ITEM: SP-AZ081**
ANZZI
CICI
SHOWER PANEL
INSTALLATION & OPERATION MANUAL
V1.0
09/07/2024
DON'T WAIT!
REGISTER NOW!
Register your product within 90 days to ensure your product is
recognized as an
purchase and is
for warranty
coverage.
Register online at
or scan the QR code at
https://anzzi.com/pages/register
PG. 2.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Anzzi CICI SP-AZ081 Series
Summary of Contents for Anzzi CICI SP-AZ081 Series
- Page 1 ITEM: SP-AZ081** ANZZI CICI SHOWER PANEL INSTALLATION & OPERATION MANUAL V1.0 09/07/2024 DON’T WAIT! REGISTER NOW! Register your product within 90 days to ensure your product is recognized as an purchase and is for warranty coverage. Register online at or scan the QR code at https://anzzi.com/pages/register...
- Page 2 IMPORTANT: Warranty will not be recognized unless product is registered. https://anzzi.com/pages/register Register online at or Scan the QR code below. Registering online is fast, secure, and ensures we receive your information. USE YOUR PHONE CAMERA FILL IN A QUICK CLICK SUBMIT AND...
- Page 3 PARTS LIST IAPMO IGC 154 ASME A112.18.1/ CSA B125.1 Part Description Part Description [01] Shower panel [07B] [02] Diverter Cartridge [08] Nipple A. Shower Head [03] Diverter Flange [09] Hand shower B. Diverter [04] Diverter Handle [10A] [05A] Plug [10B] Washer C.
- Page 4 1. Prior to installation, please make sure your package is intact. Look over the product and contact your dealer or ANZZI if you find damaged sections. 2. In order to install this shower panel, simple understanding of plumbing techniques will be necessary.
- Page 5 Mounting the Brackets of the Shower Panel -It is recommended that the shower panel be mounted at a height that will make the unit accessible to people with varying heights. Establish the percise height and position of the unit on the wall.
- Page 6 STEP 1 outlet 5"-16.5" screw hole marking of [05B] 12.6" line 2 line 2 screw hole marking of [05B] align line 1 [05B] Fig 1.1 Fig 1.2 Fig 1.3 1-1 Position the shower panel on the wall according to figure A at page 5. Draw line 1 on the wall along the bottom of shower panel.
- Page 7 STEP 2 1/4" [05A] Fig 2.1 Fig 2.2 [05B] [05C] Fig 2.3 IMPORTANT Before drilling any holes for the shower panel brackets, be sure there are no hidden cables or pipelines aligned with the desired drilling position. 2-1 Drill 1/4" holes at the marked positions. (Fig 2.1) 2-2 Install the Anchors [05A] .
- Page 8 STEP 3 connector [01] [09] [10C] [11A] [06] [10A] [11A] [10B] connector 1 [11B] connector 2 Fig 3.1 Fig 3.2 Install the Shower Holder [10C] through the hole from the right of Shower Panel [01]. Make sure the shower hose connector faces downward. (Fig 3.1) Slide the Washer [10B] to the Shower Holder [10C] from the inside of Shower Panel [01] and secure it by tightening the Nut [10A].
- Page 9 STEP 4 outlet [07A] [08] longer shank Fig 4.1 Fig 4.2 Turn off the faucet. Remove the existing shower head and shower arm assembly. (Fig 4.1) Slide the Base [07B] to the outlet. The deeper side of the Base [07B] face outside.
- Page 10 STEP 5 hose [07B] Fig 5.1 Fig 5.2 Fig 5.3 Connect the hose to the Nipple [08] and tighten it to secure. (Fig 5.2) Before hanging the shower panel onto the wall, turn on the faucet and test all water functions of the shower panel and check all connections for leaks.
- Page 11 Wipe all surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and dry any overspray that lands on nearby surfaces. DO NOT ALLOW THE CLEANER TO SOAK. Following these simple procedures will ensure your ANZZI product remains as lustrous and stunning ®...
