
Page 417 Menus and dialog boxes Trend Plot configuration menu Use the Trend configuration menu to set the trend plot waveform vertical scale and position, as well as add a label. To open the Trend configuration menu, double-tap the Trend badge in the Settings bar. You can also double-tap the Trend Plot handle. Note: Measurements that can use the trend plot as a source will list the plot in the Source menu list.
Page 418 Menus and dialog boxes Save panel fields and controls Use the Save panel controls to save the plot image or date to a file for inclusion in reports or further analysis in other applications. Field or control Description Save Plot Image Tap to open the Save As menu.
Page 419 Menus and dialog boxes Field, control, or panel Description Reference Levels panel Sets the reference levels and units used to take measurements, the scope of the reference level settings (global or local), and the method used to calculate the Top and Base waveform values. Reference Levels panel (Measurement configuration menu) on page 341.
Page 420 Menus and dialog boxes Field or control Description Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard. Harmonics Source Selects the source of harmonics calculation source (Voltage or Current) for computation of the Harmonics.
Page 421 Menus and dialog boxes Field or control Description Peak Current Sets the peak current value of the DUT. Power Preset uses the specified peak current value to compute the vertical scale. Inrush Current measurement: Configure panel Field or control Description Current Source Selects the current source used to take the measurement.
Page 422 Menus and dialog boxes Field or control Description Type Select SMPS / PFC/ Flyback: SMPS: Select this option in case of signals without noise and ringing. The Vg source is not • required. Select Vg source (Source 3), in case of noisy signal. •...
Page 423 Menus and dialog boxes Inductance measurement: Configure panel Field or control Description Voltage Source Selects the voltage source used to take the measurement. Tap the field to show the list of available sources. Current Source Selects the current source used to take the measurement. Tap the field to show the list of available sources.
Page 424 Menus and dialog boxes Turn On Time measurement: Configure panel Field or control Description Input Source Selects the channel connected to the input side of the DUT. Type Selects the input to output power conversion type. Default is DC-DC. Label Sets the name of the measurement.
Page 425 Menus and dialog boxes Field or control Description Output Voltage Sets the expected maximum voltage for each listed output, in the range of -6 kV to +6 kV, with a resolution of 0.001 V. The measurement uses this value to set the vertical scale units for each output waveform.
Page 426 Menus and dialog boxes Field or control Description Cross Section Sets the cross section dimensions of the magnetic component. The values are: • 1 nm to 1 Mm for SI • 1 ncm to 1 Mcm for CGS Magnetic Length Sets the cross section dimensions of the magnetic length.
Page 427 Menus and dialog boxes Amplitude Analysis, Ripple Analysis, Timing Analysis power measurements: Configure panel Field or control Description Source Sets the signal source or sources used to take the measurement. If the measurement requires more than one source, multiple source fields are displayed. Tap the field to show the list of available sources. Label Sets the name of the measurement.
Page 428 Menus and dialog boxes Field or control Description Points Per Decade Sets the number of frequency points between the start and stop frequency in terms of log scale. The minimum and default value is 10 frequency points. The maximum value is 100. Start Frequency Sets the generator start frequency.
Page 429 Menus and dialog boxes Field or control Description Generator Generates stimulus, as a series of sine waves with configured amplitude, which are sent to the input of the DUT. Supported signal generator is Internal and External signal source. AFG31000 series and AFG 3K series are the supported external signal source.
Page 430 Menus and dialog boxes Field or control Description Generator Generates stimulus, as a series of sine waves with configured amplitude, that is sent to the DUT input. Supported signal generator is Internal and External signal source. AFG31000 series and AFG 3K series are the supported external signal source.
Page 431 Menus and dialog boxes on page 434 Gating panel (Power measurement configuration menu) Configure Profile Use the Configure Profile menu to configure the amplitude profile for the Power Supply Rejection Ratio (PSRR), and Control Loop Response (Bode) measurements, and Impedance measurements. It is recommended to customize the internal signal generator amplitude values using the amplitude profile configuration.
Page 432 Menus and dialog boxes Start Stop Amplitude 10 MHz 20 MHz 200 mV Note: The maximum stop frequency value for the internal signal generator is 50 MHz. Connection setup for Frequency Response Analysis (FRA) measurements Frequency Response Analysis (FRA) measurements include Control Loop Response (Bode), Power Supply Rejection Ratio (PSRR), and Impedance measurements.
Page 433 Menus and dialog boxes Figure 28: Connection diagram for Impedance measurement (Passive Splitter) Figure 29: Connection diagram for Impedance measurement (Active Splitter) FRA measurements are supported for 4/5/6 oscilloscope models. Note: 1. It is recommended to use a splitter with the built-in AFG source for Impedance measurements. If you use an external AFG, use a single channel with a splitter.
Page 434 Menus and dialog boxes 2. Negative values are not displayed in the impedance plot. They are replaced by the most previous positive value. Use the following steps to make the FRA measurements: 1. Make the connections as shown in the diagram. 2.
Page 435 Menus and dialog boxes Note: • It is advised not to operate oscilloscope front panel buttons or any UI button unless necessary during measurement execution. • You can change the ACQ modes, channel vertical settings, spectrum view average settings and trigger settings during measurement execution.
Page 436 Menus and dialog boxes Power Preset Sets the oscilloscope vertical, horizontal and acquisition parameters using the user inputs like peak voltage and current for Input Capacitance, Inrush Current, Turn On Time, and Turn Off Time. For Control Loop response and PSRR measurements, it sets the built-in generator such as start frequency, impedance, and amplitude values and also sets the vertical and horizontal acquisition parameters, so that oscilloscope is ready to acquire the desired waveform once the measurement starts.
Page 437 Menus and dialog boxes Field or control Description Plots Adds a Plot view of the measurement value to the screen. Available plots depend on the measurement. Plot types include SWL Trajectory, Bar Graph, Time Trend, Histogram, Control Loop Response, PSRR, SOA, and Transient Response. Trend adds the trend plot to the Waveform view.
Page 438 Menus and dialog boxes Field or control Description The Drive column lists the directory structure, opening at the root (/) level. Use to quickly navigate to a location. Tap to list the contents of the directory in the Name pane. Double-tap an item to display the directory and any subdirectories under it.
Page 439 Menus and dialog boxes Drive name Drive letter Drive or physical USB port location Root drive User-accessible memory on the oscilloscope. Front panel USB 2.0 (top) USB 2.0 (middle) USB 2.0 (bottom) Rear panel USB 2.0 (left) USB 2.0 (right) Drive name Drive letter Drive or physical USB port location...
Page 440 Menus and dialog boxes Drive name Drive letter Drive or physical USB port location USB ports Dynamic port letter If Windows operating system is installed, the Windows operating system assigns assignment the first available drive letter (typically E:) to the first USB device attached to the oscilloscope, regardless of which port the USB device is plugged into.
Page 441 Menus and dialog boxes Field or control Description Insert Point Add voltage and current points to define mask. Points are added to the end of the existing list. Delete Point Deletes the selected point data row. Save Mask Opens the Save As menu to navigate to and select the location at which to save the SOA mask data as a .pwrmsk file.
Page 442 Menus and dialog boxes Save As configuration menu (SOA mask file) Field or control Description Save Location Lists the location where the file will be saved. The default value is the last location to which a file was saved. Use the Browse button to quickly navigate to the location to which to save the file. Or you can tap on the file path and use a keyboard to enter a new save location.
Page 443 Menus and dialog boxes Field or control Description Position Set the vertical position of the waveform using the assigned multipurpose knob or the virtual keypad. Set to 0 Tap to set the vertical position to 0 (vertical center of the graticule). Reference File Shows the path and file name of the current Reference waveform.
Page 444 Menus and dialog boxes Recall configuration menu (Ref configuration menu) fields and controls Field or control Description Look in Shows the current directory path and file name. Tap on the file path and use a keyboard to enter a new path. Or double-tap on the file name to open the virtual keyboard and enter a path.
Page 445 Menus and dialog boxes Remote channel configuration menu Use the Remote channel configuration menu to set up analog channel vertical settings, deskew settings, external attenuation, alternate units for analog channel inputs, and enable the Spectrum View for the channel. To open remote analog channel configuration menu, double-tap remote Channel badge. The following text describes remote channel settings.
Page 446 Menus and dialog boxes Table 4: Spectrum View panel, fields and controls Field or control Description Display Enables (On) or disables (Off) displaying a spectrum waveform of the channel in a Spectrum View window. If this is the first channel to display a Spectrum View, tapping On opens the Spectrum View window and displays a spectrum trace for the channel.
Page 447 Menus and dialog boxes To open the analog Channel configuration menu Other panel: 1. Double-tap an analog Channel badge on the Settings bar to open the Channel configuration menu. 2. Tap the Other panel. Not all items listed in the table are shown for all measurements; The panel only shows fields and controls relevant to the selected measurement.
Page 448 Menus and dialog boxes Save As configuration menu (Save Mask) Use the Save As configuration menu to set the location and file name to which to save the contents of a mask, as a .xml format file. To open the Save As configuration menu to save a mask to a file: 1.
Page 449 Menus and dialog boxes Field or control Description Search Type Set to Bus. Source Select the 1-Wire bus that you want to search. Mark On Sets the type of information for which to search. If the selected search type requires more input, the menu updates will show additional fields.
Page 450 Menus and dialog boxes Field or control Description Serial Number The (next) least significant 48 bits give the serial number of the device and same can be searched. Available only when Mode is Standard (15.4 Kbps). Available only when Mark On isRead ROM, Match ROM. Available only when Mode is Overdrive (125 Kbps) and when Mark On is Overdrive Match ROM.
Page 451 Menus and dialog boxes Field or control Description Disparity Sets the disparity type as Positive or Negative or Either. Available only when Mark On is Symbols and Format is 8-Bit, 10-Bit, and Symbol. Note: Set the disparity value and then query the 10 bit data value. Value Sets the value for the format.
Page 452 Menus and dialog boxes Field or control Description Search Type Set to Bus. Source Select the Auto Ethernet bus that you want to search. Mark On Select the type of information for which to search. When the speed is 100 Base-T1, the available options are Start of Frame, Start of Frame Delimiter, MAC Address, Q-Tag Control Information, MAC Length/Type, IP Header, TCP Header, Client Data, End of Packet, FCS (CRC) Error.
Page 453 Menus and dialog boxes Field or control Description IP Protocol Sets the IP protocol pattern for which to search. Tap a Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 454 Menus and dialog boxes Field or control Description Mark When Sets the mark when condition. When set to Inside Range or Outside Range, fields are displayed to set a high and low boundary pattern for the specified search range. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 455 Menus and dialog boxes Field or control Description Data Sets the data pattern for which to search. Use in conjunction with the Mark When field to specify the exact search condition. Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 456 Menus and dialog boxes Field or control Description Label Sets the label pattern for which to search. Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values. Available when Mark When is Label or Label &...
Page 457 Menus and dialog boxes Field or control Description Copy Trigger Settings to Sets the search criteria to match the current oscilloscope trigger settings. Search Copy Search Settings to Sets the current oscilloscope trigger settings to match the search criteria. Trigger See also Bus Trigger configuration on page 564...
Page 458 Menus and dialog boxes PCIe serial bus search configuration menu on page 515 PSI5 serial bus configuration menu on page 261 RS-232 serial bus search configuration menu on page 525 SDLC serial bus search configuration menu on page 527 SENT serial bus search configuration menu on page 529 SMBus serial bus search configuration menu on page 533...
Page 459 Menus and dialog boxes Field or control Description Value Sets a specific Signal value for which to search. Use knob A to set a value, or double-tap the field and enter a value using the virtual keyboard. See also CAN serial bus search configuration menu (when using a .dbc symbol definition file) on page 459 CAN serial bus configuration menu on page 238...
Page 460 Menus and dialog boxes Field or control Description Data Sets the data for which to search. Available when CAN Standard is in CAN XL, CAN 2.0 + FD (ISO) + XL, CAN 2.0, or CAN FD (ISO) except when Decode Format is set to Symbolic from CAN bus configuration menu. ID &...
Page 461 Menus and dialog boxes CAN serial bus search configuration menu (when not using a .dbc symbol definition file) Use the CAN Search configuration menu to define conditions to search for and mark on an CAN bus waveform. This menu supports searches for CAN bus events when a .dbc symbol definition file is not loaded.
Page 462 Menus and dialog boxes Field or control Description Identifier Sets the identifier pattern for which to search. The number of bits shown depends on the Identifier Format setting. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 463 Menus and dialog boxes CPHY serial bus search configuration menu Use the CPHY Search configuration menu to define the conditions to search for and mark on a CPHY bus. Table 7: CPHY search menu, fields, and controls Field or control Description Display Enables or disables displaying search marks for this search.
Page 464 Menus and dialog boxes Field or control Description Packet Name Sets the packet name for which to search. Available options are Frame Start, Frame End, Line Start, Line End, Generic Short. Available only when Packet Typeis Short and SubType is CSI. Available options are V Sync Start, V Sync End, H Sync Start, H Sync End, End Of Transmission, Color Mode Off, Color Mode On, Shutdown Peripheral, Turn On Peripheral, Generic Short Write, Generic Read, Compression, Scrambling, Execute Queue, DCS Short Write, DCS Read, DCS...
Page 465 Menus and dialog boxes Field or control Description Word Sets the word packet pattern for which to search. The number of bits shown depends on the Data words setting. Use in conjunction with the Mark, to specify the exact search condition. Tap the Binary or Hex field and use the A and B knobs to select and change the values.
Page 466 Menus and dialog boxes Field or control Description Start Select to search the start event of the packet decode. Frames Select to search on the different frames. Frame Type Sets the frame type. Available options are Normal, Sleep, Long, Polling Normal, Polling long. Default is Normal. Available when Mark On is Frames Frame ID Sets the frame id value.
Page 467 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 CXPI serial bus configuration menu on page 241 Configure custom pattern editor Use the symbol keypad to configure the custom pattern comprising of Data/K-Code values. To open the keypad, double-tap inside the character/hex fields in the custom pattern editor.
Page 468 Menus and dialog boxes Keys Description Right Arrow Moves the selection in the entry field to the right. Cancel Closes the keypad without updating the Editor. Enter Updates the value in the Entry field to the Custom Pattern Editor’s hex field and closes the keypad. Note: A minimum of one pattern and maximum of 16 patterns can be added.
Page 469 Menus and dialog boxes Note: A minimum of two patterns and maximum of eight patterns can be added. Each pattern should be separated by a space. DDR Input Configure menu Use the Input configure menu to set the logic pattern input values for CS, RAS, CAS, and WE values. Logic Pattern Levels Input Configure menu This menu is accessed from the Define Inputs button in DDR Read, DDR Write, or DDR Read &...
Page 470 Menus and dialog boxes Field or control Description Custom Data Rate Sets the custom date rate. Default is 800 MT/s. Available only when Data Rate is Custom. Burst Detection Method Sets the burst detection method to use for the measurement. •...
Page 471 Menus and dialog boxes DDR Read & Write Search configuration menu Use the DDR Read & Write search to search both read and write events on source waveforms. To create a new DDR Read & Write search: 1. Tap Add New... Search. 2.
Page 472 Menus and dialog boxes Field or control Description CAS Min Sets the CAS (Column Access Strobe) minimum cycles value. Default value is 2.0 cycles. Available only when Burst Detection Method is Chip Select, Latency + DQ/DQS Phase Alignment. CAS Max Sets the CAS maximum cycles value.
Page 473 Menus and dialog boxes Field or control Description Stop Acquisition if Event Stops input acquisition when the search event occurs. Default is not enabled. Found Search Type Set to DDR Read. Source Lists the source channel or waveform to use to search. Standard Sets the DDR standard (DDR3 or LPDDR3).
Page 474 Menus and dialog boxes Field or control Description CS Active Sets the CS signal active true state to Low or High. Default is Low. Available only when Burst Detection Method is Chip Select, Latency + DQ/DQS Phase Alignment. Logic Pattern Sets the Logic pattern values.
Page 475 Menus and dialog boxes Field or control Description Scrambling Search the scrambling mode command. Compression Search for the compression mode command. Packet Type Sets the packet type for which to search. Available options are Short or Long. Default is Short. Available only when Mark On is Packets.
Page 476 Menus and dialog boxes Edge Search configuration menu Use the Edge search to mark when the specified edge condition occurs on an analog, digital, math, or reference waveform. To create a new edge search: 1. Tap Add New... Search. 2. Set the Search Type to Edge. 3.
Page 477 Menus and dialog boxes eSPI serial bus search configuration menu Use the eSPI Search configuration menu to define the conditions to search for and mark on a eSPI bus. Table 14: eSPI search menu, fields, and controls Field or control Description Display Enables or disables displaying search marks for this search.
Page 478 Menus and dialog boxes Field or control Description Command Opcode Enables search on the command opcode of different channels specified under the mark on. The size is 8 bits. When Mark On is Channel Independent and Phase is Command, available options are Get Status, Get Configuration, Set Configuration.
Page 479 Menus and dialog boxes Field or control Description Address Enables search on the address field for different channels based on different commands and response with header classified based on cycle types. Address field can vary anywhere between 8bits/16bits/ 32bits or 64bits. Tap the Binary or Hex field and use the A and B knobs to select and change the values.
Page 480 Menus and dialog boxes Field or control Description Length Enables search on the length field for different channels based on different commands and response with header classified based on cycle types. The size is 12 bits. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 481 Menus and dialog boxes Field or control Description Virtual Wire Data Enables search on Virtual Wire Data for command and response with header under the virtual wire channel. The size is 8 bits. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 482 Menus and dialog boxes Field or control Description Search Type Set to Bus. Source Select the Ethernet bus that you want to search. Mark On Select the type of information for which to search. MAC Address Destination, Sets the MAC destination and/or source address pattern for which to search. MAC Address Source Tap a Binary or Hex field and use the A and B knobs to select and change the values.
Page 483 Menus and dialog boxes Field or control Description Data Bytes Sets the number of client data bytes for which to search (one to sixteen bytes). Use the A knob to change the value. Only available when Mark On is Client Data. Byte Offset Sets the client data byte offset (Don't Care or the number of bytes).
Page 484 Menus and dialog boxes Field or control Description Source Select the EtherCAT bus that you want to search. Mark On Select the type of information that you want to search. Start of Frame Set to Start of Frame. Type Select the type that you want to search. Available when Mark On is Protocol.
Page 485 Menus and dialog boxes Field or control Description Length Sets the length pattern that you want to search. Tap a Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values. Available when Mark On is EtherCAT Header Length.
Page 486 Menus and dialog boxes Field or control Description Address Sets the address that you want to search. Tap a Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values. Available when Mark On is Datagram, Datagram is Datagram Header, Datagram Header is Address, and Address Type is Logical.
Page 487 Menus and dialog boxes Field or control Description Quality Sets the quality of the NV header that you want to search. Tap a Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 488 Menus and dialog boxes eUSB serial bus search configuration menu Use the eUSB Search configuration menu to define conditions to search for and mark on an eUSB bus waveform. You can have multiple searches on the same bus. Field or control Description Display Enables or disables displaying search marks on this search.
Page 489 Menus and dialog boxes Field or control Description Port Address Sets the special packet address pattern for which to search. Tap the Binary or Hex and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 490 Menus and dialog boxes Field or control Description Data Bytes Sets the number of data bytes for which to search (one to sixteen bytes). Tap the field and use the A knob to change the value. Available only when Mark On is Data Packet. Byte Offset Sets the byte offset (Don't Care or the number of bytes).
Page 491 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 eUSB serial bus configuration menu on page 247 FlexRay serial bus search configuration menu Use the FlexRay Search configuration menu to define conditions to search for and mark on an FlexRay bus waveform. You can have multiple searches on the same bus.
Page 492 Menus and dialog boxes Field or control Description Header CRC Enter the header CRC pattern for which to search. Use in conjunction with the Mark When field to specify the exact search condition. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 493 Menus and dialog boxes I2C serial bus search configuration menu Use the I2C Search configuration menu to define conditions to search for and mark on an I2C bus waveform. You can have multiple searches on the same bus. Field or control Description Display Enables or disables displaying search marks on this search.
Page 494 Menus and dialog boxes I3C serial bus Search configuration menu Use the I3C Search configuration menu to define conditions to search for and mark on an I3C bus waveform. You can have multiple searches on the same bus. To access an I3C serial bus Search menu, double-tap on a I3C Search badge in the Results bar. If there are no I3C Search badges, tap the Search button and add an I3C search.
Page 495 Menus and dialog boxes Field or control Description Direction Sets the search to mark address events of the specified direction (Read, Write, or Either). Addressing Mode Sets the search to mark 7-Bit or 10-Bit address events. Address Sets the search to mark events that meet the specified address for a Device or register location. The Addressing Mode sets the number of bits in the field.
Page 496 Menus and dialog boxes I3C SDR Direct field Description and menu fields Set Exchange Time Sets the search to mark Set Exchange Time events (SETXTIME). Events occur when Master and Slave devices exchange event timing information to collect or reconstruct timestamps, synchronize controls, and do other related tasks.
Page 497 Menus and dialog boxes I3C SDR Direct field Description and menu fields Get Accept Mastership Sets the search to mark Get Accept Mastership events (GETACCMST). Events occur when a Master request occurs, and when the Current Master offers Mastership to an I3C Secondary Master. There are no menu fields or controls displayed when this item is selected.
Page 498 Menus and dialog boxes I3C SDR Direct field Description and menu fields Get Exchange Time Sets the search to mark Get Exchange Time events (GETXTIME). Use the following fields to refine the search: When the Packet button is set to Direct, all Get Exchange Time events are marked. When the Packet button is set to Response, the menu displays the following fields to refine the search: Slave Address sets the 7-bit address of a specific Slave device for which to search.
Page 499 Menus and dialog boxes I3C SDR Direct field Description and menu fields Set Route Sets the search to mark Set Route events. There are no menu fields or controls displayed when this item is selected. This item is available when Version is 1.1 in the I3C bus configration menu. Device to Device(s) Tunneling Sets the search to mark Device to Device(s) Tunneling Control events.
Page 500 Menus and dialog boxes I3C SDR Broadcast field Description and menu fields Set Max Write Length Sets the search to mark Set Max Write Length events (SETMWL). Events occur when the Master sets a maximum data write length in bytes for a slave device. There are no menu fields or controls displayed when this item is selected.
Page 501 Menus and dialog boxes I3C SDR Broadcast field Description and menu fields Define List of Group Sets the search to mark Define List of Group Addresses events. Addresses There are no menu fields or controls displayed when this item is selected. This item is available when Version is 1.1 in the I3C bus configration menu.
Page 502 Menus and dialog boxes Errors field Description Broadcast Address Sets the search to mark Broadcast Address error events (an error with Broadcast Address commands intended for multiple Slave devices). There are no menu fields or controls displayed when this item is selected. Dynamic Address Sets the search to mark Dynamic Address events.
Page 503 Menus and dialog boxes HDR Restart field Description and menu fields HDR Restart Sets the search to mark HDR Restart events. An event occurs when an HDR Restart pattern is sent on the bus. There are no menu fields or controls displayed when this item is selected. Mark On = HDR Exit The following table lists the fields available when Mark On is set to HDR Exit.
Page 504 Menus and dialog boxes Field or control Description Identifier Sets the identifier pattern for which to search. Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values. Available only when Mark On is Identifier or Identifier &...
Page 505 Menus and dialog boxes Logic Search - Define Inputs configuration menu fields and controls Field or control Description Ch(x) (analog channels) or D(x) Use to select the signal sources logic condition on which to perform the logic search (High, Low, Don't (digital Channels) Care).
Page 506 Menus and dialog boxes Field or control Description Mark When Defines the waveform logic event to mark, when Use Clock Edge is set to No. Goes True: All conditions change to a true state. • • Goes False: All conditions change to a false state. •...
Page 507 Menus and dialog boxes Manchester serial bus search configuration menu Use the Manchester Search configuration menu to define conditions to search for and mark on an manchester bus decode. You can have multiple searches on the same bus. Field or control Description Display Enables or disables displaying search marks on this search.
Page 508 Menus and dialog boxes Note: In the bus configuration, when the packet view is • On, the displayed Search options are Sync Bits, Header, Data, Trailer, and Errors. • Off, the displayed Search options are Data and Errors. See also Bus Trigger configuration on page 564 Bus Search configuration menus...
Page 509 Menus and dialog boxes Field or control Description OpCode Sets to search two bit operation codes. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values. Only available when Mark When is OpCode.
Page 510 Menus and dialog boxes Mark On = Address This table lists the menu fields displayed when Mark On is set to Address. Field or control Description Address Sets the 16 bit long field search for the specified address. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 511 Menus and dialog boxes Field or control Description Transmit/Receive Bit Sets the transmit or receive bit state for which to search. Only available when Mark On is Command. Mark when RT Address Sets the RT address condition for which to search. When set to Inside Range or Outside Range, fields are displayed to set a low and high address for the specified search range.
Page 512 Menus and dialog boxes Field or control Description Data Sets the data pattern for which to search. Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values. Available when Mark On is Data.
Page 513 Menus and dialog boxes Field or control Description Sets the UID that you want to search. Tap a Binary or Hex field and use the A and B knobs to select the values. Or double-tap on the field and use the virtual keypad to enter the values. The UID field is available for the Standard 15693 and 14443A in the NFC bus configuration menu.
Page 514 Menus and dialog boxes Field or control Description Data Sets the data pattern for which to search. The number of bits shown depends on the Data Bytes setting. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 515 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 Parallel Bus configuration menu on page 258 PCIe serial bus search configuration menu Use the PCIe Search configuration menu to define conditions to search for and mark on PCIe bus waveform. You can have multiple searches on the same bus.
Page 516 Menus and dialog boxes Field or control Description Qualifier Sets a specfic Specify qualifier for which to search. Available options are =, ≠, >, <, and >. Value Sets a specfic Specify value for which to search. Use knob A to set a value, or double-tap the field and enter a value using the virtual keyboard.
Page 517 Menus and dialog boxes Field or control Description Bus Number Sets the bus number pattern for which to search. Tap a Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 518 Menus and dialog boxes Field or control Description Pattern Sets the pattern for which to search. Tap a Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values. Available when Mark On is in Custom Pattern.
Page 519 Menus and dialog boxes Field or control Description Mark On Sets the type of information for which to search. If the selected search type requires more input, the menu updates to show additional fields. See the following Mark On tables for the menu fields associated with specific Mark On settings. When Direction is ECU to Sensor, the available settings are: •...
Page 520 Menus and dialog boxes Field or control Description Data Bits When sync mode is tooth gap, data bits are 4 and 8 bits. When sync mode is pulse width data bits are 4 , 8 and 20 Data Sets the search to mark events that meet the specified data value. For Sensor to ECU, it displays Region A.
Page 521 Menus and dialog boxes Field or control Description Register Address Sets the register address value for which to search. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 522 Menus and dialog boxes Mark On = Error This table lists the menu fields displayed when Mark On is set to Error. Field or control Description Error Sets the search to mark Error type. Available error types are Any, Parity, CRC, and Response Code. Only available when Mark On = Error and Direction = Sensor to ECU.
Page 523 Menus and dialog boxes Field or control Description Set to 50% Sets the threshold at 50% of the measured signal transition range. 50% is calculated as (Top + Bottom)/2. Time Limit Sets the time period condition to be met. High Time Limit Sets the longest acceptable pulse width time period for the range condition.
Page 524 Menus and dialog boxes Rise/Fall Time Search configuration menu fields and controls Field or control Description Display Sets the display of the mark icons to either On or Off. If you have multiple searches defined, the control turns off just the marks for the selected search. Stop Acquisition if Event Stops input acquisition when the search event occurs.
Page 525 Menus and dialog boxes RS-232 serial bus search configuration menu Use the RS-232 Search configuration menu to define conditions to search for and mark on an RS-232 bus waveform. You can have multiple searches on the same bus. Field or control Description Display Enables or disables displaying search marks on this search.
Page 526 Menus and dialog boxes Runt Search configuration menu fields and controls Field or control Description Display Sets the display of the mark icons to either On or Off. If you have multiple searches defined, the control turns off just the marks for the selected search. Stop Acquisition if Event Stops input acquisition when the search event occurs.
Page 527 Menus and dialog boxes on page 471 DDR Read & Write Search configuration menu SDLC serial bus search configuration menu Use SDLC search bus configuration to operate on point-to-point, multipoint or loop facilities on switched/dedicated, two/four-wire circuits with full-duplex or half-duplex operation. Field Description Display...
Page 528 Menus and dialog boxes Field Description Type Search for various frames. Additionally Unnumbered frame has Type to set Command, Response, and Both. Available when Mark On is Unnumbered. Unnumbered Poll Search an optional response poll is sent by the primary station to poll one station, a group of stations, or all the stations on the loop.
Page 529 Menus and dialog boxes Field Description Exchange station Identification As a command, Exchange station Identification solicits the identification of the receiving (secondary) station. An information field may be included in the frame to identify the transmitting (primary) station. Available when Mark On is Unnumbered and Type is Both. Configure The configure command contains a function descriptor (a subcommand) in a single-byte information field.
Page 530 Menus and dialog boxes Field or control Description Status / Communications Sets the value of the status/communications nibble for which to search. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 531 Menus and dialog boxes Field or control Description Mark When Sets the mark when condition. Tap the down arrow and select the condition for which to search (=, ≠, >, <, ≥, ≤, Inside Range, Outside Range). The default is =. When set to Inside Range or Outside Range, fields are displayed to set high and low boundary values for the number of clock ticks for which to mark.
Page 532 Menus and dialog boxes Setup & Hold Search configuration menu fields and controls Field or control Description Display Sets the display of the mark icons to either On or Off. If you have multiple searches defined, the control turns off just the marks for the selected search. Stop Acquisition if Event Stops input acquisition when the search event occurs.
Page 533 Menus and dialog boxes 2. Tap the Data Sources > Define Inputs button. Setup and Hold Search - Define Inputs configuration menu fields and controls Field or control Description Ch(x) (analog channels) or Use to add (Include) or exclude (Don't Include) the data signal(s) from available input channels and D(x) (digital Channels waveforms.
Page 534 Menus and dialog boxes Field or control Description Command Code Sets the 8-bit command code that you want to search. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 535 Menus and dialog boxes SPI serial bus search configuration menu Use the SPI Search configuration menu to define conditions to search for and mark on an SPI bus waveform. You can have multiple searches on the same bus. Field or control Description Display Enables or disables displaying search marks on this search.
Page 536 Menus and dialog boxes SPMI serial bus search configuration menu Use the SPMI Search configuration menu to define conditions for which you want to search and mark on an SPMI bus signal. You can have multiple searches on the same bus. Field or control Description Display...
Page 537 Menus and dialog boxes Field or control Description Copy Trigger Settings to Sets the search criteria to match the current oscilloscope trigger settings. Search Copy Search Settings to Sets the current oscilloscope trigger settings to match the search criteria. Trigger See also Bus Trigger configuration on page 564...
Page 538 Menus and dialog boxes Field or control Description Time Code Sets the time code pattern for which to search. The number of bits searched is 6. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 539 Menus and dialog boxes Field or control Description Command Response Sets the command response. Available when Mark On is Command. Following are the available command responses when Version is set to Non VR14 in SVID serial bus configuration menu. • For Get: GetReg.
Page 540 Menus and dialog boxes Timeout Search configuration menu Use the Timeout search to mark a waveform when it does not detect an expected pulse transition within a specified period of time, such as when a signal gets stuck either high or low. To create a new timeout search: 1.
Page 541 Menus and dialog boxes on page 546 Window Search configuration menu DDR Read Search configuration menu on page 469 DDR Write Search configuration menu on page 472 DDR Read & Write Search configuration menu on page 471 USB serial bus search configuration menu Use the USB Search configuration menu to define conditions to search for and mark on an USB bus waveform.
Page 542 Menus and dialog boxes Field or control Description Sync Header Sets the sync header for which to search. This search setting is available when Mark On is set to Sync Header and the fields are Control (1100b), Data (0011b), and Invalid. Character Sets the control character for which to search.
Page 543 Menus and dialog boxes Field or control Description Packet Type Sets the packet type for which to search. This search setting is available when Mark On is set to Special Packet for the USB serial bus signal speed of 1.5 Mbps, 12 Mbps, and 480 Mbps of all variants and is set to Packet for the USB serial bus signal speed of 5 Gbps and 10 Gbps of all variants.
Page 544 Menus and dialog boxes Field or control Description Error Type Sets the error type for which to search. This search setting is available when Mark On is set to Error. Available options are CRC, PID Check Bits, Token CRC5, Data CRC16, Bit Stuffing, and Error. The PID Check Bits, Token CRC5, Data CRC16, and Bit Stuffing options are available only for USB 1.0 (1.5 Mbps), USB 1.1 (12 Mbps), and USB 2.0 (480 Mbps) speed signals.
Page 545 Menus and dialog boxes Field or control Description Frame Number Sets the frame number pattern for which to search. Use in conjunction with the Mark When field to specify the exact search condition. Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 546 Menus and dialog boxes See also Bus Trigger configuration on page 564 Bus Search configuration menus on page 457 on page 271 USB serial bus configuration menu Window Search configuration menu Use the Window search to mark a waveform when the signal rises above an upper threshold level or falls below a lower threshold level (the 'window'), with or without a time limit constraint.
Page 547 Menus and dialog boxes Field or control Description Threshold Crossing • Upper: A signal remains above the upper threshold level for longer than the specified time limit before crossing the upper threshold level to a lower level. (Trigger When = Outside > Limit) •...
Page 548 Menus and dialog boxes The menu opens on the measurement name panel, which provides controls to display additional statistics to the measurement badge, display plots of the measurement, and so on. The Measurement Name panel only shows fields and controls relevant to the selected measurement.
Page 549 Menus and dialog boxes Field, control, or panel Description Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard. Channel Width Sets the channel width.
Page 550 Menus and dialog boxes ACPR measurement: Configure panel Field, control, or panel Description Source Select the input signal channel from the Source drop-down menu. Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard.
Page 551 Menus and dialog boxes The contents of the Measurement Name panel depends on the selected measurement. Field,control, or panel Description Measurement Statistics A list of statistics related to the measurement. You can add these to a measurement badge by selecting the Show Statistics in Badge control. Show Statistics in Badge Adds the listed statistical measurement readouts to the measurement badge readout.
Page 552 Menus and dialog boxes Magnitude Vs. Time menu fields and controls Field or control Description Display Tap to toggle the trace display On or Off. Each Magnitude Vs. Time trace is drawn in its own slice (stacked mode). Vertical Scale Sets the vertical scale.
Page 553 Menus and dialog boxes Field or control Description Set Phase Reference Using Sets the phase reference point to either the Trigger Point or the Cursor A position. When Set Phase Reference Using is set to Trigger Point, the reference source is based on the phase at the trigger point.
Page 554 Menus and dialog boxes Field or control Description Center Frequency Sets or shows the center frequency value of the selected trace. If Lock Center Frequency Across All Channels is unchecked, then this field updates as different channels are selected in the Source field. If Lock Center Frequency Across All Channels is checked, then this field sets all spectrum traces to use the frequency shown in the field.
Page 555 Menus and dialog boxes Field or control Description Spectrum Time Sets the channel's spectrum time location, shown as a percent of the record length. Double-tap the field to enter a value. If Lock Spectrum Time Across All Channels is unchecked, then this field updates as different channels are selected in the upper-menu Source field.
Page 556 Menus and dialog boxes Field or control Description Source Moves the spectrum trace cursors and readouts to the selected source (default) or a specific selected from the list. Selected Waveform lets you tap the screen or use a mouse to quickly move the cursors to a selected trace (Overlay mode) or slice (Stacked mode).
Page 557 Menus and dialog boxes Field or control Description Waveform Intensity Sets the brightness level of all waveforms. Graticule Style Sets the graticule style to display. Grid displays a grid, cross hairs, and frame. Time displays a vertical grid of time marks, cross hairs, and a frame. Full displays a frame and a grid.
Page 558 Menus and dialog boxes Field or control Description Readout Sets the marker readouts to show Absolute or Delta values. The default value is Absolute. Absolute readouts show the actual frequency and peak value. Delta readouts show the frequency and amplitude values of the markers relative to the Reference Marker values.
Page 559 Menus and dialog boxes TDR measurement overview Use this configuration menu to add a measurement and change measurement settings including source, scope (global or local), reference levels, and gating. To open the TDR measurement configuration menu for a measurement, double-tap a TDR measurement badge in the Results bar. TDR Measurement configuration menu fields, controls, and panels Field, control, or panel Description...
Page 560 Menus and dialog boxes This feature sets the vertical settings of voltage sources and trigger source of the oscilloscope to the TDR source channel. TDR preset calibrates each line of TDR using average acquisition mode. It also sets the optimal sample rate and horizontal scale to accommodate incident and first reflection of the voltage waveform.
Page 561 Menus and dialog boxes Figure 31: Connection diagram for TDR differential Note: The TDR Preset feature supports only the Picotest J2154A as a TDR source and the trigger is always set for negative TDR originating from the port 3. Use the following steps to run a TDR Preset on the TDR measurements: 1.
Page 562 Menus and dialog boxes Note: In case of failure, the instrument displays a popup error message. See Errors and Warnings. Note: The TDR Preset is specific to a previously calibrated termination. Rerun the TDR Preset whenever there is a significant change in the DUT termination.
Page 563 Menus and dialog boxes • Setup & Hold Trigger menu • Timeout Trigger menu • Video Trigger configuration menu on page 618 • Window Trigger menu A Trigger Event configuration menu Use this menu to set the trigger conditions for the A trigger event of a Sequence trigger. To open the A Trigger Event menu: 1.
Page 564 Menus and dialog boxes B Trigger Event menu (Sequence Trigger configuration menu) fields and controls Field or control Description Trigger Type Select the B event trigger type. Other fields and controls The fields and controls shown depend on the selected Trigger Type. Use the following links to access setting information on a specific trigger.
Page 565 Menus and dialog boxes on page 588 Parallel serial bus trigger settings panel RS-232 serial bus trigger settings panel on page 589 SENT serial bus trigger settings panel on page 590 SPI serial bus trigger settings panel on page 593 SPMI serial bus trigger settings panel on page 594 SVID serial bus trigger settings panel...
Page 566 Menus and dialog boxes Field or control Description Data Sets to trigger when the specified data bits condition occurs. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 567 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Audio serial bus trigger settings panel Field or control...
Page 568 Menus and dialog boxes Field or control Description Data Sets the data pattern on which to trigger. Use in conjunction with the Trigger When field to specify the exact trigger condition. Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 569 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Auto Ethernet serial bus trigger settings panel Note: The Auto Ethernet serial bus trigger settings panel is available when the speed is set to 10 Base-T1S.
Page 570 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. CAN serial bus trigger settings panel Field or control...
Page 571 Menus and dialog boxes Field or control Description Trigger On Select the type of information on which to trigger. Available options are Start of Frame, Types of Frame, FD Bits, Identifiers, Data, Id & Data, End of Frame, and Error. Default is Start of Frame.
Page 572 Menus and dialog boxes Field or control Description FD Bits Sets the FD bits value on which to trigger. Available only when CAN Standard is CAN FD (ISO) or CAN FD (non-ISO) bus. BRS Bit Sets the Bit Rate Switch (BRS) bit state on which to trigger. Available when Trigger On is FD Bits.
Page 573 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Ethernet serial bus trigger settings panel Field or control...
Page 574 Menus and dialog boxes Field or control Description Source Port, Destination Port Sets the source and/or destination TCP header port pattern on which to trigger. Tap a Binary, Hex or Decimal field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 575 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. 4/5/6 Series MSO MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB, MSO58LP, and LPD64 Help...
Page 576 Menus and dialog boxes FlexRay serial bus trigger settings panel Field or control Description Source Select the FlexRay bus on which to trigger. Trigger On Select the type of information on which to trigger. Indicator Bits Select the indicator bits type on which to trigger. Tap the Binary or Hex field and use the A and B knobs to select and change the values.
Page 577 Menus and dialog boxes Field or control Description Trigger When Sets the trigger when condition. When set to Inside Range or Outside Range, fields are displayed to set a high and low boundary pattern for the specified trigger type. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 578 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. I2C serial bus trigger settings panel Field or control...
Page 579 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. I3C serial bus trigger settings panel Field or control...
Page 580 Menus and dialog boxes Field or control Description Repeated Start Sets the trigger on repeated start. Addressing Mode Sets the address length as 7-Bit or 10-Bit. Direction Sets the transfer direction Read, Write, or Either. Available when Trigger On is Address and Addressing Mode is 7-Bit. Address Sets the address pattern on which to trigger based on the selected addressing mode and direction.
Page 581 Menus and dialog boxes Field or control Description Set Static as Dynamic Address Enables the trigger on Set Static as Dynamic Address. Available when Trigger On is I3C SDR Broadcast in I3C Trigger configuration menu and Version is 1.1 from the I3C Bus configuration menu. Set Dynamic Address Enables the trigger on Set Dynamic Address (SETDASA).
Page 582 Menus and dialog boxes Field or control Description Set Group Address Enables the trigger on Set Group Address for a specific Slave device. Available when Trigger On is I3C SDR Direct or I3C SDR Broadcast in I3C Trigger configuration menu and Version is 1.1 from the I3C Bus configuration menu. Slave Reset Action Enables the trigger on Slave Reset Action for a specific Slave device.
Page 583 Menus and dialog boxes Field or control Description Direction Enables trigger on T-Bit error for Read or Write direction. Available when Trigger On is Errors and Error Type is T-Bit. Broadcast Address Enables the trigger on broadcast address error. Available when Trigger On is Errors. Hot-Join Enables trigger on hot join.
Page 584 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. LIN serial bus trigger settings panel Field or control...
Page 585 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. MIL-STD-1553 serial bus trigger settings panel Field or control...
Page 586 Menus and dialog boxes Field or control Description Sync Sets to trigger on a Sync condition. Available when Trigger On = Sync. Transmit/Receive Bit Sets the transmit or receive bit on which to trigger. Available when Trigger On = Command. Trigger When RT Address Sets to trigger when the specified RT address condition occurs.
Page 587 Menus and dialog boxes Field or control Description Minimum Time Sets the minimum time for a valid RT/IMG signal. Available when Trigger On = Time (RT/IMG). Maximum Time Sets the maximum time for a valid RT/IMG signal. Available when Trigger On = Time (RT/IMG). Error Type Sets the error condition on which to trigger.
Page 588 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Parallel serial bus trigger settings panel Note: Parallel bus triggering is standard on all instruments.
Page 589 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. RS-232 serial bus trigger settings panel Field or control...
Page 590 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. SENT serial bus trigger settings panel Field or control...
Page 591 Menus and dialog boxes Field or control Description Channel Sets the SENT channel type on which to trigger. Available when Trigger On = Start of Packet. Status / Communications Sets the value of the status/communications nibble on which to trigger. Tap the Binary or Hex field and use the A and B knobs to select and change the values.
Page 592 Menus and dialog boxes Field or control Description Trigger When Sets the trigger when condition. Tap the down arrow and select the condition on which to trigger (=, ≠, >, <, ≥, ≤, Inside Range, Outside Range). The default is =. When set to Inside Range or Outside Range, fields are displayed to set high and low boundary values for the number of clock ticks on which to trigger.
Page 593 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. SPI serial bus trigger settings panel Field or control...
Page 594 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. SPMI serial bus trigger settings panel Field or control...
Page 595 Menus and dialog boxes Field or control Description Slave Address Sets the slave address value on which to trigger. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 596 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. SVID serial bus trigger settings panel Field or control...
Page 597 Menus and dialog boxes Field or control Description Slave Address Sets the slave address value on which to trigger. Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap on the field and use the virtual keypad to enter values.
Page 598 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. USB serial bus trigger settings panel Note: The USB bus trigger settings is not supported to the USB 3.0 (5 Gbps), USB 3.1 Gen 1 (5 Gbps), or USB 3.2 Gen 1 (5 Gbps) signal speed.
Page 599 Menus and dialog boxes Field or control Description Trigger On Select the type of information on which to trigger. Handshake Type Sets the handshake packet type on which to trigger. Available when Trigger On is set to Handshake Packet. Available options are Any (XX10), ACK (0010), NAK (1010), and STALL (1110). Packet Type Sets the special packet type on which to trigger.
Page 600 Menus and dialog boxes Field or control Description Data Packet Type Sets the data packet type on which to trigger. Available when Trigger On is set to Data Packet. Data Bytes Sets the number of data bytes on which to trigger (one to two bytes). Tap the field and use the A knob to change the value.
Page 601 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Edge Trigger configuration menu Use the edge Trigger menu to trigger the instrument when a signal rises and/or falls through a specified level.
Page 602 Menus and dialog boxes Settings panel (Edge Trigger configuration menu) fields and controls Field or control Description Trigger Type Set to Edge. Source Lists the source channel or waveform to use to trigger or search. Types that require multiple inputs will replace this control with a different source definition control.
Page 603 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 604 Menus and dialog boxes Logic Qualification - Define Inputs (Trigger configuration menu) fields and controls Field or control Description Chx (analog channels) or Dx Use to select the signal source logic condition on which to perform the logic trigger (High, Low, Don't (digital channels) Care).
Page 605 Menus and dialog boxes Field or control Description Clock Edge Sets the signal transition edge (rising, falling, or either) for evaluating the logic condition at that clock transition. (Use Clock Edge = Yes) Clock Threshold Sets the threshold level that the clock signal must pass through to be considered a valid transition. The clock threshold value is independent of the input signal threshold(s).
Page 606 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 607 Menus and dialog boxes Pulse Width Trigger configuration menu Use the Pulse Width Trigger to trigger on specific pulse width conditions, including when a pulse width is within or outside a range of specified times. Pulse Width triggers are often used to troubleshoot digital signals. To open the Pulse Width trigger configuration menu: 1.
Page 608 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 609 Menus and dialog boxes • Timeout Trigger menu • Video Trigger configuration menu on page 618 • Window Trigger menu Rise/Fall Time Trigger configuration menu Use the Rise/Fall Time trigger to trigger when the rise or fall time of a signal is less than, greater than, equal to, or not equal to a specified time limit.
Page 610 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 611 Menus and dialog boxes • Timeout Trigger menu • Video Trigger configuration menu on page 618 • Window Trigger menu Runt Trigger configuration menu Use the Runt trigger to trigger on waveforms where a short pulse crosses one threshold but fails to cross a second threshold before recrossing the first.
Page 612 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 613 Menus and dialog boxes • Timeout Trigger menu • Video Trigger configuration menu on page 618 • Window Trigger menu Sequence Trigger configuration menu Use Sequence triggers to trigger on a second (B) event after a first (A) event occurs. You can specify to trigger on the first occurrence of event B (with or without a time delay), or trigger after a specified number of B events occur.
Page 614 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 615 Menus and dialog boxes Settings panel (Setup & Hold Trigger configuration menu) fields and controls Field or control Description Clock Source Sets the signal to use as the clock. The clock source can be an analog, digital, math, or reference waveform.
Page 616 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 617 Menus and dialog boxes Timeout Trigger configuration menu Use the Timeout Trigger to trigger on a waveform when an expected signal does not transition within a specified period of time, such as when a signal gets stuck either high or low. To open the Timeout trigger menu: 1.
Page 618 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 619 Menus and dialog boxes Settings panel (Video Trigger configuration menu) fields and controls Field or control Description Trigger Type Set to Video. Source Lists the source channel or waveform to use to trigger or search. Video trigger only operates on a single source.
Page 620 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 621 Menus and dialog boxes • Timeout Trigger menu • Window Trigger menu Visual Trigger panel Use the Visual Trigger panel in the Trigger badge to enable Visual Trigger mode and set area combinatorial logic. To access the Visual Trigger panel: 1.
Page 622 Menus and dialog boxes Field or control Description Trigger When • Enters Window: The signal outside a window enters the window defined by the upper and lower threshold settings. • Exits Window: The signal exits the window defined by the upper and lower threshold settings. •...
Page 623 DUT. Only available if you have installed the DVM option, which is available when you register your instrument with Tektronix. Other trigger types •...
Page 624 Menus and dialog boxes • Setup and Hold Trigger menu • Timeout Trigger menu • Video Trigger configuration menu on page 618 Virtual Keyboard Use the onscreen virtual keyboard to enter textual information such as a file path, file name, label text, or on-screen callout. To access the virtual keyboard, double-tap in a menu or dialog text input box.
Page 625 Menus and dialog boxes Area Settings panel fields and controls Field or control Description Source Lists the available source signals for which to create an area. The default value is the signal source of the selected area. Shape Lists the current shape type, and also lets you change the current shape to a specified shape. Changing a shape defines the minimum rectangle that includes all vertices of the current area, and then does a best-fit approach to create the specified shape.
Page 626 Menus and dialog boxes Field or control Description Reset Points Deletes all but three data points from the table. The remaining three data points are set to a default triangle, set to two divisions for height and width, and centered in the waveform area. Note: Redo and Undo are available for most Edit Vertices panel controls.
Page 627 Menus and dialog boxes Area Combinatorial Logic menu fields and controls Field or control Description Logic expression field Displays the area combination logic for all areas associated with the same signal source. All areas are ANDed by default, including areas set as Don't Care. Use the buttons in the menu to edit or define the area combination logic, or double-tap the field and enter the logic expression directly.
Page 628 Menus and dialog boxes To create a histogram, see Create a waveform histogram on page 164. Field or control Description Display Enables or disables displaying the waveform histogram bins. Source Lists the source channel or waveform for the waveform histogram. Mode Set the mode of the histogram as Vertical or Horizontal.
Page 629 Menus and dialog boxes Save As configuration menu (Save Waveform Histogram) Use the Save As configuration menu to set the location and file name to which to save the contents of a histogram, as a .csv format file. To open the Save As configuration menu to save a histogram 1.
Page 630 Menus and dialog boxes Field or control Description Median Median is the middle histogram data value, where half of all histogram data points are less than this value and half are greater than this value. Mode Mode is the histogram data value that occurs most frequently. Standard Deviation Standard Deviation is the standard deviation (Root Mean Square deviation) of all histogram data points within or on the histogram box.
Page 631 Menus and dialog boxes Fields or controls Description Persistence Sets the length of time data points are displayed on screen before being erased. Off sets the record points to appear for the current acquisition only. Infinite continuously accumulates record points on the waveform until you change one of the acquisition display settings or clear the acquisition memory.
Page 632 Menus and dialog boxes Field,control, or panel Description Deskew panel Sets the circuit parameters to calculate the skew between voltage and current. Deskew panel (WBG-DPT measurement configuration menu) on page 639 Generator Setup panel Configure the AFG 31000 Series to generate the double pulse signal of the required amplitude and pulse widths.
Page 633 Menus and dialog boxes Field or control Description Power Preset Power Preset uses the inputs above to preset the oscilloscope for optimal Vertical, Horizontal, Trigger, and Acquisition settings. Before Power Preset, turn OFF power supply and configure AFG31000 Series. After performing Power Preset, turn on the power supply with lower Vcc. Gate Stimulus Gate Stimulus sets the oscilloscope to Single Sequence.
Page 634 Menus and dialog boxes Field or control Description Label Sets the name of the measurement. You can use the default name, or double-tap in the field and change the label using a connected keyboard or the virtual keyboard. Signal Type Sets the signal type as Voltage or Current.
Page 635 Menus and dialog boxes Diode d/dt measurement: Configure panel Field or control Description Pulse Region Sets the pulse region for the signal. Number of Pulses Sets the number of pulses in the input signal. Available when Pulse Region is set to Multiple Pulse. Label Sets the name of the measurement.
Page 636 Menus and dialog boxes Field or control Description Integration Current Levels Sets the integration current levels as Auto or Custom. Set Levels In Sets the levels as % or Absolute. Available when Integration Current Levels is Custom. Start Level and Stop Level Shows the integration levels for the current values.
Page 637 Menus and dialog boxes Field or control Description Gate Source (Vgs/Vge) Sets the voltage signal source for the power device. Vgs is the gate-source voltage when Power Device is set to MOSFET. Vge is the gate-emitter voltage when Power Device is set to IGBT. Vds Level Sets the Vds levels as Auto or Custom.
Page 638 Menus and dialog boxes Field or control Description Integration Current Stop Level The integration level value is fixed when Integration Current Level is Auto. Sets the integration level for the current Stop Level when Integration Current Level is Custom. Double-tap in the field and enter the value using a connected keyboard or the virtual keyboard. Refine Edge Finds the optimum pulse region when the edge signal is ringing or has glitches.
Page 639 Menus and dialog boxes Figure 32: Connection diagram for WBG-RDS(on) measurement. Connection setup for WBG-DPT measurements Please refer to WBG-DPT datasheet at www.tek.com for more information on connection setup for WBG-DPT measurements. Deskew panel (WBG-DPT measurement configuration menu) Use the deskew panel to adjust the skew between voltage and current in WBG-DPT measurements. To open the Deskew panel for a WBG-DPT measurement: 1.
Page 640 Menus and dialog boxes Field or control Description WBG Deskew WBG Deskew performs a double pulse test twice to compute and set the skew between Vds and Id or Vce and Ic. Turn-on the power supply and perform Preset before running the WBG Deskew. Use Generator Setup for gate stimulus automation.
Page 641 Menus and dialog boxes Field or control Description Width Sets the width of each pulse. Note: Maximum and minimum pulse width depends on duty cycle limitation of AFG31000. Sets the gap between each pulse. Note: Maximum and minimum pulse gap depends on duty cycle limitation of AFG31000. The Generator Setup panel displays a dynamic image of the configured pulse.
Page 642 Menus and dialog boxes Reference Levels panel (WBG-DPT measurement configuration Menu) Use the Reference Levels panel to set the scope of the reference level settings (global or local), the measurement reference levels (High, Mid, and Low), the units used to take measurements, and the method used to calculate the Top and Base waveform values. You can set the reference levels to be the same or different for rising and falling edges.
Page 643 Waveform acquisition Waveform acquisition Acquisition concepts The Acquisition system sets which data points are used to acquire waveforms. Acquisition hardware Before a signal is displayed, it must pass through the input channel where it is scaled and digitized. Each channel has a dedicated input amplifier and digitizer.
Page 644 Waveform acquisition position is 50 percent, then the trigger point is in the middle of the waveform record. When horizontal delay is on, the time from the trigger point to the horizontal reference is the horizontal delay. Interpolation Your instrument can interpolate between the samples it acquires when it does not have all of the actual samples it needs to fill the waveform record.
Page 645 Waveform acquisition Acquisition mode Envelope mode finds the highest and lowest record points over many acquisitions. Envelope uses Peak Detect for each individual acquisition. Average mode calculates the average value for each record point over many acquisitions. Average uses Sample mode for each individual acquisition.
Page 646 Waveform acquisition Each frame can be viewed individually and you can scroll through them by selecting frame numbers with a mouse, virtual keypad or the multi-purpose knob on the instrument’s main console. When a particular frame of interest is identified, you can use the instrument’s features to characterize, measure, zoom and analyze the waveform in detail.
Page 647 Waveform acquisition Scaling and positioning The scaling and positioning controls determine the portion of the input signal received by the acquisition system. Set the vertical scaling, positioning, and DC offsets to display the features of interest on your waveform and to avoid clipping. Each waveform Slice or Graticule contains ten major divisions.
Page 648 Waveform acquisition Note: Amplitude-related automatic measurements (for example, peak-to-peak and RMS) will be accurate for vertical windows if the waveform is not clipped (that is, the waveforms are acquired). But if signal amplitude were to extend outside the vertical acquisition window, the data acquired is clipped. Clipped data causes inaccurate results if used in amplitude-related automatic measurements.
Page 649 Triggering concepts Triggering concepts User selected trigger conditions are used to capture waveforms for measurement and analysis. The next figure shows how triggers fit into the overall instrument operation. Trigger helps you to capture meaningful waveforms to display on screen. This instrument has simple edge triggers as well as a variety of advanced triggers.
Page 650 Triggering concepts You can set the instrument to trigger on a parallel bus when the instrument detects a match to the bus pattern, or when the instrument detects that the value on the bus is < or > the value of the bus pattern. The pattern can be in Binary or Hex format. You can set the instrument to trigger on an SPI bus when the instrument detects an SS Active bus cycle or Data.
Page 651 Triggering concepts Runt trigger concepts A runt trigger occurs when the instrument detects a short pulse that crosses one threshold but fails to cross a second threshold before recrossing the first. • You can set the instrument to detect any positive or negative runt pulse, or only those wider than a specified minimum width. •...
Page 652 Triggering concepts The setup/hold violation zone spans the clocking edge as shown above. The instrument detects and triggers on data that does not become stable long enough before the clock (setup time violation) or that does not stay stable long enough after the clock (hold time violation). Timeout trigger concepts A timeout trigger occurs when the instrument does not detect an expected pulse transition within a user specified period of time, such as when a signal gets stuck either high or low.
Page 653 Triggering concepts Moving visual trigger areas To move a visual trigger area, just touch and drag the area to a new position. When dragging a visual trigger area while in Stacked or Overlay display mode, the area source remains the same. When dragging a visual trigger area while in Stacked display mode, you cannot drag a visual trigger area from one waveform slice to another.
Page 654 Triggering concepts A digital pulse train is a good example of a complex waveform. Each pulse looks like any other, so many possible trigger points exist. Not all of these will result in the same display. The holdoff period allows the instrument to trigger on the correct edge, resulting in a stable display.
Page 655 Triggering concepts Trigger slope and level The slope control determines whether the instrument finds the trigger point on the rising or the falling edge of a signal. The level control determines where on that edge the trigger point occurs. See the next figure. Learn about trigger position Trigger sources The trigger source provides the signal that triggers acquisition.
Page 656 Triggering concepts Window: Use the Window trigger to trigger when the input signal is enters or leaves a window set by two threshold levels. You can further qualify the trigger event in terms of time by using the Trigger When controls, or by using the logical state of other channels by using the Logic Qualification control.
Page 657 Waveform display concepts Waveform display concepts This instrument includes a flexible, customizable display that lets you control how waveforms appear. The figure shows how the display features fit into the overall instrument operation. The display shows analog, digital, math, reference, and bus waveforms. The waveforms include channel markers, individual waveform graticule readings, and trigger source and level indicators.
Page 658 Waveform display concepts Waveform preview mode The waveform preview attempts to show what the next acquisition will look like when the acquisition is delayed due to slow triggers or long acquisition duration, or when the acquisitions have stopped. Waveform preview recalculates math waveforms, but does not represent changes in trigger levels, trigger modes, or different acquisition modes.
Page 659 Measurement concepts Measurement concepts Blackman-Harris FFT window concepts FFT windows have various resolution bandwidths and scallop losses (see the figure below). Choose the one that best allows you to view the signal characteristics you are interested in. The Blackman-Harris window has a low amount of energy leakage compared to the other windows. Its best use is for single frequency signals to look for higher order harmonics.
Page 660 Measurement concepts Nyquist frequency The highest frequency that any digital oscilloscope can measure without errors is one-half of the sample rate. This frequency is called the Nyquist frequency. The FFT waveform displays the input signal frequency components from DC (0 Hz) to the Nyquist frequency. FFT and aliasing Aliasing occurs when the input frequency of a signal is greater than one half of the sampling frequency (the sample rate).
Page 661 Measurement concepts Gaussian window This is the default window function (see the next figure). It is unique in that the time-domain shape of an exponential Gaussian function transforms into a Gaussian exponential shape in the frequency domain. Note: This window provides optimal localization in both the time and the frequency domain. Guidelines for working with math waveforms Use the following guidelines when working with math waveforms: •...
Page 662 Measurement concepts Hamming window This window is unique in that the time domain shape does not taper all the way to zero at the ends. This makes it a good choice if you wanted to process the real and imaginary parts of the spectrum off line and inverse transform it back to the time domain. Because the data does not taper to zero, you can remove the effect of the window function from the result.
Page 663 Measurement concepts You create math waveforms to support the analysis of your channel and reference waveforms. By combining and transforming source waveforms and other data into math waveforms, you can derive the data view that your application requires. Create math waveforms that result from: •...
Page 664 Measurement concepts Predefined expressions are accessible using the FFT or Basic Math Types. The following syntax describes the valid math expressions you can use with the Equation Editor for the Advanced Math Type: A math expression is composed of settings, functions, scalars and sources. Settings have the syntax [settingName=settingValue] and are generally applied to measurements.
Page 665 Measurement concepts • Use vertical position and vertical offset to position your source waveform. The vertical position and offset will not affect your derivative waveform unless you position the source waveform off screen so that it is clipped. Measurement variables By knowing how the instrument makes calculations, you may better understand how to use your instrument and how to interpret your results.
Page 666 Measurement concepts 3. The level with the most points in the upper histogram is the Top value, and the level with the most points in the lower histogram is the Base value. If Mid gives the largest peak value within the histogram, the oscilloscope returns the Mid value for both Top and Base (this is probably a very low amplitude waveform).
Page 667 Measurement concepts The instrument calculates these values as follows: 1. Find the first Mid reference edge in the waveform record or the gated region. This is Edge1. 2. Continuing from Edge1, find the next Mid reference edge in the waveform record (or the gated region) of the opposite direction of Edge1.
Page 668 Measurement concepts Tek-Exponential window In the time domain, it is not a symmetrical bell shape as is the case with the other windows. Instead, it is exponential with a peak at the 20% position of the time domain gate. The frequency domain shape is triangular. Note: Use this window for impulse-response testing where the 20% position is the zero phase reference point.
Page 669 Measurement concepts LPF are used to remove background and high frequency noise. High-Pass Filter (HPF) A high-pass filter passes all the frequencies above the specified cutoff frequency. It rejects all the frequencies below the cutoff. HPF can be used to remove DC and low-frequency components. Both LPF and HPF are commonly used in HSS (High Speed Serial) and data communication applications.
Page 670 Measurement concepts Band-Stop Filter (BSF) A band-stop filter passes all frequencies except a configured frequency band between lower and upper cut off frequencies. BSF filters are extensively used in Medical electronic systems. All-Pass Filter The All-pass filter is whose amplitude is constant and passes all frequencies between DC to Fs /2. Enter the delay in seconds which introduces appropriate delay on the filtered output MATH waveform which is equivalent to phase shift in the frequency domain.
Page 671 Measurement concepts The standard deviation is a user input that defines the Gaussian window width. Hilbert The ideal Hilbert transform filter has a gain of 1 dB at all frequencies and shifts the phase of all frequencies by 90 degrees. Hilbert filter can be used to create quadrature signals over a wide frequency range.
Page 672 Measurement concepts Differentiator The ideal differentiator is a high pass filter that shifts phase by 90 degrees. Its frequency response would be linear all the way from DC to Fs/2. Note: Displays magnitude response plot for Differentiator filters. If the REF waveform sample rate does not match with Scope horizontal sample rate, then the user must change the oscilloscope sample rate to match with the REF sample rate.
Page 673 Measurement concepts As the filter order is increased, the passband and stop-band performance improve, with the transition from passband to stop-band becoming sharper. The Butterworth method is best suited for design problems that focus on controlling passband and stop-band ripple. This filter is used in electrophysiology and also a good choice for DC measurement applications.
Page 674 Measurement concepts The application computes and displays plots of magnitude, phase, impulse, and step responses. Note: Chebyshev II filter considers stop-band attenuation value to design the filter. The passband gain is measured above the stop-band attenuation. Elliptical Elliptical filters have passband and stop-band ripple and the sharpest roll-off near the cutoff frequency. This type of filter contains ripple behavior in both the passband and stop-band.
Page 675 Measurement concepts Bessel Thompson can be used in some RF and in particular audio applications where the preservation of the wave shape and phase of components within a signal are important. These filters are used in applications where a constant group delay is critical, such as in analog video signal processing. Raised Cosine (RC) and Root Raised Cosine (RRC) filters Raised Cosine and RRC filters are low-pass filters.
Page 676 Measurement concepts utilized. Samples per symbol is the product of current sample rate of oscilloscope and symbol duration. Since the sample rate is inherently a configuration of filter, the filter response changes for different sample rate. The UDF designs just for the current oscilloscope sample rate. The filter order is computed as Symbols x Symbol Duration x Sample Rate.
Page 677 Measurement concepts As impulse response starts, looking closer to a sinc response, the rate of magnitude transition increases rapidly to an extent where gain of output waveform start decreasing and also ripples in output waveform increases. It is advised to decrease the sample rate and symbols configuration in such situations.
Page 678 Measurement concepts Key filter parameters • A filter's response to different frequencies is characterized as passband, transition band, or stop-band. • Passband response is the filter's effect on frequency components that are passed through (mostly) unchanged. • Stop-band response: Band of frequencies that are highly attenuated post filtering. •...
Page 679 Filter file format Filter file is unique to Tektronix User Defined Filter software. When filter file is saved, it will be in the below format. // Do not edit. Generated from Tektronix Filter Editor.
Page 680 // {filter_type: lowPass, filter_name: butterworth, filter_order: 2, fs: 6250000000.0, fir_taps: 5001, cutoff_freqs: 1000000000.0} 6250000000.0;1.453238838770423980e-01,3.881643214198569058e-01, and so on 2. Filter file created for Hilbert filter. // Do not edit. Generated from Tektronix Filter Editor. // FIR filter. // {filter_type: hilbert} @6250000000.0;-7.035076590000000241e-17,1.304761389999999890e-04, and so on Note: If the recalled filter file is not in the above format, it is unable to restore the filter settings.
Page 681 Measurement algorithms Measurement algorithms Amplitude measurement algorithms AC RMS measurement algorithm AC RMS is the true Root Mean Square of the data points about the Mean (µ). This measurement can be made across the entire record or on each cycle in the record. Area measurement algorithm Area is the arithmetic area for one waveform.
Page 682 Measurement algorithms where s is the sample interval. Similarly, W(t) is the sampled waveform Ŵ(t) is the continuous function obtained by interpolation of W(t) A and B are numbers between 0.0 and RecordLength – 1.0 If A and B are integers, then: where s is the sample interval.
Page 683 Measurement algorithms Note that overshoot values should never be negative (unless Top or Base are set out-of-range). Positive Overshoot measurement algorithm Positive Overshoot is the difference between Maximum and Top, divided by the amplitude. It is the percent that the waveform goes above top.
Page 684 Measurement algorithms DDR Amplitude Measurement algorithms AOS (DDR) AOS is the total area of the signal above specified reference level. AOS Per tCK (DDR) AOS Per tCK is the total area of the signal that crosses the specified reference level, calculated over consecutive periods. It is applicable to clock and address/command waveforms.
Page 685 Measurement algorithms tPST (DDR) tPST is the width of Read or Write burst postamble. It is measured from the last falling edge crossing mid reference level to the start of an undriven state (judged by a rising trend as per JEDEC specification). Hold Diff (DDR) Hold Diff is the elapsed time between the designated edge of the single ended waveform and the designated edge of a differential waveform.
Page 686 Measurement algorithms Where, N=200 (configurable) tCH(abs) (DDR) tCH(abs) is the high pulse width of the differential clock signal. It is the time duration, the waveform remains above the mid reference voltage level. tCL(abs) (DDR) tCL(abs) is the low pulse width of the differential clock signal. It is the amount of time the waveform remains below the mid reference voltage level.
Page 687 Measurement algorithms i =1 to N N=200 (configurable) tJIT(cc) (DDR) tJIT(cc) is the absolute difference in clock period between two consecutive clock cycles. tERR(n) (DDR) tERR(n) is the cumulative error across multiple consecutive cycles from tCK(avg). It measures time difference between the sum of clock period for a 200-cycle window to n times tCK(avg).
Page 688 Measurement algorithms tCKSRE tCKSRE is the valid clock cycles required after Self Refresh Entry (SRE) command. Changing the input clock frequency or the supply voltage is permissible only after tCKSRE time when the SRE command is registered. tCKSRX tCKSRX is the valid clock cycles required before the Self Refresh Exit (SRX) command. Changing the input clock frequency or the supply voltage is permissible provided the new clock frequency or supply voltage is stable for the tCKSRX time prior to SRX command.
Page 689 Measurement algorithms DPM Transient analysis measurement algorithm Turn on time Turn On Time measures the time delay between load current going high to other rail outputs going high when power on happens. Annotation will happen on input and corresponding output waveforms. Turn off time Turn Off Time measures the time delay between current going low to other rail outputs going low when power down happens.
Page 690 Measurement algorithms Eye measurement algorithms Eye Height measurement algorithm If analysis method is Parametric, Eye Height is the minimum vertical eye opening at the mid of the unit interval. This measurement is made across the entire record. If analysis method is Histogram, Eye Height is calculated non-parametrically based on the rendered eye diagram. The eye height measurement can be controlled by configuring the parameters.
Page 691 Measurement algorithms Note: This illustration shows how the measurement is made, and does not represent how the oscilloscope actually displays an eye diagram or histograms on an eye diagram plot. Eye Width measurement algorithm If analysis method is Parametric, Eye Width is the minimum horizontal eye opening at the user-specified reference level. This measurement is made across the entire record.
Page 692 Measurement algorithms IMDA measurements: Electrical Analysis algorithms DQ0 measurement algorithm Direct Quadrature Zero Transformation (DQ0) represents the mathematical transformation of balanced three-phase circuits (ABC/XYZ) and reduces the three AC quantities to two equivalent DC quantities. It is often used to simplify the analysis of three phase synchronous machines for the control of three phase inverters.
Page 693 Measurement algorithms There are two angles, initial angle and incremental angle. The initial angle is where QEI Z index pulse starts and D-axis gets aligned at this position. This is not applicable in case of no Z index pulse. DQ0 with Resultant vector (R) updates at the rate of encoder output resolution. QEI Index pulse (Z) gets zero degree phase of the rotor magnet and D-axis gets aligned to Resultant vector (R).
Page 694 Measurement algorithms Table 19: Invalid Input and Output Wiring for Efficiency measurement Input Output DCIn 3V3I (3P3W) No LL-LN 1V1I (1P2W) 3V3I (3P3W) No LL-LN 3V3I (3P3W) No LL-LN DCOut 3V3I (3P3W) No LL-LN 1V1I (1P2W) 3V3I (3P3W) 2V2I (3P3W) 3V3I (3P3W) 3V3I (3P3W) 3V3I (3P3W)
Page 695 Measurement algorithms The sign of the RePwr is derived from sign of V and I Phase difference. The results for all the configured phases are displayed. and I are the sub measurements of IMDA Power Quality measurement. (V) and I (A) computes the RMS value at fundamental frequency of the 3 Phase signal using FFT method.
Page 696 Measurement algorithms IMDA measurements: Using Hall sensors HALL sensor needs the number of pole pairs and corresponding gear ratio to properly measure key parameters. Figure 34: This transition is for 4 pole pairs motor. The order of rising edges or the order of falling edges of HALL sensor output determines the direction of rotation. The direction of rotation differs in the case of two pole pairs.
Page 697 Measurement algorithms Speed Where difference between t and t is defined by the number of pole pairs. 60 is the RPM that is revolutions per minute. G is Gear ratio. Direction fORDERf("ORDER" ) = ( R1 - R1 - R1 fORDERf("ORDER"...
Page 698 Measurement algorithms Where Steps is 6 slots in 1 electrical cycle. Angle is computed at every edge. For i edge, you will get the transition from zero degree and multiply for increment angle (resolution of angle). IMDA measurements: Using QEI The Quadrature Encoder Interface (QEI) consists of a disc, mounted on the rotating shaft, light sources (LEDs), and light receivers (phototransistors).
Page 699 Measurement algorithms PPR is Pulse per rotation. Speed (in Hz) = Speed (in RPM) * 60 Direction The direction of rotation is determined by the phase difference between the two signals. For example, If Phase A leads Phase B, then the direction of the motor is positive or forward.
Page 700 Measurement algorithms Speed = [Frequency(envelope signal)/pole pairs] Hz Note: Resolver is supported on IMDA Mechanical measurements only. Mechanical Power algorithm IMDA supports different sensor types to measure torque, speed, and angular position of the motor. Mechanical power generated at the output of a motor is computed as the product of measured speed and torque values.
Page 701 Measurement algorithms Generally, the torque developed in any DC motor is proportional to torque constant times the armature current. In series motor, field current is proportional to the armature current. The torque produced by the rotor is estimated to be directly proportional to the current in the armature current. You must configure the Torque constant of the motor.
Page 702 Measurement algorithms Figure 36: Jitter map - Spectral + BUJ AC Common Mode AC Common Mode (Pk-Pk) is the peak-to-peak amplitude of the common mode of the sources. Voltage sources are typically filtered to include only the frequency components above the cutoff frequency (30 kHz). The filter can be disabled in the measurement configuration. The measurement can be configured to take one or two sources, and the cutoff frequency may be enabled or disabled.
Page 703 Measurement algorithms DC Common Mode measurement algorithm DC Common Mode is the arithmetic mean of the common mode of two sources. This measurement is made across the entire record. Duty Cycle Distortion (DCD) is the peak-to-peak amplitude for that portion of the deterministic jitter directly correlated with signal polarity, that is the difference between the mean positive edge displacement versus that on negative edges.
Page 704 Measurement algorithms F/8 measurement algorithm F/8 is the peak-to-peak amplitude of the periodic jitter occurring at a rate of Fb (data rate) divided by 8. This measurement is made across the entire record. F/8 is reported as non-zero even if it coincide spectrally with DDJ. ISI measurement algorithm The ISI value is defined as the range (difference between the maximum and minimum value) of DDJ-per-edge values appearing across all rising edges, or the range of DDJ-per-edge values across all falling edges, whichever is greater.
Page 705 Measurement algorithms Phase noise The Phase Noise measurement performs a jitter measurement, converts the result into the frequency domain, and reports the rms jitter integrated between two specific frequencies selected by the user. A 10 decade averaging filter is applied on the phase noise spectrum to smooth the plot. Smoothing option is on by default. You can turn off the smoothing filter from the measurement configuration panel.
Page 706 Measurement algorithms T/nT Ratio measurement algorithm T/nT Ratio is the ratio in dB of the midpoint level of the 1st bit after each transition to the midpoints of the 2nd and subsequent non-transition bit levels prior to the next transition. This measurement is made for each non-transition bit in the record. TIE (Time Interval Error) is the difference in time between an edge in the source waveform and the corresponding edge in a reference clock.
Page 707 Measurement algorithms Where: Re[k] is the Real component of k harmonic. Im[k] is the Imaginary component of k harmonic. i is the Index of the input data value. k is the Index of the harmonics, k index is calculated using the harmonics number. x[i] is the discrete set of acquire time samples.
Page 708 Measurement algorithms Where: i is the Index of harmonics. Rel[i] is the Real component of the harmonics (Cos frequency). Img[i] is the Imaginary component of the harmonics (Sin frequency). If, Rel [k] < 0 & Im[k] < 0 Phase[k] = Phase[k] - π If, Rel[k] <...
Page 709 Measurement algorithms where: • c - capacitance in farads • q - accumulated charge, which is the integration of the current waveform • v - peak-peak voltage Inrush Current algorithm Inrush Current measures the peak value of the inrush current of the DUT. It is a single source current measurement. Supports annotation where you can navigate between Previous and Next regions from the Results badge.
Page 710 Measurement algorithms Where: ApPwr is the Apparent Power, Volt-Amperes (VA). is the root mean square of the voltage. is the root mean square of the current. • Reactive Power (RePwr): The reactive power or the imaginary power delivered to and temporarily stored in the reactive (inductive or capacitive) elements of the load, measured in units of Volt-Amperes-Reactive or VAR.
Page 711 Measurement algorithms Where, σ is the Phase Angle, Degree. Note: A warning will be shown if the edges are not available for both Voltage and Current sources. Results will be shown with valid edges only. Power measurements: Amplitude Analysis algorithms Cycle Amplitude measurement algorithm Cycle Amplitude is the difference between the Top value and the Base value.
Page 712 Measurement algorithms Power measurements: Timing Analysis algorithms Frequency measurement algorithm Frequency is the reciprocal of the period. Frequency is typically measured in Hertz (Hz) where 1 Hz = 1 cycle per second. Frequency = 1 / Period Negative Duty Cycle measurement algorithm Negative Duty Cycle is the ratio of the negative pulse width to the signal period, expressed as a percentage.
Page 713 Measurement algorithms Select a specific section of the waveform on the live signal by providing inputs for high and low levels in terms of percentage and absolute value of voltage and current. Select the edge of interest by viewing it visually on the oscilloscope. You can also enter the edge number on the results panel.
Page 714 Measurement algorithms SMPS circuit diagram shows the points where switching loss can be measured. After full wave rectification, the current signal should pass through the harmonic standard and enters for DC conversation. MOSFIT plays an important role to meet the design of SMPS. Regions of T , and Conduction loss (Cond) with voltage source (Vds) and current source (Ids) are shown in Switching Loss T and Conduction loss regions.
Page 715 Measurement algorithms fswi is the Switching frequency of the ith switching cycle, in Hz. -Stop ) is the stop point of T region of the i switching cycle, in time unit. -Stop ) is the stop point of T region of the i switching cycle, in time unit.
Page 716 Measurement algorithms Total Switching Loss=Ton Loss+Toff Loss+Conduction Loss Concept to identify Ton and Toff using gate voltage for edge analysis: Use gate voltage for edge analysis with default 50% edge level and hysteresis 10%. • To find the start of Ton: The start of the Ton is 5% or 1.5 V whichever is lower on the rise slope of the gate voltage. •...
Page 717 Measurement algorithms Inductance algorithm It measures the inductance (the integral of the voltage divided by the current) of a magnetic component during in-circuit operation. The application creates a single cycle by averaging multiple cycles of current and integrated voltage. An electric circuit has electromotive force created by a change of current in the same circuit known as self-inductance or in a neighboring circuit as mutual-inductance.
Page 718 Measurement algorithms is the Initial Permeability is the Max Amplitude permeability H is the magnetic field used to induce Magnetic Flux in the magnetic material MMF is Magneto Motive Force, it is also known as Magnetic Field Strength Note: The data waveform starts from the Max value of H, decreases, and then increases again (M-N-O-P). Magnetic Field Strength (H) The previous figure shows the hysteresis in a typical magnetic material.
Page 719 Measurement algorithms In slope calculation, there are N points between the cursors: Find = (H1+H2+…Hn)/N = (B1+B2+…Bn)/N = Hi-Hav, i=1..N normi = Bi-Bav, i=1..N normi B/H = SUM (H 2+…+H N) / SUM(H 2+…H normi normi normi normi normi normi normi normi normi...
Page 720 Measurement algorithms Similarly another math calculates the Output Power using V * I at the output side Power Efficiency = Output Power / Input Power Note: If more cycles are captured, then the power solution will automatically consider all the integral cycles, starting from first (mid) crossing to the last valid (mid) crossing.
Page 721 Measurement algorithms where: • 6 is • 2 is The gain and phase margin are two metrics to tell the stability of the system. Gain for where: • is the amplitude of the input signal. • is the input signal. Phase for Bode is the time shift between the input and output signals.
Page 722 Measurement algorithms Spectrum measurements algorithm Adjacent Channel Power Ratio (ACPR) algorithm Adjacent Channel Power is the amount of power that leaks into adjacent channels. This can be specified in terms of absolute power or a ratio of adjacent channel power to the main channel power, called adjacent channel power ratio (ACPR) or adjacent channel leakage ratio (ACLR).
Page 723 Measurement algorithms Figure 39: The image shows the channel width for a given Channel Power measurement. Occupied Bandwidth algorithm The occupied bandwidth refers to the bandwidth, including energy of a certain proportion of the total transmitted power, with the center frequency of the specified channel as the center.
Page 724 Measurement algorithms 2. Determine the lower frequency value. Starting at the lowest frequency in the range and moving upward, the power distributed in each frequency is summed until this result is (100− percOfPower %)/2 of the total power. 3. Determine the upper frequency value. Starting at the highest frequency in the range and moving downward, the power distributed in each frequency is summed until the result reaches (100−...
Page 725 Measurement algorithms Delay measurement algorithm Delay is the time between a mid reference level edge on one source to a mid reference level edge on a second source. The direction of each edge can be configured by the user. Falling slew rate Falling Slew Rate is the rate of change in value as an edge transitions from the high or mid reference level to the mid or low reference level.
Page 726 Measurement algorithms Figure 41: Fall Time 3. From THF, continue the search, looking for a crossing of LowRef. Update THF if subsequent HighRef crossings are found. When a LowRef crossing is found, it becomes TLF. (Use interpolation if necessary.) 4. FallTime = TLF – THF Frequency measurement algorithm Frequency is the reciprocal of the period.
Page 727 Measurement algorithms Where: T Hold is the hold time. T Main is the source 1 (clock) Mid reference edge time in the configured direction. T 2nd is the source 2 (data) Mid2 reference edge time in the configured direction. Low Time measurement algorithm Low Time is the amount of time that a waveform cycle is below the Low reference voltage level.
Page 728 Measurement algorithms Where: NP Data is the duration for N unit intervals. T Data is the VRefMid crossing time in either direction. If T n+N Data does not exist for a given n, no measurement is recorded for that position. Negative Duty Cycle measurement algorithm Negative Duty Cycle is the ratio of the negative pulse width to the signal period expressed as a percentage.
Page 729 Measurement algorithms Positive Duty Cycle measurement algorithm Positive Duty Cycle is the ratio of the positive pulse width to the signal period, expressed as a percentage. PositiveWidth is defined in Positive Pulse Width, following. Positive Pulse Width measurement algorithm Positive Pulse Width is the time the signal remains above the mid reference level. It is the distance from a rising edge to the next falling edge.
Page 730 Measurement algorithms Setup Setup Time is the time between the mid reference level crossing of the clock source (Source1) and the closest previous mid reference level crossing of the data source (Source2). The crossings (edges) may be configured to be rising, falling or either. The application calculates this measurement using the following equation: Where: T Setup is the setup time.
Page 731 Measurement algorithms TDR measurement algorithm TDR computes the impedance waveform based on reflections from incident step function wave travelling through transmission media. The voltage waveform measurement is transformed into reflection coefficient (ρ) using the following equation: Where: is mean of complete voltage waveform mean is amplitude of incident step voltage waveform Index k indicates one measurement per sample.
Page 732 Measurement algorithms Where: is Intrinsic impedance of TDR source and oscilloscope. Default value is 50 Ω. Index t indicates that it is one measurement per sample. Note: If the incident step is not determined during acquisition, then the Zmean, Cmean, and Lmean algorithms assume that the incident step is located at time zero.
Page 733 Measurement algorithms Time to Max Time to Max is the amount of time from the trigger point to the maximum data point. This measurement can be made across the entire record or on each cycle in the record. Time to Min Time to Min is the amount of time from the trigger point to the minimum data point.
Page 734 Measurement algorithms WBG-DPT measurements algorithm Double Pulse Test (DPT) Double Pulse Test is a method to measure switching characteristics of MOSFET, IGBT, and Diode. MOSFET includes Silicon (Si), Silicon Carbide (SiC), and Gallium Nitride (GaN) power devices. Figure 43: Double pulse waveform In a DPT, the DUT is switched twice to capture the waveforms for turn on and turn off transitions.
Page 735 Measurement algorithms Reverse Recovery Analysis Algorithms Reverse recovery time (Trr) is time interval between the instant when the current passes through zero when changing from the forward direction to the reverse direction and the instant when extrapolated reverse current between A and B points reaches zero. The Trr is comprised of two time intervals t and t when rectifiers respond with their own peak reverse recovery current Irr as shown in...
Page 736 Measurement algorithms Irrm Reverse recovery current (Irrm) is the maximum reverse current that occurs during the reverse recovery time interval. Diode d/dt Diode d/dt measures the rate of change of voltage or current (slew rate) during the specified start and stop integration levels. Diode d/dt can be measured during rising or falling edge.
Page 737 Measurement algorithms Figure 45: Waveform during turn off time Vpeak Voltage peak is the maximum voltage peak value in the power device during turn off condition of collector current or drain current pulse. Usually, the voltage peak is measured in Eoff region. Ipeak Current peak is the maximum current peak value in the power device during turn on condition of a collector current or drain current pulse.
Page 738 Measurement algorithms Turn off delay time for an IGBT is the time interval between 90% of the decreasing Vge to 90% of decreasing Ic during turn off condition or specified levels. Rise time for a MOSFET is the time interval between 90% and 10% of the Vds during turn on condition or specified levels. Rise time for an IGBT is the time interval between 10% and 90% of the Ic during turn on condition or specified levels.
Page 739 Measurement algorithms (stop region). The start and stop levels are determined within the start and stop region respectively. They are found using Top and Base measurement respectively, which are derived from reference level settings. For Switching Timing Analysis, Automatic Level Determination algorithm finds the start and stop region. In case the required start level is not found in start region, search region gets expanded to stop region and vice versa.
Page 740 Measurement algorithms is the resistance of probe used for measuring current. L is the effective inductance as measured at power loop inductance. V probe is DC bus voltage. During usual operation V and V are complicated to model mathematically but at turn on/off transition one of dslow dshigh these voltages are clamped by body diode, hence it is easy to model mathematically at transition.
Page 741 Measurement algorithms Figure 48: Flat model of Vds with large differential order filter at turn on transient Figure 49: Noisy model of Vds using small differential order filter at turn on transient 4/5/6 Series MSO MSO4X, MSO4XB, MSO5X, MSO5XB, MSO64, MSO6XB, MSO58LP, and LPD64 Help...
Page 742 References References DPM badge error and warning messages These tables provide information to help resolve error or warning messages that appear on the DPM measurement badges. Error messages displayed on the DPM measurement badges Error Message Cause Suggestion Empty input The oscilloscope is waiting for a Check that the oscilloscope has a valid input waveform.
Page 743 References Error Message Cause Suggestion Input source mismatch Incorrect combination of live (active) and Ref Acquire two waveforms of the same type source waveforms. (active or ref). In the case of two Ref waveforms, the two Reacquire the Ref waveforms with the same waveforms recalled must have the same time base and record length.
Page 744 References Error Message Cause Suggestion Input source mismatch. Current signal Mismatch between input waveform and Make sure a Current waveform is set as the expected in current source. wrong source set. For example, if current input to Current Harmonics measurement. waveform is used for voltage configuration, this error is shown.
Page 745 References Error Message Cause Suggestion Invalid range Indices No data in the gated region. Make sure that the input waveforms are valid. Empty Input Input waveform has no data. Make sure to set all the valid inputs. Input all DC Input signal is pure DC.
Page 746 References Warning messages displayed on the Power measurement badges Warning Message Cause Suggestion No data in range There are no data between the two cursors. Place the cursors appropriately. Warning from Frequency measurement Not able to measure frequency value on the Adjust Hysteresis band to compute edges input waveform due to noisy waveform.
Page 747 References Warning Message Cause Suggestion No GM value No zero degree crossing on the Phase Check the test setup connections and try curve. again. Incorrect Input Trigger level Not able to find the specified Input Trigger Adjust the Input Trigger Level such that Level provided in input source of Turn On/ voltage is within the span of input source Turn Off measurement .
Page 748 References TDR badge error and warning messages Error messages displayed on TDR measurement badges Error Message Cause Suggestion Empty input The oscilloscope is waiting for a single Check the TDR source connections. Check sequence trigger. Input waveform has no that the oscilloscope has a valid input data.
Page 749 References Warning Message Cause Suggestion Deskew input source Only for the differential TDR when negative In any one of the differential TDR voltage TDR voltage waveform exhibits a skew with waveforms, change the skew settings of the respect to positive TDR voltage. voltage waveform.
Page 750 References WBG-DPT badge error and warning messages These tables provide information to help resolve error or warning messages that appear on the WBG-DPT measurement badges. Error messages displayed on WBG-DPT measurement badges Error message Cause Suggestion Invalid Pulse Region Could not find valid pulse region in WBG- Adjust the start and stop levels DPT measurement WBG Deskew failed.
Page 751 References Warning Message Cause Suggestion Adjust start and stop level for pulse <x> Could not find accurate measurement result Adjust start and stop levels from at the given pulse number measurement configure tab. If you are in Auto mode, go to Custom and set start and stop values.
Page 752 Index Numerics add (continued) visual trigger area to screen 1-Wire serial bus menu waveform to the screen 250 Kohm termination add a plot 8b10b serial bus menu Add Filter (math equation editor) Add Filter (math waveform) Add Measurements menu Add New Bus waveform button A B Sequence trigger Math waveform button...
Page 753 Area configuration menu (Visual Trigger) Bus Decode Results table ARINC429 Bus Decode Table menu Audio bus trigger settings bus inputs, parallel audio serial bus menu bus menu, parallel AUS Per tCK measurement (DDR) bus search AUS per UI measurement (DDR) bus setup Auto Ethernet serial bus menu bus setup menus...
Page 754 AOS Per tCK Constant Clock contact Tektronix AOS Per tCK measurement Control Loop Response (Bode) AOS Per UI AOS Per UI measurement Control Loop Response plot Control Loop Response plot menu...
Page 755 DDR (continued) disconnect a network drive timing measurements display tJIT(cc) eye diagram tJIT(cc) measurement display a channel tJIT(duty) display cursors tJIT(duty) measurement display cursors (spectrum view) tJIT(per) display mode tJIT(per) measurement display multi-source cursors tPST display parameters tPSTmeasurement display settings tRPRE Displayed waveform tRPRE measurement...
Page 756 edit an area (visual trigger) (continued) eye diagram plot menu (continued) rotate an area Settings Edit histogram Eye Height edit mask segment Eye Height measurement configuration panel add a vertex Eye high move a vertex EYe High remove a vertex Eye High measurement resize Eye High: Configuration panel...
Page 757 flip a segment (mask) flip an area (visual trigger) font color H Bar cursors Force button Hamming FFT window Frequency Hamming window defined front panel Acquisition handles, analog and digital Autoset button Hanning FFT window Aux In Hanning window defined Aux Trig harmonics Bus button (front panel)
Page 758 how to (continued) How to create Waveform Histogram change measurement settings How to use Waveform Histogram change persistence change waveform colors change waveform intensity change waveform interpolation I vs. ∫V plot compensate TPP series probes I vs. ∫V plot menu configure a results table connect probes I2C bus trigger settings...
Page 759 inverted screen color mode load option license file IP address loading Irrm measurement files mask files reference waveforms setup files lock to bench or rack log files, how to export logic keypad Jitter Measurement configuration menu overview Logic search menu Jitter Measurement Name panel Logic Search- Define Inputs menu Jitter measurement: SSC Freq Dev measurement...
Page 760 Math waveform (continued) Measurement algorithms (continued) differentiation bit high elements bit low guidelines burst width interactions cycle peak-to-peak offset DC common mode position differential crossover scale frequency sources HighRef math waveform equation editor histogram method math waveform menu Hold Diff (DDR) math waveforms integration algorithm LowRef...
Page 761 measurement gates (continued) Mode button (front panel) setting monitor, connecting measurement gating settings More button measurement interpolation mode Motor analysis measurement label 279, 294, 336, mount a network drive (standard instrument measurement limits mount a network drive (Windows OS instrument) Measurement Name panel mount a TekDrive Measurement Results table...
Page 762 option license, uninstall 29, Plot options acq trend install an option bar graph 103, option license file energy Other drawer histogram Channel Settings menu inductance overlay display mode phasor diagram overlay mode (waveforms) power Overlay mode, setting plot a measurement Plot button plot data file plot image file...
Page 763 probe (continued) Ref In unsupported Ref In (rear panel) probe compensation reference clock out probe compensation (TPP series) reference levels probe compensation connectors measurement probe inputs reference levels panel 286, 301, probe setup Reference Levels panel (DDR) analog reference marker (spectrum view) probes, connecting Reference waveform menu product description...
Page 764 Sample search menu (continued) acquisition mode Setup and Hold Sample acquisition mode Timeout sample interpolation Window sample rate Search menu Sampling process Logic defined search serial bus save search tables and zoom mode instrument settings searching for events reports security screen image security cable lock sessions...
Page 765 set eye mask hits spectrum view (continued) set measurement gates FFT versus Spectrum View set password front panel controls set security password graticule intensity set trigger logic qualification inputs graticule style setting up a bus how to display a spectrum trace Settings bar M, A, N, m traces settings, Edge trigger...
Page 766 TekDrive drive ( tJIT(per) measurement (DDR) unmount a TekDrive TekSecure Torque measurement algorithm TekSecure memory erase Torque measurement: Configure panel TEKTRONIX END USER LICENSE AGREEMENT Touch Off button Tektronix Technical Support touchscreen UI tasks TekVPI input connectors tPST measurement (DDR) Termination...
Page 767 Trigger menus vertical settings trigger out video output (rear panel) trigger the oscilloscope Video trigger menu Trigger types virtual keyboard Triggering virtual keypad 230, advanced visual trigger modes change an area's height sources change an area's horizontal center triggering concepts 122, change an area's logic true condition tRPRE measurement (DDR) change an area's shape...
Page 768 Waveforms (continued) math waveforms, saving Width@BER 310, Width@BER measurement Width@BER measurement configuration panel Window search menu window trigger 126, 621, Windows instrument, remote access x-axis scale (spectrum view) XY plot XY plot menu XYZ plot XYZ plot menu zoom 166, Zoom Zoom box Zoom button (front panel)

This manual is also suitable for:

Mso5 series Mso6 series Mso4x Mso4xb Mso5x Mso5xb ... Show all
