ITEM: SP-AZ082**
ANZZI
DION
SHOWER PANEL
INSTALLATION & OPERATION MANUAL
V1.0
10/01/2024
DON'T WAIT!
REGISTER NOW!
Register your product within 90 days to ensure your product is
recognized as an
purchase and is
for warranty
coverage.
Register online at
or scan the QR code at
https://anzzi.com/pages/register
PG. 2.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Anzzi DION SP-AZ082 Series
Summary of Contents for Anzzi DION SP-AZ082 Series
- Page 1 ITEM: SP-AZ082** ANZZI DION SHOWER PANEL INSTALLATION & OPERATION MANUAL V1.0 10/01/2024 DON’T WAIT! REGISTER NOW! Register your product within 90 days to ensure your product is recognized as an purchase and is for warranty coverage. Register online at or scan the QR code at https://anzzi.com/pages/register...
- Page 2 IMPORTANT: Warranty will not be recognized unless product is registered. https://anzzi.com/pages/register Register online at or Scan the QR code below. Registering online is fast, secure, and ensures we receive your information. USE YOUR PHONE CAMERA FILL IN A QUICK CLICK SUBMIT AND...
- Page 3 PARTS LIST IAPMO IGC 154 ASME A112.18.1/ CSA B125.1 Part Description Part Description [01] Shower panel [07C] Screw [02A] [08] Washer [02B] Washer [09A] Base A. Shower Head [02C] Shower Arm [09B] [03A] Gasket [10] Nipple B. Diverter [03B] Shower Head [11] Hand shower C.
- Page 4 1. Prior to installation, please make sure your package is intact. Look over the product and contact your dealer or ANZZI if you find damaged sections. 2. In order to install this shower panel, simple understanding of plumbing techniques will be necessary.
- Page 5 Mounting the Brackets of the Shower Panel Scan the QC code for a quick example install video It is recommended that the shower panel be mounted at a height that will make the unit accessible to people with varying heights. Establish the precise height and position of the unit on the wall.
- Page 6 STEP 1 [08] connector [02B] [01] [02A] [02C] [03A] outlet [03B] Fig 1 Remove the Nut [02A] and Washer [02B] from the Shower Arm [02C] and slide the Shower Arm [02C] into the Shower Panel [01] from the front. From the back of the Shower Panel [01], slide the Washer [02B] on to the Shower Arm [02C] and secure it with Nut [02A].
- Page 7 STEP 2A - Outlet above the Top of Shower Panel outlet 8"-9" screw hole marking [07B] of Bracket 31.1" line 2 line 2 lower back screw hole marking [07B] bracket of Bracket line 1 align [07B] Fig 2A.1 Fig 2A.2 Fig 2A.3 CAUTION: Follow these instructions if outlet is located above the shower panel.
- Page 8 STEP 2B - Outlet behind the Shower Panel (outlet falls under the closest back bracket) connector of shower arm 3"-13" back bracket screw hole marking [07B] of Bracket 31.1" outlet line 2 line 2 lower back screw hole marking bracket [07B] of Bracket line 1...
- Page 9 STEP 3 1/4" [07A] Fig 3.1 Fig 3.2 [07B] [07C] Fig 3.3 IMPORTANT Before drilling any holes for the shower panel brackets, be sure there are no hidden cables or pipelines aligned with the desired drilling position. 3-1 Drill 1/4" holes at the marked positions. (Fig 3.1) 3-2 Install the Anchors [07A].
- Page 10 STEP 4 connector [01] [11] [12C] [13A] [08] [12A] [13A] [12B] connector 1 [13B] connector 2 Fig 4.1 Fig 4.2 Install the Hand Shower Holder [12C] through the hole on the right of Shower Panel [01]. Make sure the shower hose connector faces downward. (Fig 4.1) Slide the Washer [12B] on to the Hand Shower Holder [12C] from the inside of Shower Panel [01] and secure it by tightening the Nut [12A].
- Page 11 STEP 5 is for outlet positioned above Base [09A] the top of shower panel installation only. outlet [09A] [10] hex nut Fig 5.1 Fig 5.2 Turn off the faucet. Remove the existing shower head and shower arm assembly. (Fig 5.1) Slide the Base [09A] on to the outlet.
- Page 12 STEP 6 hose [09B] Fig 6.1 Fig 6.2 Fig 6.3 Connect the hose to the Nipple [10] and tighten it to secure. (Fig 6.2) Test all water functions by turning on the faucet before hanging the shower panel. Retighten if necessary, but do not overtighten. Install the Cap [09B] to the Base [09A].
- Page 13 Wipe all surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and dry any overspray that lands on nearby surfaces. DO NOT ALLOW THE CLEANER TO SOAK. Following these simple procedures will ensure your ANZZI product remains as lustrous and stunning ®...
